  • Editors' Suggestion
  • Open Access

Folding lattice proteins confined on minimal grids using a quantum-inspired encoding

Anders Irbäck1,*, Lucas Knuthson1, and Sandipan Mohanty2

  • 1Computational Science for Health and Environment (COSHE), Centre for Environmental and Climate Science, Lund University, 223 62 Lund, Sweden
  • 2Jülich Supercomputing Centre, Forschungszentrum Jülich, D-52425 Jülich, Germany

  • *Contact author: anders.irback@cec.lu.se
PDF

Phys. Rev. E 112, 045302 – Published 1 October, 2025

DOI: https://doi.org/10.1103/8n7p-7lh2

Abstract

Steric clashes pose a challenge when exploring dense protein systems using conventional explicit-chain methods. A minimal example is a single lattice protein confined on a minimal grid, with no free sites. Finding its minimum energy is a hard optimization problem, with similarities to scheduling problems. It can be recast as a quadratic unconstrained binary optimization (QUBO) problem amenable to classical and quantum approaches. We show that this problem in its QUBO form can be swiftly and consistently solved for chain length 48, using either classical simulated annealing or hybrid quantum-classical annealing on a D-Wave system. In fact, the latter computations required about 10 s. We also test linear and quadratic programming methods, which work well for a lattice gas but struggle with chain constraints. All methods are benchmarked against exact results obtained from exhaustive structure enumeration, at a high computational cost.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (41)

  1. J. Jumper, R. Evans, A. Pritzel, T. Green, M. Figurnov, O. Ronneberger, K. Tunyasuvunakool, R. Bates, A. Žídek, A. Potapenko, A. Bridgland, C. Meyer, S. A. A. Kohl, A. J. Ballard, A. Cowie, B. Romera-Paredes, S. Nikolov, R. Jain, J. Adler, T. Back et al., Highly accurate protein structure prediction with AlphaFold, Nature (London) 596, 583 (2021).
  2. K. F. Lau and K. A. Dill, A lattice statistical mechanics model of the conformational and sequence spaces of proteins, Macromolecules 22, 3986 (1989).
  3. A. Šali, E. Shakhnovich, and M. Karplus, Kinetics of protein folding: A lattice model study of the requirements for folding to the native state, J. Mol. Biol. 235, 1614 (1994).
  4. N. D. Socci and J. N. Onuchic, Folding kinetics of proteinlike heteropolymers, J. Chem. Phys. 101, 1519 (1994).
  5. D. K. Klimov and D. Thirumalai, Criterion that determines the foldability of proteins, Phys. Rev. Lett. 76, 4070 (1996).
  6. H. Li, R. Helling, C. Tang, and N. Wingreen, Emergence of preferred structures in a simple model of protein folding, Science 273, 666 (1996).
  7. A. Perdomo-Ortiz, N. Dickson, M. Drew-Brook, G. Rose, and A. Aspuru-Guzik, Finding low-energy conformations of lattice protein models by quantum annealing, Sci. Rep. 2, 571 (2012).
  8. A. Robert, P. K. Barkoutsos, S. Woerner, and I. Tavernelli, Resource-efficient quantum algorithm for protein folding, npj Quantum Inf. 7, 38 (2021).
  9. A. Irbäck, L. Knuthson, S. Mohanty, and C. Peterson, Folding lattice proteins with quantum annealing, Phys. Rev. Res. 4, 043013 (2022).
  10. J. J. Hopfield and D. W. Tank, Neural computation of decisions in optimization problems, Biol. Cybern. 52, 141 (1985).
  11. C. Peterson and J. R. Anderson, Neural networks and NP-complete problems; a performance study of the graph bisectioning problem, Complex Syst. 2, 59 (1988).
  12. T. Kadowaki and H. Nishimori, Quantum annealing in the transverse Ising model, Phys. Rev. E 58, 5355 (1998).
  13. E. Farhi, J. Goldstone, S. Gutmann, J. Lapan, A. Lundgren, and D. Preda, A quantum adiabatic evolution algorithm applied to random instances of an np-complete problem, Science 292, 472 (2001).
  14. E. Farhi, J. Goldstone, and S. Gutmann, A quantum approximate optimization algorithm, arXiv:1411.4028.
  15. S. Hadfield, Z. Wang, B. O'Gorman, E. G. Rieffel, D. Venturelli, and R. Biswas, From the quantum approximate optimization algorithm to a quantum alternating operator ansatz, Algorithms 12, 34 (2019).
  16. N. Mohseni, P. L. McMahon, and T. Byrnes, Ising machines as hardware solvers of combinatorial optimization problems, Nat. Rev. Phys. 4, 363 (2022).
  17. C. Micheletti, P. Hauke, and P. Faccioli, Polymer physics by quantum computing, Phys. Rev. Lett. 127, 080501 (2021).
  18. F. Slongo, P. Hauke, P. Faccioli, and C. Micheletti, Quantum- inspired encoding enhances stochastic sampling of soft matter systems, Sci. Adv. 9, eadi0204 (2023).
  19. M. Lagerholm, C. Peterson, and B. Söderberg, Airline crew scheduling with Potts neurons, Neural Comput. 9, 1589 (1997).
  20. D. Venturelli, D. J. J. Marchand, and G. Rojo, Quantum annealing implementation of job-shop scheduling, arXiv:1506.08479.
  21. T. Stollenwerk, S. Hadfield, and Z. Wang, Toward quantum gate-model heuristics for real-world planning problems, IEEE Trans. Quantum Eng. 1, 1 (2020).
  22. S. Kirkpatrick, C. D. Gelatt, and M. P. Vecchi, Optimization by simulated annealing, Science 220, 671 (1983).
  23. C. McGeoch, P. Farré, and W. Bernoudy, D-Wave Hybrid Solver Service + Advantage: Technology Update, Technical Report No. 14-1048A-A, D-Wave Systems Inc., 2020.
  24. Gurobi Optimization, LLC, Gurobi optimizer reference manual (2024), https://www.gurobi.com/.
  25. S. Miyazawa and R. L. Jernigan, Estimation of effective interresidue contact energies from protein crystal structures: Quasi-chemical approximation, Macromolecules 18, 534 (1985).
  26. S. Miyazawa and R. L. Jernigan, Residue-residue potentials with a favorable contact pair term and an unfavorable high packing density term, for simulation and threading, J. Mol. Biol. 256, 623 (1996).
  27. P. F. Faísca and K. W. Plaxco, Cooperativity and the origins of rapid, single-exponential kinetics in protein folding, Protein Sci. 15, 1608 (2006).
  28. A. Irbäck, L. Knuthson, S. Mohanty, and C. Peterson, Using quantum annealing to design lattice proteins, Phys. Rev. Res. 6, 013162 (2024).
  29. V. S. Pande, C. Joerg, A. Y. Grosberg, and T. Tanaka, Enumerations of the Hamiltonian walks on a cubic sublattice, J. Phys. A: Math. Gen. 27, 6231 (1994).
  30. A. Kloczkowski and R. Jernigan, Computer generation and enumeration of compact self-avoiding walks within simple geometries on lattices, Comput. Theor. Polym. Sci. 7, 163 (1997).
  31. K. W. Plaxco, K. T. Simons, and D. Baker, Contact order, transition state placement and the refolding rates of single domain proteins, J. Mol. Biol. 277, 985 (1998).
  32. H. Linn, I. Lyngfelt, L. García-Álvarez, and G. Johansson, Resource analysis of quantum algorithms for coarse-grained protein folding models, Phys. Rev. Res. 6, 033112 (2024).
  33. V. Panizza, A. Roggero, P. Hauke, and P. Faccioli, Statistical mechanics of heteropolymers from lattice gauge theory, Phys. Rev. Lett. 134, 158101 (2025).
  34. G. B. Dantzig, Linear Programming and Extensions (Princeton University Press, Princeton, 1963).
  35. D. R. Morrison, S. H. Jacobson, J. J. Sauppe, and E. C. Sewell, Branch-and-bound algorithms: A survey of recent advances in searching, branching, and pruning, Discrete Optim. 19, 79 (2016).
  36. H. Marchand, A. Martin, R. Weismantel, and L. Wolsey, Cutting planes in integer and mixed integer programming, Discrete Appl. Math. 123, 397 (2002).
  37. V. Panizza, P. Hauke, C. Micheletti, and P. Faccioli, Protein design by integrating machine learning and quantum-encoded optimization, PRX Life 2, 043012 (2024).
  38. J. D. Bryngelson, J. N. Onuchic, N. D. Socci, and P. G. Wolynes, Funnels, pathways, and the energy landscape of protein folding: A synthesis, Proteins 21, 167 (1995).
  39. J. K. Brubaker, K. E. C. Booth, A. Arakawa, F. Furrer, J. Ghosh, T. Sato, and H. G. Katzgraber, Quadratic unconstrained binary optimization and constraint programming approaches for lattice-based cyclic peptide docking, arXiv:2412.10260.
  40. S. Abeln, M. Vendruscolo, C. M. Dobson, and D. Frenkel, A simple lattice model that captures protein folding, aggregation and amyloid formation, PLoS ONE 9, e85185 (2014).
  41. U. Rana, C. P. Brangwynne, and A. Z. Panagiotopoulos, Phase separation vs aggregation behavior for model disordered proteins, J. Chem. Phys. 155, 125101 (2021).
