Searching for dark matter annihilation in the Sun with the IceCube Upgrade

Dan Hooper* and Fabrizio Vassallo†

  • Department of Physics, Wisconsin IceCube Particle Astrophysics Center, University of Wisconsin, Madison, Wisconsin 53706, USA

  • *Contact author: dwhooper@wisc.edu
  • †Contact author: fevassallo@wisc.edu
PDF

Phys. Rev. D 112, 035014 – Published 12 August, 2025

DOI: https://doi.org/10.1103/qj8m-v4mr

Abstract

The IceCube Upgrade will provide unprecedented sensitivity to dark matter particles annihilating in the core of the Sun. For dark matter candidates with spin-dependent couplings to nuclei and that annihilate significantly to tau leptons or neutrinos, we find that the IceCube Upgrade will be capable of testing parameter space that is beyond the reach of existing direct detection experiments. After calculating the sensitivity of the IceCube Upgrade to dark matter annihilation in the Sun, we explore dark matter models that could be tested by this experiment, identifying two classes of scenarios as promising targets for such searches.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (87)

  1. T. Daylan, D. P. Finkbeiner, D. Hooper, T. Linden, S. K. N. Portillo, N. L. Rodd, and T. R. Slatyer, The characterization of the gamma-ray signal from the central Milky Way: A case for annihilating dark matter, Phys. Dark Universe 12, 1 (2016).
  2. D. Hooper and T. Linden, On the origin of the gamma rays from the galactic center, Phys. Rev. D 84, 123005 (2011).
  3. D. Hooper and L. Goodenough, Dark matter annihilation in the galactic center as seen by the fermi gamma ray space telescope, Phys. Lett. B 697, 412 (2011).
  4. L. Goodenough and D. Hooper, Possible evidence for dark matter annihilation in the inner Milky Way from the fermi gamma ray space telescope, arXiv:0910.2998.
  5. M. Ajello et al. (Fermi-LAT Collaboration), Fermi-LAT observations of high-energy γ-ray emission toward the galactic center, Astrophys. J. 819, 44 (2016).
  6. M. Ackermann et al. (Fermi-LAT Collaboration), The fermi galactic center GeV excess and implications for dark matter, Astrophys. J. 840, 43 (2017).
  7. M. Ackermann et al. (Fermi-LAT Collaboration), Constraints on the galactic halo dark matter from Fermi-LAT diffuse measurements, Astrophys. J. 761, 91 (2012).
  8. M. Ackermann et al. (Fermi-LAT Collaboration), Search for gamma-ray spectral lines with the Fermi Large Area Telescope and dark matter implications, Phys. Rev. D 88, 082002 (2013).
  9. A. McDaniel, M. Ajello, C. M. Karwin, M. Di Mauro, A. Drlica-Wagner, and M. A. Sánchez-Conde, Legacy analysis of dark matter annihilation from the Milky Way dwarf spheroidal galaxies with 14 years of Fermi-LAT data, Phys. Rev. D 109, 063024 (2024).
  10. M. Di Mauro, M. Stref, and F. Calore, Investigating the effect of Milky Way dwarf spheroidal galaxies extension on dark matter searches with Fermi-LAT data, Phys. Rev. D 106, 123032 (2022).
  11. L. Bergstrom, T. Bringmann, I. Cholis, D. Hooper, and C. Weniger, New limits on dark matter annihilation from AMS cosmic ray positron data, Phys. Rev. Lett. 111, 171101 (2013).
  12. F. Calore, M. Cirelli, L. Derome, Y. Genolini, D. Maurin, P. Salati, and P. D. Serpico, AMS-02 antiprotons and dark matter: Trimmed hints and robust bounds, SciPost Phys. 12, 163 (2022).
  13. A. Cuoco, M. Krämer, and M. Korsmeier, Novel dark matter constraints from antiprotons in light of AMS-02, Phys. Rev. Lett. 118, 191102 (2017).
  14. M.-Y. Cui, Q. Yuan, Y.-L. S. Tsai, and Y.-Z. Fan, Possible dark matter annihilation signal in the AMS-02 antiproton data, Phys. Rev. Lett. 118, 191101 (2017).
  15. I. Cholis, T. Linden, and D. Hooper, A robust excess in the cosmic-ray antiproton spectrum: Implications for annihilating dark matter, Phys. Rev. D 99, 103026 (2019).
  16. P. De La Torre Luque, M. W. Winkler, and T. Linden, Cosmic-ray propagation models elucidate the prospects for antinuclei detection, J. Cosmol. Astropart. Phys. 10 (2024) 017.
  17. M. W. Winkler, P. De La Torre Luque, and T. Linden, Cosmic ray antihelium from a strongly coupled dark sector, Phys. Rev. D 107, 123035 (2023).
  18. I. Cholis, T. Linden, and D. Hooper, Antideuterons and antihelium nuclei from annihilating dark matter, Phys. Rev. D 102, 103019 (2020).
  19. R. Abbasi et al. (IceCube Collaboration), Search for GeV-scale dark matter annihilation in the Sun with IceCube DeepCore, Phys. Rev. D 105, 062004 (2022).
  20. M. G. Aartsen et al. (IceCube Collaboration and PICO Collaboration), Velocity independent constraints on spin-dependent DM-nucleon interactions from IceCube and PICO, Eur. Phys. J. C 80, 819 (2020).
  21. M. G. Aartsen et al. (IceCube Collaboration), Search for annihilating dark matter in the Sun with 3 years of IceCube data, Eur. Phys. J. C 77, 146 (2017); 79, 214(E) (2019).
  22. M. G. Aartsen et al. (IceCube Collaboration), Improved limits on dark matter annihilation in the Sun with the 79-string IceCube detector and implications for supersymmetry, J. Cosmol. Astropart. Phys. 04 (2016) 022.
  23. S. Adrian-Martinez et al. (ANTARES Collaboration), Limits on dark matter annihilation in the Sun using the ANTARES neutrino telescope, Phys. Lett. B 759, 69 (2016).
  24. K. Choi et al. (Super-Kamiokande Collaboration), Search for neutrinos from annihilation of captured low-mass dark matter particles in the Sun by Super-Kamiokande, Phys. Rev. Lett. 114, 141301 (2015).
  25. M. G. Aartsen et al. (IceCube Collaboration), Search for dark matter annihilations in the Sun with the 79-string IceCube detector, Phys. Rev. Lett. 110, 131302 (2013).
  26. R. Abbasi et al. (IceCube Collaboration), Multi-year search for dark matter annihilations in the Sun with the AMANDA-II and IceCube detectors, Phys. Rev. D 85, 042002 (2012).
  27. R. Abbasi et al. (IceCube Collaboration), Limits on a muon flux from neutralino annihilations in the Sun with the IceCube 22-string detector, Phys. Rev. Lett. 102, 201302 (2009).
  28. S. Desai et al. (Super-Kamiokande Collaboration), Search for dark matter WIMPs using upward through-going muons in Super-Kamiokande, Phys. Rev. D 70, 083523 (2004); 70, 109901(E) (2004).
  29. A. Berlin and D. Hooper, High-energy neutrinos from millicharged dark matter annihilation in the Sun, Phys. Rev. D 110, 075018 (2024).
  30. T. N. Maity, A. K. Saha, S. Mondal, and R. Laha, Neutrinos from the Sun can discover dark matter-electron scattering, Phys. Rev. D 112, 023025 (2025).
  31. D. Krishna, R. Sherpa, A. K. Saha, T. N. Maity, R. Laha, and N. Raj, ν limits from Super-Kamiokande on dark matter-electron scattering in the Sun, arXiv:2503.07713.
  32. A. Ishihara (IceCube Collaboration), The IceCube Upgrade—Design and science goals, Proc. Sci. ICRC2019 (2021) 1031 [arXiv:1908.09441].
  33. M. G. Aartsen et al. (IceCube-Gen2 Collaboration), Combined sensitivity to the neutrino mass ordering with JUNO, the IceCube Upgrade, and PINGU, Phys. Rev. D 101, 032006 (2020).
  34. P. Eller et al. (IceCube Collaboration), Sensitivity of the IceCube Upgrade to atmospheric neutrino oscillations, Proc. Sci. ICRC2023 (2023) 1036 [arXiv:2307.15295].
  35. M. Rongen and D. Chirkin (IceCube Collaboration), Advances in IceCube ice modelling & what to expect from the Upgrade, J. Instrum. 16, C09014 (2021).
  36. S. Baur (IceCube Collaboration), Dark matter searches with the IceCube Upgrade, Proc. Sci. ICRC2019 (2020) 506 [arXiv:1908.08236].
  37. J. Aalbers et al. (LZ Collaboration), Dark matter search results from 4.2 Tonne-Years of exposure of the LUX-ZEPLIN (LZ) Experiment, Phys. Rev. Lett. 135, 011802 (2025).
  38. E. Aprile et al. (XENON Collaboration), WIMP dark matter search using a 3.1  tonne×year exposure of the XENONnT experiment, arXiv:2502.18005.
  39. C. Amole et al. (PICO Collaboration), Dark matter search results from the complete exposure of the PICO-60  C3F8 bubble chamber, Phys. Rev. D 100, 022001 (2019).
  40. G. Angloher et al. (CRESST Collaboration), Results on sub-GeV dark matter from a 10 eV threshold CRESST-III silicon detector, Phys. Rev. D 107, 122003 (2023).
  41. A. H. Abdelhameed et al. (CRESST Collaboration), First results from the CRESST-III low-mass dark matter program, Phys. Rev. D 100, 102002 (2019).
  42. E. Calabrese et al., The Atacama cosmology telescope: DR6 constraints on extended cosmological models, arXiv:2503.14454.
  43. N. Aghanim et al. (Planck Collaboration), Planck 2018 results. VI. Cosmological parameters, Astron. Astrophys. 641, A6 (2020); 652, C4(E) (2021).
  44. L. M. Krauss, K. Freese, D. N. Spergel, and W. H. Press, Cold dark matter candidates and the solar neutrino problem, Astrophys. J. 299, 1001 (1985).
  45. W. H. Press and D. N. Spergel, Capture by the sun of a galactic population of weakly interacting massive particles, Astrophys. J. 296, 679 (1985).
  46. K. Griest and D. Seckel, Cosmic asymmetry, neutrinos and the Sun, Nucl. Phys. B283, 681 (1987); B296, 1034(E) (1988).
  47. A. Gould, WIMP distribution in and evaporation from the Sun, Astrophys. J. 321, 560 (1987).
  48. A. Gould and G. Raffelt, Thermal conduction by massive particles, Astrophys. J. 352, 654 (1990).
  49. J. Silk, K. A. Olive, and M. Srednicki, The photino, the Sun and high-energy neutrinos, Phys. Rev. Lett. 55, 257 (1985).
  50. M. Srednicki, K. A. Olive, and J. Silk, High-energy neutrinos from the Sun and cold dark matter, Nucl. Phys. B279, 804 (1987).
  51. M. Kamionkowski, Energetic neutrinos from heavy neutralino annihilation in the sun, Phys. Rev. D 44, 3021 (1991).
  52. V. D. Barger, F. Halzen, D. Hooper, and C. Kao, Indirect search for neutralino dark matter with high-energy neutrinos, Phys. Rev. D 65, 075022 (2002).
  53. T. Flacke, A. Menon, D. Hooper, and K. Freese, Kaluza-Klein dark matter and neutrinos from annihilation in the Sun, arXiv:0908.0899.
  54. P. Schuster, N. Toro, and I. Yavin, Terrestrial and solar limits on long-lived particles in a dark sector, Phys. Rev. D 81, 016002 (2010).
  55. B. Batell, M. Pospelov, A. Ritz, and Y. Shang, Solar gamma rays powered by secluded dark matter, Phys. Rev. D 81, 075004 (2010).
  56. A. Widmark, Thermalization time scales for wimp capture by the sun in effective theories, J. Cosmol. Astropart. Phys. 05 (2017) 046.
  57. R. Catena and B. Schwabe, Form factors for dark matter capture by the sun in effective theories, J. Cosmol. Astropart. Phys. 04 (2015) 042.
  58. A. Gould, Resonant enhancements in weakly interacting massive particle capture by the Earth, Astrophys. J. 321, 571 (1987).
  59. S. Sivertsson and J. Edsjo, WIMP diffusion in the solar system including solar WIMP-nucleon scattering, Phys. Rev. D 85, 123514 (2012).
  60. A. Gould, Gravitational diffusion of solar system WIMPs, Astrophys. J. 368, 610 (1991).
  61. A. Gould, Cosmological density of WIMPs from solar and terrestrial annihilations, Astrophys. J. 388, 338 (1992).
  62. A. Gould, Resonant enhancements in WIMP capture by the Earth, Astrophys. J. 321, 571 (1987).
  63. J. Edsjo, Aspects of neutrino detection of neutralino dark matter, arXiv:hep-ph/9704384.
  64. G. Jungman and M. Kamionkowski, Neutrinos from particle decay in the sun and earth, Phys. Rev. D 51, 328 (1995).
  65. D. Hooper, F. Petriello, K. M. Zurek, and M. Kamionkowski, The new DAMA dark-matter window and energetic-neutrino searches, Phys. Rev. D 79, 015010 (2009).
  66. A. L. Fitzpatrick, D. Hooper, and K. M. Zurek, Implications of CoGeNT and DAMA for light WIMP dark matter, Phys. Rev. D 81, 115005 (2010).
  67. P. Crotty, High-energy neutrino fluxes from supermassive dark matter, Phys. Rev. D 66, 063504 (2002).
  68. R. Gandhi, C. Quigg, M. H. Reno, and I. Sarcevic, Ultrahigh-energy neutrino interactions, Astropart. Phys. 5, 81 (1996).
  69. S. I. Dutta, M. H. Reno, I. Sarcevic, and D. Seckel, Propagation of muons and taus at high-energies, Phys. Rev. D 63, 094020 (2001).
  70. E. Richard et al. (Super-Kamiokande Collaboration), Measurements of the atmospheric neutrino flux by Super-Kamiokande: Energy spectra, geomagnetic effects, and solar modulation, Phys. Rev. D 94, 052001 (2016).
  71. P. Agnes et al. (DarkSide-50 Collaboration), Search for low-mass dark matter WIMPs with 12 ton-day exposure of DarkSide-50, Phys. Rev. D 107, 063001 (2023).
  72. N. F. Bell, M. J. Dolan, and S. Robles, Searching for dark matter in the Sun using Hyper-Lamiokande, J. Cosmol. Astropart. Phys. 11 (2021) 004.
  73. A. Tumasyan et al. (CMS Collaboration), Search for resonant and nonresonant production of pairs of dijet resonances in proton-proton collisions at s=13  TeV, J. High Energy Phys. 07 (2023) 161.
  74. A. M. Sirunyan et al. (CMS Collaboration), Search for dijet resonances in proton–proton collisions at s=13  TeV and constraints on dark matter and other models, Phys. Lett. B 769, 520 (2017); 772, 882(E) (2017).
  75. M. Aaboud et al. (ATLAS Collaboration), Search for low-mass dijet resonances using trigger-level jets with the ATLAS detector in pp collisions at s=13  TeV, Phys. Rev. Lett. 121, 081801 (2018).
  76. V. Khachatryan et al. (CMS Collaboration), Search for narrow resonances in dilepton mass spectra in proton-proton collisions at s=13  TeV and combination with 8 TeV data, Phys. Lett. B 768, 57 (2017).
  77. A. M. Sirunyan et al. (CMS Collaboration), Search for high-mass resonances in dilepton final states in proton-proton collisions at s=13  TeV, J. High Energy Phys. 06 (2018) 120.
  78. G. Aad et al. (ATLAS Collaboration), Search for high-mass dilepton resonances using 139  fb−1 of pp collision data collected at s=13  TeV with the ATLAS detector, Phys. Lett. B 796, 68 (2019).
  79. A. Berlin, D. Hooper, and S. D. McDermott, Simplified dark matter models for the galactic center gamma-ray excess, Phys. Rev. D 89, 115022 (2014).
  80. D. P. Finkbeiner, S. Galli, T. Lin, and T. R. Slatyer, Searching for dark matter in the CMB: A compact parametrization of energy injection from new physics, Phys. Rev. D 85, 043522 (2012).
  81. T. R. Slatyer, Indirect dark matter signatures in the cosmic dark ages. I. Generalizing the bound on s-wave dark matter annihilation from Planck results, Phys. Rev. D 93, 023527 (2016).
  82. H.-Y. Cheng and C.-W. Chiang, Revisiting scalar and pseudoscalar couplings with nucleons, J. High Energy Phys. 07 (2012) 009.
  83. A. Hayrapetyan et al. (CMS Collaboration), Search for new physics in multijet events with at least one photon and large missing transverse momentum in proton-proton collisions at 13 TeV, J. High Energy Phys. 10 (2023) 046.
  84. T. C. Collaboration et al. (CMS Collaboration), Search for supersymmetry in proton-proton collisions at 13 TeV in final states with jets and missing transverse momentum, J. High Energy Phys. 10 (2019) 244.
  85. G. Aad et al. (ATLAS Collaboration), The quest to discover supersymmetry at the ATLAS experiment, Phys. Rep. 1116, 261 (2025).
  86. G. Aad et al. (ATLAS Collaboration), Search for squarks and gluinos in final states with one isolated lepton, jets, and missing transverse momentum at s=13 with the ATLAS detector, Eur. Phys. J. C 81, 600 (2021); 81, 956(E) (2021).
  87. P. Langacker, The physics of heavy Z′ gauge bosons, Rev. Mod. Phys. 81, 1199 (2009).
