Landau-de Gennes modeling of confinement effects and cybotactic clusters in bent-core nematic liquid crystals

Yucen Han

Prabakaran Rajamanickam

Bedour Alturki

Apala Majumdar*

  • *Contact author: apala.majumdar@manchester.ac.uk
PDF

Phys. Rev. E 113, 025403 – Published 2 February, 2026

DOI: https://doi.org/10.1103/w85s-mwn3

Abstract

We study bent-core nematic (BCN) systems in two-dimensional (2D) and three-dimensional (3D) settings, focusing on the role of cybotactic clusters, phase transitions, confinement effects, and applied external fields. We propose a generalized version of Madhusudana's two-state model for BCNs [Phys. Rev. E 96, 022710 (2017)] with two order parameters: Qg to describe the ambient ground-state (GS) molecules and Qc to describe the additional ordering induced by the cybotactic clusters. The equilibria are modeled by minimizers of an appropriately defined free energy, with an empirical coupling term between Qg and Qc. We demonstrate two phase transitions in spatially homogeneous 3D BCN systems at fixed temperatures: a first-order nematic-paranematic transition followed by a paranematic-isotropic phase transition driven by the GS-cluster coupling. We also numerically compute and give heuristic insights into solution landscapes of confined BCN systems on 2D square domains, tailored by the GS-cluster coupling, temperature, and external fields. This benchmark example illustrates the potential of this generalized model to capture tunable director profiles, cluster properties, and potential biaxiality induced by antagonistic Qg and Qc profiles.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (33)

  1. P.-G. De Gennes and J. Prost, The Physics of Liquid Crystals (Oxford University Press, Oxford, 1993), Vol. 83.
  2. A. Jákli, O. D. Lavrentovich, and J. V. Selinger, Physics of liquid crystals of bent-shaped molecules, Rev. Mod. Phys. 90, 045004 (2018).
  3. J. Etxebarria and M. B. Ros, Bent-core liquid crystals in the route to functional materials, J. Mater. Chem. 18, 2919 (2008).
  4. O. Francescangeli, F. Vita, and E. T. Samulski, The cybotactic nematic phase of bent-core mesogens: State of the art and future developments, Soft Matter 10, 7685 (2014).
  5. N. Vaupotič, D. Pociecha, M. Čepič, K. Gomola, J. Mieczkowski, and E. Gorecka, Evidence for general tilt columnar liquid crystalline phase, Soft Matter 5, 2281 (2009).
  6. G. Shanker, M. Prehm, M. Nagaraj, J. K. Vij, M. Weyland, A. Eremin, and C. Tschierske, 1, 2, 4-oxadiazole-based bent-core liquid crystals with cybotactic nematic phases, ChemPhysChem 15, 1323 (2014).
  7. M. Gao, Y.-K. Kim, C. Zhang, V. Borshch, S. Zhou, H.-S. Park, A. Jákli, O. D. Lavrentovich, M.-G. Tamba, A. Kohlmeier, et al., Direct observation of liquid crystals using cryo-TEM: Specimen preparation and low-dose imaging, Microsc. Res. Tech. 77, 754 (2014).
  8. N. V. Madhusudana, Two-state model for nematic liquid crystals made of bent-core molecules, Phys. Rev. E 96, 022710 (2017).
  9. D. Wiant, K. Neupane, S. Sharma, J. T. Gleeson, S. Sprunt, A. Jakli, N. Pradhan, and G. Iannacchione, Observation of a possible tetrahedratic phase in a bent-core liquid crystal, Phys. Rev. E 77, 061701 (2008).
  10. S. Patranabish, Y. Wang, A. Sinha, and A. Majumdar, One-dimensional theoretical analysis of coupling and confinement effects on the cybotactic clusters of bent-core nematic liquid crystals, Phys. Rev. E 99, 012703 (2019).
  11. D. Mandal, Y. Wang, S. Kaur, G. Mohiuddin, A. Majumdar, and A. Sinha, Dispersion of multiferroic nanoparticles in a bent-core nematic liquid crystal: Experimental and theoretical study, J. Mol. Liq. 430 127624 (2025).
  12. A. Majumdar, Equilibrium order parameters of nematic liquid crystals in the Landau-de Gennes theory, Eur. J. Appl. Math. 21, 181 (2010).
  13. J. Yin, Y. Wang, J. Z. Chen, P. Zhang, and L. Zhang, Construction of a pathway map on a complicated energy landscape, Phys. Rev. Lett. 124, 090601 (2020).
  14. C. Luo, A. Majumdar, and R. Erban, Multistability in planar liquid crystal wells, Phys. Rev. E 85, 061702 (2012).
  15. H. Kusumaatmaja and A. Majumdar, Free energy pathways of a multistable liquid crystal device, Soft Matter 11, 4809 (2015).
  16. G. Canevari and A. Zarnescu, Design of effective bulk potentials for nematic liquid crystals via colloidal homogenisation, Math. Models Methods Appl. Sci. 30, 309 (2020).
  17. Y. Han, J. Harris, A. Majumdar, and L. Zhang, Elastic anisotropy in the reduced Landau–de Gennes model, Proc. R. Soc. A 478, 20210966 (2022).
  18. Wolfram Research Inc., Wolfram|Alpha Notebook Edition (Wolfram Research, Inc., Champaign, IL, 2025).
  19. D. Golovaty, J. A. Montero, and P. Sternberg, Dimension reduction for the Landau-de Gennes model in planar nematic thin films, J. Nonlinear Sci. 25, 1431 (2015).
  20. S. Kralj and A. Majumdar, Order reconstruction patterns in nematic liquid crystal wells, Proc. R. Soc. A 470, 20140276 (2014).
  21. Y. Wang, G. Canevari, and A. Majumdar, Order reconstruction for nematics on squares with isotropic inclusions: A Landau–de Gennes study, SIAM J. Appl. Math. 79, 1314 (2019).
  22. M. Robinson, C. Luo, P. E. Farrell, R. Erban, and A. Majumdar, From molecular to continuum modelling of bistable liquid crystal devices, Liq. Cryst. 44, 2267 (2017).
  23. Y. Han, J. Yin, P. Zhang, A. Majumdar, and L. Zhang, Solution landscape of a reduced Landau–de Gennes model on a hexagon, Nonlinearity 34, 2048 (2021).
  24. J. Milnor, Morse Theory (Princeton University Press, Princeton, 2016), Vol. 51.
  25. J. Yin, L. Zhang, and P. Zhang, High-index optimization-based shrinking dimer method for finding high-index saddle points, SIAM J. Sci. Comput. 41, A3576 (2019).
  26. A. G. Kurosh and G. Yankovsky, Higher Algebra (MIR Publishers, Moscow, USSR, 1972).
  27. S. M. Selby, CRC Standard Mathematical Tables (CRC Press, Cleveland, 1975).
  28. B. Shi, Y. Han, and L. Zhang, Nematic liquid crystals in a rectangular confinement: Solution landscape, and bifurcation, SIAM J. Appl. Math. 82, 1808 (2022).
  29. L. Zhang, Q. Du, and Z. Zheng, Optimization-based shrinking dimer method for finding transition states, SIAM J. Sci. Comput. 38, A528 (2016).
  30. D. Longsine and S. McCormick, Simultaneous Rayleigh-quotient minimization methods for Ax=λBx, Linear Algebra Appl. 34, 195 (1980).
  31. J. Xia and Y. Han, A simple tensorial theory of smectic C liquid crystals, Phys. Rev. Res. 6, 033232 (2024).
  32. Y. Han, J. Harris, J. Walton, and A. Majumdar, Tailored nematic and magnetization profiles on two-dimensional polygons, Phys. Rev. E 103, 052702 (2021).
  33. https://github.com/cen0880/bent-core-nematic-liquid-crystals.git.
