Transformation of the Maxwell-Boltzmann distribution to a power law

Ari Laor* and Igor Gitelman†

  • *Contact author: laor@physics.technion.ac.il
  • †Contact author: giigor@campus.technion.ac.il
PDF

Phys. Rev. E 113, 044135 – Published 27 April, 2026

DOI: https://doi.org/10.1103/mwrm-tyjz

Abstract

Power-law (PL) distribution functions (DF) are prevalent in highly diverse systems. The systems range in size from nanometer to mega light years, in complexity from dust grains to living organisms, and characterize the distribution of various events in nature and in various human activities. To gain some insight on why PL DF are so prevalent, we explore the conditions leading to the formation of a PL DF in a simple system of colliding hard sphere. We follow the time evolution of the energy DF through direct Monte Carlo simulations. In statistical equilibrium, the DF evolves into the Maxwell-Boltzmann DF. A transition to a PL DF occurs when the following occurs: (1) The system is initially far from equilibrium. For example, a mix of light and heavy particles with the same velocity. (2) The system dynamics is scale free, which holds in the intermediate asymptotic regime, far from the initial and the final equilibrium states. The scale-free dynamics leads to a DF which evolves in a self-similar form. (3) The system is open with a scale-free boundary condition. For example, a constant injection of particles far from equilibrium. The DF PL index is set by the time dependence of the self-similar DF and by the boundary condition. The PL index is independent of the self-similar DF form. Conditions (1)–(3) are common in a great variety of systems, which may explain why PL DF are so prevalent in nature.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. M. E. J. Newman, Power laws, Pareto distributions and Zipf's law, Contemp. Phys. 46, 323 (2005).
  2. X. Gabaix, P. Gopikrishnan, V. Plerou, and H. E. Stanley, A theory of power-law distributions in financial market fluctuations, Nature (London) 423, 267 (2003).
  3. M. V. Simkin and V. P. Roychowdhury, Re-inventing Willis Phys. Rep. 502, 1 (2011).
  4. M. J. Aschwanden, N. B. Crosby, M. Dimitropoulou, M. K. Georgoulis, S. Hergarten, J. McAteer, A. V. Milovanov, S. Mineshige, L. Morales, N. Nishizuka, G. Pruessner, R. Sanchez, A. S. Sharma, A. Strugarek, and V. Uritsky, 25 Years of self-organized criticality: Solar and astrophysics, Space Sci. Rev. 198, 47 (2016).
  5. M. Kleiber, Body size and metabolic rate, Physiol. Rev. 27, 511 (1947).
  6. G. I. Barenblatt, Scaling, Self-similarity, and Intermediate Asymptotics (Cambridge University Press, Cambridge, 1996).
  7. C. Mouhot and L. Pareschi, Fast algorithms for computing the Boltzmann collision operator, Math. Comput. 75, 1833 (2006).
  8. L. Wu, C. White, T. J. Scanlon, J. M. Reese, and Y. Zhang, Deterministic numerical solutions of the Boltzmann equation using the fast spectral method, J. Comput. Phys. 250, 27 (2013).
  9. Z. Cai and M. Torrilhon, Approximation of the linearized Boltzmann collision operator for hard-sphere and inverse-power-law models, J. Comput. Phys. 295, 617 (2015).
  10. G. B. Rybicki and A. P. Lightman, Radiative Processes in Astrophysics (Wiley-Interscience, New York, 1979).
  11. A. V. Kats, V. M. Kontorovich, S. S. Moiseev, and V. E. Novikov, Exact power-law solutions of the particle kinetic equations, Zh. Eksp. Teor. Fiz. 71, 177 (1976) [JETP 44, 93 (1976)].
  12. M. R. Collier, On generating Kappa-like distribution functions using velocity space Lévy flights, Geophys. Res. Lett. 20, 1531 (1993).
  13. R. Hanel and S. Thurner, On the derivation of power-law distributions within classical statistical mechanics far from the thermodynamic limit, Phys. A (Amsterdam) 365, 162 (2006).
  14. A. Hankey and H. E. Stanley, Systematic application of generalized homogeneous functions to static scaling, dynamic scaling, and universality, Phys. Rev. B 6, 3515 (1972).
  15. J. T. Cushing, Vector lorentz transformations, Am. J. Phys. 35, 858 (1967).
  16. I. S. Gradshteyn and I. M. Ryzhik, Table of Integrals, Series, and Products (Academic, New York, 2014).
  17. P. L. Krapivsky, S. Redner, and E. Ben-Naim, A Kinetic View of Statistical Physics (Cambridge University Press, Cambridge, 2010).
  18. L. O. Drury, An introduction to the theory of diffusive shock acceleration of energetic particles in tenuous plasmas, Rep. Prog. Phys. 46, 973 (1983).
  19. F. C. Jones, A theoretical review of diffusive shock acceleration, Astrophys. J. Suppl. Series 90, 561 (1994).
  20. A. Achterberg, Y. A. Gallant, J. G. Kirk, and A. W. Guthmann, Particle acceleration by ultrarelativistic shocks: theory and simulations, Mon. Not. R. Astron. Soc. 328, 393 (2001).
  21. M. Lemoine and B. Revenu, Relativistic Fermi acceleration with shock compressed turbulence, Mon. Not. R. Astron. Soc. 366, 635 (2006).
  22. M. Lemoine, Effective theory for stochastic particle acceleration, with application to magnetized turbulence, Phys. Rev. E 112, 015205 (2025).
  23. J. C. Brown, The deduction of energy spectra of non-thermal electrons in flares from the observed dynamic spectra of hard X-ray bursts, Sol. Phys. 18, 489 (1971).
  24. T. S. Bastian, A. O. Benz, and D. E. Gary, Radio emission from solar flares, Annu. Rev. Astron. Astrophys. 36, 131 (1998).
  25. C. L. Sarazin, The energy spectrum of primary cosmic-ray electrons in clusters of galaxies and inverse Compton emission, Astrophys. J. 520, 529 (1999).
  26. A. A. Schekochihin, S. C. Cowley, W. Dorland, G. W. Hammett, G. G. Howes, E. Quataert, and T. Tatsuno, Astrophysical gyrokinetics: Kinetic and fluid turbulent cascades in magnetized weakly collisional plasmas, Astrophys. J. Suppl. Series 182, 310 (2009).
  27. B. T. Park and V. Petrosian, Fokker-planck equations of stochastic acceleration: Green's functions and boundary conditions, Astrophys. J. 446, 699 (1995).
  28. I. S. Aranson and J. S. Olafsen, Velocity fluctuations in electrostatically driven granular media, Phys. Rev. E 66, 061302 (2002).
  29. E. Ben-Naim, B. Machta, and J. Machta, Power-law velocity distributions in granular gases, Phys. Rev. E 72, 021302 (2005).
  30. K. Fujii, Collisional-energy-cascade model for nonthermal velocity distributions of neutral atoms in plasmas, Phys. Rev. E 108, 025204 (2023).
  31. R. A. Sunyaev and L. G. Titarchuk, Comptonization of X-rays in plasma clouds - Typical radiation spectra, Astron. Astrophys. 86, 121 (1980).
  32. M. P. H. Stumpf and M. A. Porter, Critical truths about power laws, Science 335, 665 (2012).
  33. G. B. West, J. H. Brown, and B. J. Enquist, A general model for the origin of allometric scaling laws in biology, Science 276, 122 (1997).
  34. M. Patriarca and A. Chakraborti, Kinetic exchange models: From molecular physics to social science, Am. J. Phys. 81, 618 (2013).
  35. B. Blasius, Power-law distribution in the number of confirmed COVID-19 cases, Chaos 30, 093123 (2020).
  36. A.-L. Barabási and R. Albert, Emergence of scaling in random networks, Science 286, 509 (1999).
  37. I. Gitelman and A. Laor, Mbtopl_codes (v1.0): Code and data for “On the transformation of the Maxwell-Boltzmann distribution to a power law” (v1.0), Zenodo (2026), https://zenodo.org/records/18642015.
  38. D. Cubero, J. Casado-Pascual, J. Dunkel, P. Talkner, and P. Hänggi, Thermal equilibrium and statistical thermometers in special relativity, Phys. Rev. Lett. 99, 170601 (2007).
  39. J. Dunkel, P. Hänggi, and S. Weber, Time parameters and Lorentz transformations of relativistic stochastic processes, Phys. Rev. E 79, 010101(R) (2009).
  40. S. M. Molnar and J. Godfrey, Empirical test for relativistic kinetic theories based on the Sunyaev–Zel'dovich effect, Astrophys. J. 902, 143 (2020).
  41. L. D. Landau and E. M. Lifshitz, The Classical Theory of Fields, 4th ed. (Pergamon, Oxford, 1980).
  42. F. Peano, M. Marti, L. O. Silva, and G. Coppa, Statistical kinetic treatment of relativistic binary collisions, Phys. Rev. E 79, 025701(R) (2009).
  43. V. Pierrard and M. Lazar, Kappa distributions: Theory and applications in space plasmas, Sol. Phys. 267, 153 (2010).
  44. G. Livadiotis and D. McComas, Invariant kappa distribution in space plasmas out of equilibrium, Astrophys. J. 741, 88 (2011).
  45. G. Livadiotis and D. J. McComas, Understanding kappa distributions: A toolbox for space science and astrophysics, Space Sci. Rev. 175, 183 (2013).
  46. B. Arbutina and V. Zeković, On the distribution function of suprathermal particles at collisionless shocks, J. High Energy Astrophys. 32, 65 (2021).
  47. D. C. Nicholls, M. A. Dopita, and R. S. Sutherland, Resolving the electron temperature discrepancies in H ii regions and planetary nebulae: κ-distributed electrons, Astrophys. J. 752, 148 (2012).
  48. B. T. Draine and C. D. Kreisch, Electron energy distributions in H ii regions and planetary nebulae: κ-distributions do not apply, Astrophys. J. 862, 30 (2018).
