Enhancement of dark photon haloscope sensitivity with degenerate modes: Toward axion-level form factor and polarization determination

Jose R. Navarro-Madrid1,*, José Reina-Valero2, Alejandro Díaz-Morcillo1, and Benito Gimeno2

  • *Contact author: joser.navarro@upct.es
PDF

Phys. Rev. D 112, 103029 – Published 14 November, 2025

DOI: https://doi.org/10.1103/l9cq-nj8c

Abstract

The dark photon has been postulated as a potential constituent of dark matter, exhibiting notable similarities to the axion. The primary distinction between the two particles lies in the nature of their respective fields: the dark photon field is a vector field with a polarization direction that remains undetermined. This work explores the prospect of utilizing three degenerate modes for scanning the three dimensions of space in order to mitigate the low form factor expected in the detection of the dark photon due to their unknown polarization. The employment of a haloscope with three orthogonal and degenerate modes in conjunction with the coherent sum of signals is demonstrated in this work in order to enhance the dark photon form factor up to the axion form factor, and to determine the direction of the dark photon polarization vector. We show in this manuscript that the maximum form factor is achieved in cavities of cubic, spherical, and cylindrical geometries, considering the introduction of tuning elements. To achieve this adequately, some conditions reviewed in this article must be fulfilled in the resonant cavity, leading to uncertainties in the final measurement. Finally, this technique can allow the simultaneous search for dark matter axions and dark photons, and to the knowledge of the authors, the method shown in this work is the most effective one for detecting dark photons with microwave resonant cavities.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (27)

  1. R. D. Peccei and H. R. Quinn, CP conservation in the presence of pseudoparticles, Phys. Rev. Lett. 38, 1440 (1977).
  2. S. Weinberg, A new light boson?, Phys. Rev. Lett. 40, 223 (1978).
  3. F. Wilczek, Problem of strong P and T invariance in the presence of instantons, Phys. Rev. Lett. 40, 279 (1978).
  4. E. G. M. Fabbrichesi and G. Lanfranchi, The Physics of the Dark Photon (Springer, Cham, 2020).
  5. A. Caputo, A. J. Millar, C. A. J. O’Hare, and E. Vitagliano, Dark photon limits: A handbook, Phys. Rev. D 104, 095029 (2021).
  6. B. M. Brubaker et al., First results from a microwave cavity axion search at 24μeV, Phys. Rev. Lett. 118, 061302 (2017).
  7. O. Kwon et al., First results from an axion haloscope at CAPP around 10.7μeV, Phys. Rev. Lett. 126, 191802 (2021).
  8. S. Ahyoune et al., RADES axion search results with a high-temperature superconducting cavity in an 11.7 T magnet, J. High Energy Phys. 04 (2025) 113.

  9. All equations in this article are expressed in SI units unless otherwise specified.

  10. P. Sikivie, Experimental tests of the invisible axion, Phys. Rev. Lett. 51, 1415 (1983); 52, 695(E) (1984).
  11. P. Sikivie, Detection rates for invisible-axion searches, Phys. Rev. D 32, 2988 (1985).
  12. C. O’Hare, cajohare/axionlimits: Axionlimits, https://cajohare.github.io/AxionLimits/ (2020).
  13. P. Navarro, B. Gimeno, J. Monzó-Cabrera, A. Díaz-Morcillo, and D. Blas, Study of a cubic cavity resonator for gravitational waves detection in the microwave frequency range, Phys. Rev. D 109, 104048 (2024).
  14. J. Reina-Valero, J. R. Navarro-Madrid, D. Blas, A. Díaz-Morcillo, I. G. Irastorza, B. Gimeno, and J. Monzó-Cabrera, High-frequency gravitational waves detection with the BabyIAXO haloscopes, Phys. Rev. D 111, 043024 (2025).
  15. P. Arias, D. Cadamuro, M. Goodsell, J. Jaeckel, J. Redondo, and A. Ringwald, WISPy cold dark matter, J. Cosmol. Astropart. Phys. 06 (2012) 013.
  16. A. Diaz-Morcillo, J. García Barceló, A. Lozano-Guerrero et al., Design of new resonant haloscopes in the search for the dark matter axion: A review of the first steps in the RADES Collaboration, Universe 8, 5 (2021).

  17. In this case, the DP polarization remains constant with respect to the galactic reference frame, but one should take into account that the laboratory reference frame is movable, thus varying the DP polarization as well, depending on the periodic movement of the reference frame.

  18. F. Bajjali, S. Dornbusch, M. Ekmedžić, D. Horns, C. Kasemann, A. Lobanov, A. Mkrtchyan, L. H. Nguyen, M. Tluczykont, G. Tuccari, J. Ulrichs, G. Wieching, and A. Zensus, First results from brass-p broadband searches for hidden photon dark matter, J. Cosmol. Astropart. Phys. 08 (2023) 077.
  19. H. An, S. Ge, W.-Q. Guo, X. Huang, J. Liu, and Z. Lu, Direct detection of dark photon dark matter using radio telescopes, Phys. Rev. Lett. 130, 181001 (2023).
  20. L. H. Nguyen, A. Lobanov, and D. Horns, First results from the wispdmx radio frequency cavity searches for hidden photon dark matter, J. Cosmol. Astropart. Phys. 10 (2019) 014.
  21. R. Cervantes, J. Aumentado, C. Braggio, B. Giaccone, D. Frolov, A. Grassellino, R. Harnik, F. Lecocq, O. Melnychuk, R. Pilipenko, S. Posen, and A. Romanenko, Deepest sensitivity to wavelike dark photon dark matter with superconducting radio frequency cavities, Phys. Rev. D 110, 043022 (2024).
  22. S. Adachi, R. Fujinaka, Y. Muto, H. Nakata, Y. Sueno, T. Sumida, J. Suzuki, O. Tajima, H. Takeuchi, and S. Honda (DOSUE-RR Collaboration), Search for dark photon dark matter in the mass range 41−74μeV using millimeter-wave receiver and radioshielding box, Phys. Rev. D 109, 012008 (2024).
  23. R. S. Giuseppe Conciauro and Marco Guglielmi, Advanced Modal Analysis (Wiley, New York, 1999).
  24. P. Arcioni, M. Bozzi, M. Bressan, G. Conciauro, and L. Perregrini, The BI-RME method: An historical overview, in 2014 International Conference on Numerical Electromagnetic Modeling and Optimization for RF, Microwave, and Terahertz Applications (NEMO) (IEEE, Pavia, Italy, 2014), pp. 1–4, 10.1109/NEMO.2014.6995653.
  25. P. Navarro, B. Gimeno, A. Álvarez Melcón, S. A. Cuendis, C. Cogollos, A. Díaz-Morcillo, J. Gallego, J. G. Barceló, J. Golm, I. Irastorza, A. L. Guerrero, and C. P. Garay, Wide-band full-wave electromagnetic modal analysis of the coupling between dark-matter axions and photons in microwave resonators, Phys. Dark Universe 36, 101001 (2022).

  26. CST Studio Suite.

  27. No magnet is needed for DP detection. However, this method is intended for the simultaneous search for DPs and axions, where a magnet is needed.
