Casimir effect in magnetic dual chiral density waves

Daisuke Fujii1,2,*, Katsumasa Nakayama3,†, and Kei Suzuki1,‡

  • *Contact author: daisuke@rcnp.osaka-u.ac.jp
  • †Contact author: katsumasa.nakayama@riken.jp
  • ‡Contact author: k.suzuki.2010@th.phys.titech.ac.jp
PDF

Phys. Rev. D 112, 034020 – Published 20 August, 2025

DOI: https://doi.org/10.1103/z59j-86kj

Abstract

We theoretically investigate the Casimir effect originating from Dirac fields in finite-density matter under a magnetic field. In particular, we focus on quark fields in the magnetic dual chiral density wave phase as a possible inhomogeneous ground state of interacting Dirac-fermion systems. In this system, the distance dependence of Casimir energy shows a complex oscillatory behavior by the interplay between the chemical potential, magnetic field, and inhomogeneous ground state. By decomposing the total Casimir energy into contributions of each Landau level, we elucidate what types of Casimir effects are realized from each Landau level: The lowest or some types of higher Landau levels lead to different behaviors of Casimir energies. Furthermore, we point out characteristic behaviors due to level splitting between different fermion flavors, i.e., up and down quarks. These findings provide new insights into Dirac-fermion (or quark) matter with a finite thickness.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (103)

  1. H. B. G. Casimir, On the attraction between two perfectly conducting plates, Proc. Kon. Ned. Akad. Wetensch. 51, 793 (1948).
  2. S. K. Lamoreaux, Demonstration of the Casimir force in the 0.6 to 6  μm range, Phys. Rev. Lett. 78, 5 (1997); 81, 5475(E) (1998).
  3. G. Bressi, G. Carugno, R. Onofrio, and G. Ruoso, Measurement of the Casimir force between parallel metallic surfaces, Phys. Rev. Lett. 88, 041804 (2002).
  4. G. Plunien, B. Müller, and W. Greiner, The Casimir effect, Phys. Rep. 134, 87 (1986).
  5. V. M. Mostepanenko and N. N. Trunov, The Casimir effect and its applications, Sov. Phys. Usp. 31, 965 (1988).
  6. M. Bordag, U. Mohideen, and V. M. Mostepanenko, New developments in the Casimir effect, Phys. Rep. 353, 1 (2001).
  7. K. A. Milton, The Casimir Effect: Physical Manifestations of Zero-Point Energy (World Scientific, Singapore, 2001).
  8. G. L. Klimchitskaya, U. Mohideen, and V. M. Mostepanenko, The Casimir force between real materials: Experiment and theory, Rev. Mod. Phys. 81, 1827 (2009).
  9. L. M. Woods, D. A. R. Dalvit, A. Tkatchenko, P. Rodriguez-Lopez, A. W. Rodriguez, and R. Podgornik, Materials perspective on Casimir and van der Waals interactions, Rev. Mod. Phys. 88, 045003 (2016).
  10. T. Gong, M. R. Corrado, A. R. Mahbub, C. Shelden, and J. N. Munday, Recent progress in engineering the Casimir effect—Applications to nanophotonics, nanomechanics, and chemistry, Nanophotonics 10, 523 (2021).
  11. B.-S. Lu, The Casimir effect in topological matter, Universe 7, 237 (2021).
  12. K. Johnson, The M.I.T. bag model, Acta Phys. Pol. B 6, 865 (1975).
  13. S. G. Mamaev and N. N. Trunov, Vacuum expectation values of the energy-momentum tensor of quantized fields on manifolds with different topologies and geometries. III, Sov. Phys. J. 23, 551 (1980).
  14. I. E. Dzyaloshinskii, E. M. Lifshitz, and L. P. Pitaevskii, The general theory of van der Waals forces, Adv. Phys. 10, 165 (1961).
  15. D. Robaschik, K. Scharnhorst, and E. Wieczorek, Radiative corrections to the Casimir pressure under the influence of temperature and external fields, Ann. Phys. (N.Y.) 174, 401 (1987).
  16. M. V. Cougo-Pinto, C. Farina, and A. C. Tort, Fermionic Casimir effect in an external magnetic field, Conf. Proc. C 9809142, 235 (1999).
  17. M. V. Cougo-Pinto, C. Farina, and A. C. Tort, The influence of an external magnetic field on the fermionic Casimir effect, Braz. J. Phys. 31, 84 (2001).
  18. E. Elizalde, F. C. Santos, and A. C. Tort, Confined quantum fields under the influence of a uniform magnetic field, J. Phys. A 35, 7403 (2002).
  19. M. Ostrowski, Casimir effect in external magnetic field, Acta Phys. Pol. B 37, 1753 (2006).
  20. M. S. R. Miltao and F. A. Farias, The Casimir energy of Dirac field under a general boundary condition using the zeta function method, Acta Phys. Pol. B 39, 1931 (2008).
  21. Y. A. Sitenko, Casimir effect with quantized charged spinor matter in background magnetic field, Phys. Rev. D 91, 085012 (2015).
  22. Y. A. Sitenko, Influence of quantized massive matter fields on the Casimir effect, Mod. Phys. Lett. A 30, 1550099 (2015).
  23. Y. A. Sitenko and S. A. Yushchenko, Pressure from the vacuum of confined spinor matter, Int. J. Mod. Phys. A 30, 1550184 (2015).
  24. K. Nakayama and K. Suzuki, Dirac/Weyl-node-induced oscillating Casimir effect, Phys. Lett. B 843, 138017 (2023).
  25. A. Rohim, A. Romadani, and A. Salim Adam, Casimir effect of Lorentz-violating charged Dirac field in background magnetic field, Prog. Theor. Exp. Phys. 2024, 033B01 (2024).
  26. A. Erdas, Magnetic corrections to the fermionic Casimir effect in Horava-Lifshitz theories, Int. J. Mod. Phys. A 38, 2350117 (2023).
  27. A. Flachi, M. Nitta, S. Takada, and R. Yoshii, Fermion Casimir effect and magnetic Larkin-Ovchinnikov phases, Phys. Rev. D 111, 016003 (2025).
  28. M. V. Cougo-Pinto, C. Farina, M. R. Negrao, and A. C. Tort, Bosonic Casimir effect in an external magnetic field, J. Phys. A 32, 4457 (1999).
  29. M. V. Cougo-Pinto, C. Farina, M. R. Negrao, and A. C. Tort, Magnetic permeability of constrained scalar QED vacuum, Phys. Lett. B 483, 144 (2000).
  30. M. V. Cougo-Pinto, C. Farina, M. R. Negrao, and A. Tort, Casimir effect at finite temperature of charged scalar field in an external magnetic field, arXiv:hep-th/9810033.
  31. M. V. Cougo-Pinto, C. Farina, and M. R. Negrao, Magnetic properties of confined bosonic vacuum at finite temperature, arXiv:hep-th/9811095.
  32. A. Erdas and K. P. Seltzer, Finite temperature Casimir effect for charged massless scalars in a magnetic field, Phys. Rev. D 88, 105007 (2013).
  33. A. Erdas and K. P. Seltzer, Finite temperature Casimir effect for massive scalars in a magnetic field, Int. J. Mod. Phys. A 29, 1450091 (2014).
  34. Y. A. Sitenko and S. A. Yushchenko, The Casimir effect with quantized charged scalar matter in background magnetic field, Int. J. Mod. Phys. A 29, 1450052 (2014).
  35. A. Erdas, Magnetic field corrections to the repulsive Casimir effect at finite temperature, Int. J. Mod. Phys. A 31, 07 (2016).
  36. A. Erdas, Casimir effect of a Lorentz-violating scalar in magnetic field, Int. J. Mod. Phys. A 35, 2050209 (2020).
  37. S. R. Haridev and P. Samantray, Revisiting vacuum energy in compact spacetimes, Phys. Lett. B 835, 137489 (2022).
  38. A. Erdas, Thermal effects on the Casimir energy of a Lorentz-violating scalar in magnetic field, Int. J. Mod. Phys. A 36, 2150155 (2021).
  39. A. Erdas, Casimir effect of a doubly Lorentz-violating scalar in magnetic field, Int. J. Mod. Phys. A 39, 2450141 (2024).
  40. D. Fujii, K. Nakayama, and K. Suzuki, Dual chiral density wave induced oscillating Casimir effect, Phys. Rev. D 110, 014039 (2024).
  41. F. Dautry and E. M. Nyman, Pion condensation and the σ-model in liquid neutron matter, Nucl. Phys. A319, 323 (1979).
  42. T. Tatsumi and E. Nakano, Dual chiral density wave in quark matter, arXiv:hep-ph/0408294.
  43. E. Nakano and T. Tatsumi, Chiral symmetry and density waves in quark matter, Phys. Rev. D 71, 114006 (2005).
  44. I. E. Frolov, V. C. Zhukovsky, and K. G. Klimenko, Chiral density waves in quark matter within the Nambu–Jona-Lasinio model in an external magnetic field, Phys. Rev. D 82, 076002 (2010).
  45. T. Tatsumi, K. Nishiyama, and S. Karasawa, Novel Lifshitz point for chiral transition in the magnetic field, Phys. Lett. B 743, 66 (2015).
  46. K. Nishiyama, S. Karasawa, and T. Tatsumi, Hybrid chiral condensate in the external magnetic field, Phys. Rev. D 92, 036008 (2015).
  47. S. Carignano, E. J. Ferrer, V. de la Incera, and L. Paulucci, Crystalline chiral condensates as a component of compact stars, Phys. Rev. D 92, 105018 (2015).
  48. E. J. Ferrer and V. de la Incera, Novel topological effects in dense QCD in a magnetic field, Nucl. Phys. B931, 192 (2018).
  49. E. J. Ferrer and V. de la Incera, Dissipationless Hall current in dense quark matter in a magnetic field, Phys. Lett. B 769, 208 (2017).
  50. H. Abuki, Chiral crystallization in an external magnetic background: Chiral spiral versus real kink crystal, Phys. Rev. D 98, 054006 (2018).
  51. E. J. Ferrer and V. de la Incera, Absence of Landau-Peierls instability in the magnetic dual chiral density wave phase of dense QCD, Phys. Rev. D 102, 014010 (2020).
  52. B. Feng, E. J. Ferrer, and I. Portillo, Lack of Debye and Meissner screening in strongly magnetized quark matter at intermediate densities, Phys. Rev. D 101, 056012 (2020).
  53. E. J. Ferrer and V. de la Incera, Axion-polaritons in the magnetic dual chiral density wave phase of dense QCD, Nucl. Phys. B994, 116307 (2023).
  54. E. J. Ferrer, V. de la Incera, and P. Sanson, Quark matter contribution to the heat capacity of magnetized neutron stars, Phys. Rev. D 103, 123013 (2021).
  55. F. Anzuini and A. Melatos, Gradient expansion technique for inhomogeneous, magnetized quark matter, Eur. Phys. J. A 57, 220 (2021).
  56. W. Gyory and V. de la Incera, Phase transitions and resilience of the magnetic dual chiral density wave phase at finite temperature and density, Phys. Rev. D 106, 016011 (2022).
  57. E. J. Ferrer and A. Hackebill, Speed of sound for hadronic and quark phases in a magnetic field, Nucl. Phys. A1031, 122608 (2023).
  58. H. M. Ghalati and N. Sadooghi, Magnetic dual chiral density wave phase in rotating cold quark matter, Phys. Rev. D 108, 054032 (2023).
  59. E. J. Ferrer, W. Gyory, and V. de la Incera, Thermal phonon fluctuations and stability of the magnetic dual chiral density wave phase in dense QCD, Phys. Rev. D 109, 036023 (2024).
  60. E. J. Ferrer and V. de la Incera, Axion-polaritons in quark stars: A possible solution to the missing pulsar problem, Eur. Phys. J. C 84, 133 (2024).
  61. E. J. Ferrer and V. de la Incera, Magnetic dual chiral density wave: A candidate quark matter phase for the interior of neutron stars, Universe 7, 458 (2021).
  62. Y. Nambu and G. Jona-Lasinio, Dynamical model of elementary particles based on an analogy with superconductivity. I, Phys. Rev. 122, 345 (1961).
  63. Y. Nambu and G. Jona-Lasinio, Dynamical model of elementary particles based on an analogy with superconductivity. II, Phys. Rev. 124, 246 (1961).
  64. U. Vogl and W. Weise, The Nambu and Jona-Lasinio model: Its implications for hadrons and nuclei, Prog. Part. Nucl. Phys. 27, 195 (1991).
  65. S. P. Klevansky, The Nambu–Jona-Lasinio model of quantum chromodynamics, Rev. Mod. Phys. 64, 649 (1992).
  66. T. Hatsuda and T. Kunihiro, QCD phenomenology based on a chiral effective Lagrangian, Phys. Rep. 247, 221 (1994).
  67. M. Buballa, NJL-model analysis of dense quark matter, Phys. Rep. 407, 205 (2005).
  68. E. J. Ferrer, V. P. Gusynin, and V. de la Incera, Boundary effects in the magnetic catalysis of chiral symmetry breaking, Phys. Lett. B 455, 217 (1999).
  69. L. M. Abreu, E. B. S. Corrêa, C. A. Linhares, and A. P. C. Malbouisson, Finite-volume and magnetic effects on the phase structure of the three-flavor Nambu–Jona-Lasinio model, Phys. Rev. D 99, 076001 (2019).
  70. L. M. Abreu, E. S. Nery, and E. B. S. Corrêa, Boundary effects on constituent quark masses and on chiral susceptibility in a four-fermion interaction model, Physica (Amsterdam) 572A, 125885 (2021).
  71. L. M. Abreu, E. B. S. Corrêa, and E. S. Nery, Properties of neutral mesons in a hot and magnetized quark matter: Size-dependent effects, Phys. Rev. D 105, 056010 (2022).
  72. L. M. Abreu, E. B. S. Corrêa, and E. S. Nery, Inverse magnetic catalysis and size-dependent effects on the chiral symmetry restoration, Eur. Phys. J. A 59, 157 (2023).
  73. E. B. S. Corrêa, Phase transition in a four-fermion interaction model under boundary conditions and electromagnetic effects, Phys. Rev. D 108, 076002 (2023).
  74. D. Ebert and K. G. Klimenko, Cooper pairing and finite-size effects in a Nambu–Jona-Lasinio-type four-fermion model, Phys. Rev. D 82, 025018 (2010).
  75. E. M. Lifshitz, The theory of molecular attractive forces between solids, Sov. Phys. JETP 2, 73 (1956).
  76. D. Fujii, K. Nakayama, and K. Suzuki, Lifshitz formulas for finite-density Casimir effect, Phys. Lett. B 868, 139758 (2025).
  77. A. Actor, I. Bender, and J. Reingruber, Casimir effect on a finite lattice, Fortschr. Phys. 48, 303 (2000).
  78. M. Pawellek, Finite-sites corrections to the Casimir energy on a periodic lattice, arXiv:1303.4708.
  79. T. Ishikawa, K. Nakayama, and K. Suzuki, Casimir effect for lattice fermions, Phys. Lett. B 809, 135713 (2020).
  80. T. Ishikawa, K. Nakayama, and K. Suzuki, Lattice-fermionic Casimir effect and topological insulators, Phys. Rev. Res. 3, 023201 (2021).
  81. K. Nakayama and K. Suzuki, Remnants of the nonrelativistic Casimir effect on the lattice, Phys. Rev. Res. 5, L022054 (2023).
  82. K. Nakata and K. Suzuki, Magnonic Casimir effect in ferrimagnets, Phys. Rev. Lett. 130, 096702 (2023).
  83. Y. V. Mandlecha and R. V. Gavai, Lattice fermionic Casimir effect in a slab bag and universality, Phys. Lett. B 835, 137558 (2022).
  84. B. Swingle and M. Van Raamsdonk, Enhanced negative energy with a massless Dirac field, J. High Energy Phys. 08 (2023) 183.
  85. K. Nakata and K. Suzuki, Non-Hermitian Casimir effect of magnons, npj Spintronics 2, 11 (2024).
  86. E. Flores, C. Ireland, N. Jamhour, V. Lasasso, N. Kurth, and M. Leinbach, Casimir force in discrete scalar fields I: 1D and 2D cases, arXiv:2309.00624.
  87. K. Nakayama and K. Suzuki, Casimir effect in axion electrodynamics with lattice regularizations, Phys. Rev. D 109, 065002 (2024).
  88. C. W. J. Beenakker, Topologically protected Casimir effect for lattice fermions, Phys. Rev. Res. 6, 023058 (2024).
  89. K. Fukushima, S. Imaki, and Z. Qiu, Anomalous Casimir effect in axion electrodynamics, Phys. Rev. D 100, 045013 (2019).
  90. I. Brevik, Axion electrodynamics and the axionic Casimir effect, Universe 7, 133 (2021).
  91. F. Canfora, D. Dudal, T. Oosthuyse, P. Pais, and L. Rosa, The Casimir effect in chiral media using path integral techniques, J. High Energy Phys. 09 (2022) 095.
  92. T. Oosthuyse and D. Dudal, Interplay between chiral media and perfect electromagnetic conductor plates: Repulsive vs. attractive Casimir force transitions, SciPost Phys. 15, 213 (2023).
  93. A. M. Favitta, I. H. Brevik, and M. M. Chaichian, Axion electrodynamics: Green’s functions, zero-point energy and optical activity, Ann. Phys. (Amsterdam) 455, 169396 (2023).
  94. Y. Ema, M. Hazumi, H. Iizuka, K. Mukaida, and K. Nakayama, Zero Casimir force in axion electrodynamics and the search for a new force, Phys. Rev. D 108, 016009 (2023).
  95. M. N. Chernodub, V. A. Goy, A. V. Molochkov, and H. H. Nguyen, Casimir effect in Yang-Mills theory in D=2+1, Phys. Rev. Lett. 121, 191601 (2018).
  96. M. N. Chernodub, V. A. Goy, and A. V. Molochkov, Phase structure of lattice Yang-Mills theory on T2×R2, Phys. Rev. D 99, 074021 (2019).
  97. M. Kitazawa, S. Mogliacci, I. Kolbé, and W. A. Horowitz, Anisotropic pressure induced by finite-size effects in SU(3) Yang-Mills theory, Phys. Rev. D 99, 094507 (2019).
  98. M. N. Chernodub, V. A. Goy, A. V. Molochkov, and A. S. Tanashkin, Boundary states and non-Abelian Casimir effect in lattice Yang-Mills theory, Phys. Rev. D 108, 014515 (2023).
  99. G. Cao and A. Huang, Solitonic modulation and Lifshitz point in an external magnetic field within Nambu–Jona-Lasinio model, Phys. Rev. D 93, 076007 (2016).
  100. D. T. Son and M. A. Stephanov, Axial anomaly and magnetism of nuclear and quark matter, Phys. Rev. D 77, 014021 (2008).
  101. T. Brauner and N. Yamamoto, Chiral soliton lattice and charged pion condensation in strong magnetic fields, J. High Energy Phys. 04 (2017) 132.
  102. N. P. Armitage, E. J. Mele, and A. Vishwanath, Weyl and Dirac semimetals in three dimensional solids, Rev. Mod. Phys. 90, 015001 (2018).
  103. B. Q. Lv, T. Qian, and H. Ding, Experimental perspective on three-dimensional topological semimetals, Rev. Mod. Phys. 93, 025002 (2021).
