Ice impact on thermal noise in cryogenic gravitational-wave detectors

Guido Alex Iandolo1,2,*, Alex Amato1,2, Henk Jan Bulten2, Stefan Hild1,2, Pascal Huysmans1, Paul Laeven1, Luca Massaro1,2, Peter G. Murray3, Simon C. Tait3,4 et al.

Janis Wöhler1,2, Iain W. Martin3, and Jessica Steinlechner1,2,3,†

  • *Contact author: g.iandolo@maastrichtuniversity.nl
  • †Contact author: jessica.steinlechner@ligo.org
PDF

Phys. Rev. D 114, 062002 – Published 4 September, 2026

DOI: https://doi.org/10.1103/k28k-5yn3

Abstract

Future gravitational-wave detectors, such as the Einstein Telescope and Laser Interferometer Gravitational Wave Observatory (LIGO) Voyager, are planned to implement cryogenic technology. For the Kamioka gravitational wave detector, where cryogenics has already been adopted, issues related to the growth of an ice layer on mirror surfaces were reported. Further studies have confirmed the presence of nanometric layers in cryogenic experiments in which ice led to an increase in optical loss and to oscillations of the mirror reflectance. In this study, we investigate the mechanical loss of an ice layer grown on a silicon substrate. The results show that the total mechanical loss increases over time with the thickness of the ice layer, indicating that even a few nanometers of ice can impact the sensitivity of gravitational-wave detectors.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (31)

  1. B. P. Abbott, R. Abbott, T. D. Abbott, M. R. Abernathy, F. Acernese, K. Ackley, C. Adams, T. Adams, P. Addesso, R. X. Adhikari et al., Observation of gravitational waves from a binary black hole merger, Phys. Rev. Lett. 116, 061102 (2016).
  2. B. P. Abbott, R. Abbott, T. D. Abbott, F. Acernese, K. Ackley, C. Adams, T. Adams, P. Addesso, R. X. Adhikari, V. B. Adya et al., GW170814: A three-detector observation of gravitational waves from a binary black hole coalescence, Phys. Rev. Lett. 119, 141101 (2017).
  3. B. P. Abbott, R. Abbott, T. D. Abbott, F. Acernese, K. Ackley, C. Adams, T. Adams, P. Addesso, R. X. Adhikari, V. B. Adya et al., GW170817: Observation of gravitational waves from a binary neutron star inspiral, Phys. Rev. Lett. 119, 161101 (2017).
  4. J. Aasi et al., Advanced LIGO, Classical Quantum Gravity 32, 074001 (2015).
  5. F. Acernese et al., Advanced Virgo: A second-generation interferometric gravitational wave detector, Classical Quantum Gravity 32, 024001 (2015).
  6. T. Akutsu, M. Ando, K. Arai, Y. Arai, S. Araki, A. Araya, N. Aritomi, Y. Aso, S.-W. Bae, Y.-B. Bae et al., Overview of KAGRA: Detector design and construction history, Prog. Theor. Exp. Phys. 2021, 05A101 (2020).
  7. T. Corbitt and N. Mavalvala, Review: Quantum noise in gravitational-wave interferometers, J. Opt. B Quantum Semiclassical Opt 6, S675 (2004).
  8. G. M. Harry, H. Armandula, E. Black, D. R. M. Crooks, G. Cagnoli, J. Hough, P. Murray, S. Reid, S. Rowan, P. Sneddon, M. M. Fejer, R. Route, and S. D. Penn, Thermal noise from optical coatings in gravitational wave detectors, Appl. Opt. 45, 1569 (2006).
  9. R. X. Adhikari, K. Arai, A. F. Brooks, C. Wipf, O. Aguiar, P. Altin, B. Barr, L. Barsotti, R. Bassiri, and A. Bell, A cryogenic silicon interferometer for gravitational-wave detection, Classical Quantum Gravity 37, 165003 (2020).
  10. Einstein Telescope Steering Committee, Einstein Telescope:Science case, design study and feasibility report (2020), https://apps.et-gw.eu/tds/?r=17196.
  11. A. Utina, A. Amato, J. Arends, C. Arina, M. de Baar, M. Baars, P. Baer, N. van Bakel, W. Beaumont, and A Bertolini, ETpathfinder: A cryogenic testbed for interferometric gravitational-wave detectors, Classical Quantum Gravity 39, 215008 (2022).
  12. K. Hasegawa, T. Akutsu, N. Kimura, Y. Saito, T. Suzuki, T. Tomaru, A. Ueda, and S. Miyoki, Molecular adsorbed layer formation on cooled mirrors and its impacts on cryogenic gravitational wave telescopes, Phys. Rev. D 99, 022003 (2019).
  13. L. Spallino, M. Angelucci, A. Pasqualetti, K. Battes, C. Day, S. Grohmann, E. Majorana, F. Ricci, and R. Cimino, Cryogenic vacuum considerations for future gravitational wave detectors, Phys. Rev. D 104, 062001 (2021).
  14. Z. Dohnálek, G. A. Kimmel, P. Ayotte, R. S. Smith, and B. D. Kay, The deposition angle-dependent density of amorphous solid water films, J. Chem. Phys. 118, 364 (2003).
  15. S. Tanioka, K. Hasegawa, and Y. Aso, Optical loss study of molecular layer for a cryogenic interferometric gravitational-wave detector, Phys. Rev. D 102, 022009 (2020).
  16. M. Magnozzi, F. Bisio, G. Gemme, M. Granata, C. Michel, L. Pinard, and M. Canepa, Detecting ultrathin ice on materials for optical coatings at cryogenic temperatures, J. Phys. D Appl. Phys. 56, 475105 (2023).
  17. J. Steinlechner and I. W. Martin, Thermal noise from icy mirrors in gravitational wave detectors, Phys. Rev. Res. 1, 013008 (2019).
  18. J. Hessinger and R. Pohl, Annealing of amorphous ice films, J. Non-Cryst. Solids 208, 151 (1996).
  19. J. Hessinger, B. White, and R. Pohl, Elastic properties of amorphous and crystalline ice films, Planet. Space Sci. 44, 937 (1996), Solar System Ices.
  20. E. Cesarini, M. Lorenzini, E. Campagna, F. Martelli, F. Piergiovanni, F. Vetrano, G. Losurdo, and G. Cagnoli, A “gentle” nodal suspension for measurements of the acoustic attenuation in materials, Rev. Sci. Instrum. 80, 053904 (2009).
  21. O. Stenzel, Optical Coatings. Material Aspects in Theory and Practice (Springer, Berlin, Heidelberg, 2014).
  22. M. N. Polyanskiy, Refractiveindex.info database of optical constants, Sci. Data 11, 94 (2024).
  23. G. A. Iandolo, A. Amato, G. Cagnoli, A. Delmonte, J. Hennig, M. Hennig, S. Steinlechner, J. Wöhler, S. Hild, and J. Steinlechner, Mechanical characterization of silicon for the ETpathfinder test masses, Phys. Rev. D 112, 043041 (2025).
  24. M. Granata, L. Balzarini, J. Degallaix, V. Dolique, R. Flaminio, D. Forest, D. Hofman, C. Michel, R. Pedurand, L. Pinard, B. Sassolas, N. Straniero, J. Teillon, and G. Cagnoli, Internal friction and young’s modulus measurements on SiO2 and Ta2O5 films done with an ultra-high q silicon-wafer suspension, Arch. Metall. Mater. 60.
  25. M. A. Hopcroft, W. D. Nix, and T. W. Kenny, What is the Young’s modulus of silicon?, J. Microelectromech. Syst. 19, 229 (2010).
  26. E. L. Gromnitskaya, O. V. Stal’gorova, V. V. Brazhkin, and A. G. Lyapin, Ultrasonic study of the nonequilibrium pressure-temperature diagram of H2O ice, Phys. Rev. B 64, 094205 (2001).
  27. P. Ehrenfreund and H. Fraser, Ice chemistry in space, in Solid State Astrochemistry, edited by V. Pirronello, J. Krelowski, and G. Manicò pp. 317–356 (Springer Netherlands, Dordrecht, 2003), https://ui.adsabs.harvard.edu/abs/2003ssac.proc..317E/abstract.
  28. K. Craig, J. Steinlechner, P. G. Murray, A. S. Bell, I. Birney, K. Haughian, J. Hough, I. MacLaren, S. Penn, S. Reid, R. Robie, S. Rowan, and I. W. Martin, Mirror coating solution for the cryogenic Einstein Telescope, Phys. Rev. Lett. 122, 231102 (2019).
  29. A. Bar-Nun, G. Notesco, and T. Owen, Trapping of N2, CO and Ar in amorphous ice—Application to comets, Icarus 190, 655 (2007).
  30. P. Ehrenfreund, A. Boogert, P. Gerakines, A. Tielens, and E. van Dishoeck, Infrared spectroscopy of interstellar apolar ice analogs, Astron. Astrophys. 328, 649 (1997).
  31. G. A. Iandolo, J. Steinlechner, and A. Amato, Ice impact on thermal noise in cryogenic gravitational-wave detectors, 10.5281/zenodo.17964684 (2025).

Outline

Information

Phys. Rev. D 114, 062002– Published 4 September, 2026
  • Received 10 October 2025
  • Accepted 13 July 2026
