Updated constraint for the gravitational wave background from the gamma-ray Pulsar Timing Array

Serena Valtolina1,2,3,*, Colin J. Clark1,2, Rutger van Haasteren1,2, Aurélien Chalumeau4,5, H. Thankful Cromartie6,†, Matthew Kerr7, Lars Nieder1,2, and Aditya Parthasarathy4,8,3

  • *Contact author: svaltolina@mpifr-bonn.mpg.de
  • †Present address: Resident at Naval Research Laboratory, Washington, DC 20375, USA.
PDF

Phys. Rev. D 113, 063061 – Published 30 March, 2026

DOI: https://doi.org/10.1103/rrz1-mdkg

Abstract

Fermi Large Area Telescope observations of gamma-ray pulsars can be used to build a pulsar timing array (PTA) experiment to search for gravitational wave (GW) signals at nanohertz frequencies. At those frequencies, the dominant signal is expected to be a stochastic gravitational wave background (GWB) produced by the incoherent superposition of the quasimonochromatic GW emissions from a population of supermassive black hole binaries. While the radio PTAs have recently announced compelling evidence for a GWB signal with a power law spectrum of strain amplitude ≈2–3×10−15 (at the frequency of 1  yr−1), in 2022, an analysis of 12.5 years of Fermi data for 35 pulsars led to an upper limit of 1×10−14 for the GWB amplitude. The analysis was carried out on times of arrival obtained by folding from six months up to one year of photon observations. A photon-by-photon approach was also tested to infer constraints on the GWB amplitude from individual pulsars, but without accounting for the cross-pulsar correlations that a GWB would induce. Here, we reanalyze the same dataset using a regularized likelihood method that correctly models cross-pulsar correlations directly from the photons, while additionally marginalizing over the uncertain pulse profile shape. While the two methods are not expected to have significant differences in sensitivity, we prove through simulations of gamma-ray PTA datasets that the photon-by-photon method for GWB recoveries is, statistically, more robust. The resulting upper limit obtained for the GWB strain amplitude is 1.2×10−14, indicating that the improved method yields a consistent result with the previous analyses.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (64)

  1. D. R. Lorimer and M. Kramer, Handbook of Pulsar Astronomy, Vol. 4 (Cambridge University Press, 2004).
  2. M. Rajagopal and R. W. Romani, Astrophys. J. 446, 543 (1995).
  3. A. H. Jaffe and D. C. Backer, Astrophys. J. 583, 616 (2003).
  4. J. S. B. Wyithe and A. Loeb, Astrophys. J. 590, 691 (2003).
  5. A. Sesana, A. Vecchio, and C. N. Colacino, Mon. Not. R. Astron. Soc. 390, 192 (2008).
  6. P. A. Rosado, A. Sesana, and J. Gair, Mon. Not. R. Astron. Soc. 451, 2417 (2015).
  7. R. W. Hellings and G. S. Downs, Astrophys. J. Lett. 265, L39 (1983).
  8. B. Allen and J. D. Romano, Phys. Rev. D 108, 043026 (2023).
  9. J. P. W. Verbiest, S. J. Vigeland, N. K. Porayko, S. Chen, and D. J. Reardon, Results Phys. 61, 107719 (2024).
  10. J. P. W. Verbiest and G. M. Shaifullah, Classical Quantum Gravity 35, 133001 (2018).
  11. G. H. Janssen, G. Hobbs, M. McLaughlin et al., Proc. Sci. AASKA14 (2015) 037 [arXiv:1501.00127].
  12. M. T. Lam, J. A. Ellis, G. Grillo et al., Astrophys. J. 861, 132 (2018).
  13. L. Lentati, R. M. Shannon, W. A. Coles et al., Mon. Not. R. Astron. Soc. 458, 2161 (2016).
  14. J. M. Cordes, R. M. Shannon, and D. R. Stinebring, Astrophys. J. 817, 16 (2016).
  15. J. Y. Donner, J. P. W. Verbiest, C. Tiburzi, S. Osłowski, D. Michilli, M. Serylak, J. M. Anderson, A. Horneffer, M. Kramer, J.-M.Grießmeier, J. Künsemöller, J. W. T. Hessels, M. Hoeft, and A. Miskolczi, Astron. Astrophys. 624, A22 (2019).
  16. P. S. Ray et al., Astrophys. J. Suppl. Ser. 194, 17 (2011).
  17. W. B. Atwood, A. A. Abdo, M. Ackermann et al., Astrophys. J. 697, 1071 (2009).
  18. H. J. Pletsch and C. J. Clark, Astrophys. J. 807, 18 (2015).
  19. H. Xu, S. Chen et al. (CPTA Collaboration), Res. Astron. Astrophys. 23, 075024 (2023).
  20. J. Antoniadis et al. (EPTA Collaboration and InPTA Collaboration), Astron. Astrophys. 678, A50 (2023).
  21. G. Agazie et al. (NANOGrav Collaboration), Astrophys. J. Lett. 951, L8 (2023).
  22. D. J. Reardon, A. Zic et al. (PPTA Collaboration), Astrophys. J. Lett. 951, L6 (2023).
  23. M. T. Miles, R. M. Shannon, D. J. Reardon et al., Mon. Not. R. Astron. Soc. 536, 1489 (2024).
  24. The Fermi-LAT Collaboration, Science 376, 521 (2022).
  25. S. Valtolina and R. van Haasteren, Phys. Rev. D 112, 043046 (2025).
  26. R. van Haasteren, Y. Levin, P. McDonald, and T. Lu, Mon. Not. R. Astron. Soc. 395, 1005 (2009).
  27. R. van Haasteren and Y. Levin, Mon. Not. R. Astron. Soc. 428, 1147 (2012).
  28. L. Lentati, P. Alexander, M. P. Hobson, S. Taylor, J. Gair, S. T. Balan, and R. van Haasteren, Phys. Rev. D 87, 104021 (2013).
  29. R. van Haasteren and M. Vallisneri, Phys. Rev. D 90, 104012 (2014).
  30. J. A. Ellis, M. Vallisneri, S. R. Taylor, and P. T. Baker, enterprise: Enhanced Numerical Toolbox Enabling a Robust PulsaR Inference SuitE, Astrophysics Source Code Library, record ascl:1912.015 (2019).
  31. C. J. Clark, S. Valtolina, L. Nieder, and R. van Haasteren, arXiv:2601.07592.
  32. J. Luo, S. Ransom, P. Demorest, P. S. Ray, A. Archibald, M. Kerr, R. J. Jennings, M. Bachetti, R. van Haasteren, C. A. Champagne, J. Colen, C. Phillips, J. Zimmerman, K. Stovall, M. T. Lam, and F. A. Jenet, Astrophys. J. 911, 45 (2021).
  33. A. Susobhanan, D. Kaplan, A. Archibald et al., Astrophys. J. 971, 150 (2024).
  34. P. Bickel, B. Kleijn, and J. Rice, Astrophys. J. 685, 384 (2008).
  35. M. Kerr, Astrophys. J. 732, 38 (2011).
  36. P. Bruel, Astro. Astrophys. 622, A108 (2019).
  37. M. Kerr, Astrophys. J. 885, 92 (2019).
  38. S. J. Chamberlin, J. D. E. Creighton, X. Siemens, P. Demorest, J. Ellis, L. R. Price, and J. D. Romano, Phys. Rev. D 91, 044048 (2015).
  39. https://github.com/vallis/libstempo/blob/master/libstempo/toasim.py.
  40. S. Burke-Spolaor, S. R. Taylor, M. Charisi, T. Dolch, J. S. Hazboun, A. M. Holgado, L. Z. Kelley, T. J. W. Lazio, D. R. Madison, N. McMann, C. M. F. Mingarelli, A. Rasskazov, X. Siemens, J. J. Simon, and T. L. Smith, Astron. Astrophys. Rev. 27, 5 (2019).
  41. S. R. Cook, A. Gelman, and D. B. Rubin, J. Comput. Graph. Stat. 15, 675 (2006).
  42. S. Talts, M. Betancourt, D. Simpson, A. Vehtari, and A. Gelman, arXiv:1804.06788.
  43. M. B. Wilk and R. Gnanadesikan, Biometrika 55, 1 (1968).
  44. J. Antoniadis, P. Arumugam et al., Astron. Astrophys. 678, A49 (2023).
  45. A. D. Johnson, P. M. Meyers et al., Phys. Rev. D 109, 103012 (2024).
  46. S. Valtolina, G. Shaifullah, A. Samajdar, and A. Sesana, Astron. Astrophys. 683, A201 (2024).
  47. L. Nieder, B. Allen, C. J. Clark, and H. J. Pletsch, Astrophys. J. 901, 156 (2020).
  48. J. Antoniadis, Z. Arzoumanian et al., Mon. Not. R. Astron. Soc. 510, 4873 (2022).
  49. T.-Y. Cao, S. jie Zheng, S.-X. Yi, M.-Y. Ge, Y.-T. Yin, Y.-M. Duan, X. Yang, and Wen, Astrophys. J. Suppl. Ser. 282, 42 (2026).
  50. F. A. Jenet, G. B. Hobbs, W. van Straten, R. N. Manchester, M. Bailes, J. P. W. Verbiest, R. T. Edwards, A. W. Hotan, J. M. Sarkissian, and S. M. Ord, Astrophys. J. 653, 1571 (2006).
  51. R. M. Shannon et al., Science 342, 334 (2013).
  52. R. M. Shannon, V. Ravi et al., Science 349, 1522 (2015).
  53. R. van Haasteren, Y. Levin et al., Mon. Not. R. Astron. Soc. 414, 3117 (2011).
  54. L. Lentati, S. R. Taylor et al., Mon. Not. R. Astron. Soc. 453, 2576 (2015).
  55. P. B. Demorest, R. D. Ferdman et al., Astrophys. J. 762, 94 (2013).
  56. Z. Arzoumanian, P. T. Baker et al., Astrophys. J. 859, 47 (2018).
  57. Z. Arzoumanian, P. T. Baker et al., Astrophys. J. Lett. 905, L34 (2020).
  58. J. P. W. Verbiest, L. Lentati et al., Mon. Not. R. Astron. Soc. 458, 1267 (2016).
  59. C. R. Harris et al., Nature (London) 585, 357 (2020).
  60. J. D. Hunter, Comput. Sci. Eng. 9, 90 (2007).
  61. D. Foreman-Mackey, J. Open Source Software 1, 24 (2016).
  62. P. Virtanen et al., Nat. Methods 17, 261 (2020).
  63. J. Ellis and R. van Haasteren, jellis18/ptmcmcsampler: Official release, 10.5281/zenodo.1037579 (2017).
  64. M. Kerr and A. Parthasarathy, Software and data release for Fermi Pulsar Timing Array, Zenodo, 10.5281/zenodo.6374291 (2022).

Outline

Information

Phys. Rev. D 113, 063061– Published 30 March, 2026
  • Received 18 November 2025
  • Accepted 13 February 2026
