Electronic direct detection of light dark matter with intermediate-mass mediators

Connor Stratman* and Tanner Trickle†

  • *Contact author: connor35@illinois.edu
  • †Contact author: ttrickle@illinois.edu
PDF

Phys. Rev. D 114, 035039 – Published 25 August, 2026

DOI: https://doi.org/10.1103/v2r4-53pm

Abstract

Recent years have seen dramatic improvements in the sensitivity of electron-based direct detection experiments. Typically, the sensitivity to dark matter scattering is determined in the light and heavy mediator mass limits. In this paper we show that the light and heavy mediator mass limits are not separated by a single scale, but instead can be separated by up to 3 orders of magnitude in mediator mass for sub-GeV mass dark matter. We calculate the background-free sensitivity in Si and Ge targets, and a projected DAMIC-M sensitivity, to sub-GeV mass dark matter models with “intermediate-mass” mediators between the light and heavy mediator limits. This allows us to determine the precise range of mediator masses that electron-based direct detection experiments are sensitive to when the dark matter relic abundance is generated via freeze-in. We make the calculations presented here publicly available in an updated release of EXCEED-DM.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (60)

  1. Y. Wang et al. (CDEX Collaboration), Improved limits on solar axions and bosonic dark matter from the CDEX-1B experiment using the profile likelihood ratio method, Phys. Rev. D 101, 052003 (2020).
  2. Z. Y. Zhang et al. (CDEX Collaboration), Constraints on sub-GeV dark matter–electron scattering from the CDEX-10 experiment, Phys. Rev. Lett. 129, 221301 (2022).
  3. I. Arnquist et al. (DAMIC-M Collaboration), First constraints from DAMIC-M on sub-GeV dark-matter particles interacting with electrons, Phys. Rev. Lett. 130, 171003 (2023).
  4. K. Aggarwal et al. (DAMIC-M Collaboration), Probing benchmark models of hidden-sector dark matter with DAMIC-M, Phys. Rev. Lett. 135, 071002 (2025).
  5. Q. Arnaud et al. (EDELWEISS Collaboration), First germanium-based constraints on sub-MeV dark matter with the EDELWEISS experiment, Phys. Rev. Lett. 125, 141301 (2020).
  6. P. Adari et al. (SENSEI Collaboration), First direct-detection results on Sub-GeV dark matter using the SENSEI detector at SNOLAB, Phys. Rev. Lett. 134, 011804 (2025).
  7. T. Aralis et al. (SuperCDMS Collaboration), Constraints on dark photons and axionlike particles from the SuperCDMS soudan experiment, Phys. Rev. D 101, 052008 (2020); 103, 039901(E) (2021).
  8. D. W. Amaral et al. (SuperCDMS Collaboration), Constraints on low-mass, relic dark matter candidates from a surface-operated SuperCDMS single-charge sensitive detector, Phys. Rev. D 102, 091101 (2020).
  9. A. Aguilar-Arevalo et al. (Oscura Collaboration), The Oscura experiment, arXiv:2202.10518.
  10. L. J. Hall, K. Jedamzik, J. March-Russell, and S. M. West, Freeze-in production of FIMP dark matter, J. High Energy Phys. 03 (2010) 080.
  11. X. Chu, T. Hambye, and M. H. G. Tytgat, The four basic ways of creating dark matter through a portal, J. Cosmol. Astropart. Phys. 05 (2012) 034.
  12. T. Hambye, M. H. G. Tytgat, J. Vandecasteele, and L. Vanderheyden, Dark matter from dark photons: A taxonomy of dark matter production, Phys. Rev. D 100, 095018 (2019).
  13. C. Dvorkin, T. Lin, and K. Schutz, Making dark matter out of light: Freeze-in from plasma effects, Phys. Rev. D 99, 115009 (2019); 105, 119901(E) (2022).
  14. T. Lin, Dark matter models and direct detection, Proc. Sci. TASI2018 (2019) 009. [arXiv:1904.07915].
  15. Y. Kahn and T. Lin, Searches for light dark matter using condensed matter systems, Rep. Prog. Phys. 85, 066901 (2022).
  16. K. M. Zurek, Dark matter candidates of a very low mass, Annu. Rev. Nucl. Part. Sci. 74, 287 (2024).
  17. C. Stratman and T. Trickle, Results for electronic direct detection of light dark matter with intermediate-mass mediators (2026), 10.5281/zenodo.19805613.
  18. M. E. Peskin and D. V. Schroeder, An Introduction to Quantum Field Theory (Addison-Wesley, Reading, USA, 1995).
  19. S. M. Griffin, K. Inzani, T. Trickle, Z. Zhang, and K. M. Zurek, Multichannel direct detection of light dark matter: Target comparison, Phys. Rev. D 101, 055004 (2020).
  20. S. M. Griffin, K. Inzani, T. Trickle, Z. Zhang, and K. M. Zurek, Extended calculation of dark matter-electron scattering in crystal targets, Phys. Rev. D 104, 095015 (2021).
  21. T. Trickle, Extended calculation of electronic excitations for direct detection of dark matter, Phys. Rev. D 107, 035035 (2023).
  22. C. E. Dreyer, R. Essig, M. Fernandez-Serra, A. Singal, and C. Zhen, Fully ab-initio all-electron calculation of dark matter-electron scattering in crystals with evaluation of systematic uncertainties, Phys. Rev. D 109, 115008 (2024).
  23. S. Knapen, J. Kozaczuk, and T. Lin, Dark matter-electron scattering in dielectrics, Phys. Rev. D 104, 015031 (2021).
  24. Y. Hochberg, Y. Kahn, N. Kurinsky, B. V. Lehmann, T. C. Yu, and K. K. Berggren, Determining dark-matter–electron scattering rates from the dielectric function, Phys. Rev. Lett. 127, 151802 (2021).
  25. C. Dreyer, R. Essig, M. Fernandez-Serra, M. Hott, and A. Singal, All-electron dark matter-electron scattering with random-phase approximation dielectric screening and local field effects, arXiv:2603.12326.
  26. T. Trickle, Z. Zhang, K. M. Zurek, K. Inzani, and S. M. Griffin, Multi-channel direct detection of light dark matter: Theoretical framework, J. High Energy Phys. 03 (2020) 036.
  27. D. Baxter et al., Recommended conventions for reporting results from direct dark matter searches, Eur. Phys. J. C 81, 907 (2021).
  28. R. Essig, J. Mardon, and T. Volansky, Direct detection of sub-GeV dark matter, Phys. Rev. D 85, 076007 (2012).
  29. R. Essig, M. Fernandez-Serra, J. Mardon, A. Soto, T. Volansky, and T.-T. Yu, Direct detection of sub-GeV dark matter with semiconductor targets, J. High Energy Phys. 05 (2016) 046.
  30. P. N. Bhattiprolu, R. McGehee, and A. Pierce, Dark sink enhances the direct detection of freeze-in dark matter, Phys. Rev. D 110, L031702 (2024).
  31. T. Trickle, EXCEED-DMv1.0.0: User manual results for Si and Ge (2022), 10.5281/zenodo.7250090.
  32. C. A. Klein, Bandgap dependence and related features of radiation ionization energies in semiconductors, J. Appl. Phys. 39, 2029 (1968).
  33. B. Streetman and S. Banerjee, Solid State Electronic Devices (Pearson, London, 2015).
  34. S. Derenzo, R. Essig, A. Massari, A. Soto, and T.-T. Yu, Direct detection of sub-GeV dark matter with scintillating targets, Phys. Rev. D 96, 016026 (2017).
  35. S. Baker and R. D. Cousins, Clarification of the use of chi square and likelihood functions in fits to histograms, Nucl. Instrum. Methods 221, 437 (1984).
  36. G. Cowan, K. Cranmer, E. Gross, and O. Vitells, Asymptotic formulae for likelihood-based tests of new physics, Eur. Phys. J. C 71, 1554 (2011); 73, 2501(E) (2013).
  37. M. Cirelli, E. Del Nobile, and P. Panci, Tools for model-independent bounds in direct dark matter searches, J. Cosmol. Astropart. Phys. 10 (2013) 019.
  38. S. Navas et al. (Particle Data Group Collaboration), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
  39. S. S. Wilks, The likelihood test of independence in contingency tables, Ann. Math. Stat. 6, 190 (1935).
  40. S. S. Wilks, The large-sample distribution of the likelihood ratio for testing composite hypotheses, Ann. Math. Stat. 9, 60 (1938).
  41. M. Fabbrichesi, E. Gabrielli, and G. Lanfranchi, The dark photon, arXiv:2005.01515.
  42. A. Caputo, J. Park, and S. Yun, Heavy dark photon handbook: Cosmological and astrophysical bounds, Phys. Rev. D 113, 075001 (2026).
  43. A. Caputo and R. Essig, The dark photon: A 2026 perspective, arXiv:2603.08430.
  44. S. Knapen, T. Lin, and K. M. Zurek, Light dark matter: Models and constraints, Phys. Rev. D 96, 115021 (2017).
  45. W. DeRocco, P. W. Graham, and S. Rajendran, Exploring the robustness of stellar cooling constraints on light particles, Phys. Rev. D 102, 075015 (2020).
  46. S. Chakraborty, T. H. Jung, V. Loladze, T. Okui, and K. Tobioka, Solar origin of the XENON1T excess without stellar cooling problems, Phys. Rev. D 102, 095029 (2020).
  47. F.-Y. Cyr-Racine, R. de Putter, A. Raccanelli, and K. Sigurdson, Constraints on large-scale dark acoustic oscillations from cosmology, Phys. Rev. D 89, 063517 (2014).
  48. K. Schutz and K. M. Zurek, Detectability of light dark matter with superfluid helium, Phys. Rev. Lett. 117, 121302 (2016).
  49. S. Knapen, T. Lin, M. Pyle, and K. M. Zurek, Detection of light dark matter with optical phonons in polar materials, Phys. Lett. B 785, 386 (2018).
  50. T. K. Bui et al. (TESSERACT Collaboration), First limits on light dark matter interactions in a low threshold two-channel athermal phonon detector from the TESSERACT collaboration, Phys. Rev. Lett. 135, 161002 (2025).
  51. T. Trickle, Z. Zhang, and K. M. Zurek, Detecting light dark matter with magnons, Phys. Rev. Lett. 124, 201801 (2020).
  52. P. Abbamonte et al., SPLENDOR: A novel detector platform to search for light dark matter with narrow-gap semiconductors, arXiv:2507.17782.
  53. H. An, M. Pospelov, J. Pradler, and A. Ritz, Directly detecting MeV-scale dark matter via solar reflection, Phys. Rev. Lett. 120, 141801 (2018); 121, 259903(E) (2018).
  54. T. Emken, R. Essig, and H. Xu, Solar reflection of dark matter with dark-photon mediators, J. Cosmol. Astropart. Phys. 07 (2024) 023.
  55. R. Essig, R. Plestid, and A. Singal, Collective excitations and low-energy ionization signatures of relativistic particles in silicon detectors, Commun. Phys. 7, 416 (2024).
  56. Z.-L. Liang, L. Su, L. Wu, and B. Zhu, Plasmon-enhanced direct detection of sub-MeV dark matter, Phys. Rev. Lett. 134, 071001 (2025).
  57. https://github.com/tanner-trickle/EXCEED-DM.
  58. https://zenodo.org/records/19805613.
  59. G. Krnjaic, Testing thermal-relic dark matter with a dark photon mediator, arXiv:2505.04626.
  60. P. N. Bhattiprolu, R. McGehee, E. Petrosky, and A. Pierce, Sub-MeV dark sink dark matter, Phys. Rev. D 111, 035027 (2025).
