Boundary-driven anisotropic coarsening in conserved phase separation

Emilio N. M. Cirillo1,*, Nicklas Jävergård2,†, Adrian Muntean2,‡, and Stela Andrea Muntean3,§

  • *Contact author: emilio.cirillo@uniroma1.it
  • †Contact author: nicklas.javergard@kau.se
  • ‡Contact author: adrian.muntean@kau.se
  • §Contact author: andrea.muntean@kau.se
PDF

Phys. Rev. E 114, L042111 – Published 27 October, 2026

DOI: https://doi.org/10.1103/7c82-vpdb

Abstract

Universal scaling in phase separation is typically assumed to be isotropic in systems with conserved dynamics. Here we show that boundary forcing alone can break this dynamical scaling symmetry, leading to anisotropic coarsening, with different effective global growth laws observed parallel and perpendicular to the boundary. We consider a ternary mixture with two conserved components and a passive species undergoing surface evaporation, which provides a simple setting to investigate this effect. In this case, evaporation leads to a progressive mass loss and to the formation of macroscopic concentration gradients, which, in turn, drive anisotropic coarsening, with different effective growth laws observed parallel and perpendicular to the boundary. At the same time, bulk regions appear to retain the standard Model B scaling, suggesting that the observed anisotropy is mainly induced by boundary fluxes rather than by changes in the intrinsic dynamics. Our results indicate that boundary conditions can play an important role in breaking scaling symmetry and may offer a way to influence coarsening behavior in nonequilibrium phase separation.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (29)

  1. M. Laradji, O. G. Mouritsen, and S. Toxvaerd, Spinodal decomposition in multicomponent fluid mixtures: A molecular dynamics study, Phys. Rev. E 53, 3673 (1996).
  2. H. Hoppe and N. S. Sariciftci, Organic solar cells: An overview, J. Mater. Res. 19, 1924 (2004).
  3. E. Moons, Conjugated polymer blends: Linking film morphology to performance of light emitting diodes and photodiodes, J. Phys.: Condens. Matter 14, 12235 (2002).
  4. S. Nilsson, A. Bernasik, A. Budkowski, and E. Moons, Morphology and phase segregation of spin-casted films of polyfluorene/PCBM blends, Macromolecules 40, 8291 (2007).
  5. J. W. Cahn and J. E. Hilliard, Free energy of a nonuniform system. I. Interfacial free energy, J. Chem. Phys. 28, 258 (1958).
  6. A. J. Bray, Theory of phase-ordering kinetics, Adv. Phys. 43, 357 (1994).
  7. P. C. Hohenberg and B. I. Halperin, Theory of dynamic critical phenomena, Rev. Mod. Phys. 49, 435 (1977).
  8. A. J. Bray, Universal scaling function for domain growth in the Glauber-Ising chain, J. Phys. A: Math. Gen. 23, L67 (1990).
  9. A. Chauhan, D. Gogoi, S. Puri, and A. Singh, Effect of amphiphilic polymers on phase separating binary mixtures: A DPD simulation study, J. Chem. Phys. 159, 204901 (2023).
  10. E. N. M. Cirillo, G. Gonnella, and S. Stramaglia, Anisotropic dynamical scaling in a spin model with competing interactions, Phys. Rev. E 56, 5065 (1997).
  11. F. Corberi, G. Gonnella, and A. Lamura, Two-scale competition in phase separation with shear, Phys. Rev. Lett. 83, 4057 (1999).
  12. D. Davis, Parameshwaran A., and B. Sen Gupta, Phase separation and rheology of segregating binary fluid under shear, Phys. Rev. E 111, 065414 (2025).
  13. A. Onuki, Phase Transition Dynamics (Cambridge University Press, Cambridge, 2002).
  14. R. D. Deegan, O. Bakajin, T. F. Dupont, G. Huber, S. R. Nagel, T. A. Witten, et al., Capillary flow as the cause of ring stains from dried liquid drops, Nature (London) 389, 827 (1997).
  15. R. G. Larson, Transport and deposition patterns in drying sessile droplets, AIChE J. 60, 1538 (2014).
  16. I. Hopkinson and M. Myatt, Phase separation in ternary polymer solutions induced by solvent loss, Macromolecules 35, 5153 (2002).
  17. R. Bishnu, R. Mukherjee, N. Bhandaru, and A. Dutta, Morphology prediction for polymer blend thin films using machine learning, Soft Matter 21, 5284 (2025).
  18. U. Thiele, Thin film evolution equations from (evaporating) dewetting liquid layers to epitaxial growth, J. Phys.: Condens. Matter 22, 084019 (2010).
  19. S. Puri and K. Binder, Surface-directed spinodal decomposition: Phenomenology and numerical results, Phys. Rev. A 46, R4487 (1992).
  20. R. Bhattacharyya, Kinetics and morphology of surface-directed spinodal decomposition, Physica A 695, 131612 (2026).
  21. E. N. M. Cirillo, N. Jävergård, R. Lyons, A. Muntean, and S. A. Muntean, 3D morphology formation in a mixture of three differently averse components, Modelling Simul. Mater. Sci. Eng. 33, 055014 (2025).
  22. S. A. Muntean, V. C. E. Kronberg, M. Colangeli, A. Muntean, J. van Stam, E. Moons, and E. N. M. Cirillo, Quantitative analysis of phase formation and growth in ternary mixtures upon evaporation of one component, Phys. Rev. E 106, 025306 (2022).
  23. M. Blume, Theory of the first–order magnetic phase change in UO2, Phys. Rev. 141, 517 (1966).
  24. E. N. M. Cirillo, V. Jacquier, and C. Spitoni, Homogeneous and heterogeneous nucleation in the three-state Blume–Capel model, Physica D 461, 134125 (2024).
  25. C. Mendes, G. M. Buendía, and P. A. Rikvold, Numerical simulation of a two-dimensional Blume-Capel ferromagnet in an oscillating magnetic field with a constant bias, Phys. Rev. E 110, 044133 (2024).
  26. R. Marra and M. Mourragui, Phase segregation dynamics for the Blume–Capel model with Kac interaction, Stochastic Processes Appl. 88, 79 (2000).
  27. J. L. Lebowitz and O. Penrose, Rigorous treatment of the van der Waals-Maxwell theory of the liquid-vapor transition, J. Math. Phys. 7, 98 (1966).
  28. G. Giacomin and J. L. Lebowitz, Phase segregation dynamics in particle systems with long range interactions. I. Macroscopic limits, J. Stat. Phys. 87, 37 (1997).
  29. R. Lyons, E. N. M. Cirillo, and A. Muntean, Phase separation and morphology formation in interacting ternary mixtures under evaporation: Well-posedness and numerical simulation of a non-local evolution system, Nonlinear Anal. Real World Appl. 77, 104039 (2024).
