How to understand the ρ resonance from the quark model and ππ P-wave phase shift

Wen-Ze Zhao1, Ru-Hui Ni1,*, and Jia-Jun Wu1,2,†

  • *Contact author: niruhui@ucas.ac.cn
  • †Contact author: wujiajun@ucas.ac.cn
PDF

Phys. Rev. D 114, 014020 – Published 8 July, 2026

DOI: https://doi.org/10.1103/rn1z-fdh7

Abstract

As the lightest isovector vector meson, the ρ meson is an important object for investigating the structure of resonant states in strong interactions. Owing to its strong coupling to the ππ channel and its large decay width, the conventional constituent quark model treatment, in which it is simply regarded as a pure qq¯ bound state while the hadronic-channel coupling effects are neglected, is insufficient to fully characterize its physical properties. To this end, in the present work we establish a unified framework for studying the structure and resonant properties of the ρ meson by combining the quark-gluon and hadronic degrees of freedom. At the quark-gluon level, we first determine the parameters of the chiral quark model by refitting a set of narrow mesons for which open Okubo-Zweig-Iizuka-allowed strong-decay channels are absent or strongly suppressed. With these parameters fixed, the bare mass of the ρ meson is obtained and used as the input for the subsequent hadronic-level analysis. At the hadronic level, based on inverse-scattering theory, we construct a model including the coupling between the bare state and the ππ continuum, extract the ρ0−ππ interaction using the P-wave ππ scattering phase-shift data, and further calculate the width of the ρ meson as well as the bare-state component in the physical state. The present work also provides a generalizable analytical framework for further studies of other hadronic resonances with significant coupled-channel effects.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (52)

  1. S. Godfrey and N. Isgur, Mesons in a relativized quark model with chromodynamics, Phys. Rev. D 32, 189 (1985).
  2. N. Isgur and G. Karl, p-wave baryons in the quark model, Phys. Rev. D 18, 4187 (1978).
  3. S. Capstick and N. Isgur, Baryons in a relativized quark model with chromodynamics, Phys. Rev. D 34, 2809 (1986).
  4. F. Wang, G.-H. Wu, L.-J. Teng, and T. Goldman, Quark delocalization, color screening, and nuclear intermediate range attraction, Phys. Rev. Lett. 69, 2901 (1992).
  5. F. Wang, J.-L. Ping, G.-H. Wu, L.-J. Teng, and T. Goldman, Quark delocalization, color screening, and dibaryons, Phys. Rev. C 51, 3411 (1995).
  6. G. Yang, J. Ping, and J. Segovia, Tetra- and penta-quark structures in the constituent quark model, Symmetry 12, 1869 (2020).
  7. Y. Yang, C. Deng, J. Ping, and T. Goldman, s-wave qqq¯q¯ state in the constituent quark model, Phys. Rev. D 80, 114023 (2009).
  8. H. Huang, C. Deng, J. Ping, and F. Wang, Possible pentaquarks with heavy quarks, Eur. Phys. J. C 76, 624 (2016).
  9. B.-R. He, M. Harada, and B.-S. Zou, Quark model with hidden local symmetry and its application to Tcc, Phys. Rev. D 108, 054025 (2023).
  10. J. Vijande, F. Fernandez, and A. Valcarce, Constituent quark model study of the meson spectra, J. Phys. G 31, 481 (2005).
  11. D. Ebert, R. N. Faustov, and V. O. Galkin, Mass spectra and regge trajectories of light mesons in the relativistic quark model, Phys. Rev. D 79, 114029 (2009).
  12. Q.-T. Song, D.-Y. Chen, X. Liu, and T. Matsuki, Charmed-strange mesons revisited: Mass spectra and strong decays, Phys. Rev. D 91, 054031 (2015).
  13. W.-J. Deng, H. Liu, L.-C. Gui, and X.-H. Zhong, Charmonium spectrum and electromagnetic transitions with higher multipole contributions, Phys. Rev. D 95, 034026 (2017).
  14. K.-L. Wang, Y.-X. Yao, X.-H. Zhong, and Q. Zhao, Strong and radiative decays of the low-lying s- and p-wave singly heavy baryons, Phys. Rev. D 96, 116016 (2017).
  15. X.-H. Zhong and Q. Zhao, Charmed baryon strong decays in a chiral quark model, Phys. Rev. D 77, 074008 (2008).
  16. M.-S. Liu, Q.-F. Lü, X.-H. Zhong, and Q. Zhao, All-heavy tetraquarks, Phys. Rev. D 100, 016006 (2019).
  17. Y.-R. Liu, H.-X. Chen, W. Chen, X. Liu, and S.-L. Zhu, Pentaquark and tetraquark states, Prog. Part. Nucl. Phys. 107, 237 (2019).
  18. R.-H. Ni, J.-J. Wu, and X.-H. Zhong, Unified unquenched quark model for heavy-light mesons with chiral dynamics, Phys. Rev. D 109, 116006 (2024).
  19. R.-H. Ni, Q. Deng, J.-J. Wu, and X.-H. Zhong, Bottomonia in an unquenched quark model, Phys. Rev. D 111, 114027 (2025).
  20. C.-Q. Pang, J.-Z. Wang, X. Liu, and T. Matsuki, A systematic study of mass spectra and strong decay of strange mesons, Eur. Phys. J. C 77, 861 (2017).
  21. E. Eichten, K. Gottfried, T. Kinoshita, J. Kogut, K. D. Lane, and T. M. Yan, Spectrum of charmed quark-antiquark bound states, Phys. Rev. Lett. 34, 369 (1975).
  22. E. Eichten, K. Gottfried, T. Kinoshita, K. D. Lane, and T. M. Yan, Charmonium: The model, Phys. Rev. D 17, 3090 (1978).
  23. E. Eichten, K. Gottfried, T. Kinoshita, K. D. Lane, and T. M. Yan, Charmonium: Comparison with experiment, Phys. Rev. D 21, 203 (1980).
  24. K. Johnson, The M. I. T. Bag model, Acta Phys. Pol. B 6, 865 (1975), https://www.actaphys.uj.edu.pl/R/6/11/865.
  25. A. Chodos, R. L. Jaffe, K. Johnson, C. B. Thorn, and V. F. Weisskopf, New extended model of hadrons, Phys. Rev. D 9, 3471 (1974).
  26. A. Chodos, R. L. Jaffe, K. Johnson, and C. B. Thorn, Baryon structure in the bag theory, Phys. Rev. D 10, 2599 (1974).
  27. T. DeGrand, R. L. Jaffe, K. Johnson, and J. Kiskis, Masses and other parameters of the light hadrons, Phys. Rev. D 12, 2060 (1975).
  28. Y. Nambu, Strings, monopoles, and gauge fields, Phys. Rev. D 10, 4262 (1974).
  29. P. Bicudo, N. Cardoso, and M. Cardoso, Colour flux-tubes in static Pentaquark and Tetraquark systems, Prog. Part. Nucl. Phys. 67, 440 (2012).
  30. N. Isgur and J. Paton, Flux-tube model for hadrons in QCD, Phys. Rev. D 31, 2910 (1985).
  31. R. Machleidt, K. Holinde, and C. Elster, The bonn meson-exchange model for the nucleon–nucleon interaction, Phys. Rep. 149, 1 (1987).
  32. F. Myhrer and J. Wroldsen, The nucleon-nucleon force and the quark degrees of freedom, Rev. Mod. Phys. 60, 629 (1988).
  33. R. Machleidt, The Meson theory of nuclear forces and nuclear structure, Adv. Nucl. Phys. 19, 189 (1989).
  34. G. Ecker, Chiral perturbation theory, Prog. Part. Nucl. Phys. 35, 1 (1995).
  35. N. Brambilla, A. Pineda, J. Soto, and A. Vairo, Effective-field theories for heavy quarkonium, Rev. Mod. Phys. 77, 1423 (2005).
  36. L. Meng, B. Wang, G.-J. Wang, and S.-L. Zhu, Chiral perturbation theory for heavy hadrons and chiral effective field theory for heavy hadronic molecules, Phys. Rep. 1019, 1 (2023).
  37. C. Quigg and J. L. Rosner, Quantum mechanics with applications to quarkonium, Phys. Rep. 56, 167 (1979).
  38. W. Lucha, F. F. Schöberl, and D. Gromes, Bound states of quarks, Phys. Rep. 200, 127 (1991).
  39. X.-L. Gao, Z.-H. Guo, Z. Xiao, and Z.-Y. Zhou, Scrutinizing ππ scattering in light of recent lattice phase shifts, Phys. Rev. D 105, 094002 (2022).
  40. Z.-Y. Zhou and Z. Xiao, The Origin of light 0+ scalar resonances, Phys. Rev. D 83, 014010 (2011).
  41. Z.-Y. Zhou and Z. Xiao, Relativistic Friedrichs–Lee model and quark-pair creation model, Eur. Phys. J. C 80, 1191 (2020).
  42. Y. Li and J.-J. Wu, Inverse scattering problem with a bare state, Phys. Rev. D 105, 116024 (2022).
  43. J. Weinstein and N. Isgur, Do multiquark hadrons exist?, Phys. Rev. Lett. 48, 659 (1982).
  44. J. Weinstein and N. Isgur, qqqq− system in a potential model, Phys. Rev. D 27, 588 (1983).
  45. J. Weinstein and N. Isgur, kK¯ molecules, Phys. Rev. D 41, 2236 (1990).
  46. R. K. Bhaduri, L. E. Cohler, and Y. Nogami, Quark-quark interaction and the nonrelativistic quark model, Phys. Rev. Lett. 44, 1369 (1980).
  47. S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
  48. E. Hiyama, Y. Kino, and M. Kamimura, Gaussian expansion method for few-body systems, Prog. Part. Nucl. Phys. 51, 223 (2003).
  49. P. Estabrooks and A. Martin, ππ phase-shift analysis below the KK¯ threshold, Nucl. Phys. B79, 301 (1974).
  50. S. D. Protopopescu, M. Alston-Garnjost, A. Barbaro-Galtieri, S. M. Flatté, J. H. Friedman, T. A. Lasinski, G. R. Lynch, M. S. Rabin, and F. T. Solmitz, ππ partial-wave analysis from reactions π+p→π+π−Δ++ and π+p→K+K−Δ++ at 7.1  GeV/c, Phys. Rev. D 7, 1279 (1973).
  51. B. Hyams et al., ππ phase shift analysis from 600-MeV to 1900-MeV, Nucl. Phys. B64, 134 (1973).
  52. F. Vidal and J. LeTourneux, Multichannel scattering with nonlocal and confining potentials. I. General theory, Phys. Rev. C 45, 418 (1992).
