Two-population Rouse models for polymer segmental dynamics in nanocomposites

Jack R. Rooks1, Giovanni Ferraro2,3, Emiliano Fratini2,3, Naresh C. Osti4, Osawa Takahito5, Antonio Faraone6,*, and Norman J. Wagner1,†

  • *Contact author: antonio.faraone@nist.gov
  • †Contact author: wagnernj@udel.edu
PDF

Phys. Rev. E 113, 015405 – Published 7 January, 2026

DOI: https://doi.org/10.1103/s8k6-cvfr

Abstract

Segmental dynamics of polymer chains in a model nanocomposite of poly(ethylene oxide) and silica nanoparticles (NPs) was investigated using quasielastic neutron scattering. The dynamics can be accurately described with the Rouse model. The bulklike polymer far from the NP surface behaves as the neat polymer. However, the slower polymer in the interface close to the NP surface is described either with a second Rouse population with different relaxation time or using the suppressed Rouse model. These simple two-population models accurately reproduce the experimental data, with the suppressed Rouse model describing topological constraints, on average, every 12 beads with an interfacial thickness up to 13.5 beads, and the effect of the interface extending to a layer of thickness comparable to the end-to-end distance of the polymer. This modeling provides an explanation for the observed reinforcement in PNC even at low loadings, consistent with current understanding of the relevance of the interphase.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (28)

  1. E. J. Bailey and K. I. Winey, Prog. Polym. Sci. 105, 101242 (2020).
  2. M. Krutyeva et al., Phys. Rev. Lett. 110, 108303 (2013).
  3. E. Senses, S. Darvishi, M. S. Tyagi, and A. Faraone, Macromolecules 53, 4982 (2020).
  4. E. Senses, A. Faraone, and P. Akcora, Sci. Rep. 6, 29326 (2016).
  5. J. Kim et al., ACS Macro Letters 13, 720 (2024).
  6. J. Berriot, H. Montes, F. Lequeux, D. Long, and P. Sotta, Macromolecules 35, 9756 (2002).
  7. E. J. Bailey, P. J. Griffin, M. Tyagi, and K. I. Winey, Macromolecules 52, 669 (2019).
  8. A. Papon, K. Saalwächter, K. Schäler, L. Guy, F. Lequeux, and H. Montes, Macromolecules 44, 913 (2011).
  9. A. P. Holt, P. J. Griffin, V. Bocharova, A. L. Agapov, A. E. Imel, M. D. Dadmun, J. R. Sangoro, and A. P. Sokolov, Macromolecules 47, 1837 (2014).
  10. S. Cheng et al., Phys. Rev. Lett. 116, 038302 (2016).
  11. A. R. Brás et al., Soft Matter 7, 11169 (2011).
  12. K. Niedzwiedz, A. Wischnewski, W. Pyckhout-Hintzen, J. Allgaier, D. Richter, and A. Faraone, Macromolecules 41, 4866 (2008).
  13. J. Kim et al. (unpublished).
  14. J. Choi, M. J. A. Hore, J. S. Meth, N. Clarke, K. I. Winey, and R. J. Composto, ACS Macro Lett. 2, 485 (2013).
  15. E. Senses, S. Narayanan, Y. Mao, and A. Faraone, Phys. Rev. Lett. 119, 237801 (2017).
  16. flexible_cylinder, https://www.sasview.org/docs/user/models/flexible_cylinder.html.
  17. S. Brunauer, P. H. Emmett, and E. Teller, J. Am. Chem. Soc. 60, 309 (1938).
  18. E. Mamontov and K. W. Herwig, Rev. Scient. Instru. 82, 085109 (2011).
  19. R. L. Paul, Analyst 122, 35R (1997).
  20. P. A. Kienzle, J. Krycka, N. Patel, and I. Sahin, Bumps (Version 0.9.1) (University of Maryland, College Park, MD, 2011).
  21. See Supplemental Material at http://link.aps.org/supplemental/10.1103/s8k6-cvfr for sample preparation, additional details on the experiment and fitting, and relaxation time distribution.
  22. J. Becht, K. H. Hellwege, and W. Knappe, Kolloid-Z. u. Z. Polymere 216, 150 (1967).
  23. D. Richter, Neutron Spin Echo in Polymer Systems, Advances in Polymer Science Vol. 174 (Springer, Berlin, 2005).
  24. Error bars in this letter represent one standard deviation.
  25. K. Niedzwiedz, A. Wischnewski, M. Monkenbusch, D. Richter, A. C. Genix, A. Arbe, J. Colmenero, M. Strauch, and E. Straube, Phys. Rev. Lett. 98, 168301 (2007).
  26. A. Sharma, M. Kruteva, S. Ehlert, M. Dulle, S. Förster, and D. Richter, Macromolecules 56, 4952 (2023).
  27. F. W. Starr, J. F. Douglas, D. Meng, and S. K. Kumar, ACS Nano 10, 10960 (2016).
  28. D. Richter, L. Willner, A. Zirkel, B. Farago, L. J. Fetters, and J. S. Huang, Macromolecules 27, 7437 (1994).
