Generalized parton distributions from symbolic regression

Andrew Dotson1,*, Zaki Panjsheeri2,†, Anusha Reddy Singireddy3, Douglas Q. Adams2, Marija Čuić2, Emmanuel Ortiz-Pacheco4, Saraswati Pandey2, Marie Boër5, Gia-Wei Chern2 et al. (EXCLAIM Collaboration)

Gia-Wei Chern2, Michael Engelhardt1, Gary R. Goldstein6, Yaohang Li3, Huey-Wen Lin4, Simonetta Liuti2,‡, and Matthew D. Sievert1 (EXCLAIM Collaboration)

  • *Contact author: adots004@nmsu.edu
  • †Contact author: zap2nd@virginia.edu
  • ‡Contact author: sl4y@virginia.edu
PDF

Phys. Rev. D 114, 054054 – Published 29 September, 2026

DOI: https://doi.org/10.1103/ynm6-znr4

Abstract

Artificial intelligence/machine learning–informed symbolic regression is the next stage of scientific modeling. We utilize a highly customizable symbolic regression package “PySR” (python symbolic regression) to model the x and t dependence of the flavor isovector combination Hu−d(x,t,ξ) at ξ=0. These PySR models were trained on generalized parton distribution (GPD) results provided by both lattice QCD and phenomenological sources Goldstein Gonzalez Liuti, Goloskokov Kroll, and Vanderhaeghen Guichon Guidal. We demonstrate, for the first time, the consistency and systematic convergence of symbolic regression by quantifying the disparate models through their Taylor expansion coefficients. In addition to PySR penalizing models with higher complexity and mean-squared error, we implement schemes that test specific physics hypotheses, including force-factorized x and t dependence and Regge behavior in PySR GPDs. We show that PySR can identify factorizing GPD sources based on their response to the force-factorized model. Knowing the precise behavior of the GPDs, and their uncertainties in a wide range in x and t, crucially impacts our ability to concretely and quantitatively predict hadronic spatial distributions and their derived quantities.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (70)

  1. R. A. Khalek et al., arXiv:2103.05419.
  2. M. Diehl, Eur. Phys. J. C 19, 485 (2001).
  3. A. Belitsky and A. Radyushkin, Phys. Rep. 418, 1 (2005).
  4. K. Kumericki, S. Liuti, and H. Moutarde, Eur. Phys. J. A 52, 157 (2016).
  5. L. Biggio, T. Bendinelli, A. Neitz, A. Lucchi, and G. Parascandolo, arXiv:2106.06427.
  6. N. Makke and S. Chawla, Mach. Learn. Sci. Tech. 6, 025003 (2025).
  7. M. Morales-Alvarado, D. Conde, J. Bendavid, V. Sanz, and M. Ubiali, in 38th conference on Neural Information Processing Systems (2024), arXiv:2412.07839.
  8. S. Meissner, A. Metz, and M. Schlegel, J. High Energy Phys. 08 (2009) 056.
  9. J. Collins, Foundations of Perturbative QCD (Cambridge University Press, 2011), Vol. 32, ISBN [Amazon][WorldCat], [Amazon][WorldCat], [Amazon][WorldCat].
  10. J. Collins and T. Rogers, Phys. Rev. D 91, 074020 (2015).
  11. X.-D. Ji and J. Osborne, Phys. Rev. D 57, R1337 (1998).
  12. X.-D. Ji and J. Osborne, Phys. Rev. D 58, 094018 (1998).
  13. X.-D. Ji, Phys. Rev. D 55, 7114 (1997).
  14. M. Diehl, Phys. Rep. 388, 41 (2003).
  15. X.-D. Ji, Phys. Rev. Lett. 78, 610 (1997).
  16. M. Burkardt, Phys. Rev. D 62, 071503 (2000); 66, 119903(E) (2002).
  17. M. Burkardt, Phys. Rev. D 72, 094020 (2005).
  18. A. V. Belitsky, X.-d. Ji, and F. Yuan, Phys. Rev. D 69, 074014 (2004).
  19. S. Liuti and S. K. Taneja, Phys. Rev. D 70, 074019 (2004).
  20. D. Dutta, K. Hafidi, and M. Strikman, Prog. Part. Nucl. Phys. 69, 1 (2013).
  21. P. Jain, B. Pire, and J. P. Ralston, Phys. Rep. 271, 67 (1996).
  22. S. J. Brodsky and G. F. de Teramond, MDPI Phys. 4, 633 (2022).
  23. B. Kriesten, S. Liuti, L. Calero-Diaz, D. Keller, A. Meyer, G. R. Goldstein, and J. Osvaldo Gonzalez-Hernandez, Phys. Rev. D 101, 054021 (2020).
  24. M. Cranmer, arXiv:2305.01582.
  25. https://astroautomata.com/PySR/ (2023), accessed:2024-12-20.
  26. S.-M. Udrescu and M. Tegmark, Sci. Adv. 6, eaay2631 (2020).
  27. R. Dubcakova, Genet. Program. Evolvable Mach. 12, 173 (2011).
  28. N. Makke, SR-LivingReview, https://github.com/nmakke/SR-LivingReview?tab=readme-ov-file, accessed: 2024-12-01.
  29. H.-W. Lin, Phys. Rev. Lett. 127, 182001 (2021).
  30. D. Foreman-Mackey, J. Open Source Softwaare 1, 24 (2016).
  31. W. H. Press, S. A. Teukolsky, W. T. Vetterling, and B. P. Flannery, Numerical Recipes: The Art of Scientific Computing, 3rd ed. (Cambridge University Press, Cambridge, 2007).
  32. Scikit-learn clustering examples, https://scikit-learn.org/1.5/modules/clustering.html, accessed: 2024-12-01.
  33. S. Lloyd, IEEE Trans. Inf. Theory 28, 129 (1982).
  34. F. Pedregosa, G. Varoquaux, A. Gramfort, V. Michel, B. Thirion, O. Grisel, M. Blondel, P. Prettenhofer, R. Weiss, V. Dubourg et al., J. Mach. Learn. Res. 12, 2825 (2011).
  35. V. Satopaa, J. Albrecht, D. Irwin, and B. Raghavan, in 2011 31st International Conference on Distributed Computing Systems Workshops (IEEE Computer Society, Los Alamitos, CA, USA, 2011), pp. 166–171.
  36. kneed 0.8.5, https://pypi.org/project/kneed/, accessed: 2025-03-01.
  37. E. Follana, Q. Mason, C. Davies, K. Hornbostel, G. P. Lepage, J. Shigemitsu, H. Trottier, and K. Wong, Phys. Rev. D 75, 054502 (2007).
  38. A. Bazavov, C. Bernard, J. Komijani, C. DeTar, L. Levkova, W. Freeman, S. Gottlieb, R. Zhou, U. M. Heller, J. E. Hetrick et al. (MILC Collaboration), Phys. Rev. D 87, 054505 (2013).
  39. X. Ji, Y.-S. Liu, Y. Liu, J.-H. Zhang, and Y. Zhao, Rev. Mod. Phys. 93, 035005 (2021).
  40. H.-W. Lin, J.-W. Chen, X. Ji, L. Jin, R. Li, Y.-S. Liu, Y.-B. Yang, J.-H. Zhang, and Y. Zhao, Phys. Rev. Lett. 121, 242003 (2018).
  41. G. R. Goldstein, J. O. G. Hernandez, and S. Liuti, Phys. Rev. D 91, 114013 (2015).
  42. B. Kriesten, P. Velie, E. Yeats, F. Y. Lopez, and S. Liuti, Phys. Rev. D 105, 056022 (2022).
  43. S. Goloskokov and P. Kroll, Eur. Phys. J. C 74, 2725 (2014).
  44. M. Vanderhaeghen, P. A. M. Guichon, and M. Guidal, Phys. Rev. Lett. 80, 5064 (1998).
  45. M. Vanderhaeghen, P. A. M. Guichon, and M. Guidal, Phys. Rev. D 60, 094017 (1999).
  46. M. Cranmer, Make PySR look for strictly factorised functions, https://github.com/MilesCranmer/PySR/discussions/465.
  47. T. Regge, Nuovo Cimento 14, 951 (1959).
  48. Y. V. Kovchegov and E. Levin, Quantum Chromodynamics at High Energy (Oxford University Press, Oxford, 2013), Vol. 33, ISBN [Amazon][WorldCat], [Amazon][WorldCat], [Amazon][WorldCat], [Amazon][WorldCat], [Amazon][WorldCat].
  49. S. J. Brodsky and G. R. Farrar, Phys. Rev. Lett. 31, 1153 (1973).
  50. R. D. Ball et al. (NNPDF Collaboration), Eur. Phys. J. C 82, 428 (2022).
  51. G. D. Cates, C. W. de Jager, S. Riordan, and B. Wojtsekhowski, Phys. Rev. Lett. 106, 252003 (2011).
  52. I. A. Qattan and J. Arrington, Phys. Rev. C 86, 065210 (2012).
  53. H.-W. Lin, Phys. Lett. B 824, 136821 (2022).
  54. C. Alexandrou et al., Phys. Rev. D 101, 034519 (2020).
  55. C. Alexandrou, S. Bacchio, M. Constantinou, J. Finkenrath, K. Hadjiyiannakou, K. Jansen, G. Koutsou, and A. Vaquero Aviles-Casco, Phys. Rev. D 100, 014509 (2019).
  56. S. Bhattacharya, K. Cichy, M. Constantinou, X. Gao, A. Metz, J. Miller, S. Mukherjee, P. Petreczky, F. Steffens, and Y. Zhao, Phys. Rev. D 108, 014507 (2023).
  57. P. V. Landshoff, J. C. Polkinghorne, and R. D. Short, Nucl. Phys. B28, 225 (1971).
  58. D. W. Sivers, Annu. Rev. Nucl. Part. Sci. 32, 149 (1982).
  59. M. Vanderhaeghen, P. A. M. Guichon, and M. Guidal, Phys. Rev. D 60, 094017 (1999).
  60. S. V. Goloskokov and P. Kroll, Eur. Phys. J. C 42, 281 (2005).
  61. A. Paszke, S. Gross, F. Massa, A. Lerer, J. Bradbury, G. Chanan, T. Killeen, Z. Lin, N. Gimelshein, L. Antiga et al., arXiv:1912.01703.
  62. K. Kumericki, D. Mueller, and A. Schafer, J. High Energy Phys. 07 (2011) 073.
  63. E. R. Nocera, R. D. Ball, S. Forte, G. Ridolfi, and J. Rojo, Nucl. Phys. B887, 276 (2014).
  64. R. D. Ball et al. (NNPDF Collaboration), J. High Energy Phys. 04 (2015) 040.
  65. H. Moutarde, P. Sznajder, and J. Wagner, Eur. Phys. J. C 79, 614 (2019).
  66. J. Grigsby, B. Kriesten, J. Hoskins, S. Liuti, P. Alonzi, and M. Burkardt, Phys. Rev. D 104, 016001 (2021).
  67. S. Kullback and R. A. Leibler, Ann. Math. Stat. 22, 79 (1951).
  68. scipy.stats. entropy, https://docs.scipy.org/doc/scipy/reference/generated/scipy.stats.entropy.html, accessed: 2025-03-03.
  69. M. Pincus, Oper. Res. 18, 1225 (1970).
  70. S. Kirkpatrick, C. D. Gelatt, and M. P. Vecchi, Science 220, 671 (1983).
