Model of deep zonal flows in giant planets
Phys. Rev. Fluids 10, 103501 – Published 7 October, 2025
DOI: https://doi.org/10.1103/29fk-jthg
Abstract
A mechanism by which the surface zonal flows of giant planets can be gradually attenuated with depth is explored. The zonal flow is driven by an imposed forcing in a thin layer near the surface. A meridional circulation is set up, analogous to the Ferrel-like cells observed in Jupiter's atmosphere. Acting on a stably stratified thin surface layer, the meridional flow induces a horizontal temperature anomaly which leads to a gradual reduction of the zonal winds with depth, governed by the thermal wind equation. Our model is a Boussinesq plane layer, with gravity acting parallel to the rotation axis. A suite of fully three-dimensional time-dependent numerical simulations has been performed to investigate the model behavior. Below the forced stable layer, convection is occurring, typically in the form of tall thin cells. The fluctuating components of the three-dimensional flow can be driven by either the convection or the Reynolds stresses associated with the jet shear flow. When fluctuations are mainly driven by convection in the form of tall thin columns and the forcing is relatively weak, the horizontal temperature anomaly persists much deeper into the interior than when it is driven by shear flow. The zonal jets can therefore extend deep into the interior, consistent with the Juno gravity data.
Physics Subject Headings (PhySH)
Article Text
References (28)
- Y. Kaspi, E. Galanti, W. B. Hubbard, and D. J. Stevenson, Jupiter's atmospheric jet streams extend thousands of kilometres deep, Nature (London) 555, 223 (2018).
- Y. Kaspi, E. Galanti, R. S. Park, and K. Duer, Observational evidence for cylindrically oriented zonal flows on Jupiter, Nat. Astron. 7, 1463 (2023).
- C. A. Jones, The deep winds of Jupiter, Nat. Astron. 7, 1417 (2023).
- E. Galanti, Y. Kaspi, K. Duer, L. Fletcher, A. Ingersoll, C. Li, G. Orton, T. Guillot, S. Levin, and S. Bolton, Constraints on the latitudinal profile of Jupiter's deep jets, Geophys. Res. Lett. 48, e2021GL092912 (2021).
- M. French, A. Becker, W. Lorenzen, N. Nettelmann, M. Bethkenhagen, J. Wicht, and R. Redmer, Ab initio simulations for material properties along the Jupiter adiabat, Astrophys. J. Suppl. 202, 5 (2012).
- Y.-K. Tsang and C. Jones, Characterising Jupiter's dynamo radius using its magnetic energy spectrum, Earth Planet. Sci. Lett. 530, 115879 (2020).
- M. Heimpel, J. Aurnou, and J. Wicht, Simulation of equatorial and high-latitude jets on Jupiter in a deep convection model, Nature (London) 438, 193 (2005).
- C. A. Jones and K. M. Kuzanyan, Compressible convection in the deep atmospheres of giant planets, Icarus 204, 227 (2009).
- U. Christensen, J. Wicht, and W. Dietrich, Mechanisms for limiting the depth of the zonal winds in the gas giant planets, Astrophys. J. 890, 61 (2020).
- U. R. Christensen and P. N. Wulff, Quenching of zonal winds in Jupiter's interior, Proc. Natl. Acad. Sci. USA 121, e2402859121 (2024).
- T. Gastine and J. Wicht, Stable stratification promotes multiple zonal jets in a turbulent Jovian dynamo model, Icarus 368, 114514 (2021).
- K. M. Moore, A. Barik, S. Stanley, D. J. Stevenson, N. Nettelmann, R. Helled, T. Guillot, B. Militzer, and S. Bolton, Dynamo simulations of Jupiter's magnetic field: The role of stable stratification and a dilute core, JGR Planets 127, e2022JE007479 (2022).
- S. Brygoo, P. Loubeyre, M. Millot, J. R. Rygg, P. M. Celliers, J. H. Eggert, R. Jeanloz, and C. W., Evidence of hydrogen-helium immiscibility at Jupiter-interior conditions, Nature (London) 593, 517 (2021).
- P. Read, The dynamics of Jupiter's and Saturn's weather layers: A synthesis after Cassini and Juno, Ann. Rev. Fluid Mech. 56, 271 (2024).
- A. P. Showman, P. J. Gierasch, and Y. Lian, Deep zonal winds can result from shallow driving in a giant-planet atmosphere, Icarus 182, 513 (2006).
- M. Heimpel, R. Yadav, N. Featherstone, and J. Aurnou, Polar and mid-latitude vortices and zonal flows on Jupiter and Saturn, Icarus 379, 114942 (2022).
- T. Schneider and J. Liu, Formation of jets and equatorial superrotation on Jupiter, J. Atmos. Sci. 66, 579 (2009).
- A. Ingersoll, R. Beebe, J. Mitchell, G. Garneau, G. Yagi, and J. Müller, Interaction of eddies and mean zonal flow on Jupiter as inferred from Voyager 1 and 2 images, J. Geophys. Res. 86, 8733 (1981).
- C. Salyk, A. Ingersoll, J. Lorre, A. Vasavada, and A. Del Genio, Interaction between eddies and mean flow in Jupiter's atmosphere: Analysis of Cassini imaging data, Icarus 185, 430 (2006).
- K. Duer, N. Gavriel, E. Galanti, Y. Kaspi, and L. Fletcher, Evidence for multiple Ferrel-like cells on Jupiter, Geophys. Res. Lett. 48, e2021GL095651 (2021).
- A. Ingersoll, S. Atreya, S. Bolton, S. Brueshaber, L. Fletcher, S. Levin, C. Li, L. Li, J. Lunine, G. Orton, and H. Waite, Jupiter's overturning circulation: Breaking waves take the place of solid boundaries, Geophys. Res. Lett. 48, e2021GL095756 (2021).
- K. J. Burns, G. M. Vasil, J. S. Oishi, D. Lecoanet, and B. P. Brown, Dedalus: A flexible framework for numerical simulations with spectral methods, Phys. Rev. Res. 2, 023068 (2020).
- R. Ecke and O. Shishkina, Turbulent rotating Rayleigh–Bénard convection, Annu. Rev. Fluid Mech. 55, 603 (2023).
- M. Parisi, Y. Kaspi, E. Galanti, D. Durante, S. Bolton, S. Levin, D. Buccino, and L. Fletcher, The depth of Jupiter's Great Red Spot constrained by Juno's gravity overflights, Science 374, 964 (2021).
- K. Hori, C. A. Jones, A. Antunano, L. N. Fletcher, and S. M. Tobias, Jupiter's cloud-level variability triggered by torsional oscillations in the interior, Nat. Astron. 7, 825 (2023).
- www.dirac.ac.uk.
- L. K. Currie and C. A. Jones, Durham University Research Data Repository, http://doi.org/10.15128/r2zk51vg84z.
- J. Tollefson, M. H. Wong, I. de Pater, and A. A. Simon, Changes in Jupiter's zonal wind profile preceding and during the Juno mission, Icarus 296, 163 (2017).
