Searching for dark photons from dark-scalar decays at CEPC and FCC-ee

Kingman Cheung1,2,3,*, Fei-Tung Chung1,†, and Zeren Simon Wang4,‡

  • *Contact author: cheung@phys.nthu.edu.tw
  • †Contact author: feitung.chung@gapp.nthu.edu.tw
  • ‡Contact author: wzs@hfut.edu.cn
PDF

Phys. Rev. D 113, 015013 – Published 12 January, 2026

DOI: https://doi.org/10.1103/xs4d-jfrs

Abstract

We investigate the sensitivity of proposed circular electron positron collider (CEPC) and future circular collider in its electron–positron mode (FCC-ee) with a center-of-mass energy of 240 GeV to long-lived dark photons heavier than 2 GeV that are pair produced via the prompt decays of a light scalar mixed with the Standard-Model Higgs boson. We compute the production and decay rates of both the light scalar and the dark photon, and develop two search strategies targeting displaced vertices within the inner tracker of the main detectors. Using Monte Carlo simulations, we evaluate the signal acceptance and projected sensitivity for each strategy. Our results show that, for the scalar-Higgs mixing angle set at 10−2 just below the current upper limit, the proposed searches at CEPC and FCC-ee can probe a dark-photon kinetic-mixing parameter several orders of magnitude below existing bounds, for dark photons lighter than half the dark-scalar mass.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (75)

  1. J. Beacham et al., J. Phys. G 47, 010501 (2020).
  2. P. Agrawal et al., Eur. Phys. J. C 81, 1015 (2021).
  3. C. Antel et al., Eur. Phys. J. C 83, 1122 (2023).
  4. L. B. Okun, Sov. Phys. JETP 56, 502 (1982), http://jetp.ras.ru/cgi-bin/dn/e_056_03_0502.pdf.
  5. P. Galison and A. Manohar, Phys. Lett. 136B, 279 (1984).
  6. B. Holdom, Phys. Lett. 166B, 196 (1986).
  7. C. Boehm and P. Fayet, Nucl. Phys. B683, 219 (2004).
  8. M. Pospelov, Phys. Rev. D 80, 095002 (2009).
  9. D. Curtin, R. Essig, S. Gori, and J. Shelton, J. High Energy Phys. 02 (2015) 157.
  10. D. O’Connell, M. J. Ramsey-Musolf, and M. B. Wise, Phys. Rev. D 75, 037701 (2007).
  11. J. D. Wells, arXiv:0803.1243.
  12. C. Bird, P. Jackson, R. V. Kowalewski, and M. Pospelov, Phys. Rev. Lett. 93, 201803 (2004).
  13. M. Pospelov, A. Ritz, and M. B. Voloshin, Phys. Lett. B 662, 53 (2008).
  14. G. Krnjaic, Phys. Rev. D 94, 073009 (2016).
  15. I. Boiarska, K. Bondarenko, A. Boyarsky, V. Gorkavenko, M. Ovchynnikov, and A. Sokolenko, J. High Energy Phys. 11 (2019) 162.
  16. S. Gopalakrishna, S. Jung, and J. D. Wells, Phys. Rev. D 78, 055002 (2008).
  17. M. Dong et al. (CEPC Study Group), arXiv:1811.10545.
  18. W. Abdallah et al. (CEPC Study Group), Radiat. Detect. Technol. Methods 8, 1 (2024); 9, 184(E) (2025).
  19. S. P. Adhya et al. (CEPC Study Group), arXiv:2510.05260.
  20. X. Ai et al., Chin. Phys. C 49, 123108 (2025).
  21. A. Abada et al. (FCC Collaboration), Eur. Phys. J. Special Topics 228, 261 (2019).
  22. B. Fuks, J. Kriewald, M. Nemevšek, and F. Nesti, J. High Energy Phys. 06 (2025) 254.
  23. M. Ahlers, J. Jaeckel, J. Redondo, and A. Ringwald, Phys. Rev. D 78, 075005 (2008).
  24. B. Batell, M. Pospelov, and A. Ritz, Phys. Rev. D 79, 115008 (2009).
  25. E. Weihs and J. Zurita, J. High Energy Phys. 02 (2012) 041.
  26. H. Davoudiasl, H.-S. Lee, I. Lewis, and W. J. Marciano, Phys. Rev. D 88, 015022 (2013).
  27. D. Curtin et al., Phys. Rev. D 90, 075004 (2014).
  28. A. Falkowski and R. Vega-Morales, J. High Energy Phys. 12 (2014) 037.
  29. N. Bakhet, M. Y. Khlopov, and T. Hussein, arXiv:1507.02594.
  30. E. Izaguirre and D. Stolarski, Phys. Rev. Lett. 121, 221803 (2018).
  31. K. Jodłowski, F. Kling, L. Roszkowski, and S. Trojanowski, Phys. Rev. D 101, 095020 (2020).
  32. T. Araki, K. Asai, H. Otono, T. Shimomura, and Y. Takubo, J. High Energy Phys. 03 (2021) 072; 06 (2021) 87.
  33. A. L. Foguel, G. M. Salla, and R. Z. Funchal, J. High Energy Phys. 12 (2022) 063.
  34. K. Cheung, Y. Kim, Y. Kwon, C. J. Ouseph, A. Soffer, and Z. S. Wang, J. High Energy Phys. 05 (2024) 094.
  35. T. Araki, K. Asai, Y. Nakashima, and T. Shimomura, J. High Energy Phys. 12 (2024) 124.
  36. A. M. Sirunyan et al. (CMS Collaboration), Phys. Rev. Lett. 124, 131802 (2020).
  37. R. Aaij et al. (LHCb Collaboration), Phys. Rev. Lett. 124, 041801 (2020).
  38. J. P. Lees et al. (BABAR Collaboration, Phys. Rev. Lett. 113, 201801 (2014).
  39. V. Khachatryan et al. (CMS Collaboration), J. High Energy Phys. 10 (2015) 144.
  40. A. M. Sirunyan et al. (CMS Collaboration), J. High Energy Phys. 06 (2018) 127; 03 (2019) 128(E).
  41. A. Tumasyan et al. (CMS Collaboration), J. High Energy Phys. 11 (2021) 057.
  42. M. Aaboud et al. (ATLAS Collaboration), Phys. Rev. D 98, 052008 (2018).
  43. G. Aad et al. (ATLAS Collaboration), Eur. Phys. J. C 80, 1165 (2020).
  44. G. Aad et al. (ATLAS Collaboration), Eur. Phys. J. C 81, 332 (2021).
  45. G. Aad et al. (ATLAS Collaboration), J. High Energy Phys. 07 (2023) 040.
  46. A. M. Sirunyan et al. (CMS Collaboration), Phys. Lett. B 785, 462 (2018).
  47. G. Aad et al. (ATLAS Collaboration), Phys. Rev. D 105, 012006 (2022).
  48. R. Barate et al. (LEP Working Group for Higgs boson searches, ALEPH, DELPHI, L3, OPAL Collaborations), Phys. Lett. B 565, 61 (2003).
  49. M. Acciarri et al., Phys. Lett. B 385, 454 (1996).
  50. T. Ferber, A. Grohsjean, and F. Kahlhoefer, Prog. Part. Nucl. Phys. 136, 104105 (2024).
  51. M. He, X.-G. He, C.-K. Huang, and G. Li, J. High Energy Phys. 03 (2018) 139.
  52. M. He, X.-G. He, and C.-K. Huang, Int. J. Mod. Phys. A 32, 1750138 (2017).
  53. S. Biswas, E. Gabrielli, M. Heikinheimo, and B. Mele, Phys. Rev. D 96, 055012 (2017).
  54. K. Park, K. Kim, A. Sytov, and K. Cho, J. Astron. Space Sci. 40, 259 (2023).
  55. J. Liu, X.-P. Wang, and F. Yu, J. High Energy Phys. 06 (2017) 077.
  56. S. C. İnan and A. V. Kisselev, Eur. Phys. J. C 82, 592 (2022).
  57. J. Jiang, C.-Y. Li, S.-Y. Li, S. D. Pathak, Z.-G. Si, and X.-H. Yang, Chin. Phys. C 44, 023105 (2020).
  58. W.-F. Chang, J. N. Ng, and G. White, Phys. Rev. D 97, 115015 (2018).
  59. K. Cheung and Z. S. Wang, Phys. Rev. D 101, 035003 (2020).
  60. S. Alipour-Fard, N. Craig, M. Jiang, and S. Koren, Chin. Phys. C 43, 053101 (2019).
  61. Z. S. Wang and K. Wang, Phys. Rev. D 101, 075046 (2020).
  62. G. Ripellino, M. Vande Voorde, A. Gallén, and R. Gonzalez Suarez, J. High Energy Phys. 06 (2025) 143.
  63. B. Bhattacherjee, C. Bose, H. K. Dreiner, N. Ghosh, S. Matsumoto, and R. Sengupta, arXiv:2503.08780.
  64. P. Olgoso, P. Paradisi, and N. Selimovic, arXiv:2507.17803.
  65. A. Djouadi, Phys. Rep. 457, 1 (2008).
  66. J. Alwall, R. Frederix, S. Frixione, V. Hirschi, F. Maltoni, O. Mattelaer, H. S. Shao, T. Stelzer, P. Torrielli, and M. Zaro, J. High Energy Phys. 07 (2014) 079.
  67. M. Bauer, P. Foldenauer, and J. Jaeckel, J. High Energy Phys. 07 (2018) 094.
  68. M. D’Onofrio, O. Fischer, and Z. S. Wang, Phys. Rev. D 101, 015020 (2020).
  69. M. Fabbrichesi, E. Gabrielli, and G. Lanfranchi, The Physics of the Dark Photon (Springer, Cham, 2021).
  70. C. Bierlich et al., SciPost Phys. Codebases 2022, 8 (2022).
  71. Z. S. Wang, Y. Zhang, and W. Liu, J. High Energy Phys. 01 (2025) 070.
  72. K. Cheung, F.-T. Chung, G. Cottin, and Z. S. Wang, J. High Energy Phys. 07 (2024) 209.
  73. G. Aad et al. (ATLAS Collaboration), J. High Energy Phys. 06 (2023) 200.
  74. F. Blekman, N. Desai, A. Filimonova, A. R. Sahasransu, and S. Westhoff, J. High Energy Phys. 11 (2020) 112.
  75. H. Fukuda, N. Nagata, H. Oide, H. Otono, and S. Shirai, Phys. Rev. Lett. 124, 101801 (2020).
