Data-driven core-collapse supernova multilateration with first neutrino events

Farrukh Azfar1, Jeff Tseng1,*, Marta Colomer Molla2, Kate Scholberg3, Alec Habig4, Segev BenZvi5, Melih Kara6, James Kneller7, Jost Migenda8 et al.

Dan Milisavljevic9 and Evan O’Connor10

  • *Contact author: jeff.tseng@physics.ox.ac.uk
PDF

Phys. Rev. D 113, 063005 – Published 3 March, 2026

DOI: https://doi.org/10.1103/t1qp-1q9z

Abstract

A Galactic core-collapse supernova (CCSN) is likely to be observed in neutrino detectors around the world minutes to hours before the electromagnetic radiation arrives. The SuperNova Early Warning System (SNEWS2.0) network of neutrino and dark matter detectors aims to use the relative arrival times of the neutrinos at the different experiments to point back to the supernova so as to facilitate follow-up observation. One of the simplest methods to estimate the CCSN direction is to use the first neutrino events detected through the inverse β decay (IBD) process, ν¯ep→e+n. We will consider neutrino detectors sensitive to IBD interactions with low backgrounds. The difference in signal arrival times between a large and a small detector will be biased, however, with the first event at the smaller detector, on average, arriving later than that at the larger detector. This bias can be mitigated by using these first events in a data-driven approach without recourse to simulations or models. The resulting method requires, at minimum, only the times of the first events at most detectors, along with a longer time series of events from one larger detector to act as a reference lightcurve. In this article, we demonstrate this method and its uncertainty estimate using pairs of detectors of different sizes and with different supernova distances. Finally, we use this method to calculate probability skymaps using four detectors currently in operation, Super-Kamiokande, Jiangmen Underground Neutrino Observatory (JUNO), Large Volume Detector (LVD), and SNO+, and show that the calculated probabilities yield appropriate confidence intervals for all supernova directions. The area of the 68% confidence interval varies by distance and direction, but is expected to be a few thousand square degrees. The resulting skymaps should be useful for the multimessenger community as a rapid, initial pointing to follow up on the SNEWS2.0 Galactic CCSN neutrino alert.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (44)

  1. See, for instance, Refs. [2, 3, 4], and recent articles such as Refs. [5, 6, 7].

  2. Y. Koshio, G. D. O. Gann, E. O’Sullivan, and I. Tamborra, Snowmass 2021 topical group report: Neutrinos from natural sources, arXiv:2209.04298.
  3. S. Furusawa and H. Nagakura, Nuclei in core-collapse supernovae engine, Prog. Part. Nucl. Phys. 129, 104018 (2023).
  4. A. Arcones et al., White paper on nuclear astrophysics and low energy nuclear physics Part 1: Nuclear astrophysics, Prog. Part. Nucl. Phys. 94, 1 (2017).
  5. L. Visinelli, T. T. Yanagida, and M. Zantedeschi, Do neutrinos bend? Consequences of an ultralight gauge field as dark matter, Phys. Dark Universe 46, 101659 (2024).
  6. A. Lella, E. Ravensburg, P. Carenza, and M. C. D. Marsh, Supernova limits on ‘QCD axion-like particles’, Phys. Rev. D 110, 043019 (2024).
  7. C. Li, Z. Liu, W. Lu, and Z. Ye, Low-energy supernova constraints on millicharged particles, J. High Energy Phys. 07 (2025) 116.
  8. K. Rozwadowska, F. Vissani, and E. Cappellaro, On the rate of core collapse supernovae in the Milky Way, New Astron. 83, 101498 (2021).
  9. S. Al Kharusi et al. (SNEWS Collaboration), SNEWS 2.0: A next-generation supernova early warning system for multi-messenger astronomy, New J. Phys. 23, 031201 (2021).
  10. J. F. Beacom and P. Vogel, Can a supernova be located by its neutrinos?, Phys. Rev. D 60, 033007 (1999).
  11. T. Mühlbeier, H. Nunokawa, and R. Zukanovich Funchal, Revisiting the triangulation method for pointing to supernova and failed supernova with neutrinos, Phys. Rev. D 88, 085010 (2013).
  12. V. Brdar, M. Lindner, and X.-J. Xu, Neutrino astronomy with supernova neutrinos, J. Cosmol. Astropart. Phys. 04 (2018) 025.
  13. N. B. Linzer and K. Scholberg, Triangulation pointing to core-collapse supernovae with next-generation neutrino detectors, Phys. Rev. D 100, 103005 (2019).
  14. A. Coleiro, M. Colomer Molla, D. Dornic, M. Lincetto, and V. Kulikovskiy, Combining neutrino experimental light-curves for pointing to the next galactic core-collapse supernova, Eur. Phys. J. C 80, 856 (2020).
  15. Y. Kashiwagi et al. (Super-Kamiokande Collaboration), Performance of SK-Gd’s upgraded real-time supernova monitoring system, Astrophys. J. 970, 93 (2024).
  16. A. Abed Abud et al. (DUNE Collaboration), Supernova pointing capabilities of DUNE, Phys. Rev. D 111, 092006 (2025).
  17. Y. Fukuda et al. (Super-Kamiokande Collaboration), The Super-Kamiokande detector, Nucl. Instrum. Methods Phys. Res., Sect. A 501, 418 (2003).
  18. A. Abusleme et al. (JUNO Collaboration), JUNO physics and detector, Prog. Part. Nucl. Phys. 123, 103927 (2022).
  19. M. Aglietta et al., The most powerful scintillator supernovae detector: LVD, Nuovo Cimento Soc. Ital. Fis. 105A, 1793 (1992).
  20. V. Albanese et al. (SNO+ Collaboration), The SNO+experiment, J. Instrum. 16, P08059 (2021).
  21. A. Odrzywolek, M. Misiaszek, and M. Kutschera, Detection possibility of the pair—annihilation neutrinos from the neutrino—cooled pre-supernova star, Astropart. Phys. 21, 303 (2004).
  22. A. Odrzywolek, M. Misiaszek, and M. Kutschera, Neutrinos from pre-supernova star, Acta Phys. Pol. B 35, 1981 (2004).
  23. K. M. Patton, C. Lunardini, and R. J. Farmer, Presupernova neutrinos: Realistic emissivities from stellar evolution, Astrophys. J. 840, 2 (2017).
  24. K. M. Patton, C. Lunardini, R. J. Farmer, and F. X. Timmes, Neutrinos from beta processes in a presupernova: Probing the isotopic evolution of a massive star, Astrophys. J. 851, 6 (2017).
  25. V. Brdar and X.-J. Xu, Timing and multi-channel: Novel method for determining the neutrino mass ordering from supernovae, J. Cosmol. Astropart. Phys. 08 (2022) 067.
  26. E. O’Connor et al., Global comparison of core-collapse supernova simulations in spherical symmetry, J. Phys. G 45, 104001 (2018).
  27. R. M. Cabezón, K.-C. Pan, M. Liebendörfer, T. Kuroda, K. Ebinger, O. Heinimann, F.-K. Thielemann, and A. Perego, Core-collapse supernovae in the hall of mirrors. A three-dimensional code-comparison project, Astron. Astrophys. 619, A118 (2018).
  28. M. G. Aartsen et al. (IceCube Collaboration), The IceCube neutrino observatory: Instrumentation and online systems, J. Instrum. 12, P03012 (2017).
  29. R. Abbasi et al. (IceCube Collaboration), An end-to-end test of the sensitivity of IceCube to the neutrino burst from a core-collapse supernova, Proc. Sci., ICRC2021 (2021) 1085 [arXiv:2107.08098].
  30. S. Adrian-Martinez et al. (KM3Net Collaboration), Letter of intent for KM3NeT 2.0, J. Phys. G 43, 084001 (2016).
  31. R. Cross, A. Fritz, and S. Griswold (IceCube Collaboration), Eleven year search for supernovae with the IceCube neutrino observatory, Proc. Sci., ICRC2019 (2020) 889 [arXiv:1908.07249].
  32. S. Aiello et al. (KM3NeT Collaboration), The KM3NeT potential for the next core-collapse supernova observation with neutrinos, Eur. Phys. J. C 81, 445 (2021).
  33. A. Mirizzi, I. Tamborra, H.-T. Janka, N. Saviano, K. Scholberg, R. Bollig, L. Hudepohl, and S. Chakraborty, Supernova neutrinos: Production, oscillations and detection, Riv. Nuovo Cimento 39, 1 (2016).
  34. A. L. Baxter et al. (The SNEWS Collaboration), SNEWPY: A data pipeline from supernova simulations to neutrino signals, Astrophys. J. 925, 107 (2022).
  35. A. L. Baxter et al., SNEWPY: A data pipeline from supernova simulations to neutrino signals, J. Open Source Software 6, 3772 (2021).
  36. S. E. Woosley and A. Heger, Nucleosynthesis and remnants in massive stars of solar metallicity, Phys. Rep. 442, 269 (2007).

  37. A. Beck et al., https://github.com/SNOwGLoBES/snowglobes (2016).

  38. K. M. Górski, E. Hivon, A. J. Banday, B. D. Wandelt, F. K. Hansen, M. Reinecke, and M. Bartelmann, HEALPix: A framework for high-resolution discretization and fast analysis of data distributed on the sphere, Astrophys. J. 622, 759 (2005).

  39. http://healpix.sf.net/

  40. J.-S. Wang, J. Tseng, S. Gullin, and E. P. O’Connor, Nonradial neutrino emission upon black hole formation in core collapse supernovae, Phys. Rev. D 104, 104030 (2021).
  41. S. Gullin, E. P. O’Connor, J.-S. Wang, and J. Tseng, Neutrino echos following black hole formation in core-collapse supernovae, Astrophys. J. 926, 212 (2022).
  42. J. D. Hunter, Matplotlib: A 2d graphics environment, Comput. Sci. Eng. 9, 90 (2007).
  43. A. Zonca, L. Singer, D. Lenz, M. Reinecke, C. Rosset, E. Hivon, and K. Gorski, healpy: Equal area pixelization and spherical harmonics transforms for data on the sphere in Python, J. Open Source Softwaare 4, 1298 (2019).
  44. A. L. Baxter et al., SNEWPY: Supernova neutrino early warning models for Python, 10.21105/joss.03772 (2021).
