First axion search results of the SUPAX prototype experiment

T. Schneemann*

H. Bekker and A. Wickenbrock

D. Budker

K. Schmieden† and M. Schott

M. Unni

  • *Contact author: tischnee@uni-mainz.de
  • †Contact author: kristof.schmieden@cern.ch
PDF

Phys. Rev. D 114, 032012 – Published 24 August, 2026

DOI: https://doi.org/10.1103/n4gd-k232

Abstract

The SUPerconduction AXion search experiment (supax) is a future haloscope-type detector designed to probe axionlike particles as candidates for dark matter and solutions to the strong-CP problem in the mass range between 8  μeV and 30  μeV. In the course of the preparation of supax, a prototype experiment was built and operated. Using a copper cavity, cooled down to a temperature of 2 K and operated in a magnetic field of 12 T, we probe axion masses around 34  μeV and exclude axion-photon couplings down to |gaγγ|>1.6×10−13  GeV−1. The data were also used to exclude dark photons in the same mass range with a kinetic mixing parameter of χ>1.4×10−12. Details of the experimental setup and the analysis strategy are summarized in this paper.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (29)

  1. R. D. Peccei and H. R. Quinn, CP conservation in the presence of pseudoparticles, Phys. Rev. Lett. 38, 1440 (1977).
  2. F. Wilczek, Problem of strong P and T invariance in the presence of instantons, Phys. Rev. Lett. 40, 279 (1978).
  3. S. Weinberg, A new light boson?, Phys. Rev. Lett. 40, 223 (1978).
  4. J. Preskill, M. B. Wise, and F. Wilczek, Cosmology of the invisible axion, Phys. Lett. 120B, 127 (1983).
  5. L. Abbott and P. Sikivie, A cosmological bound on the invisible axion, Phys. Lett. 120B, 133 (1983).
  6. M. Dine and W. Fischler, The not-so-harmless axion, Phys. Lett. 120B, 137 (1983).
  7. J. Ipser and P. Sikivie, Are galactic halos made of axions?, Phys. Rev. Lett. 50, 925 (1983).
  8. M. S. Turner, F. Wilczek, and A. Zee, Formation of structure in an axion dominated universe, Phys. Lett. 125B, 35 (1983); 125B, 519(E) (1983).
  9. Z. G. Berezhiani and M. Y. Khlopov, Cosmology of spontaneously broken gauge family symmetry, Z. Phys. C 49, 73 (1991).
  10. K. Saikawa, J. Redondo, A. Vaquero, and M. Kaltschmidt, Spectrum of global string networks and the axion dark matter mass, J. Cosmol. Astropart. Phys. 10 (2024) 043.
  11. H. Primakoff, Photoproduction of neutral mesons in nuclear electric fields and the mean life of the neutral meson, Phys. Rev. 81, 899 (1951).
  12. P. Sikivie, Experimental tests of the invisible axion, Phys. Rev. Lett. 51, 1415 (1983); 52, 695(E) (1984).
  13. R. Khatiwada et al. (ADMX Collaboration), Axion dark matter experiment: Detailed design and operations, Rev. Sci. Instrum. 92, 124502 (2021).
  14. S. J. Asztalos, G. Carosi, C. Hagmann, D. Kinion, K. van Bibber, M. Hotz, L. J. Rosenberg, G. Rybka, J. Hoskins, J. Hwang, P. Sikivie, D. B. Tanner, R. Bradley, J. Clarke (ADMX Collaboration), SQUID-based microwave cavity search for dark-matter axions, Phys. Rev. Lett. 104, 041301 (2010).
  15. L. Zhong et al. (HAYSTAC Collaboration), Results from phase 1 of the HAYSTAC microwave cavity axion experiment, Phys. Rev. D 97, 092001 (2018).
  16. X. Bai et al. (HAYSTAC Collaboration), Dark matter axion search with HAYSTAC phase II, Phys. Rev. Lett. 134, 151006 (2025).
  17. S. Ahyoune et al., RADES axion search results with a high-temperature superconducting cavity in an 11.7 T magnet, J. High Energy Phys. 04 (2025) 113.
  18. A. Rettaroli et al. (QUAX Collaboration), Search for axion dark matter with the QUAX–LNF tunable haloscope, Phys. Rev. D 110, 022008 (2024).
  19. Y. Kim, J. Jeong, S. Youn, S. Bae, K. Lee, A. F. van Loo, Y. Nakamura, S. Oh, T. Seong, S. Uchaikin, J. E. Kim, and Y. K. Semertzidis, Experimental search for invisible dark matter axions around 22  μeV, Phys. Rev. Lett. 133, 051802 (2024).
  20. S. Ahn et al., Extensive search for axion dark matter over 1 GHz with Capp’s main axion experiment, Phys. Rev. X 14, 031023 (2024).
  21. D. Chouhan, T. Schneemann, K. Schmieden, and M. Schott, Conceptual design report of the SUPAX experiment, Nucl. Instrum. Methods Phys. Res., Sect. A 1092, 171896 (2026).
  22. D. J. E. Marsh, Axion cosmology, Phys. Rep. 643, 1 (2016).
  23. L. Di Luzio, M. Giannotti, E. Nardi, and L. Visinelli, The landscape of QCD axion models, Phys. Rep. 870, 1 (2020).
  24. P. Sikivie, Detection rates for “invisible” axion searches, Phys. Rev. D 32, 2988 (1985); 36, 974(E) (1987).
  25. A. Savitzky and M. J. E. Golay, Smoothing and differentiation of data by simplified least squares procedures, Anal. Chem. 36, 1627 (2002).
  26. M. S. Turner, Periodic signatures for the detection of cosmic axions, Phys. Rev. D 42, 3572 (1990).
  27. A. Caputo, A. J. Millar, C. A. O’Hare, and E. Vitagliano, Dark photon limits: A handbook, Phys. Rev. D 104, 095029 (2021).
  28. C. O’Hare, cajohare/axionlimits: Axionlimits, (2020).
  29. D. Amaral et al., Global detector network to search for high-frequency gravitational waves (GravNet): Conceptual design, arXiv:2603.24645.
