Three-body molecular states composed of D(*) and two nucleons

Si-Yi Chen1, Fei-Yu Chen1, Xu-Liang Chen1, Lu Meng2,*, Ning Li1,†, and Wei Chen1,3,‡

  • *Contact author: lmeng@seu.edu.cn
  • †Contact author: lining59@mail.sysu.edu.cn
  • ‡Contact author: chenwei29@mail.sysu.edu.cn
PDF

Phys. Rev. D 113, 116026 – Published 15 June, 2026

DOI: https://doi.org/10.1103/kv8n-p7ms

Abstract

We study the three-body systems DNN and D*NN within a hadronic molecular framework by combining a realistic nucleon-nucleon interaction with a D(*)N potential constrained by heavy-quark symmetry. The three-body Schrödinger equation is solved with the Gaussian expansion method, and the analytic structure of the spectrum is investigated using the complex scaling method. We find that the DNN system supports a robust and compact bound state in the I(JP)=12(1−) channel over a broad range of cutoff values, even when the corresponding DN subsystem is weakly bound or unbound. For D*NN, the spin-1 nature of the heavy meson and the associated spin-dependent forces generate a clear spin hierarchy: deeply bound states appear in both 0− and 2− channels, while the 1− channel exhibits a characteristic two-branch pattern with a strongly bound compact branch and a more weakly bound, spatially extended branch. The root-mean-square radii indicate pronounced spatial compression compared with the deuteron scale, highlighting the cooperative roles of realistic NN correlations, the D(*)N interactions, and heavy-quark symmetry in forming compact heavy-flavor few-body bound states. No three-body resonances under complex scaling are found in the explored parameter space. Our results provide quantitative benchmarks for future experimental searches for such charmed-meson-nuclear bound states.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (95)

  1. S. K. Choi et al. (Belle Collaboration), Observation of a narrow charmonium-like state in exclusive B±→K±π+π−J/ψ decays, Phys. Rev. Lett. 91, 262001 (2003).
  2. M. Ablikim et al. (BESIII Collaboration), Observation of a charged charmoniumlike structure in e+e−→π+π−J/ψ at s=4.26  GeV, Phys. Rev. Lett. 110, 252001 (2013).
  3. Z. Q. Liu et al. (Belle Collaboration), Study of e+e−→π+π−J/ψ and observation of a charged charmoniumlike state at Belle, Phys. Rev. Lett. 110, 252002 (2013); 111, 019901(E) (2013).
  4. R. Aaij et al. (LHCb Collaboration), Observation of J/ψp resonances consistent with pentaquark states in Λb0→J/ψK−p decays, Phys. Rev. Lett. 115, 072001 (2015).
  5. R. Aaij et al. (LHCb Collaboration), Observation of a narrow pentaquark state, Pc(4312)+, and of two-peak structure of the Pc(4450)+, Phys. Rev. Lett. 122, 222001 (2019).
  6. R. Aaij et al. (LHCb Collaboration), Study of the doubly charmed tetraquark Tcc+, Nat. Commun. 13, 3351 (2022).
  7. R. Aaij et al. (LHCb Collaboration), Observation of an exotic narrow doubly charmed tetraquark, Nat. Phys. 18, 751 (2022).
  8. E. S. Swanson, The new heavy mesons: A status report, Phys. Rep. 429, 243 (2006).
  9. M. B. Voloshin, Charmonium, Prog. Part. Nucl. Phys. 61, 455 (2008).
  10. N. Brambilla et al., Heavy quarkonium: Progress, puzzles, and opportunities, Eur. Phys. J. C 71, 1534 (2011).
  11. N. Brambilla et al., QCD and strongly coupled gauge theories: Challenges and perspectives, Eur. Phys. J. C 74, 2981 (2014).
  12. A. Hosaka, T. Iijima, K. Miyabayashi, Y. Sakai, and S. Yasui, Exotic hadrons with heavy flavors: X, Y, Z, and related states, Prog. Theor. Exp. Phys. 2016, 062C01 (2016).
  13. H.-X. Chen, W. Chen, X. Liu, and S.-L. Zhu, The hidden-charm pentaquark and tetraquark states, Phys. Rep. 639, 1 (2016).
  14. A. Esposito, A. Pilloni, and A. D. Polosa, Multiquark resonances, Phys. Rep. 668, 1 (2017).
  15. R. F. Lebed, R. E. Mitchell, and E. S. Swanson, Heavy-quark QCD exotica, Prog. Part. Nucl. Phys. 93, 143 (2017).
  16. A. Ali, J. S. Lange, and S. Stone, Exotics: Heavy pentaquarks and tetraquarks, Prog. Part. Nucl. Phys. 97, 123 (2017).
  17. F.-K. Guo, C. Hanhart, U.-G. Meißner, Q. Wang, Q. Zhao, and B.-S. Zou, Hadronic molecules, Rev. Mod. Phys. 90, 015004 (2018); 94, 029901(E) (2022).
  18. S. L. Olsen, T. Skwarnicki, and D. Zieminska, Nonstandard heavy mesons and baryons: Experimental evidence, Rev. Mod. Phys. 90, 015003 (2018).
  19. Y.-R. Liu, H.-X. Chen, W. Chen, X. Liu, and S.-L. Zhu, Pentaquark and tetraquark states, Prog. Part. Nucl. Phys. 107, 237 (2019).
  20. N. Brambilla, S. Eidelman, C. Hanhart, A. Nefediev, C.-P. Shen, C. E. Thomas, A. Vairo, and C.-Z. Yuan, The XYZ states: Experimental and theoretical status and perspectives, Phys. Rep. 873, 1 (2020).
  21. L. Meng, B. Wang, G.-J. Wang, and S.-L. Zhu, Chiral perturbation theory for heavy hadrons and chiral effective field theory for heavy hadronic molecules, Phys. Rep. 1019, 2266 (2023).
  22. H.-X. Chen, W. Chen, X. Liu, Y.-R. Liu, and S.-L. Zhu, An updated review of the new hadron states, Rep. Prog. Phys. 86, 026201 (2023).
  23. M.-Z. Liu, Y.-W. Pan, Z.-W. Liu, T.-W. Wu, J.-X. Lu, and L.-S. Geng, Three ways to decipher the nature of exotic hadrons: Multiplets, three-body hadronic molecules, and correlation functions, Phys. Rep. 1108, 1 (2025).
  24. Z.-G. Wang, Review of the QCD sum rules for exotic states, Front. Phys. (Beijing) 21, 016300 (2026).
  25. C. Van Der Leun and C. Alderliesten, The deuteron binding energy, Nucl. Phys. A380, 261 (1982).
  26. W. Horiuchi, Y. Suzuki, T. Uesaka, and M. Miwa, Total reaction cross section on a deuteron target and the eclipse effect of the constituent neutron and proton, Phys. Rev. C 102, 054601 (2020).
  27. R. Greenwood and W. Black, The binding energy of the deuteron determined from measurement of the hydrogen neutron capture gamma-ray energy, Phys. Lett. 21, 702 (1966).
  28. V. G. J. Stoks, R. A. M. Klomp, C. P. F. Terheggen, and J. J. de Swart, Construction of high quality N N potential models, Phys. Rev. C 49, 2950 (1994).
  29. R. B. Wiringa, V. G. J. Stoks, and R. Schiavilla, An accurate nucleon-nucleon potential with charge independence breaking, Phys. Rev. C 51, 38 (1995).
  30. T.-S. Park, K. Kubodera, D.-P. Min, and M. Rho, The power of effective field theories in nuclei: The deuteron, N N scattering and electroweak processes, Nucl. Phys. A646, 83 (1999).
  31. K. Hassaneen, H. Abo-Elsebaa, E. Sultan, and H. Mansour, Nuclear binding energy and symmetry energy of nuclear matter with modern nucleon–nucleon potentials, Ann. Phys. (Amsterdam) 326, 566 (2011).
  32. H. Krebs, Nuclear currents in chiral effective field theory, Eur. Phys. J. A 56, 234 (2020).
  33. H. A. Bethe, The meson theory of nuclear forces. Part 2. Theory of the deuteron, Phys. Rev. 57, 390 (1940).
  34. R. Machleidt, The high precision, charge dependent Bonn nucleon-nucleon potential (CD-Bonn), Phys. Rev. C 63, 024001 (2001).
  35. S. R. Beane, E. Chang, W. Detmold, H. W. Lin, T. C. Luu, K. Orginos, A. Parreno, M. J. Savage, A. Torok, and A. Walker-Loud (NPLQCD Collaboration), The deuteron and exotic two-body bound states from lattice QCD, Phys. Rev. D 85, 054511 (2012).
  36. E. Epelbaum, H.-W. Hammer, and U.-G. Meißner, Modern theory of nuclear forces, Rev. Mod. Phys. 81, 1773 (2009).
  37. R. Machleidt and D. R. Entem, Chiral effective field theory and nuclear forces, Phys. Rep. 503, 1 (2011).
  38. E. Epelbaum, H. Krebs, and P. Reinert, High-precision nuclear forces from chiral EFT: State-of-the-art, challenges and outlook, Front. Phys. 8, 98 (2020).
  39. H. Krebs and E. Epelbaum, Toward consistent nuclear interactions from chiral Lagrangians. II. Symmetry preserving regularization, Phys. Rev. C 110, 044004 (2024).
  40. H. Krebs and E. Epelbaum, Toward consistent nuclear interactions from chiral Lagrangians. I. The path-integral approach, Phys. Rev. C 110, 044003 (2024).
  41. M. F. M. Lutz and E. E. Kolomeitsev, Baryon resonances from chiral coupled-channel dynamics, Nucl. Phys. A755, 29 (2005).
  42. C. Garcia-Recio, V. K. Magas, T. Mizutani, J. Nieves, A. Ramos, L. L. Salcedo, and L. Tolos, The s-wave charmed baryon resonances from a coupled-channel approach with heavy quark symmetry, Phys. Rev. D 79, 054004 (2009).
  43. J. He, Y.-T. Ye, Z.-F. Sun, and X. Liu, The observed charmed hadron Λc(2940)+ and the D*N interaction, Phys. Rev. D 82, 114029 (2010).
  44. J. Haidenbauer, G. Krein, U.-G. Meissner, and L. Tolos, DN interaction from meson exchange, Eur. Phys. J. A 47, 18 (2011).
  45. S. Sakai, F.-K. Guo, and B. Kubis, Extraction of ND scattering lengths from the Λb→π−pD0 decay and properties of the Σc(2800)+, Phys. Lett. B 808, 135623 (2020).
  46. S. Yasui and K. Sudoh, Exotic nuclei with open heavy flavor mesons, Phys. Rev. D 80, 034008 (2009).
  47. Y. Yamaguchi, S. Ohkoda, S. Yasui, and A. Hosaka, Exotic baryons from a heavy meson and a nucleon—Positive parity states -, Phys. Rev. D 85, 054003 (2012).
  48. Y. Yamaguchi, S. Yasui, and A. Hosaka, Open charm and bottom meson-nucleon potentials à la the nuclear force, Phys. Rev. D 106, 094001 (2022).
  49. L. Zhao, H. Huang, and J. Ping, ND and NB systems in quark delocalization color screening model, Eur. Phys. J. A 53, 28 (2017).
  50. D. R. Entem, P. G. Ortega, and F. Fernández, Hadronic molecules in the heavy baryon spectrum, AIP Conf. Proc. 1701, 050003 (2016).
  51. D. Zhang, D. Yang, X.-F. Wang, and K. Nakayama, Possible S-wave ND(*) and NB¯(*) bound states in a chiral quark model, arXiv:1903.01207.
  52. B. Wang, L. Meng, and S.-L. Zhu, D(*)N interaction and the structure of Σc(2800) and Λc(2940) in chiral effective field theory, Phys. Rev. D 101, 094035 (2020).
  53. C.-W. Shen, Y.-H. Lin, and H.-J. Jing, Towards the LHCb pentaquark modes in the single-charm sector, arXiv:2511.15649.
  54. Y. Dong, A. Faessler, T. Gutsche, and V. E. Lyubovitskij, Charmed baryon Σc(2800) as a ND hadronic molecule, Phys. Rev. D 81, 074011 (2010).
  55. P. G. Ortega, D. R. Entem, and F. Fernandez, Quark model description of the Λc(2940)+ as a molecular D*N state and the possible existence of the Λb(6248), Phys. Lett. B 718, 1381 (2013).
  56. J.-R. Zhang, S-wave D(*)N molecular states: Σc(2800) and Λc(2940)+?, Phys. Rev. D 89, 096006 (2014).
  57. R. Aaij et al. (LHCb Collaboration), Study of the D0p amplitude in Λb0→D0pπ− decays, J. High Energy Phys. 05 (2017) 030.
  58. S. Acharya et al. (ALICE Collaboration), First study of the two-body scattering involving charm hadrons, Phys. Rev. D 106, 052010 (2022).
  59. H. Garcilazo, A. Valcarce, and T. F. Caramés, Three-body systems with open flavor heavy mesons, Phys. Rev. D 96, 074009 (2017).
  60. S.-Q. Luo, T.-W. Wu, M.-Z. Liu, L.-S. Geng, and X. Liu, Triple-charm molecular states composed of D*D*D and D*D*D*, Phys. Rev. D 105, 074033 (2022).
  61. H.-L. Fu, Y.-H. Lin, F.-K. Guo, H.-W. Hammer, U.-G. Meißner, A. Rusetsky, and X. Zhang, Exploring Efimov states in D*D*D* and DD*D* three-body systems, J. High Energy Phys. 07 (2025) 081.
  62. T.-W. Wu, M.-Z. Liu, and L.-S. Geng, Implication of the existence of JPC=0−−D¯sDK bound state on the nature of Ds0*(2317), and a new configuration of exotic state, Phys. Rev. Lett. 135, 031902 (2025).
  63. A. Doté, M. Bayar, C. W. Xiao, T. Hyodo, M. Oka, and E. Oset, A narrow quasi-bound state of the DNN system, Nucl. Phys. A914, 499 (2013).
  64. E. Hiyama, Y. Kino, and M. Kamimura, Gaussian expansion method for few-body systems, Prog. Part. Nucl. Phys. 51, 223 (2003).
  65. J. Aguilar and J. M. Combes, A class of analytic perturbations for one-body Schroedinger hamiltonians, Commun. Math. Phys. 22, 269 (1971).
  66. E. Balslev and J. M. Combes, Spectral properties of many-body Schroedinger operators with dilatation-analytic interactions, Commun. Math. Phys. 22, 280 (1971).
  67. H.-X. Zhu, L. Meng, Y. Ma, N. Li, W. Chen, and S.-L. Zhu, Constraining the DDD* three-body bound state via the Zc(3900) pole, Phys. Rev. D 111, 094022 (2025).
  68. L.-Z. Wen, Y. Ma, L. Meng, and S.-L. Zhu, ϕnn, J/ψNN, and ηcnn systems based on HAL QCD interactions, Phys. Rev. D 111, 114004 (2025).
  69. Y.-K. Chen, L. Meng, J.-Z. Wang, and S.-L. Zhu, Existence of the DD*K¯* and BB*K* three-body molecular states, arXiv:2602.12010.
  70. Y. Ma, L. Meng, L.-Z. Wen, and S.-L. Zhu, Trilepton and tetralepton bound and resonant states: The QED counterpart of multiquark states, Phys. Rev. D 111, 073001 (2025).
  71. L.-Z. Wen and S.-L. Zhu, Bound and resonant states of muonic few-body Coulomb systems: Extended stochastic variational approach, Phys. Rev. A 113, 3 (2026).
  72. Y.-K. Chen, W.-L. Wu, L. Meng, and S.-L. Zhu, Unified description of the Qsq¯q¯ molecular bound states, molecular resonances, and compact tetraquark states in the quark potential model, Phys. Rev. D 109, 014010 (2024).
  73. Y. Ma, W.-L. Wu, L. Meng, Y.-K. Chen, and S.-L. Zhu, Fully strange tetraquark resonant states as the cousins of X(6900), Phys. Rev. D 110, 074026 (2024).
  74. L. Meng, Y.-K. Chen, Y. Ma, and S.-L. Zhu, Tetraquark bound states in constituent quark models: Benchmark test calculations, Phys. Rev. D 108, 114016 (2023).
  75. W.-L. Wu, Y.-K. Chen, L. Meng, and S.-L. Zhu, Benchmark calculations of fully heavy compact and molecular tetraquark states, Phys. Rev. D 109, 054034 (2024).
  76. W.-L. Wu, Y. Ma, Y.-K. Chen, L. Meng, and S.-L. Zhu, Fully heavy tetraquark resonant states with different flavors, Phys. Rev. D 110, 034030 (2024).
  77. W.-L. Wu, Y. Ma, Y.-K. Chen, L. Meng, and S.-L. Zhu, Doubly heavy tetraquark bound and resonant states, Phys. Rev. D 110, 094041 (2024).
  78. L. D. Faddeev, Scattering theory for a three-particle system, Sov. Phys. JETP 12, 1014 (1961).
  79. Y. Akaishi and T. Yamazaki, Nuclear k¯ bound states in light nuclei, Phys. Rev. C 65, 044005 (2002).
  80. N. V. Shevchenko, A. Gal, J. Mares, and J. Revai, K¯NN quasi-bound state and the K¯N interaction: Coupled-channel Faddeev calculations of the K¯NN−πΣN system, Phys. Rev. C 76, 044004 (2007).
  81. A. Dote, T. Hyodo, and W. Weise, K- pp system with chiral SU(3) effective interaction, Nucl. Phys. A804, 197 (2008).
  82. K. Topolnicki, J. Golak, R. Skibiński, H. Witała, and C. A. Bertulani, First-order neutron-deuteron scattering in a three-dimensional approach, Eur. Phys. J. A 51, 132 (2015).
  83. X. Zhang, C. Hanhart, U.-G. Meißner, and J.-J. Xie, Remarks on non-perturbative three–body dynamics and its application to the KKK¯ system, Eur. Phys. J. A 58, 20 (2022).
  84. M. Agnello et al. (FINUDA Collaboration), Evidence for a kaon-bound state K−pp produced in K− absorption reactions at rest, Phys. Rev. Lett. 94, 212303 (2005).
  85. T. Yamazaki et al., Indication of a deeply bound compact K−pp state formed in the pp→pΛK+ reaction at 2.85 GeV, Phys. Rev. Lett. 104, 132502 (2010).
  86. R. Machleidt, K. Holinde, and C. Elster, The Bonn meson exchange model for the nucleon nucleon interaction, Phys. Rep. 149, 1 (1987).
  87. R. L. Workman et al. (Particle Data Group), Review of particle physics, Prog. Theor. Exp. Phys. 2022, 083C01 (2022).
  88. R. Casalbuoni, A. Dandrea, N. Di Bartolomeo, R. Gatto, F. Feruglio, and G. Nardulli, Phenomenology of heavy meson chiral Lagrangians, Phys. Rep. 281, 145 (1997).
  89. A. F. Falk and M. E. Luke, Strong decays of excited heavy mesons in chiral perturbation theory, Phys. Lett. B 292, 119 (1992).
  90. M. B. Wise, Chiral perturbation theory for hadrons containing a heavy quark, Phys. Rev. D 45, R2188 (1992).
  91. N. Li, Z.-F. Sun, X. Liu, and S.-L. Zhu, Coupled-channel analysis of the possible D(*)D(*),B¯(*)B¯(*) and D(*)B¯(*) molecular states, Phys. Rev. D 88, 114008 (2013).
  92. X. Liu, Y.-R. Liu, W.-Z. Deng, and S.-L. Zhu, Z+(4430) as a D1′D*(D1D*) molecular state, Phys. Rev. D 77, 094015 (2008).
  93. H.-x. Zhu, L. Meng, Y. Ma, N. Li, W. Chen, and S.-L. Zhu, Coupling constants of one-boson-exchange interactions determined by X(3872), Tcc(3875) and Zc(3900) poles, 10.5281/zenodo.14464767 (2024).
  94. W. J. Romo, Inner product for resonant states and shell-model applications, Nucl. Phys. A116, 617 (1968).
  95. S.-Y. Chen, F.-Y. Chen, X.-L. Chen, L. Meng, N. Li, and W. Chen, Dataset for article: Three-body molecular states composed of D(*) and two nucleons, Zenodo, 2026, 10.5281/zenodo.20337529.
