Efficient laser-plasma acceleration of protons via near-critical mass limited targets

Johannes Gebhard1,*, Peter Hilz3,4, Felix Balling1, Joey Kalis1, Martin Speicher1, Leonard Doyle1, Alexander Sävert3,2,4, Georg Schäfer3,4, Pooyan Khademi3,4 et al.

Bin Liu3,4, Matt Zepf2,3,4, and Jörg Schreiber1,†

  • *Contact author: johannes.gebhard@physik.uni-muenchen.de
  • †Contact author: joerg.schreiber@lmu.de
PDF

Phys. Rev. E 112, 035204 – Published 9 September, 2025

DOI: https://doi.org/10.1103/z7y1-1zbz

Abstract

Isolated micro-targets are a promising avenue to high-performance laser-driven proton and ion accelerators due to their ability to confine the coupled laser energy to a small volume and small number of particles. Experimental results on proton emission from levitated plastic micro-spheres with an initial diameter of 1 µm are presented. For a laser with only 0.4 J contained within the central spot, proton energies of up to 27 MeV were observed with micro-spheres pre-expanded to near-critical density. Three-dimensional PIC simulations reveal that the combination of a ponderomotively driven process similar to radiation pressure ‘hole-boring’ generates a dense plasma bunch propagating at 0.1 c with the subsequent expansion of the moving bunch driven by hot electrons boosting the maximum proton energy Emax considerably. Simulations agree well with the observed experimental results and suggest a scaling of 54MeV/J1/2, predicting that 100 MeV protons are possible with only 4 J in a Gaussian spot.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (37)

  1. R. A. Snavely et al., Phys. Rev. Lett. 85, 2945 (2000).
  2. T. Ziegler et al., Nat. Phys. 20, 1211 (2024).
  3. A. Macchi, M. Borghesi, and M. Passoni, Rev. Mod. Phys. 85, 751 (2013).
  4. S. C. Wilks et al., Phys. Plasmas 8, 542 (2001).
  5. S. C. Wilks, W. L. Kruer, M. Tabak, and A. B. Langdon, Phys. Rev. Lett. 69, 1383 (1992).
  6. T. Nakamura, S. V. Bulanov, T. Esirkepov, and M. Kando, Phys. Rev. Lett. 105, 135002 (2010).
  7. N. P. Dover et al., Light Sci. Appl. 12, 71 (2023).
  8. A. Henig et al., Phys. Rev. Lett. 103, 045002 (2009).
  9. D. Jung et al., Phys. Plasmas 20, 083103 (2013).
  10. L. Yin, B. J. Albright, B. M. Hegelich, and J. C. Fernández, Laser Part. Beams 24, 291 (2006).
  11. K. Nishihara, H. Amitani, M. Murakami, S. V. Bulanov, and T. Z. Esirkepov, Nucl. Instr. Meth. Phys. Res., Sect. A. 464, 98 (2001).
  12. A. Robinson, P. Gibbon, M. Zepf, S. Kar, R. Evans, and C. Bellei, Plasma Phys. Control. Fusion 51, 024004 (2009).
  13. T. Schlegel, N. Naumova, V. T. Tikhonchuk, C. Labaune, I. V. Sokolov, and G. Mourou, Phys. Plasmas 16, 083103 (2009).
  14. L. O. Silva, M. Marti, J. R. Davies, R. A. Fonseca, C. Ren, F. S. Tsung, and W. B. Mori, Phys. Rev. Lett. 92, 015002 (2004).
  15. A. Henig et al., Phys. Rev. Lett. 102, 095002 (2009).
  16. T. Esirkepov, M. Borghesi, S. V. Bulanov, G. Mourou, and T. Tajima, Phys. Rev. Lett. 92, 175003 (2004).
  17. A. Macchi, F. Cattani, T. V. Liseykina, and F. Cornolti, Phys. Rev. Lett. 94, 165003 (2005).
  18. A. Henig et al., Phys. Rev. Lett. 103, 245003 (2009).
  19. A. Macchi, S. Veghini, and F. Pegoraro, Phys. Rev. Lett. 103, 085003 (2009).
  20. B. Qiao, M. Zepf, M. Borghesi, B. Dromey, M. Geissler, A. Karmakar, and P. Gibbon, Phys. Rev. Lett. 105, 155002 (2010).
  21. J. Schreiber, F. Bell, and Z. Najmudin, High Power Laser Sci. Eng. 2, e41 (2014).
  22. P. R. Bolton, K. Parodi, and J. Schreiber, Applications of Laser-Driven Particle Acceleration (CRC Press, Taylor & Francis Group, Boca Raton; London; New York, 2018).
  23. M. Zimmer, S. Scheuren, T. Ebert, G. Schaumann, B. Schmitz, J. Hornung, V. Bagnoud, C. Rödel, and M. Roth, Phys. Rev. E 104, 045210 (2021).
  24. W. Yu, H. Xu, F. He, M. Y. Yu, S. Ishiguro, J. Zhang, and A. Y. Wong, Phys. Rev. E 72, 046401 (2005).
  25. Y. Fukuda et al., Phys. Rev. Lett. 103, 165002 (2009).
  26. A. Stockem Novo, M. C. Kaluza, R. A. Fonseca, and L. O. Silva, Sci. Rep. 6, 29402 (2016).
  27. A. Bhagawati and N. Das, Phys. Plasmas 29, 053107 (2022).
  28. T. M. Ostermayr et al., Rev. Sci. Instrum. 89, 013302 (2018).
  29. T. Ostermayr, Relativistically intense laser-microplasma interactions, Ph.D. thesis, LMU München: Fakultät für Physik, 2018.
  30. P. Hilz et al., Nat. Commun. 9, 423 (2018).
  31. J. Derouillat et al., Comput. Phys. Commun. 222, 351 (2018).
  32. A. J. Mackinnon et al., Phys. Rev. Lett. 86, 1769 (2001).
  33. J. Schreiber et al., Phys. Rev. Lett. 97, 045005 (2006).
  34. R. Matsui, Y. Fukuda, and Y. Kishimoto, Phys. Rev. Lett. 122, 014804 (2019).
  35. T. Ziegler et al., Sci. Rep. 11, 7338 (2021).
  36. https://www.microparticles-shop.de/.
  37. S. Reinhardt, Detection of laser–accelerated protons, Ph.D. thesis, LMU München: Fakultät für Physik, 2012.
