Phase structure of heavy dense lattice QCD and the three-state Potts model

Shinji Ejiri1 and Masanari Koiida2

PDF

Phys. Rev. D 113, 074515 – Published 21 April, 2026

DOI: https://doi.org/10.1103/xbd7-v9yw

Abstract

The nature of the finite temperature phase transition of QCD depends on the particle density and the mass of the dynamical quarks. We discuss the properties of the phase transition at high density, considering an effective theory describing the high-density heavy-quark limit of QCD. This effective theory is a simple model in which the Polyakov loop is a dynamical variable, and the quark Boltzmann factor is controlled by only one parameter, C(μ,mq), which is a function of the quark mass mq and the chemical potential μ. The Polyakov loop is an order parameter of Z3 symmetry, and the fundamental properties of the phase transition are thought to be determined by the Z3 symmetry broken by the phase transition. By replacing the Polyakov loop with Z3 spin, we find that the effective model becomes a three-dimensional three-state Potts model (Z3 spin model) with a complex external field term. We investigate the phase structure of the Potts model and discuss QCD in the heavy-quark region. As the density varies from μ=0 to μ=∞, we find that the phase transition is first order in the low-density region, changes to a crossover at the critical point, and then becomes first order again. This strongly suggests the existence of a first-order phase transition in the high-density heavy-quark region of QCD.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (47)

  1. H. Saito, S. Ejiri, S. Aoki, T. Hatsuda, K. Kanaya, Y. Maezawa, H. Ohno, T. Umeda (WHOT-QCD Collaboration), Phase structure of finite temperature QCD in the heavy quark region, Phys. Rev. D 84, 054502 (2011).
  2. H. Saito, S. Ejiri, S. Aoki, K. Kanaya, Y. Nakagawa, H. Ohno, K. Okuno, and T. Umeda, Histograms in heavy-quark QCD at finite temperature and density, Phys. Rev. D 89, 034507 (2014).
  3. S. Ejiri, S. Itagaki, R. Iwami, K. Kanaya, M. Kitazawa, A. Kiyohara, M. Shirogane, T. Umeda (WHOT-QCD Collaboration), End point of the first-order phase transition of QCD in the heavy quark region by reweighting from quenched QCD, Phys. Rev. D 101, 054505 (2020).
  4. A. Kiyohara, M. Kitazawa, S. Ejiri, and K. Kanaya, Finite-size scaling around the critical point in the heavy quark region of QCD, Phys. Rev. D 104, 114509 (2021).
  5. R. Ashikawa, M. Kitazawa, S. Ejiri, and K. Kanaya, High-precision analysis of the critical point in heavy-quark QCD at Nt=6, Phys. Rev. D 110, 074508 (2024).
  6. F. Cuteri, O. Philipsen, A. Schön, and A. Sciarra, Deconfinement critical point of lattice QCD with Nf=2 Wilson fermions, Phys. Rev. D 103, 014513 (2021).
  7. A. Bazavov, H. T. Ding, P. Hegde, F. Karsch, E. Laermann, S. Mukherjee, P. Petreczky, and C. Schmidt, Chiral phase structure of three flavor QCD at vanishing baryon number density, Phys. Rev. D 95, 074505 (2017).
  8. X. Y. Jin, Y. Kuramashi, Y. Nakamura, S. Takeda, and A. Ukawa, Critical point phase transition for finite temperature 3-flavor QCD with non-perturbatively O(a) improved Wilson fermions at Nt=10, Phys. Rev. D 96, 034523 (2017).
  9. A. Bazavov et al. (HotQCD Collaboration), Chiral crossover in QCD at zero and non-zero chemical potentials, Phys. Lett. B 795, 15 (2019).
  10. Y. Kuramashi, Y. Nakamura, H. Ohno, and S. Takeda, Nature of the phase transition for finite temperature Nf=3 QCD with nonperturbatively O(a) improved Wilson fermions at Nt=12, Phys. Rev. D 101, 054509 (2020).
  11. S. Borsanyi, Z. Fodor, J. N. Guenther, R. Kara, S. D. Katz, P. Parotto, A. Pasztor, C. Ratti, and K. K. Szabo, QCD crossover at finite chemical potential from lattice simulations, Phys. Rev. Lett. 125, 052001 (2020).
  12. F. Cuteri, O. Philipsen, and A. Sciarra, On the order of the QCD chiral phase transition for different numbers of quark flavours, J. High Energy Phys. 11 (2021) 141.
  13. L. Dini, P. Hegde, F. Karsch, A. Lahiri, C. Schmidt, and S. Sharma, Chiral phase transition in three-flavor QCD from lattice QCD, Phys. Rev. D 105, 034510 (2022).
  14. S. Borsanyi, Z. Fodor, M. Giordano, S. D. Katz, D. Nogradi, A. Pasztor, and C. H. Wong, Lattice simulations of the QCD chiral transition at real baryon density, Phys. Rev. D 105, L051506 (2022).
  15. R. V. Gavai, M. E. Jaensch, O. Kaczmarek, F. Karsch, M. Sarkar, R. Shanker, S. Sharma, S. Sharma, and T. Ueding, Aspects of the chiral crossover transition in (2+1)-flavor QCD with Möbius domain-wall fermions, Phys. Rev. D 111, 034507 (2025).
  16. Y. Zhang, Y. Aoki, S. Hashimoto, I. Kanamori, T. Kaneko, and Y. Nakamura, Three flavor QCD phase transition with Mobius domain wall fermions, Proc. Sci. LATTICE2024 (2025) 193 [arXiv:2501.15494].
  17. R. D. Pisarski and F. Wilczek, Remarks on the chiral phase transition in chromodynamics, Phys. Rev. D 29, 338 (1984).
  18. S. Ejiri, K. Kanaya, and M. Kitazawa, Chemical potential dependence of the endpoint of first-order phase transition in heavy-quark region of finite-temperature lattice QCD, Proc. Sci. LATTICE2023 (2024) 174 [arXiv:2311.11508].
  19. F. Karsch, C. R. Allton, S. Ejiri, S. J. Hands, O. Kaczmarek, E. Laermann, and C. Schmidt, Where is the chiral critical point in three flavor QCD?, Nucl. Phys. B, Proc. Suppl. 129, 614 (2004).
  20. P. de Forcrand and O. Philipsen, The QCD phase diagram for three degenerate flavors and small baryon density, Nucl. Phys. B673, 170 (2003).
  21. S. Ejiri and N. Yamada, End point of a first-order phase transition in many-flavor lattice QCD at finite temperature and density, Phys. Rev. Lett. 110, 172001 (2013).
  22. X. Y. Jin, Y. Kuramashi, Y. Nakamura, S. Takeda, and A. Ukawa, Finite size scaling study of Nf=4 finite density QCD on the lattice, Phys. Rev. D 88, 094508 (2013).
  23. F. Y. Wu, The Potts model, Rev. Mod. Phys. 54, 235 (1982).
  24. T. A. DeGrand and C. E. DeTar, Phase structure of QCD at high temperature with massive quarks and finite quark density: A Z(3) paradigm, Nucl. Phys. B225, 590 (1983).
  25. T. Banks and A. Ukawa, Deconfining and chiral phase transitions in quantum chromodynamics at finite temperature, Nucl. Phys. B225, 145–155 (1983).
  26. T. C. Blum, J. E. Hetrick, and D. Toussaint, High density QCD with static quarks, Phys. Rev. Lett. 76, 1019 (1996).
  27. G. Aarts and I. O. Stamatescu, Stochastic quantization at finite chemical potential, J. High Energy Phys. 09 (2008) 018.
  28. G. Aarts, E. Seiler, D. Sexty, and I. O. Stamatescu, Complex Langevin dynamics and zeroes of the fermion determinant, J. High Energy Phys. 05 (2017) 044.
  29. Z. Y. Xie, J. Chen, M. P. Qin, J. W. Zhu, L. P. Yang, and T. Xiang, Coarse-graining renormalization by higher-order singular value decomposition, Phys. Rev. B 86, 045139 (2012).
  30. S. Morita and N. Kawashima, Calculation of higher-order moments by higher-order tensor renormalization group, Comput. Phys. Commun. 236, 65 (2019).
  31. N. Wakabayashi, S. Ejiri, K. Kanaya, and M. Kitazawa, Scope and convergence of the hopping parameter expansion in finite-temperature quantum chromodynamics with heavy quarks around the critical point, Prog. Theor. Exp. Phys. 2022, 033B05 (2022).
  32. S. Ejiri, Canonical partition function and center symmetry breaking in finite density lattice gauge theories, Phys. Rev. D 106, 114505 (2022).
  33. F. Karsch and S. Stickan, The three-dimensional, three state Potts model in an external field, Phys. Lett. B 488, 319 (2000).
  34. R. Narayanan and H. Neuberger, Infinite N phase transitions in continuum Wilson loop operators, J. High Energy Phys. 03 (2006) 064.
  35. M. Luscher, Trivializing maps, the Wilson flow and the HMC algorithm, Commun. Math. Phys. 293, 899 (2010).
  36. M. Lüscher, Properties and uses of the Wilson flow in lattice QCD, J. High Energy Phys. 08 (2010) 071.
  37. A. M. Ferrenberg and R. H. Swendsen, New Monte Carlo technique for studying phase transitions, Phys. Rev. Lett. 61, 2635 (1988).
  38. K. Binder, Finite size scaling analysis of Ising model block distribution functions, Z. Phys. B 43, 119 (1981).
  39. A. Pelissetto and E. Vicari, Critical phenomena and renormalization group theory, Phys. Rep. 368, 549 (2002).
  40. S. Ejiri, Existence of the critical point in finite density lattice QCD, Phys. Rev. D 77, 014508 (2008).
  41. S. Ejiri et al. (WHOT-QCD Collaboration), Equation of state and heavy-quark free energy at finite temperature and density in two flavor lattice QCD with Wilson quark action, Phys. Rev. D 82, 014508 (2010).
  42. S. Ejiri, First-order phase transitions in the heavy quark region of lattice QCD at high temperatures and high densities, Proc. Sci. LATTICE2024 (2025) 162 [arXiv:2501.18828].
  43. A. Roberge and N. Weiss, Gauge theories with imaginary chemical potential and the phases of QCD, Nucl. Phys. B275, 734 (1986).
  44. C. Bonati and M. D’Elia, The three-dimensional, three state Potts model in a negative external field, Phys. Rev. D 82, 114515 (2010).
  45. C. N. Yang and T. D. Lee, Statistical theory of equations of state and phase transitions. 1. Theory of condensation, Phys. Rev. 87, 404 (1952).
  46. T. D. Lee and C. N. Yang, Statistical theory of equations of state and phase transitions. 2. Lattice gas and Ising model, Phys. Rev. 87, 410 (1952).
  47. S. Ejiri, Lee-Yang zero analysis for the study of QCD phase structure, Phys. Rev. D 73, 054502 (2006).
