Surfing on chemical waves: A simple yet dynamically rich two-sphere responsive gel swimmer

Joseph J. Webber* and Thomas D. Montenegro-Johnson†

  • *Contact author: joe.webber@warwick.ac.uk
  • †Contact author: tom.montenegro-johnson@warwick.ac.uk
PDF

Phys. Rev. Fluids 10, 100501 – Published 3 October, 2025

DOI: https://doi.org/10.1103/52bv-vyb5

Abstract

Self-oscillating gels are chemically responsive hydrogels coupled to an oscillating chemical reaction of a stimulus solute. In response to the oscillating solute concentration field, responsive gels periodically swell and deswell, expelling their adsorbed water as they transition to a drier state, and reswelling once they return to a hydrophilic state. This volume phase transition occurs when the local stimulus concentration crosses a critical value, about which the hydrophilicity of the polymer chains changes abruptly. These gels have been used to make surface crawlers or other pulsatile machines, but here we show that a very simple system comprising two oscillating gel spheres linked by a rigid rod can also swim in the inertialess Stokes regime—albeit rather slowly. Developing a full continuum-mechanical model for a gel that employs a reaction described by the Brusselator model to generate oscillating chemical concentrations that couple to gel and fluid dynamics, we quantify the rate of shrinkage and swelling and associated flows as the gels pump out or draw in water. Herein, we derive analytical results for the swimming velocity of these swimmers, and upon placing them in a solute bath, identify two modes of behavior upon encountering propagating reaction-diffusion waves: “bobbing” and “surfing.” Though somewhat slower than flagellated swimmers, the relative simplicity of the system, with no hinges or moving components, lends itself well to large-scale production.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (53)

  1. E. Lauga, Life around the scallop theorem, Soft Matter 7, 3060 (2011).
  2. E. Lauga and T. R. Powers, The hydrodynamics of swimming microorganisms, Rep. Prog. Phys. 72, 096601 (2009).
  3. E. M. Purcell, Life at low Reynolds number, Am. J. Phys. 45, 3 (1977).
  4. H. C. Berg, Motile behavior of bacteria, Phys. Today 53(1), 24 (2000).
  5. H. C. Berg, Bacterial flagellar motor, Curr. Biol. 18, R689 (2008).
  6. S. S. Suarez and A. A. Pacey, Sperm transport in the female reproductive tract, Human Reprod. Update. 12, 23 (2006).
  7. T. D. Montenegro-Johnson, A. A. Smith, D. J. Smith, D. Loghin, and J. R. Blake, Modelling the fluid mechanics of cilia and flagella in reproduction and development, Eur. Phys. J. E 35, 111 (2012).
  8. M. J. Lighthill, On the squirming motion of nearly spherical deformable bodies through liquids at very small Reynolds numbers, Commun. Pure Appl. Math. 5, 109 (1952).
  9. J. R. Blake, A spherical envelope approach to ciliary propulsion, J. Fluid Mech. 46, 199 (1971).
  10. A. Najafi and R. Golestanian, Simple swimmer at low Reynolds number: Three linked spheres, Phys. Rev. E 69, 062901 (2004).
  11. J. E. Avron, O. Kenneth, and D. H. Oaknin, Pushmepullyou: An efficient micro-swimmer, New J. Phys. 7, 234 (2005).
  12. F. Box, E. Han, C. R. Tipton, and T. Mullin, On the motion of linked spheres in a Stokes flow, Exp. Fluids 58, 29 (2017).
  13. D. Klotsa, K. A. Baldwin, R. J. A. Hill, R. M. Bowley, and M. R. Swift, Propulsion of a two-sphere swimmer, Phys. Rev. Lett. 115, 248102 (2015).
  14. D. R. Hewitt, Swimming in viscoplastic fluids, Rheol. Acta 63, 673 (2024).
  15. S. Ahmed and J. Perez-Mercader, Interactions and oscillatory dynamics of chemically powered soft swimmers, J. Phys. Chem. B 129, 554 (2025).
  16. Z. Mao, M. Kuroki, Y. Otsuka, and S. Maeda, Contraction waves in self-oscillating polymer gels, Extreme Mech. Lett. 39, 100830 (2020).
  17. I. Tanasijević, O. Jung, L. Koens, A. Mourran, and E. Lauga, Jet-driven viscous locomotion of confined thermoresponsive microgels, Appl. Phys. Lett. 120, 104101 (2022).
  18. B. Nasouri, A. Khot, and G. J. Elfring, Elastic two-sphere swimmer in Stokes flow, Phys. Rev. Fluids 2, 043101 (2017).
  19. T. D. Montenegro-Johnson, D. J. Smith, and D. Loghin, Physics of rheologically enhanced propulsion: Different strokes in generalized Stokes, Phys. Fluids 25, 081903 (2013).
  20. O. Silverberg, E. Demir, G. Mishler, B. Hosoume, N. Trivedi, C. Tisch, D. Plascencia, O. S. Pak, and I. E. Araci, Realization of a push-me-pull-you swimmer at low Reynolds numbers, Bionspir. Biomim. 15, 064001 (2020).
  21. B. P. Belousov, Periodicheski deistvuyushchaya reaktsia i ee mekhanism, Ref. Radiats. Med. 1, 145 (1959).
  22. R. Yoshida, T. Takahashi, T. Yamaguchi, and H. Ichijo, Self-oscillating gel, J. Am. Chem. Soc. 118, 5134 (1996).
  23. S. Maeda, Y. Hara, T. Sakai, R. Yoshida, and S. Hashimoto, Self-walking gel, Adv. Mater. 19, 3480 (2007).
  24. Y. Murase, S. Maeda, S. Hashimoto, and R. Yoshida, Design of a mass transport surface utilizing peristaltic motion of a self-oscillating gel, Langmuir 25, 483 (2009).
  25. P. Glandsdorff and I. Prigogine, Thermodynamic Theory of Structure, Stability and Fluctuations (Wiley, New York, NY, 1971)
  26. G. G. Stokes, On the theory of oscillatory waves, Trans. Cambridge Philos. Soc. 8, 441 (1847).
  27. R. J. Field and M. Burger, Oscillations and Travelling Waves in Chemical Systems (Wiley, New York, NY, 1985).
  28. L. Ren, L. Yuan, Q. Gao, R. Teng, J. Wang, and I. R. Epstein, Chemomechanical origin of directed locomotion driven by internal chemical signals, Sci. Adv. 6, aaz9125 (2020).
  29. I. R. Epstein, V. K. Vanag, A. C. Balazs, O. Kuksenok, P. Dayal, and A. Bhattacharya, Chemical oscillators in structured media, Acc. Chem. Res. 45, 2160 (2012).
  30. V. V. Yashin and A. C. Balazs, Modeling polymer gels exhibiting self-oscillations due to the Belousov-Zhabotinsky reaction, Macromolecules 39, 2024 (2006).
  31. V. V. Yashin and A. C. Balazs, Theoretical and computational modeling of self-oscillating polymer gels, J. Chem. Phys. 126, 124707 (2007).
  32. O. Kuksenok, V. V. Yashin, and A. C. Balazs, Three-dimensional model for chemoresponsive polymer gels undergoing the Belousov-Zhabotinsky reaction, Phys. Rev. E 78, 041406 (2008).
  33. J. J. Webber and T. D. Montenegro-Johnson, Poromechanical modelling of responsive hydrogel pumps, J. Fluid Mech. 1009, A38 (2025).
  34. O. Kuksenok, P. Dayal, A. Bhattacharya, V. V. Yashin, D. Deb, I. C. Chen, K. J. van Vliet, and A. C. Balasz, Chemo-responsive, self-oscillating gels that undergo biomimetic communication, Chem. Soc. Rev. 42, 7257 (2013).
  35. J. J. Webber and T. D. Montenegro-Johnson, Oscillating chemical reactions enable communication between responsive hydrogels, Phys. Rev. Res. 7, L032055 (2025).
  36. J. J. Webber and M. G. Worster, A linear-elastic-nonlinear-swelling theory for hydrogels. Part 1. Modelling of super-absorbent gels, J. Fluid Mech. 960, A37 (2023).
  37. C. W. MacMinn, E. R. Dufresne, and J. S. Wettlaufer, Large deformations of a soft porous material, Phys. Rev. Appl. 5, 044020 (2016).
  38. J. J. Webber, M. A. Etzold, and M. G. Worster, A linear-elastic-nonlinear-swelling theory for hydrogels. Part 2. Displacement formulation, J. Fluid Mech. 960, A38 (2023).
  39. R. J. Field, E. Körös, and R. M. Noyes, Oscillations in chemical systems. II. Thorough analysis of temporal oscillation in the bromate-cerium-malonic acid system, J. Am. Chem. Soc. 94, 8649 (1972).
  40. I. Prigogine and R. Lefever, Symmetry breaking instabilities in dissipative systems. II, J. Chem. Phys. 48, 1695 (1968).
  41. P. Borckmans, K. Banyaich, A. de Wit, and G. Dewel, A model for self-oscillating miniaturized gels, in Nonlinear Dynamics in Polymeric Systems, edited by J. A. Pojman and Q. Tran-Cong-Miyata (ACS Publications, Washington, DC, 2003).
  42. R. Lefever and G. Nicolis, Chemical instabilities and sustained oscillations, J. Theor. Biol. 30, 267 (1971).
  43. J. Boissonade, Oscillatory dynamics induced in polyelectrolyte gels by a non-oscillatory reaction: A model, Eur. Phys. J. E 28, 337 (2009).
  44. Z. Xu, J. Zhang, Y.-N. Young, P. Yue, and J. J. Feng, Comparison of four boundary conditions for the fluid-hydrogel interface, Phys. Rev. Fluids 7, 093301 (2022).
  45. L. E. Becker, S. A. Koehler, and H. A. Stone, On self-propulsion of micro-machines at low Reynolds number: Purcell's three-link swimmer, J. Fluid Mech. 490, 15 (2003).
  46. J. Happel and H. Brenner, Low Reynolds Number Hydrodynamics (Martinus Nijhoff Publishers/Kluwer, Leiden, Netherlands, 1983).
  47. H. Lamb, Hydrodynamics, 6th ed. (Cambridge University Press, Cambridge, UK, 1932).
  48. R. Golestanian and A. Ajdari, Analytic results for the three-sphere swimmer at low Reynolds number, Phys. Rev. E 77, 036308 (2008).
  49. T. Spratte, C. Arndt, I. Wacker, M. Hauck, R. Adelung, R. R. Schröder, F. Schütt, and C. Selhuber-Unkel, Thermoresponsive hydrogels with improved actuation function by interconnected microchannels, Adv. Intell. Syst. 4, 2100081 (2022).
  50. T. Tanaka and D. J. Fillmore, Kinetics of swelling of gels, J. Chem. Phys. 70, 1214 (1979).
  51. M. T. J. J. M. Punter, H. M. Wyss, and B. M. Mulder, Compression and swelling of hydrogels in polymer solutions: A dominant-mode model, Phys. Rev. E 102, 062607 (2020).
  52. J. J. Webber and T. D. Montenegro-Johnson, Surfing on chemical waves: Code for paper (MATLAB code used to produce figures), https://github.com/JWebber/Surfing-on-chemical-waves-code-for-paper (2025).
  53. K. Deller, T. Erneux, and A. Bayliss, Asymptotic and numerical study of Brusselator chaos, Eur. J. Appl. Math. 2, 341 (1991).
