  • Editors' Suggestion
  • Open Access

Threshold and quasistationary distribution for the susceptible-infectious-susceptible model on networks

George T. Cantwell1,* and Cristopher Moore2,†

  • *Contact author: gtc31@cam.ac.uk
  • †Contact author: moore@santafe.edu
PDF

Phys. Rev. E 113, 064305 – Published 12 June, 2026

DOI: https://doi.org/10.1103/385j-2f29

Abstract

We study the Susceptible-Infectious-Susceptible model on arbitrary networks. The well-established pair approximation treats neighboring pairs of nodes exactly while making a mean-field approximation for the rest of the network. We improve the method by expanding the state space dynamically, giving nodes a memory of when they last became susceptible. The resulting approximation is simple to implement and appears to be highly accurate, both in locating the epidemic threshold and in computing the quasistationary fraction of infected individuals above the threshold, for both finite graphs and infinite random graphs.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (36)

  1. I. Z. Kiss, J. C. Miller, and P. L. Simon, Mathematics of Epidemics on Networks: From Exact to Approximate Models, Interdisciplinary Applied Mathematics (Springer International Publishing, Cham, 2017), Vol. 46.
  2. R. Pastor-Satorras, C. Castellano, P. Van Mieghem, and A. Vespignani, Epidemic processes in complex networks, Rev. Mod. Phys. 87, 925 (2015).
  3. M. J. Keeling and K. T. Eames, Networks and epidemic models, J. R. Soc., Interface 2, 295 (2005).
  4. P. Grassberger, On the critical behavior of the general epidemic process and dynamical percolation, Math. Biosci. 63, 157 (1983).
  5. M. E. J. Newman, Spread of epidemic disease on networks, Phys. Rev. E 66, 016128 (2002).
  6. C. Moore and M. E. J. Newman, Epidemics and percolation in small-world networks, Phys. Rev. E 61, 5678 (2000).
  7. O. Diekmann, M. C. M. De Jong, and J. A. J. Metz, A deterministic epidemic model taking account of repeated contacts between the same individuals, J. Appl. Probab. 35, 448 (1998).
  8. R. Pastor-Satorras and A. Vespignani, Epidemic spreading in scale-free networks, Phys. Rev. Lett. 86, 3200 (2001).
  9. T. E. Harris, Contact interactions on a lattice, Ann. Probab. 2, 969 (1974).
  10. G. H. Weiss and M. Dishon, On the asymptotic behavior of the stochastic and deterministic models of an epidemic, Math. Biosci. 11, 261 (1971).
  11. Y. Wang, D. Chakrabarti, C. Wang, and C. Faloutsos, Epidemic spreading in real networks: An eigenvalue viewpoint, in Proceedings of the 22nd International Symposium on Reliable Distributed Systems, 2003, Florence , Italy (IEEE, Piscataway, NJ, 2003), pp. 25–34.
  12. D. Chakrabarti, Y. Wang, C. Wang, J. Leskovec, and C. Faloutsos, Epidemic thresholds in real networks, ACM Trans. Inf. Syst. Secur. 10, 1 (2008).
  13. P. Van Mieghem, J. Omic, and R. Kooij, Virus spread in networks, IEEE/ACM Trans. Networking 17, 1 (2009).
  14. P. Van Mieghem, The N-intertwined SIS epidemic network model, Computing 93, 147 (2011).
  15. M. J. Keeling, The effects of local spatial structure on epidemiological invasions, Proc. R. Soc. London, Ser. B 266, 859 (1999).
  16. A. S. Mata and S. C. Ferreira, Pair quenched mean-field theory for the susceptible-infected-susceptible model on complex networks, Europhys. Lett. 103, 48003 (2013).
  17. M. Shrestha, S. V. Scarpino, and C. Moore, Message-passing approach for recurrent-state epidemic models on networks, Phys. Rev. E 92, 022821 (2015).
  18. E. Cator and P. Van Mieghem, Second-order mean-field susceptible-infected-susceptible epidemic threshold, Phys. Rev. E 85, 056111 (2012).
  19. J. P. Gleeson, High-accuracy approximation of binary-state dynamics on networks, Phys. Rev. Lett. 107, 068701 (2011).
  20. B. Karrer and M. E. J. Newman, Message passing approach for general epidemic models, Phys. Rev. E 82, 016101 (2010).
  21. B. Karrer, M. E. J. Newman, and L. Zdeborová, Percolation on sparse networks, Phys. Rev. Lett. 113, 208702 (2014).
  22. R. S. Ferreira and S. C. Ferreira, Critical behavior of the contact process on small-world networks, Eur. Phys. J. B 86, 462 (2013).
  23. J. P. Gleeson, Binary-state dynamics on complex networks: Pair approximation and beyond, Phys. Rev. X 3, 021004 (2013).
  24. P. Zhang, Inference of kinetic Ising model on sparse graphs, J. Stat. Phys. 148, 502 (2012).
  25. A. Y. Lokhov, M. Mézard, and L. Zdeborová, Dynamic message-passing equations for models with unidirectional dynamics, Phys. Rev. E 91, 012811 (2015).
  26. E. Domínguez, D. Machado, and R. Mulet, The cavity master equation: Average and fixed point of the ferromagnetic model in random graphs, J. Stat. Mech. (2020) 073304.
  27. E. Aurell, D. Machado Perez, and R. Mulet, A closure for the master equation starting from the dynamic cavity method, J. Phys. A: Math. Theor. 56, 17LT02 (2023).
  28. F. Behrens, B. Hudcová, and L. Zdeborová, Backtracking dynamical cavity method, Phys. Rev. X 13, 031021 (2023).
  29. E. Ortega, D. Machado, and A. Lage-Castellanos, Dynamics of epidemics from cavity master equations: Susceptible-infectious-susceptible models, Phys. Rev. E 105, 024308 (2022).
  30. F. Krzakala, C. Moore, E. Mossel, J. Neeman, A. Sly, L. Zdeborová, and P. Zhang, Spectral redemption in clustering sparse networks, Proc. Natl. Acad. Sci. USA 110, 20935 (2013).
  31. J. R. Norris, Markov Chains, Cambridge Series in Statistical and Probabilistic Mathematics (Cambridge University Press, 1997).
  32. This construction is essentially opposite to the so-called linear chain trick [35]. Because real-world recovery times are not well modeled by an exponential distribution, more accurate epidemic models can be constructed by incorporating extra states, so that the total time it takes to recover is, e.g., Gamma-distributed. Thus the linear chain trick deliberately changes the behavior of the model, whereas our additional states are constructed so that they make no change to the model whatsoever.
  33. M. Morris and R. Rothenberg, HIV transmission network metastudy project: An archive of data from eight network studies (1988–2001) 1: Version 1 (2011).
  34. L. Šubelj and M. Bajec, Robust network community detection using balanced propagation, Eur. Phys. J. B 81, 353 (2011).
  35. N. MacDonald, Time Lags in Biological Models, Lecture Notes in Biomathematics (Springer, Berlin, 1978).
  36. G. Cantwell, SISK: Pair-approximation for the SISK model, GitHub repository, 2025, https://github.com/gcant/SISK.
