Formation of extremal Reissner-Nordström black holes: Insights from numerics

Maxime Gadioux*, Harvey S. Reall†, and Jorge E. Santos‡

  • *Contact author: mjhg2@cam.ac.uk
  • †Contact author: hsr1000@cam.ac.uk
  • ‡Contact author: jss55@cam.ac.uk
PDF

Phys. Rev. D 113, 084001 – Published 1 April, 2026

DOI: https://doi.org/10.1103/k4dn-j3s6

Abstract

An extremal Reissner-Nordström black hole can form in finite time in the gravitational collapse of a massless charged scalar field. The proof of this is based on the method of characteristic gluing, which involves making an Ansatz for the scalar field at the horizon. We perform a numerical investigation of the characteristic gluing procedure for several different Ansätze. In each case, gluing is possible only if the final black hole mass is large enough. We find that the minimum required mass varies significantly for different Ansätze. We also consider the effect of including a mass term for the scalar field. In this case, for each Ansatz we determine the maximum mass-to-charge ratio for the scalar field such that gluing is possible. Analogous results are obtained for a nonzero cosmological constant.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (19)

  1. J. M. Bardeen, B. Carter, and S. W. Hawking, The four laws of black hole mechanics, Commun. Math. Phys. 31, 161 (1973).
  2. W. Israel, Third law of black-hole dynamics: A formulation and proof, Phys. Rev. Lett. 57, 397 (1986).
  3. C. Kehle and R. Unger, Gravitational collapse to extremal black holes and the third law of black hole thermodynamics, arXiv:2211.15742.
  4. C. Kehle and R. Unger, Extremal black hole formation as a critical phenomenon, arXiv:2402.10190.
  5. S. Aretakis, S. Czimek, and I. Rodnianski, The characteristic gluing problem for the Einstein vacuum equations: Linear and nonlinear analysis, Ann. Henri Poincare 25, 3081 (2024).
  6. S. Aretakis, S. Czimek, and I. Rodnianski, Characteristic gluing to the Kerr family and application to spacelike gluing, Commun. Math. Phys. 403, 275 (2023).
  7. S. Aretakis, S. Czimek, and I. Rodnianski, The characteristic gluing problem for the Einstein equations and applications, Duke Math. J. 174, 355 (2025).
  8. S. Czimek and I. Rodnianski, Obstruction-free gluing for the Einstein equations, arXiv:2210.09663.
  9. M. W. Choptuik, Universality and scaling in gravitational collapse of a massless scalar field, Phys. Rev. Lett. 70, 9 (1993).
  10. C. Gundlach, Understanding critical collapse of a scalar field, Phys. Rev. D 55, 695 (1997).
  11. C. Gundlach and J. M. Martín-García, Critical phenomena in gravitational collapse, Living Rev. Relativity 10, 5 (2007).
  12. H. S. Reall, Third law of black hole mechanics for supersymmetric black holes and a quasilocal mass-charge inequality, Phys. Rev. D 110, 124059 (2024).
  13. A. M. McSharry and H. S. Reall, On the third law of black hole mechanics for supersymmetric black holes, Phys. Rev. D 112, 104009 (2025).
  14. J. Luk, On the local existence for the characteristic initial value problem in general relativity, arXiv:1107.0898.
  15. F. Rossetti, Strong cosmic censorship for the spherically symmetric Einstein-Maxwell-charged-Klein-Gordon system with positive Λ: Stability of the Cauchy horizon and H1 extensions, Ann. Henri Poincare 26, 675 (2025).
  16. M. Dafermos, The stability problem for extremal black holes, Gen. Relativ. Gravit. 57, 60 (2025).
  17. M. Gadioux, Data for “Formation of extremal Reissner-Nordström black holes: Insights from numerics”, GitHub, https://github.com/mgadioux/formation-of-extremal-Reissner-Nordstrom-black-holes-insights-from-numerics (2026).
  18. C. G. Broyden, A class of methods for solving nonlinear simultaneous equations, Math. Comput. 19, 577 (1965).
  19. R. Marin, Ck-regular extremal black holes in maximally-symmetric spacetime and the third law of black hole thermodynamics, arXiv:2411.17938.
