Flexoelectricity-driven softening of bend elasticity leads to spontaneous chiral symmetry breaking in a polar fluid

Aitor Erkoreka1, Josu Martinez-Perdiguero1, Luka Cmok2,3, Ema Hanžel2,3, Jordan Hobbs4, Calum J. Gibb5, Richard J. Mandle4,5, Nerea Sebastián2, and Alenka Mertelj2,*

  • *Contact author: alenka.mertelj@ijs.si
PDF

Phys. Rev. E 114, 045407 – Published 21 October, 2026

DOI: https://doi.org/10.1103/m11g-4rj9

Abstract

The origin of the recently observed spontaneous chiral symmetry breaking in polar fluids composed of achiral molecules is an unsolved problem, raising fundamental questions about how heliconical structures emerge in such systems. Here, we investigate the pretransitional fluctuations leading to the formation of the spontaneously chiral twist-bend ferroelectric nematic phase using dielectric spectroscopy, light scattering, and small-angle x-ray scattering. We observe simultaneous softening of the bend elastic constant and the emergence of a collective dielectric mode on approaching the transition. By developing a theoretical model, we show that these phenomena are signatures of a flexoelectricity-driven transition arising from the coupling between electric polarization and bend deformation.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (44)

  1. R. J. Mandle, S. J. Cowling, and J. W. Goodby, A nematic to nematic transformation exhibited by a rod-like liquid crystal, Phys. Chem. Chem. Phys. 19, 11429 (2017).
  2. H. Nishikawa, K. Shiroshita, H. Higuchi, Y. Okumura, Y. Haseba, S.-i. Yamamoto, K. Sago, and H. Kikuchi, A fluid liquid-crystal material with highly polar order, Adv. Mater. 29, 1702354 (2017).
  3. N. Sebastián, L. Cmok, R. J. Mandle, M. R. de la Fuente, I. D. Olenik, M. Čopič, and A. Mertelj, Ferroelectric-ferroelastic phase transition in a nematic liquid crystal, Phys. Rev. Lett. 124, 037801 (2020).
  4. X. Chen, E. Korblova, D. Dong, X. Wei, R. Shao, L. Radzihovsky, M. A. Glaser, J. E. Maclennan, D. Bedrov, D. M. Walba, and N. A. Clark, First-principles experimental demonstration of ferroelectricity in a thermotropic nematic liquid crystal: Polar domains and striking electro-optics, Proc. Natl. Acad. Sci. USA 117, 14021 (2020).
  5. N. Sebastián, M. Čopič, and A. Mertelj, Ferroelectric nematic liquid-crystalline phases, Phys. Rev. E 106, 021001 (2022).
  6. P. Kumari, B. Basnet, M. O. Lavrentovich, and O. D. Lavrentovich, Chiral ground states of ferroelectric liquid crystals, Science 383, 1364 (2024).
  7. Y. Song, S. Aya, and M. Huang, Updated view of new liquid-matter ferroelectrics with nematic and smectic orders, Giant 19, 100318 (2024).
  8. H. Kikuchi, H. Matsukizono, K. Iwamatsu, S. Endo, S. Anan, and Y. Okumura, Fluid layered ferroelectrics with global C∞v symmetry, Adv. Sci. 9, 2202048 (2022).
  9. J. Hobbs, C. J. Gibb, and R. J. Mandle, Emergent antiferroelectric ordering and the coupling of liquid crystalline and polar order, Small Sci. 4, 2400189 (2024).
  10. J. Hobbs, C. J. Gibb, D. Pociecha, J. Szydłowska, E. Górecka, and R. J. Mandle, Polar order in a fluid like ferroelectric with a tilted lamellar structure–Observation of a polar smectic C (SmCp) phase, Angew. Chem. Int. Ed. 64, e202416545 (2024).
  11. D. Pociecha, J. Szydlowska, N. Vaupotič, K. Kwiatkowska, M. Juodka, J. Spiess, J. M. Storey, C. T. Imrie, R. Walker, and E. Gorecka, Twist grain boundary phases in proper ferroelectric liquid crystals realm, Adv. Sci. 12, e08405 (2025).
  12. J. Karcz, J. Herman, N. Rychłowicz, P. Kula, E. Górecka, J. Szydlowska, P. W. Majewski, and D. Pociecha, Spontaneous chiral symmetry breaking in polar fluid–heliconical ferroelectric nematic phase, Science 384, 1096 (2024).
  13. H. Nishikawa, D. Okada, D. Kwaria, A. Nihonyanagi, M. Kuwayama, M. Hoshino, and F. Araoka, Emergent ferroelectric nematic and heliconical ferroelectric nematic states in an achiral “straight” polar rod mesogen, Adv. Sci. 11, 2405718 (2024).
  14. C. J. Gibb, J. Hobbs, D. I. Nikolova, T. Raistrick, S. R. Berrow, A. Mertelj, N. Osterman, N. Sebastián, H. F. Gleeson, and R. J. Mandle, Spontaneous symmetry breaking in polar fluids, Nat. Commun. 15, 5845 (2024).
  15. J. Hobbs, C. J. Gibb, and R. J. Mandle, Ferri- and ferro-electric switching in spontaneously chiral polar liquid crystals, Nat. Commun. 16, 7510 (2025).
  16. M. Cestari, S. Diez-Berart, D. A. Dunmur, A. Ferrarini, M. R. de la Fuente, D. J. B. Jackson, D. O. Lopez, G. R. Luckhurst, M. A. Perez-Jubindo, R. M. Richardson, J. Salud, B. A. Timimi, and H. Zimmermann, Phase behavior and properties of the liquid-crystal dimer 1′′, 7′′-bis(4-cyanobiphenyl-4′-yl) heptane: A twist-bend nematic liquid crystal, Phys. Rev. E 84, 031704 (2011).
  17. K. Adlem, M. Čopič, G. R. Luckhurst, A. Mertelj, O. Parri, R. M. Richardson, B. D. Snow, B. A. Timimi, R. P. Tuffin, and D. Wilkes, Chemically induced twist-bend nematic liquid crystals, liquid crystal dimers, and negative elastic constants, Phys. Rev. E 88, 022503 (2013).
  18. V. Borshch, Y.-K. Kim, J. Xiang, M. Gao, A. Jákli, V. P. Panov, J. K. Vij, C. T. Imrie, M. G. Tamba, G. H. Mehl, and O. D. Lavrentovich, Nematic twist-bend phase with nanoscale modulation of molecular orientation, Nat. Commun. 4, 2635 (2013).
  19. A. G. Vanakaras and D. J. Photinos, A molecular theory of nematic–nematic phase transitions in mesogenic dimers, Soft Matter 12, 2208 (2016).
  20. A. G. Vanakaras, E. T. Samulski, and D. J. Photinos, Polar-twisted, nano-modulated nematics: Form chirality and physical properties, Liquids 4, 768 (2024).
  21. S. M. Shamid, S. Dhakal, and J. V. Selinger, Statistical mechanics of bend flexoelectricity and the twist-bend phase in bent-core liquid crystals, Phys. Rev. E 87, 052503 (2013).
  22. P. De Gregorio, E. Frezza, C. Greco, and A. Ferrarini, Density functional theory of nematic elasticity: Softening from the polar order, Soft Matter 12, 5188 (2016).
  23. L. Longa and G. Pająk, Modulated nematic structures induced by chirality and steric polarization, Phys. Rev. E 93, 040701(R) (2016).
  24. L. Longa and W. Tomczyk, Twist–bend nematic phase from the Landau–de Gennes perspective, J. Phys. Chem. C 124, 22761 (2020).
  25. M. Čopič and A. Mertelj, Q-tensor model of twist-bend and splay nematic phases, Phys. Rev. E 101, 022704 (2020).
  26. J. V. Selinger, Director deformations, geometric frustration, and modulated phases in liquid crystals, Annu. Rev. Condens. Matter Phys. 13, 49 (2022).
  27. P. M. Rupnik, E. Hanžel, M. Lovšin, N. Osterman, C. J. Gibb, R. J. Mandle, N. Sebastián, and A. Mertelj, Antiferroelectric order in nematic liquids: Flexoelectricity versus electrostatics, Adv. Sci. 12, 2414818 (2025).
  28. X. Chen, V. Martinez, E. Korblova, G. Freychet, M. Zhernenkov, M. A. Glaser, C. Wang, C. Zhu, L. Radzihovsky, J. E. Maclennan, D. M. Walba, and N. A. Clark, The smectic ZA phase: Antiferroelectric smectic order as a prelude to the ferroelectric nematic, Proc. Natl. Acad. Sci. USA 120, e2217150120 (2023).
  29. A. Sterle, P. M. Rupnik, L. Cmok, A. Erkoreka, M. Lavrič, N. Osterman, C. J. Gibb, J. Hobbs, J. Martinez-Perdiguero, R. J. Mandle, A. Mertelj, and N. Sebastián, Elasticity-driven periodic polarization patterns in confined chiral ferroelectric nematic fluid, Adv. Mater. e75002 (2026).
  30. E. E. Zavvou, A. Jarosik, H. Nádasi, R. Tuffin, P. K. Karahaliou, C. Krontiras, M. Klasen-Memmer, and A. Eremin, Signatures of polar order in a ferroelectric nematic liquid crystal: Splay stiffening and twist softening, Soft Matter 21, 7508 (2025).
  31. A. Erkoreka, J. Martinez-Perdiguero, R. J. Mandle, A. Mertelj, and N. Sebastián, Dielectric spectroscopy of a ferroelectric nematic liquid crystal and the effect of the sample thickness, J. Mol. Liq. 387, 122566 (2023).
  32. A. Erkoreka, A. Mertelj, M. Huang, S. Aya, N. Sebastián, and J. Martinez-Perdiguero, Collective and non-collective molecular dynamics in a ferroelectric nematic liquid crystal studied by broadband dielectric spectroscopy, J. Chem. Phys. 159, 184502 (2023).
  33. N. A. Clark, X. Chen, J. E. MacLennan, and M. A. Glaser, Dielectric spectroscopy of ferroelectric nematic liquid crystals: Measuring the capacitance of insulating interfacial layers, Phys. Rev. Res. 6, 013195 (2024).
  34. Broadband Dielectric Spectroscopy, edited by F. Kremer and A. Schönhals (Springer, Berlin, Heidelberg, 2003).
  35. P.-G. de Gennes and J. Prost, The Physics of Liquid Crystals, 2nd ed., International Series of Monographs on Physics (Clarendon, Oxford, England, 1995).
  36. R. B. Meyer, Piezoelectric effects in liquid crystals, Phys. Rev. Lett. 22, 918 (1969).
  37. N. Sebastián, L. Cmok, A. Petelin, R. J. Mandle, and A. Mertelj, Distinctive features of pretransitional behaviour between nematic phases as revealed by DDM, Liq. Cryst. 51, 1047 (2024).
  38. I. Dozov, On the spontaneous symmetry breaking in the mesophases of achiral banana-shaped molecules, Europhys. Lett. 56, 247 (2001).
  39. Flexoelectricity in Liquid Crystals: Theory, Experiments and Applications, edited by A. Buka and N. Eber (Imperial College Press, London, 2012).
  40. H. Nishikawa, D. Okada, D. Kwaria, A. Nihonyanagi, M. Kuwayama, M. Hoshino, and F. Araoka, CCDC 2356894: Experimental crystal structure determination (2025), doi: 10.5517/ccdc.csd.cc2k3jv2.
  41. H. Nishikawa, D. Kwaria, A. Nihonyanagi, and F. Araoka, 3D hierarchical twists in polar fluids: Chirality regulation by ultralow electric field, Adv. Mater. 38, e13451 (2025).
  42. A. Erkoreka et al., Supporting Data for Flexoelectricity-driven softening of bend elasticity leads to spontaneous chiral symmetry breaking in a polar fluid [Dataset], Zenodo, 2026, 10.5281/zenodo.20282283.
  43. A. Petelin, Cross-differential dynamic microscopy (Version V0.2.0) [Computer software], Zenodo, 2020, https://doi.org/10.5281/zenodo.3800382.
  44. J. C. Everts and M. Ravnik, Ionically charged topological defects in nematic fluids, Phys. Rev. X 11, 011054 (2021).
