Effective range expansion with the left-hand cut: Higher order improvements

Wen-Jia Wang1,*, Bing Wu1,†, Meng-Lin Du1,‡, and Feng-Kun Guo2,3,4,§

  • *Contact author: wwenjia@std.uestc.edu.cn
  • †Contact author: wu.bing@uestc.edu.cn
  • ‡Contact author: du.ml@uestc.edu.cn
  • §Contact author: fkguo@itp.ac.cn
PDF

Phys. Rev. D 114, 014003 – Published 6 July, 2026

DOI: https://doi.org/10.1103/tdyn-422c

Abstract

A model-independent parametrization of the low-energy scattering amplitude that incorporates the left-hand cut from one-particle exchange, an extension of the conventional effective range expansion (ERE), was recently proposed and successfully applied to the low-energy DD* system [, Effective-range expansion with a long-range force, Phys. Rev. Lett. 135, 011903 (2025)]. While the original formulation is based on a nonrelativistic approximation and is thus limited to a [1, 1] approximant for self-consistency, we extend the framework by explicitly including the higher order terms up to O(k6). We systematically investigate the reliability and robustness of the generalized ERE by incorporating relativistic kinematic effects. In addition, we develop a relativistic version of the ERE that accounts for the left-hand cut contributions. These results affirm the generalized ERE as a robust and systematically improvable framework for near-threshold scattering processes, providing both analytical and numerical reliability for applications in two-body scattering problems with a particle exchange.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (43)

  1. H. A. Bethe, Theory of the effective range in nuclear scattering, Phys. Rev. 76, 38 (1949).
  2. J. M. Blatt and J. D. Jackson, On the interpretation of neutron-proton scattering data by the Schwinger variational method, Phys. Rev. 76, 18 (1949).
  3. S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
  4. M.-Z. Liu, Y.-W. Pan, Z.-W. Liu, T.-W. Wu, J.-X. Lu, and L.-S. Geng, Three ways to decipher the nature of exotic hadrons: Multiplets, three-body hadronic molecules, and correlation functions, Phys. Rep. 1108, 1 (2025).
  5. F.-K. Guo, C. Hanhart, U.-G. Meißner, Q. Wang, Q. Zhao, and B.-S. Zou, Hadronic molecules, Rev. Mod. Phys. 90, 015004 (2018); 94, 029901(E) (2022).
  6. H.-X. Chen, W. Chen, X. Liu, Y.-R. Liu, and S.-L. Zhu, An updated review of the new hadron states, Rep. Prog. Phys. 86, 026201 (2023).
  7. L. Meng, B. Wang, G.-J. Wang, and S.-L. Zhu, Chiral perturbation theory for heavy hadrons and chiral effective field theory for heavy hadronic molecules, Phys. Rep. 1019, 1 (2023).
  8. N. Brambilla, S. Eidelman, C. Hanhart, A. Nefediev, C.-P. Shen, C. E. Thomas, A. Vairo, and C.-Z. Yuan, The XYZ states: Experimental and theoretical status and perspectives, Phys. Rep. 873, 1 (2020).
  9. V. Baru, X.-K. Dong, M.-L. Du, A. Filin, F.-K. Guo, C. Hanhart, A. Nefediev, J. Nieves, and Q. Wang, Effective range expansion for narrow near-threshold resonances, Phys. Lett. B 833, 137290 (2022).
  10. X.-K. Dong, F.-K. Guo, and B.-S. Zou, A survey of heavy-heavy hadronic molecules, Commun. Theor. Phys. 73, 125201 (2021).
  11. X.-K. Dong, F.-K. Guo, and B.-S. Zou, A survey of heavy-antiheavy hadronic molecules, Progr. Phys. 41, 65 (2021).
  12. M. Mai, U.-G. Meißner, and C. Urbach, Towards a theory of hadron resonances, Phys. Rep. 1001, 1 (2023).
  13. J.-H. Chen, J. Chen, F.-K. Guo, Y.-G. Ma, C.-P. Shen, Q.-Y. Shou, Q. Shou, Q. Wang, J.-J. Wu, and B.-S. Zou, Production of exotic hadrons in pp and nuclear collisions, Nucl. Sci. Tech. 36, 55 (2025).
  14. M. Döring, J. Haidenbauer, M. Mai, and T. Sato, Dynamical coupled-channel models for hadron dynamics, Prog. Part. Nucl. Phys. 146, 104213 (2025).
  15. C. Hanhart, Hadronic molecules and multiquark states, arXiv:2504.06043.
  16. H. van Haeringen and L. P. Kok, Modified effective range function, Phys. Rev. A 26, 1218 (1982).
  17. A. S. Reiner, On the anomalous effective range expansion for nucleon-deuteron scattering in the S = 12 state, Phys. Lett. 28B, 387 (1969).
  18. A. C. Phillips and G. Barton, Relations between low-energy three nucleon observables, Phys. Lett. 28B, 378 (1969).
  19. L. Spruch, T. F. O’Malley, and L. Rosenberg, Modification of effective-range theory in the presence of a long-range potential, Phys. Rev. Lett. 5, 375 (1960).
  20. T. F. O’Malley, L. Spruch, and L. Rosenberg, Modification of effective-range theory in the presence of a long-range (r−4) potential, J. Math. Phys. (N.Y.) 2, 491 (1961).
  21. A. M. Badalian, L. P. Kok, M. I. Polikarpov, and Y. A. Simonov, Resonances in coupled channels in nuclear and particle physics, Phys. Rep. 82, 31 (1982).
  22. G. F. Chew and S. Mandelstam, Theory of low-energy pion pion interactions, Phys. Rev. 119, 467 (1960).
  23. R. J. Eden, P. V. Landshoff, D. I. Olive, and J. C. Polkinghorne, The Analytic S-Matrix (Cambridge University Press, Cambridge, England, 1966).
  24. X. Zhang, H.-L. Fu, F.-K. Guo, and H.-W. Hammer, Neutron scattering off one-neutron halo nuclei in halo effective field theory, Phys. Rev. C 108, 044304 (2023).
  25. M.-L. Du, A. Filin, V. Baru, X.-K. Dong, E. Epelbaum, F.-K. Guo, C. Hanhart, A. Nefediev, J. Nieves, and Q. Wang, Role of left-hand cut contributions on pole extractions from lattice data: Case study for Tcc(3875)+, Phys. Rev. Lett. 131, 131903 (2023).
  26. M.-L. Du, F.-K. Guo, and B. Wu, Effective-range expansion with a long-range force, Phys. Rev. Lett. 135, 011903 (2025).
  27. S. M. Dawid, M. H. E. Islam, and R. A. Briceño, Analytic continuation of the relativistic three-particle scattering amplitudes, Phys. Rev. D 108, 034016 (2023).
  28. L. Meng, V. Baru, E. Epelbaum, A. A. Filin, and A. M. Gasparyan, Solving the left-hand cut problem in lattice QCD: Tcc(3875)+ from finite volume energy levels, Phys. Rev. D 109, L071506 (2024).
  29. D. Gülmez, U. G. Meißner, and J. A. Oller, A chiral covariant approach to ρρ scattering, Eur. Phys. J. C 77, 460 (2017).
  30. M.-L. Du, D. Gülmez, F.-K. Guo, U.-G. Meißner, and Q. Wang, Interactions between vector mesons and dynamically generated resonances, Eur. Phys. J. C 78, 988 (2018).
  31. M.-L. Du, F.-K. Guo, and B. Wu, Effective range expansion with the left-hand cut and its application to the Tcc(3875), Proc. Sci. CD2024 (2026) 062 [arXiv:2502.19774].
  32. R. E. Cutkosky, Singularities and discontinuities of Feynman amplitudes, J. Math. Phys. (N.Y.) 1, 429 (1960).
  33. H.-J. Jing, X.-H. Cao, and F.-K. Guo, Discontinuity calculus and applications to two-body coupled-channel scattering, Front. Phys. 21, 056201 (2026).
  34. A. D. Martin and T. D. Spearman, Elementary Particle Theory (North-Holland, Amsterdam, 1970).
  35. B. Wu, X.-H. Cao, X.-K. Dong, and F.-K. Guo, σ exchange in the one-boson exchange model involving the ground state octet baryons, Phys. Rev. D 109, 034026 (2024).
  36. J. A. Oller, A Brief Introduction to Dispersion Relations, SpringerBriefs in Physics (Springer, New York, 2019).
  37. J. A. Oller, Coupled-channel approach in hadron-hadron scattering, Prog. Part. Nucl. Phys. 110, 103728 (2020).
  38. C.-W. Shen, Y.-h. Lin, and U.-G. Meißner, PccN states in a unitarized coupled-channel approach, Eur. Phys. J. C 83, 70 (2023).
  39. D. B. Kaplan, M. J. Savage, and M. B. Wise, Nucleon-nucleon scattering from effective field theory, Nucl. Phys. B478, 629 (1996).
  40. J. Nieves, Renormalization of the one pion exchange NN interaction in presence of derivative contact interactions, Phys. Lett. B 568, 109 (2003).
  41. J. A. Oller and D. R. Entem, The exact discontinuity of a partial wave along the left-hand cut and the exact N/D method in non-relativistic scattering, Ann. Phys. (Amsterdam) 411, 167965 (2019).
  42. D. R. Entem, J. Nieves, and J. A. Oller, Contact potentials in presence of a regular finite-range interaction using dimensional regularization and the N/D method, Phys. Rev. D 112, 096007 (2025).
  43. B.-Y. Liu, B. Wu, J.-W. Fu, M.-L. Du, F.-K. Guo, and U.-G. Meißner, Extraction of the pion-nucleon coupling constant using the effective-range expansion with the left-hand cut, arXiv:2602.03115.
