Open Access

Odd-parity strange baryons $Σ ({\frac{1}{2}}^{-})$ below 1.8 GeV with a Hamiltonian effective field theory

Zhong-Lin Ma ^1,2,3, Zhan-Wei Liu ^1,2,3,*, and Jiong-Jiong Liu ^4,1

¹School of Physical Science and Technology, Lanzhou University, Lanzhou 730000, China
²Research Center for Hadron and CSR Physics, Lanzhou University and Institute of Modern Physics of CAS, Lanzhou 730000, China
³Lanzhou Center for Theoretical Physics, MoE Frontiers Science Center for Rare Isotopes, Key Laboratory of Quantum Theory and Applications of MoE, Key Laboratory of Theoretical Physics of Gansu Province, Gansu Provincial Research Center for Basic Disciplines of Quantum Physics, Lanzhou University, Lanzhou 730000, China
⁴State Grid Xinjiang Electric Power Research Institute, Urumqi 830011, Xinjiang, China

^*Contact author: liuzhanwei@lzu.edu.cn

Phys. Rev. D 113, 014037 – Published 29 January, 2026

DOI: https://doi.org/10.1103/m32c-wk63

Abstract

We examine the spectrum of the $Σ ({\frac{1}{2}}^{-})$ family based on the experimental $K^{-} p$ scattering data and lattice QCD simulations within the Hamiltonian effective field theory. Especially, two different scenarios are constructed in order to clarify whether there is one or two $Σ ({\frac{1}{2}}^{-})$ resonances with masses around 1.5–1.7 GeV. The relevant lattice QCD data support our scenario with two resonance poles at $1687 - 110 i$ and $1714 - 14 i MeV$ in which the bare strange triquark core plays an important role. We also show an extra clear cusp structure around 1.4 GeV in our scattering T matrices associated with the odd-parity strange baryons.

Physics Subject Headings (PhySH)

Article Text

References (93)

M. Sumihama et al. (Belle Collaboration), Observation of $Ξ (1620)^{0}$ and evidence for $Ξ (1690)^{0}$ in $Ξ_{c}^{+} \to Ξ^{-} π^{+} π^{+}$ decays, Phys. Rev. Lett. 122, 072501 (2019).
R. Aaij et al. (LHCb Collaboration), Observation of $J / ψ p$ resonances consistent with pentaquark states in $Λ_{b}^{0} \to J / ψ K^{-} p$ decays, Phys. Rev. Lett. 115, 072001 (2015).
R. Aaij et al. (LHCb Collaboration), Observation of a narrow pentaquark state, $P_{c} (4312)^{+}$ , and of two-peak structure of the $P_{c} (4450)^{+}$ , Phys. Rev. Lett. 122, 222001 (2019).
R. Aaij et al. (LHCb Collaboration), Study of the doubly charmed tetraquark $T_{c c}^{+}$ , Nat. Commun. 13, 3351 (2022).
R. Aaij et al. (LHCb Collaboration), Observation of an exotic narrow doubly charmed tetraquark, Nat. Phys. 18, 751 (2022).
A. Feijoo, D. Gazda, V. Magas, and A. Ramos, The $\bar{K} N$ interaction in higher partial waves, Symmetry 13, 1434 (2021).
M. Ablikim et al. (BESIII Collaboration), Partial wave analysis of $ψ (3686) \to Λ {\bar{Σ}}^{0} π^{0} + c . c$ , J. High Energy Phys. 02 (2025) 212.
F. L. Wang, S. Q. Luo, R. Q. Qian, and X. Liu, Spectroscopic properties of double-strangeness molecular tetraquarks, Phys. Rev. D 110, 114041 (2024).
C. Helminen and D. O. Riska, Low lying $q q q q \bar{q}$ states in the baryon spectrum, Nucl. Phys. A699, 624 (2002).
A. Zhang, Y. R. Liu, P. Z. Huang, W. Z. Deng, X. L. Chen, and S. L. Zhu, $J^{P} = {\frac{1}{2}}^{-}$ pentaquarks in Jaffe and Wilczek’s diquark model, High Energy Phys. Nucl. Phys. 29, 250 (2005).
D. Jido, J. A. Oller, E. Oset, A. Ramos, and U. G. Meissner, Chiral dynamics of the two $Λ (1405)$ states, Nucl. Phys. A725, 181 (2003).
J. A. Oller and U. G. Meissner, Chiral dynamics in the presence of bound states: Kaon nucleon interactions revisited, Phys. Lett. B 500, 263 (2001).
K. P. Khemchandani, A. Martínez Torres, and J. A. Oller, Hyperon resonances coupled to pseudoscalar- and vector-baryon channels, Phys. Rev. C 100, 015208 (2019).
Y. Kamiya, K. Miyahara, S. Ohnishi, Y. Ikeda, T. Hyodo, E. Oset, and W. Weise, Antikaon-nucleon interaction and $Λ$ (1405) in chiral SU(3) dynamics, Nucl. Phys. A954, 41 (2016).
J. A. Oller, On the strangeness -1 S-wave meson-baryon scattering, Eur. Phys. J. A 28, 63 (2006).
H. P. Li, C. W. Xiao, W. H. Liang, J. J. Wu, E. Wang, and E. Oset, How to unravel the nature of the $Σ * (1430) (1 / 2 −)$ state from correlation functions, Phys. Rev. D 110, 114018 (2024).
B. S. Zou, Five-quark components in baryons, Nucl. Phys. A835, 199 (2010).
J. X. Lu, L. S. Geng, M. Doering, and M. Mai, Cross-channel constraints on resonant Antikaon-Nucleon scattering, Phys. Rev. Lett. 130, 071902 (2023).
J. He, Role of $Σ^{*} (1 / 2^{-})$ baryons in $Λ_{c} \to Λ π^{+} π^{+} π^{-}$ decay, Phys. Rev. C 112, 015205 (2025).
J. X. Lin, J. Song, M. Albaladejo, A. Feijoo, and E. Oset, Testing the nature of the $Σ$ *(1430), Phys. Rev. D 112, 014044 (2025).
L. Roca and E. Oset, Isospin 0 and 1 resonances from $π Σ$ photoproduction data, Phys. Rev. C 88, 055206 (2013).
J. K. Kim, $\bar{K} N$ interaction in the region 0 to 1200 mev/c and hyperon resonances, Phys. Rev. Lett. 27, 356 (1971).
W. Langbein and F. Wagner, An energy independent coupled channel phase shift analysis for the $\bar{K} N$ system, Nucl. Phys. B47, 477 (1972).
M. D. Jones, A study of the reaction $K^{-} p \to Σ^{0} η$ near threshold, Nucl. Phys. B73, 141 (1974).
D. Guo, J. Shi, I. Strakovsky, and B. S. Zou, Analysis of $Σ^{*}$ via isospin selective reaction $K_{L} p \to π^{+} Σ^{0}$ , Phys. Rev. D 112, 034006 (2025).
P. Gao, J. Shi, and B. S. Zou, $Σ$ Resonances from $K^{-} N \to π Λ$ reactions with the center of mass energy from 1550 to 1676 MeV, Phys. Rev. C 86, 025201 (2012).
X. H. Zhong and Q. Zhao, Low energy reactions $K^{-} p \to Σ^{0} π^{0}$ , $Λ π^{0}$ , ${\bar{K}}^{0} n$ and the strangeness $S = - 1$ hyperons, Phys. Rev. C 88, 015208 (2013).
D. Faiman, Sigma (1750): A hadron and its constituents, Nuovo Cimento Soc. Ital. Fis. 30A, 498 (1975).
H. Kamano, S. X. Nakamura, T. S. H. Lee, and T. Sato, Dynamical coupled-channels model of $K^{-} p$ reactions: Determination of partial-wave amplitudes, Phys. Rev. C 90, 065204 (2014).
H. Kamano, S. X. Nakamura, T. S. H. Lee, and T. Sato, Dynamical coupled-channels model of $K^{-} p$ reactions. II. Extraction of $Λ^{*}$ and $Σ^{*}$ hyperon resonances, Phys. Rev. C 92, 025205 (2015); 95, 049903(E) (2017).
E. Wang, L. S. Geng, J. J. Wu, J. J. Xie, and B. S. Zou, Review of the low-lying excited baryons $Σ^{*} (1 / 2^{-})$ , Chin. Phys. Lett. 41, 101401 (2024).
B. Conforto et al. (Rutherford-London Collaboration), $K^{-} p$ reactions from 0.96-GeV/c to 1.355-GeV/c involving two-body final states, Nucl. Phys. B105, 189 (1976).
S. Prakhov, B. M. K. Nefkens, V. Bekrenev, W. J. Briscoe, N. Knecht, A. Koulbardis, N. Kozlenko, S. Kruglov, G. Lolos, I. Lopatin et al., Measurement of $π^{0} Λ$ , $\bar{K^{0}} n$ , and $π^{0} Σ^{0}$ production in $K^{-} p$ interactions for $p (K^{-})$ between 514 and 750 MeV/c, Phys. Rev. C 80, 025204 (2009).
M. Alston-Garnjost, R. W. Kenney, D. L. Pollard, R. R. Ross, R. D. Tripp, H. Nicholson, and M. Ferro-Luzzi, Precision measurement of the $K^{-} p \to \bar{K^{0}} n$ cross-section below 1.1-GeV/c, Phys. Rev. Lett. 38, 1003 (1977).
R. Armenteros, P. Baillon, C. Bricman, M. Ferro-Luzzi, D. E. Plane, N. Schmitz, E. Burkhardt, H. Filthuth, E. Kluge, H. Oberlack et al., New experimental results on the reations $K^{-} p \to \bar{K^{0}} n$ and $K^{-} p \to π Σ$ and a partial-wave analysis between 430 and 800 mev/c, Nucl. Phys. B14, 91 (1969).
R. Armenteros, P. Baillon, C. Bricman, M. Ferro-Luzzi, E. Pagiola, J. O. Petersen, D. E. Plane, N. Schmitz, E. Burkhardt, H. Filthuth et al., $K^{-} p$ cross-sections from 440 to 800 mev/c, Nucl. Phys. B21, 15 (1970).
S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
M. Tanabashi et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 98, 030001 (2018).
Y. Ma et al. (Belle Collaboration), First observation of $Λ π^{+}$ and $Λ π^{-}$ signals near the $K^{-} N$ ( $I = 1$ ) mass threshold in $Λ_{c}^{+} \to Λ π^{+} π^{+} π^{-}$ decay, Phys. Rev. Lett. 130, 151903 (2023).
M. Ablikim et al. (BESIII Collaboration), Observation of $Λ_{c}^{+} \to Λ a_{0} (980)^{+}$ and evidence for $Σ (1380)^{+}$ in $Λ_{c}^{+} \to Λ π^{+} η$ , Phys. Rev. Lett. 134, 021901 (2025).
K. Moriya et al. (CLAS Collaboration), Measurement of the $Σ$ $π$ photoproduction line shapes near the $Λ$ (1405), Phys. Rev. C 87, 035206 (2013).
K. Wang, Y. F. Wang, B. C. Liu, and F. Huang, Search for the $Σ$ (1380)1/2-state in $Λ_{c}^{+} \to π^{+} Λ γ$ decay by triangle singularity, Phys. Rev. D 110, 094017 (2024).
W. T. Lyu, S. C. Zhang, G. Y. Wang, J. J. Wu, E. Wang, L. S. Geng, and J. J. Xie, Evidence of the low-lying baryon $Σ ({\frac{1}{2}}^{-})$ in the process $Λ c + \to η π + Λ$ , Phys. Rev. D 110, 054020 (2024).
J. J. Xie and L. S. Geng, $Σ_{1 / 2^{-}}^{*} (1380)$ in the $Λ_{c}^{+} \to η π^{+} Λ$ decay, Phys. Rev. D 95, 074024 (2017).
J. J. Wu, S. Dulat, and B. S. Zou, Evidence for a new Sigma* resonance with $J^{P} = 1 / 2^{-}$ in the old data of $K^{-} p \to Λ π^{+} π^{-}$ reaction, Phys. Rev. D 80, 017503 (2009).
Y. Li, W. T. Lyu, G. Y. Wang, L. Li, W. C. Yan, and E. Wang, Study of $Ξ c + \to Λ K^{-} 0 π +$ and search for the low-lying baryons $Ξ (1 / 2 -)$ and $Σ (1 / 2 -)$ , Phys. Rev. D 111, 054011 (2025).
Q. Huang, Z. X. Ma, J. J. Wu, R. G. Ping, J. He, and H. X. Huang, Role of the triangle singularity in the isospin breaking process $J / ψ \to Λ Λ^{-} π$ and the possible evidence of $Σ * (12 −)$ states, Phys. Rev. D 110, 034018 (2024).
A. Xu, R. Li, X. Luo, and H. Sun, The theoretical study of $p \bar{p} \to \bar{Λ} Σ η$ reaction, Eur. Phys. J. C 84, 1107 (2024).
A. V. Sarantsev, M. Matveev, V. A. Nikonov, A. V. Anisovich, U. Thoma, and E. Klempt, Hyperon II: Properties of excited hyperons, Eur. Phys. J. A 55, 180 (2019).
H. Zhang, J. Tulpan, M. Shrestha, and D. M. Manley, Multichannel parametrization of $\bar{K} N$ scattering amplitudes and extraction of resonance parameters, Phys. Rev. C 88, 035205 (2013).
Z. W. Liu, J. M. M. Hall, D. B. Leinweber, A. W. Thomas, and J. J. Wu, Structure of the $Λ (1405)$ from Hamiltonian effective field theory, Phys. Rev. D 95, 014506 (2017).
J. M. M. Hall, W. Kamleh, D. B. Leinweber, B. J. Menadue, B. J. Owen, A. W. Thomas, and R. D. Young, Lattice QCD evidence that the $Λ$ (1405) resonance is an Antikaon-Nucleon molecule, Phys. Rev. Lett. 114, 132002 (2015).
J. J. Liu, Z. W. Liu, K. Chen, D. Guo, D. B. Leinweber, X. Liu, and A. W. Thomas, Structure of the $Λ$ (1670) resonance, Phys. Rev. D 109, 054025 (2024).
Z. W. Liu, W. Kamleh, D. B. Leinweber, F. M. Stokes, A. W. Thomas, and J. J. Wu, Hamiltonian effective field theory study of the $N^{*} (1535)$ resonance in lattice QCD, Phys. Rev. Lett. 116, 082004 (2016).
C. D. Abell, D. B. Leinweber, Z. W. Liu, A. W. Thomas, and J. J. Wu, Low-lying odd-parity nucleon resonances as quark-model-like states, Phys. Rev. D 108, 094519 (2023).
Y. Zhuge, Z. W. Liu, D. B. Leinweber, and A. W. Thomas, Pion photoproduction of nucleon excited states with Hamiltonian effective field theory, Phys. Rev. D 110, 094015 (2024).
J. J. Wu, T. S. H. Lee, A. W. Thomas, and R. D. Young, Finite-volume Hamiltonian method for coupled-channels interactions in lattice QCD, Phys. Rev. C 90, 055206 (2014).
L. Hockley, C. Abell, D. Leinweber, and A. Thomas, Understanding the nature of the $Δ (1600)$ resonance, Phys. Rev. D 111, 076027 (2025).
F. C. Han, Z. W. Liu, D. B. Leinweber, and A. W. Thomas, Structure of the $Ω^{-} (2012)$ with Hamiltonian effective field theory, Phys. Rev. D 112, L051503 (2025).
J. Bulava et al. (Baryon Scattering (BaSc) Collaboration), Lattice QCD study of $π Σ − K^{-} N$ scattering and the $Λ$ (1405) resonance, Phys. Rev. D 109, 014511 (2024).
J. Bulava et al. (Baryon Scattering (BaSc) Collaboration), Two-pole nature of the $Λ$ (1405) resonance from Lattice QCD, Phys. Rev. Lett. 132, 051901 (2024).
Georg P. Engel, C. B. Lang, Daniel Mohler, and Andreas Schäfer, QCD with two light dynamical chirally improved quarks: Baryons, Phys. Rev. D 87, 074504 (2013).
G. P. Engel, C. B. Lang, M. Limmer, D. Mohler, and A. Schafer, QCD with two light dynamical chirally improved quarks: Mesons, Phys. Rev. D 85, 034508 (2012).
G. P. Engel et al. (BGR (Bern-Graz-Regensburg) Collaboration), Low-lying $Λ$ baryons from the lattice, Phys. Rev. D 87, 034502 (2013).
S. Weinberg, Pion scattering lengths, Phys. Rev. Lett. 17, 616 (1966).
A. W. Thomas, Low-energy pion scattering in the cloudy bag model, J. Phys. G 7, L283 (1981).
K. Piscicchia, M. Skurzok, M. Cargnelli, R. Del Grande, L. Fabbietti, J. Marton, P. Moskal, À. Ramos, A. Scordo, D. L. Sirghi et al., First simultaneous $K - p \to Σ 0 π 0$ , $Λ π 0$ cross section measurements at $98 MeV / c$ , Phys. Rev. C 108, 055201 (2023).
G. S. Abrams and B. Sechi-Zorn, Charge-exchange scattering of low-energy K- mesons in hydrogen, Phys. Rev. 139, B454 (1965).
M. Sakitt, T. B. Day, R. G. Glasser, N. Seeman, J. H. Friedman, W. E. Humphrey, and R. R. Ross, Low-energy K- meson interactions in hydrogen, Phys. Rev. 139, B719 (1965).
J. K. Kim, Low energy $K^{-} p$ interaction of the 1405 MeV $Y_{0}^{*}$ resonance as $\bar{K} N$ bound state, Phys. Rev. Lett. 14, 29 (1965).
T. S. Mast, M. Alston-Garnjost, R. O. Bangerter, A. S. Barbaro-Galtieri, F. T. Solmitz, and R. D. Tripp, Elastic, charge exchange, and total $K^{-} p$ cross-sections in the momentum range 220-MeV/c to 470-MeV/c, Phys. Rev. D 14, 13 (1976).
R. O. Bangerter, M. Alston-Garnjost, A. Barbaro-Galtieri, T. S. Mast, F. T. Solmitz, and R. D. Tripp, Reactions $K^{-} p \to Σ^{-} π^{+}$ and $K^{-} p \to Σ^{+} π^{-}$ in the momentum range from 220-MeV/c to 470-MeV/c, Phys. Rev. D 23, 1484 (1981).
J. Ciborowski et al., Kaon scattering and charged sigma hyperon production in $K^{-} P$ interactions below 300-mev/c, J. Phys. G 8, 13 (1982).
D. Evans, J. V. Major, E. Rondio, J. A. Zakrzewski, J. E. Conboy, D. J. Miller, and T. Tymieniecka, Charge exchange scattering in $K^{-} P$ interactions below 300-MeV/c, J. Phys. G 9, 885 (1983).
T. S. Mast, M. Alston-Garnjost, R. O. Bangerter, A. S. Barbaro-Galtieri, F. T. Solmitz, and R. D. Tripp, The reactions $K^{-} p \to Σ^{0} π^{0}$ and $K^{-} p \to Λ π^{0}$ in the momentum range 240-MeV/c to 450-MeV/c, Phys. Rev. D 11, 3078 (1975).
P. Nordin, S- and P-wave interactions of K- mesons in hydrogen, Phys. Rev. 123, 2168 (1961).
D. Berley, S. P. Yamin, R. R. Kofler, A. Mann, G. W. Meisner, S. S. Yamamoto, J. Thompson, and W. Willis, $K^{-} p$ amplitudes near the $Λ$ (1520), Phys. Rev. D 1, 1996 (1970); 3, 2297(E) (1971).
M. Ferro-Luzzi, R. D. Tripp, and M. B. Watson, Excited hyperon of mass 1520 MeV, Phys. Rev. Lett. 8, 28 (1962).
M. B. Watson, M. Ferro-Luzzi, and R. D. Tripp, Analysis of $Y_{0}^{*}$ (1520) and determination of the sigma parity, Phys. Rev. 131, 2248 (1963).
P. Eberhard, A. H. Rosenfeld, F. T. Solmitz, R. D. Tripp, and M. B. Watson, K–hydrogen charge-exchange scattering, Phys. Rev. Lett. 2, 312 (1959).
M. F. M. Lutz and E. E. Kolomeitsev, Relativistic chiral SU(3) symmetry, large N(c) sum rules and meson baryon scattering, Nucl. Phys. A700, 193 (2002).
G. l. He and R. H. Landau, A cloudy bag model for the S-D wave anti-K—N system, Phys. Rev. C 48, 3047 (1993).
X. H. Zhong and Q. Zhao, The $K^{-} p \to π^{0} Σ^{0}$ reaction at low energies in a chiral quark model, Phys. Rev. C 79, 045202 (2009).
E. Oset and A. Ramos, Nonperturbative chiral approach to s wave anti-K N interactions, Nucl. Phys. A635, 99 (1998).
Y. Ikeda, T. Hyodo, and W. Weise, Chiral SU(3) theory of antikaon-nucleon interactions with improved threshold constraints, Nucl. Phys. A881, 98 (2012).
Z. H. Guo and J. A. Oller, Meson-baryon reactions with strangeness $- 1$ within a chiral framework, Phys. Rev. C 87, 035202 (2013).
M. Mai and U. G. Meißner, Constraints on the chiral unitary $\bar{K} N$ amplitude from $π Σ K^{+}$ photoproduction data, Eur. Phys. J. A 51, 30 (2015).
P. Wang, D. B. Leinweber, A. W. Thomas, and R. D. Young, Chiral extrapolation of nucleon magnetic form factors, Phys. Rev. D 75, 073012 (2007).
C. F. Perdrisat, V. Punjabi, and M. Vanderhaeghen, Nucleon electromagnetic form factors, Prog. Part. Nucl. Phys. 59, 694 (2007).
P. Mergell, U. G. Meissner, and D. Drechsel, Dispersion theoretical analysis of the nucleon electromagnetic form-factors, Nucl. Phys. A596, 367 (1996).
B. Kubis and U. G. Meissner, Low-energy analysis of the nucleon electromagnetic form-factors, Nucl. Phys. A679, 698 (2001).
B. Kubis and U. G. Meissner, Baryon form-factors in chiral perturbation theory, Eur. Phys. J. C 18, 747 (2001).
A. N. Hiller Blin, Systematic study of octet-baryon electromagnetic form factors in covariant chiral perturbation theory, Phys. Rev. D 96, 093008 (2017).

Phys. Rev. D 113, 014037– Published 29 January, 2026

Vol. 113, Iss. 1 — 1 January 2026

Received 24 September 2025
Accepted 14 January 2026

DOI: https://doi.org/10.1103/m32c-wk63

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article’s title, journal citation, and DOI. Funded by SCOAP³.
