Shock-compression-based equation of state for perfluorohexane

Anunay Prasanna1,*, Guillaume T. Bokman1, Samuele Fiorini1, Armand Sieber1, Bratislav Lukić2, Daniel Foster2,†, and Outi Supponen1

  • *Contact author: aanunay@ethz.ch
  • †Present address: Spectroscopy and Imaging Division, Soft X-ray Spectroscopy and Imaging Team, Japan Synchrotron Radiation Research Institute (JASRI) SRIS #209, 468-1, Aramaki Aza Aoba, Sendai, Miyagi 980-8572, Japan.
PDF

Phys. Rev. E 112, 065101 – Published 1 December, 2025

DOI: https://doi.org/10.1103/999d-nk9z

Abstract

Perfluorohexane is a biocompatible material that serves as a liquid core for acoustically responsive agents in biomedical applications. Despite its relatively widespread usage, there is a lack of experimental data determining its thermodynamic properties. This challenges numerical simulations to predict the acoustic response of agents developed using this material. In this study, we employ the well-established method of shock compression of materials at relatively high pressures (100–400 MPa) to estimate a kinematic equation of state for perfluorohexane. We use multi-objective optimization to obtain the Noble-Abel stiffened-gas equation of state, which is suitable for hydrodynamic numerical simulations. We then apply the extrapolated equation of state to simulate shock-wave propagation within a perfluorohexane droplet showing excellent agreement with equivalent experiments. This promotes the use of numerical simulations as a valuable tool for understanding the complex acoustic interactions involved in these biomedical agents, ultimately facilitating their translation for clinical purposes.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (62)

  1. G. Shakya, M. Cattaneo, G. Guerriero, A. Prasanna, S. Fiorini, and O. Supponen, Ultrasound-responsive microbubbles and nanodroplets: A pathway to targeted drug delivery, Adv. Drug Delivery Rev. 206, 115178 (2024).
  2. K. C. Lowe, Fluorinated blood substitutes and oxygen carriers, J. Fluorine Chem. 109, 59 (2001).
  3. G. Picheth, S. Houvenagel, C. Dejean, O. Couture, R. Alves de Freitas, L. Moine, and N. Tsapis, Echogenicity enhancement by end-fluorinated polylactide perfluorohexane nanocapsules: Towards ultrasound-activable nanosystems, Acta Biomaterialia 64, 313 (2017).
  4. O. D. Kripfgans, J. B. Fowlkes, D. L. Miller, O. P. Eldevik, and P. L. Carson, Acoustic droplet vaporization for therapeutic and diagnostic applications, Ultrasound Med. Biol. 26, 1177 (2000).
  5. R. Díaz-López, N. Tsapis, and E. Fattal, Liquid perfluorocarbons as contrast agents for ultrasonography and F19-MRI, Pharm. Res. 27, 1 (2010).
  6. A. V. Namen, S. Jandhyala, T. Jordan, and G. P. Luke, Repeated acoustic vaporization of perfluorohexane nanodroplets for contrast-enhanced ultrasound imaging, IEEE Trans. Ultrasonics Ferroelectrics Frequency Control 68, 3497 (2021).
  7. Q. Zeng, L. Qiao, L. Cheng, C. Li, Z. Cao, Z. Chen, Y. Wang, and J. Liu, Perfluorohexane-loaded polymeric nanovesicles with oxygen supply for enhanced sonodynamic therapy, ACS Biomater. Sci. Eng. 6, 2956 (2020).
  8. H. Xiao, M. Aliabouzar, and M. L. Fabiilli, Acoustically responsive scaffolds: Unraveling release kinetics and mechanisms for sustained, steady drug delivery, J. Control. Release 374, 205 (2024).
  9. M. A. Borden, G. Shakya, A. Upadhyay, and K. H. Song, Acoustic nanodrops for biomedical applications, Curr. Opin. Colloid Interface Sci. 50, 101383 (2020).
  10. H. Maeda, Toward a full understanding of the EPR effect in primary and metastatic tumors as well as issues related to its heterogeneity, Adv. Drug Delivery Rev. 91, 3 (2015).
  11. O. Shpak, M. Verweij, H. J. Vos, N. De Jong, D. Lohse, and M. Versluis, Acoustic droplet vaporization is initiated by superharmonic focusing, Proc. Natl. Acad. Sci. USA 111, 1697 (2014).
  12. S. Fiorini, A. Prasanna, G. Shakya, M. Cattaneo, and O. Supponen, Positive pressure matters in acoustic droplet vaporization, Phys. Rev. Res. 7, 023322 (2025).
  13. A. M. Loske, Medical and Biomedical Applications of Shock Waves, Shock Wave and High Pressure Phenomena (Springer, Cham, 2017).
  14. M. Maier, B. Averbeck, S. Milz, H. J. Refior, and C. Schmitz, Substance P and prostaglandin E2 release after shock wave application to the rabbit femur, Clin. Orthopaedics Related Res. 406, 237 (2003).
  15. R. Beisteiner, E. Matt, C. Fan, H. Baldysiak, M. Schönfeld, T. Philippi Novak, A. Amini, T. Aslan, R. Reinecke, J. Lehrner et al., Transcranial pulse stimulation with ultrasound in Alzheimer's disease—A new navigated focal brain therapy, Adv. Sci. 7, 1902583 (2020).
  16. T. Kisch, W. Wuerfel, V. Forstmeier, E. Liodaki, F. H. Stang, K. Knobloch, P. Mailaender, and R. Kraemer, Repetitive shock wave therapy improves muscular microcirculation, J. Surg. Res. 201, 440 (2016).
  17. F. Marano, M. Argenziano, R. Frairia, A. Adamini, O. Bosco, L. Rinella, N. Fortunati, R. Cavalli, and M. G. Catalano, Doxorubicin-loaded nanobubbles combined with extracorporeal shock waves: Basis for a new drug delivery tool in anaplastic thyroid cancer, Thyroid 26, 705 (2016).
  18. F. Marano, R. Frairia, L. Rinella, M. Argenziano, B. Bussolati, C. Grange, R. Mastrocola, I. Castellano, L. Berta, R. Cavalli et al., Combining doxorubicin-nanobubbles and shockwaves for anaplastic thyroid cancer treatment: Preclinical study in a xenograft mouse model, Endocrine-Related Cancer 24, 275 (2017).
  19. R. Menikoff and B. J. Plohr, The Riemann problem for fluid flow of real materials, Rev. Mod. Phys. 61, 75 (1989).
  20. K. Gao, A. Köster, M. Thol, J. Wu, and E. W. Lemmon, Equations of state for the thermodynamic properties of n-perfluorobutane, n-perfluoropentane, and n-perfluorohexane, Ind. Eng. Chem. Res. 60, 17207 (2021).
  21. J. P. Cocchi, R. Saurel, and J. C. Loraud, Treatment of interface problems with Godunov-type schemes, Shock Waves 5, 347 (1996).
  22. M. H. Rice and J. M. Walsh, Equation of state of water to 250 kilobars, J. Chem. Phys. 26, 824 (1957).
  23. L. M. Barker and R. E. Hollenbach, Shock-wave studies of PMMA, fused silica, and sapphire, J. Appl. Phys. 41, 4208 (1970).
  24. W. J. Nellis and A. C. Mitchell, Shock compression of liquid argon, nitrogen, and oxygen to 90 GPa (900 kbar), J. Chem. Phys. 73, 6137 (1980).
  25. A. C. Mitchell and W. J. Nellis, Equation of state and electrical conductivity of water and ammonia shocked to the 100 GPa (1 Mbar) pressure range, J. Chem. Phys. 76, 6273 (1982).
  26. W. J. M. Rankine, XV. On the thermodynamic theory of waves of finite longitudinal disturbance, Phil. Trans. R. Soc. 160, 277 (1870).
  27. H. Hugoniot, Mémoire sur la propagation du mouvement dans un fluide indéfini (première partie), J. l'Ecole Polytechnique 3, 477 (1887).
  28. R. Saurel, F. Petitpas, and R. Abgrall, Modelling phase transition in metastable liquids: Application to cavitating and flashing flows, J. Fluid Mech. 607, 313 (2008).
  29. G. A. Cox and M. A. Christie, Fitting of a multiphase equation of state with swarm intelligence, J. Phys.: Condens. Matter 27, 405201 (2015).
  30. P. C. Myint, L. X. Benedict, C. J. Wu, and J. L. Belof, Minimization of Gibbs energy in high-pressure multiphase, multicomponent mixtures through particle swarm optimization, ACS Omega 6, 13341 (2021).
  31. G. Robert, V. Dubois, and P. Legrand, Using maximum likelihood estimation approach to adjust parameters of multiphase equations of state: Molybdenum as an example, J. Appl. Phys. 131, 105901 (2022).
  32. O. Le Métayer and R. Saurel, The Noble-Abel stiffened-gas equation of state, Phys. Fluids 28, 046102 (2016).
  33. M. E. Rutherford, D. J. Chapman, J. G. Derrick, J. R. W. Patten, P. A. Bland, A. Rack, G. S. Collins, and D. E. Eakins, Probing the early stages of shock-induced chondritic meteorite formation at the mesoscale, Sci. Rep. 7, 45206 (2017).
  34. A. Rack, B. Lukić, D. J. Chapman, J. Strucka, Y. Yao, K. Mughal, D. Maler, S. Efimov, O. Belozerov, Y. Krasik et al., Dynamic loading platforms coupled to ultra-high speed x-ray imaging at beamline ID19 of the European Synchrotron ESRF, High Press. Res. 44, 400 (2024).
  35. G. T. Bokman, L. Biasiori-Poulanges, D. W. Meyer, and O. Supponen, Scaling laws for bubble collapse driven by an impulsive shock wave, J. Fluid Mech. 967, A33 (2023).
  36. K. Schmidmayer, F. Petitpas, S. Le Martelot, and É. Daniel, ECOGEN: An open-source tool for multiphase, compressible, multiphysics flows, Comput. Phys. Commun. 251, 107093 (2020).
  37. T. Trummler, S. H. Bryngelson, K. Schmidmayer, S. J. Schmidt, T. Colonius, and N. A. Adams, Near-surface dynamics of a gas bubble collapsing above a crevice, J. Fluid Mech. 899, A16 (2020).
  38. B. Dorschner, L. Biasiori-Poulanges, K. Schmidmayer, H. El-Rabii, and T. Colonius, On the formation and recurrent shedding of ligaments in droplet aerobreakup, J. Fluid Mech. 904, A20 (2020).
  39. G. T. Bokman, L. Biasiori-Poulanges, B. Lukić, K. Schmidmayer, C. Bourquard, E. Baumann, A. Rack, B. J. Olson, and O. Supponen, Impulse-driven release of gas-encapsulated drops, J. Fluid Mech. 1001, A51 (2024).
  40. A. K. Kapila, R. Menikoff, J. B. Bdzil, S. F. Son, and D. S. Stewart, Two-phase modeling of deflagration-to-detonation transition in granular materials: Reduced equations, Phys. Fluids 13, 3002 (2001).
  41. R. Saurel, F. Petitpas, and R. A. Berry, Simple and efficient relaxation methods for interfaces separating compressible fluids, cavitating flows and shocks in multiphase mixtures, J. Comput. Phys. 228, 1678 (2009).
  42. O. Le Métayer, J. Massoni, and R. Saurel, Élaboration des lois d'état d'un liquide et de sa vapeur pour les modèles d'écoulements diphasiques, Int. J. Therm. Sci. 43, 265 (2004).
  43. J. L. Jordan, D. Casem, and M. Zellner, Shock response of polymethylmethacrylate, J. Dyn. Behav. Mater. 2, 372 (2016).
  44. H. Kleine, H. Grönig, and K. Takayama, Simultaneous shadow, schlieren and interferometric visualization of compressible flows, Optics Lasers Eng. 44, 170 (2006).
  45. J. H. Gladstone and T. Dale, XIV. Researches on the refraction, dispersion, and sensitiveness of liquids, Phil. Trans. R. Soc. 153, 317 (1863).
  46. T. J. Ahrens, Equation of state, in High-Pressure Shock Compression of Solids, edited by J. R. Asay and M. Shahinpoor (Springer, New York, NY, 1993), pp. 75–113.
  47. J. N. Marsh, C. S. Hall, S. A. Wickline, and G. M. Lanza, Temperature dependence of acoustic impedance for specific fluorocarbon liquids, J. Acoust. Soc. Am. 112, 2858 (2002).
  48. J. Blank and K. Deb, Pymoo: Multi-objective optimization in Python, IEEE Access 8, 89497 (2020).
  49. K. Deb, A. Pratap, S. Agarwal, and T. Meyarivan, A fast and elitist multiobjective genetic algorithm: NSGA-II, IEEE Trans. Evol. Comput. 6, 182 (2002).
  50. K. Deb, K. Sindhya, and T. Okabe, Self-adaptive simulated binary crossover for real-parameter optimization, in Proceedings of the 9th Annual Conference on Genetic and Evolutionary Computation (ACM Digital Library, New York, NY, USA, 2007), pp. 1187–1194.
  51. J. Blank and K. Deb, A running performance metric and termination criterion for evaluating evolutionary multi-and many-objective optimization algorithms, in 2020 IEEE Congress on Evolutionary Computation (CEC) (IEEE, Piscataway, NJ, 2020), pp. 1–8.
  52. See Supplemental Material at http://link.aps.org/supplemental/10.1103/999d-nk9z for experimental videos of (1) impact experiment with uf=109m/s and (2) shock-droplet interaction for R=662µm.
  53. P. T. Boggs and J. E. Rogers, Orthogonal distance regression, in Statistical Analysis of Measurement Error Models and Applications: Proceedings of the AMS-IMS-SIAM Joint Summer Research Conference Held June 10–16, 1989, edited by P. J. Brown and W. A. Fuller, Contemporary Mathematics (American Mathematical Society, Providence, 1990), Vol. 112, p. 186.
  54. L. I. Pavlinov, I. B. Rabinovich, N. A. Okladnov, and S. A. Arzhakov, Heat capacity of copolymers of methyl methacrylate with methacrylic acid in the region 25–190 ∘C, Polymer Sci. USSR 9, 539 (1967).
  55. A. P. Wierzbicki, The use of reference objectives in multiobjective optimization, in Multiple Criteria Decision Making Theory and Application, Lectures in Economics and Mathematical Systems, edited by G. Fandel and T. Gal (Springer, Berlin, 1980), Vol. 177, pp. 468–486.
  56. K. Schmidmayer and L. Biasiori-Poulanges, Geometry effects on the droplet shock-induced cavitation, Phys. Fluids 35, 063315 (2023).
  57. D. H. Dolan, Extreme measurements with photonic Doppler velocimetry (PDV), Rev. Sci. Instrum. 91, 051501 (2020).
  58. V. Kilic, C. S. DiMarco, J. M. Diamond, P. Chu, K. T. Ramesh, Z. Wang, and M. A. Foster, Time lens photon Doppler velocimetry (TL-PDV) for extreme measurements, Nat. Commun. 15, 7732 (2024).
  59. E. Johnsen and T. Colonius, Shock-induced collapse of a gas bubble in shockwave lithotripsy, J. Acoust. Soc. Am. 124, 2011 (2008).
  60. A. Prasanna et al., Shock-compression-based equation of state for perfluorohexane (1.0.0) [Data set], Zenodo (2025), 10.5281/zenodo.15129970.
  61. A. C. Mitchell and W. J. Nellis, Shock compression of aluminum, copper, and tantalum, J. Appl. Phys. 52, 3363 (1981).
  62. A. Possolo, Simple guide for evaluating and expressing the uncertainty of nist measurement results, Technical Report, National Institute of Standards and Technology, Gaithersburg, MD, 2015.
