Topology-agnostic, hierarchical graph network for event reconstruction

Nathalie Soybelman*, Nilotpal Kakati, and Eilam Gross

Francesco A. Di Bello†

  • *Contact author: nathalie.soybelman@weizmann.ac.il
  • †Present address: University of Pisa, Italy.
PDF

Phys. Rev. D 113, 012014 – Published 26 January, 2026

DOI: https://doi.org/10.1103/z57h-y3rx

Abstract

Event reconstruction at the LHC, the task of assigning observed physics objects to their true origins, is a central challenge for precision measurements and searches. Many existing machine learning approaches address this problem but rely on a single event topology, restricting their applicability to realistic analyses where multiple signal and background processes with different structures are present. To overcome this, we present TIGER, a novel hierarchical graph network that is fundamentally topology agnostic. By incorporating only the common underlying structure of sequential two-body decays, our model can reconstruct complex events without process-specific assumptions. This flexible architecture supports multitask learning, enabling simultaneous event reconstruction and classification. TIGER thus provides a powerful and generalizable tool for physics analysis at the LHC.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (38)

  1. L. Evans and P. Bryant, LHC machine, J. Instrum. 3, S08001 (2008).
  2. F. A. Di Bello, E. Dreyer, S. Ganguly, E. Gross, L. Heinrich, A. Ivina, M. Kado, N. Kakati, L. Santi, J. Shlomi, and M. Tusoni, Reconstructing particles in jets using set transformer and hypergraph prediction networks, Eur. Phys. J. C 83, 596 (2023).
  3. N. Kakati, E. Dreyer, A. Ivina, F. A. Di Bello, L. Heinrich, M. Kado, and E. Gross, HGPflow: Extending hypergraph particle flow to collider event reconstruction, Eur. Phys. J. C 85, 847 (2025).
  4. J. Pata, J. Duarte, F. Mokhtar, E. Wulff, J. Yoo, J.-R. Vlimant, M. Pierini, and M. Girone, Machine learning for particle flow reconstruction at cms, J. Phys. Conf. Ser. 2438, 012100 (2023).
  5. L. Ehrke, J. A. Raine, K. Zoch, M. Guth, and T. Golling, Topological reconstruction of particle physics processes using graph neural networks, Phys. Rev. D 107, 116019 (2023).
  6. M. J. Fenton, A. Shmakov, T.-W. Ho, S.-C. Hsu, D. Whiteson, and P. Baldi, Permutationless many-jet event reconstruction with symmetry preserving attention networks, Phys. Rev. D 105, 112008 (2022).
  7. A. Shmakov, M. J. Fenton, T.-W. Ho, S.-C. Hsu, D. Whiteson, and P. Baldi, Spanet: Generalized permutationless set assignment for particle physics using symmetry preserving attention, SciPost Phys. 12, 178 (2022).
  8. ATLAS Collaboration, Top-quark mass measurement in the all-hadronic tt¯ decay channel at s=8 TeV with the ATLAS detector, J. High Energy Phys. 09 (2017) 118.
  9. ATLAS Collaboration, Measurements of top-quark pair single- and double-differential cross-sections in the all-hadronic channel in pp collisions at s=13 TeV using the ATLAS detector, J. High Energy Phys. 01 (2021) 033.
  10. J. Erdmann, S. Guindon, K. Kroeninger, B. Lemmer, O. Nackenhorst, A. Quadt, and P. Stolte, A likelihood-based reconstruction algorithm for top-quark pairs and the KLFitter framework, Nucl. Instrum. Methods Phys. Res., Sect. A 748, 18 (2014).
  11. C. Birch-Sykes, B. Le, Y. Peters, E. Simpson, and Z. Zhang, Reconstructing short-lived particles using hypergraph representation learning, Phys. Rev. D 111, 032004 (2025).
  12. M. J. Fenton, A. Shmakov, H. Okawa, Y. Li, K.-Y. Hsiao, S.-C. Hsu, D. Whiteson, and P. Baldi, Reconstruction of unstable heavy particles using deep symmetry-preserving attention networks, Commun. Phys. 7, 139 (2024).
  13. H. Li, M. Stamenkovic, A. Shmakov, M. Fenton, D. S.-C. Chao, K. M. White, C. Mikkelsen, J. Mitic, C. M. Suarez, M. Quinnan, G. Landsberg, H. Newman, P. Baldi, D. Whiteson, and J. Duarte, Reconstruction of boosted and resolved multi-higgs-boson events with symmetry-preserving attention networks, J. High Energy Phys. 11 (2025) 119.
  14. B. M. Dillon and M. Spannowsky, Theory-informed neural networks for particle physics, arXiv:2507.13447.
  15. Z. Zhang, C. Birch-Sykes, B. Le, Y. Peters, and E. Simpson, Top quark pair production with fully hadronic final states at the LHC, 10.5281/zenodo.10653837 (2024).
  16. J. Alwall, M. Herquet, F. Maltoni, O. Mattelaer, and T. Stelzer, madgraph 5: Going beyond, J. High Energy Phys. 06 (2011) 128.
  17. T. Sjöstrand, S. Mrenna, and P. Skands, A brief introduction to pythia 8.1, Comput. Phys. Commun. 178, 852 (2008).
  18. J. de Favereau, C. Delaere, P. Demin, A. Giammanco, V. Lemaître, A. Mertens, and M. Selvaggi (DELPHES 3 Collaboration), delphes 3, A modular framework for fast simulation of a generic collider experiment, J. High Energy Phys. 02 (2014) 057.
  19. M. Cacciari, G. P. Salam, and G. Soyez, The anti-ktjet clustering algorithm, J. High Energy Phys. 04 (2008) 063.

  20. https://mlphysics.ics.uci.edu/data/2023_spanet/

  21. S. Mondal and L. Mastrolorenzo, Machine learning in high energy physics: A review of heavy-flavor jet tagging at the LHC, Eur. Phys. J. Special Topics 233, 2657 (2024).
  22. G. Aad et al. (ATLAS Collaboration), Transforming jet flavour tagging at ATLAS, arXiv:2505.19689.
  23. J. Brehmer, V. Bresó, P. de Haan, T. Plehn, H. Qu, J. Spinner, and J. Thaler, A lorentz-equivariant transformer for all of the LHC, SciPost Phys. 19, 108 (2025).
  24. J. Ho, B. R. Roberts, S. Han, and H. Wang, Pretrained event classification model for high energy physics analysis, arXiv:2412.10665.
  25. J. Y. Araz, D. Athanasakos, M. Ploskon, and F. Ringer, Graph theory inspired anomaly detection at the LHC, arXiv:2506.19920.
  26. P. Calafiura, J. Chan, L. Delabrouille, and B. Wang, EggNet: An evolving graph-based graph attention network for particle track reconstruction, arXiv:2407.13925.
  27. D. Murnane, S. Thais, and A. Thete, Equivariant graph neural networks for charged particle tracking, in 21th International Workshop on Advanced Computing and Analysis Techniques in Physics Research: AI meets Reality (2023), arXiv:2304.05293.
  28. R. Liu, P. Calafiura, S. Farrell, X. Ju, D. T. Murnane, and T. M. Pham, Hierarchical graph neural networks for particle track reconstruction, arXiv:2303.01640.
  29. R. Miller, A. Shmakov, K. Oh, J. Lee, P. Baldi, L. Condren, M. Vessella, and D. Whiteson, Fast and precise track fitting with machine learning, arXiv:2505.02937.
  30. L. Heinrich, B. Huth, A. Salzburger, and T. Wettig, Combined track finding with GNN & CKF, in 8th International Connecting the Dots Workshop (CTD 2023) (2024), arXiv:2401.16016.
  31. D. Kobylianskii, N. Soybelman, E. Dreyer, and E. Gross, Graph-based diffusion model for fast shower generation in calorimeters with irregular geometry, Phys. Rev. D 110, 072003 (2024).
  32. W. S. Peebles and S. Xie, Scalable diffusion models with transformers, in 2023 IEEE/CVF International Conference on Computer Vision (ICCV), (IEEE International Conference on Computer Vision, 2022) p. 4172.
  33. Z. Zhang, J. Bu, M. Ester, J. Zhang, C. Yao, Z. Yu, and C. Wang, Hierarchical graph pooling with structure learning, arXiv:1911.05954.
  34. Z. Ying, J. You, C. Morris, X. Ren, W. Hamilton, and J. Leskovec, Hierarchical graph representation learning with differentiable pooling, in Advances in Neural Information Processing Systems, edited by S. Bengio, H. Wallach, H. Larochelle, K. Grauman, N. Cesa-Bianchi, and R. Garnett (Curran Associates, Inc., 2018), Vol. 31.
  35. Search for Higgs boson decay to a charm quark-antiquark pair via ttH production, Technical Report No. CMS-PAS-HIG-24-018, CERN, Geneva, 2025, https://cds.cern.ch/record/2929444.
  36. ATLAS Collaboration, Measurements of WH and ZH production with higgs boson decays into bottom quarks and direct constraints on the charm Yukawa coupling in 13 TeV pp collisions with the ATLAS detector, J. High Energy Phys. 04 (2025) 075.
  37. ATLAS Collaboration, Combination of searches for Higgs boson pair production in pp collisions at s=13 TeV with the ATLAS detector, Phys. Rev. Lett. 133, 101801 (2024).
  38. https://github.com/nathaliesoy/tiger.
