Finite-temperature properties of the Frenkel-Kontorova model: Relation to tribological systems and fluid rheology

Shubham Agarwal and Martin H. Müser*

  • Department of Materials Science and Engineering, Campus C6 3, Saarland University, 66123 Saarbrücken, Germany

  • *Contact author: martin.mueser@mx.uni-saarland.de
PDF

Phys. Rev. E 112, 045502 – Published 7 October, 2025

DOI: https://doi.org/10.1103/ll2g-k2gq

Abstract

The Frenkel-Kontorova model is a simple yet generic framework for the description of tribological phenomena and processes, including dry solid friction and the motion of adsorbed layers. As revealed in this work, it also reproduces qualitatively various features of complex liquids, such as, power-law subdiffusion between the ballistic and the diffusive regimes as well as a crossover from a non-Arrhenius to an Arrhenius dependence of the diffusion coefficient near the temperature, where the specific heat assumes its maximum. By systematically analyzing these thermal and kinetic properties, we also identify and clarify several misconceptions prevalent in the literature. Most notably, we show that the shear thinning with a shear-thinning exponent close to zero can be the natural consequence from enforced basin hopping: the energy drops caused by shear-induced instabilities dictate the friction-velocity dependence at medium shear rates rather than the way how shear forces reduce the free energy barriers for directed motion. Our findings thus demonstrate that even if the rheology is described by semiempirical theories such as the Eyring model, any agreement with experimental data, whether past, present, or future, may be purely coincidental.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (51)

  1. J. Frenkel and T. Kontorova, On the theory of plastic deformation and twinning, Phys. Z. Sowjetunion 13, 137 (1939).
  2. L. M. Floría and J. J. Mazo, Dissipative dynamics of the Frenkel-Kontorova model, Adv. Phys. 45, 505 (1996).
  3. O. M. Braun, T. Dauxois, M. V. Paliy, and M. Peyrard, Nonlinear mobility of the generalized Frenkel-Kontorova model, Phys. Rev. E 55, 3598 (1997).
  4. A. Vanossi and O. M. Braun, Driven dynamics of simplified tribological models, J. Phys.: Condens. Matter 19, 305017 (2007).
  5. T. Strunz and F.-J. Elmer, Driven Frenkel-Kontorova model. I. Uniform sliding states and dynamical domains of different particle densities, Phys. Rev. E 58, 1601 (1998).
  6. T. Strunz and F.-J. Elmer, Driven Frenkel-Kontorova model. II. Chaotic sliding and nonequilibrium melting and freezing, Phys. Rev. E 58, 1612 (1998).
  7. R. Peierls, The size of a dislocation, Proc. Phys. Soc. 52, 34 (1940).
  8. F. R. N. Nabarro, Dislocations in a simple cubic lattice, Proc. Phys. Soc. 59, 256 (1947).
  9. C. A. Coulomb, Théorie des machines simples, Memoirs de Mathematique et de Physique de l'acadmie Royale (Bachelier, Paris, 1785), pp. 161–342.
  10. M. H. Müser, M. Urbakh, and M. O. Robbins, Statistical mechanics of static and low-velocity kinetic friction, in Advances in Chemical Physics, edited by I. Prigogine and S. A. Rice (John Wiley & Sons, Inc., 2003).
  11. A. Benassi, M. Ma, M. Urbakh, and A. Vanossi, The breakdown of superlubricity by driving-induced commensurate dislocations, Sci. Rep. 5, 16134 (2015).
  12. J. A van den Ende, A. S. de Wijn, and A. Fasolino, The effect of temperature and velocity on superlubricity, J. Phys.: Condens. Matter 24, 445009 (2012).
  13. M. H. Müser, Structural lubricity: Role of dimension and symmetry, Europhys. Lett. 66, 97 (2004).
  14. T. Brazda, A. Silva, N. Manini, A. Vanossi, R. Guerra, E. Tosatti, and C. Bechinger, Experimental observation of the aubry transition in two-dimensional colloidal monolayers, Phys. Rev. X 8, 011050 (2018).
  15. J. Norell, A. Fasolino, and A. S. de Wijn, Emergent friction in two-dimensional Frenkel-Kontorova models, Phys. Rev. E 94, 023001 (2016).
  16. C. A. Angell, Relaxation in liquids, polymers and plastic crystals—strong/fragile patterns and problems, J. Non-Cryst. Solids 131-133, 13 (1991).
  17. H. Eyring, Viscosity, plasticity, and diffusion as examples of absolute reaction rates, J. Chem. Phys. 4, 283 (1936).
  18. H. Spikes and W. Tysoe, On the commonality between theoretical models for fluid and solid friction, wear and tribochemistry, Tribol. Lett. 59, 21 (2015).
  19. P. J. Carreau, Rheological equations from molecular network theories, Trans. Soc. Rheol. 16, 99 (1972).
  20. K. Yasuda, R. C. Armstrong, and R. E. Cohen, Shear flow properties of concentrated solutions of linear and star branched polystyrenes, Rheol. Acta 20, 163 (1981).
  21. A. Vanossi, G. E. Santoro, N. Manini, E. Tosatti, and O. M. Braun, Lubricated friction between incommensurate substrates, Tribol. Int. 41, 920 (2008).
  22. D. C. Rapaport, Hydrogen bonds in water: Network organization and lifetimes, Mol. Phys. 50, 1151 (1983).
  23. T. D. Kühne, M. Krack, F. R. Mohamed, and M. Parrinello, Efficient and accurate Car-Parrinello-like approach to Born-Oppenheimer molecular dynamics, Phys. Rev. Lett. 98, 066401 (2007).
  24. S. Aubry and P. Y. Le Daeron, The discrete Frenkel-Kontorova model and its extensions, Physica D (Amsterdam) 8, 381 (1983).
  25. S. Aubry, The twist map, the extended Frenkel-Kontorova model and the devil's staircase, Physica D (Amsterdam) 7, 240 (1983).
  26. U. Bengtzelius, W. Gotze, and A. Sjolander, Dynamics of supercooled liquids and the glass transition, J. Phys. C: Solid State Phys. 17, 5915 (1984).
  27. L. Prandtl, Ein gedankenmodell zur kinetischen theorie der festen körper, Z. Angew. Math. Mech. 8, 85 (1928).
  28. V. L. Popov and J. A. T. Gray, Prandtl-Tomlinson model: History and applications in friction, plasticity, and nanotechnologies, Z. Angew. Math. Mech. 92, 683 (2012).
  29. M. H. Müser, Shear thinning in the prandtl model and its relation to generalized newtonian fluids, Lubricants 8, 38 (2020).
  30. H. Gao and M. H. Müser, On the shear-thinning of alkanes, Tribol. Lett. 72, 16 (2024).
  31. S. J. Manzi, W. T. Tysoe, and O. J. Furlong, Temperature dependences in the Tomlinson/Prandtl model for atomic sliding friction, Tribol. Lett. 55, 363 (2014).
  32. S. J. Manzi, S. E. Carrera, O. J. Furlong, G. D. Kenmoe, and W. T. Tysoe, Prandtl–Tomlinson-type models for molecular sliding friction, Tribol. Lett. 69, 147 (2021).
  33. O. M. Braun, M. V. Paliy, J. Röder, and A. R. Bishop, Locked-to-running transition in the two-dimensional underdamped driven Frenkel-Kontorova model, Phys. Rev. E 63, 036129 (2001).
  34. M. Hirano and K. Shinjo, Atomistic locking and friction, Phys. Rev. B 41, 11837 (1990).
  35. M. H. Müser, Frenkel-Kontorova, https://github.com/mueser/Frenkel-Kontorova.git.
  36. N. Grønbech-Jensen, Complete set of stochastic verlet-type thermostats for correct Langevin simulations, Mol. Phys. 118, e1662506 (2020).
  37. S. Agarwal, S. V. Sukhomlinov, M. Honecker, and M. H. Müser, Advanced langevin thermostats: Properties, extensions to rheology, and a lean momentum-conserving approach, J. Chem. Phys. 163, 124110 (2025).
  38. P. Español and P. Warren, Statistical mechanics of dissipative particle dynamics, Europhys. Lett. 30, 191 (1995).
  39. T. Soddemann, B. Dünweg, and K. Kremer, Dissipative particle dynamics: A useful thermostat for equilibrium and nonequilibrium molecular dynamics simulations, Phys. Rev. E 68, 046702 (2003).
  40. I. Vattulainen, M. Karttunen, G. Besold, and J. M. Polson, Integration schemes for dissipative particle dynamics simulations: From softly interacting systems towards hybrid models, J. Chem. Phys. 116, 3967 (2002).
  41. H. Risken, The Fokker-Planck Equation: Methods of Solution and Applications, 2nd ed., Springer Series in Synergetics Vol. 18 (Springer, Berlin, 1989).
  42. H. A. Kramers, Brownian motion in a field of force and the diffusion model of chemical reactions, Physica (Amsterdam) 7, 284 (1940).
  43. P. Hänggi, P. Talkner, and M. Borkovec, Reaction-rate theory: Fifty years after kramers, Rev. Mod. Phys. 62, 251 (1990).
  44. V. Ambegaokar and B. I. Halperin, Voltage due to thermal noise in the dc Josephson effect, Phys. Rev. Lett. 22, 1364 (1969).
  45. R. Metzler and J. Klafter, The random walk's guide to anomalous diffusion: A fractional dynamics approach, Phys. Rep. 339, 1 (2000).
  46. W. Kob and H. C. Andersen, Testing mode-coupling theory for a supercooled binary Lennard-Jones mixture I: The van Hove correlation function, Phys. Rev. E 51, 4626 (1995).
  47. F. R. Krajewski and M. H. Müser, Quantum creep and quantum-creep transitions in 1D sine-Gordon chains, Phys. Rev. Lett. 92, 030601 (2004).
  48. C. A. Angell, Formation of glasses from liquids and biopolymers, Science 267, 1924, (1995).
  49. J. Sim, S. Wu, S. Hwang, L. Lu, and R. R. Zhao, Selective actuation enabled multifunctional magneto-mechanical metamaterial for programming elastic wave propagation, Adv. Funct. Mater. 35, 2422325 (2025).
  50. A. H. B. De Vries, B. E. Krenn, R. van Driel, and J. S. Kanger, Micro magnetic tweezers for nanomanipulation inside live cells, Biophys. J. 88, 2137 (2005).
  51. B. E. Vos, T. M. Muenker, and T. Betz, Characterizing intracellular mechanics via optical tweezers-based microrheology, Curr. Opin. Cell Biol. 88, 102374 (2024).
