Multicritical points of gravitational solitons and a black hole in four dimensions

Moisés Bravo-Gaete*

Moaathe Belhaj Ahmed† and Robert B. Mann‡

Constanza Quijada§

  • *Contact author: moisesbravog@gmail.com, mbravo@ucm.cl
  • †Contact author: hoothyy789@gmail.com
  • ‡Contact author: rbmann@uwaterloo.ca
  • §Contact author: constanza.quijada@unab.cl

Phys. Rev. D 114, 044037 – Published 12 August, 2026

DOI: https://doi.org/10.1103/jnk2-zc4k

Abstract

We present the first realization of multicritical points in four-dimensional general relativity, specifically within the context of Plebański nonlinear electrodynamics, using a polynomial structural function denoted as H(P). We show that this construction provides a systematic mechanism to engineer multicritical behavior in gravitational systems. By establishing an explicit mapping between matter theories expressed as power series in the Maxwell invariant F and the Plebański formulation, we construct new families of electrically charged asymptotically anti–de Sitter black holes and magnetically charged solitons. In the grand-canonical ensemble, we analyze their thermodynamic properties and uncover a rich phase structure. We demonstrate that the soliton sector develops multiple swallowtail structures, signaling first-order phase transitions and allowing the coexistence of several magnetically charged solitons with a single electrically charged black hole. These configurations define multicritical points that generalize previously known triple points. We further show that the number of coexisting phases is controlled by the degree of the polynomial structural function, providing a direct link between the nonlinear electrodynamics couplings and the thermodynamic phase structure. In contrast, the black hole branch does not display swallowtail behavior, and it does not allow multiple electrically charged black holes to coexist with a magnetically charged soliton.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. M. Natsuume, Lect. Notes Phys. 903, 1 (2015).
  2. J. M. Maldacena, Adv. Theor. Math. Phys. 2, 231 (1998).
  3. S. S. Gubser, I. R. Klebanov, and A. M. Polyakov, Phys. Lett. B 428, 105 (1998).
  4. E. Witten, Adv. Theor. Math. Phys. 2, 253 (1998).
  5. S. W. Hawking and D. N. Page, Commun. Math. Phys. 87 (1983) 577.
  6. E. Witten, Adv. Theor. Math. Phys. 2, 505 (1998).
  7. A. Chamblin, R. Emparan, C. V. Johnson, and R. C. Myers, Phys. Rev. D 60, 064018 (1999).
  8. D. Kubiznak, R. B. Mann, and M. Teo, Classical Quantum Gravity 34, 063001 (2017).
  9. R. B. Mann, Int. J. Mod. Phys. D 34, 2542001 (2025).
  10. D. Kubiznak and R. B. Mann, J. High Energy Phys. 07 (2012) 033.
  11. D. Kubiznak and R. B. Mann, Can. J. Phys. 93, 999 (2015).
  12. S. W. Wei, Y. X. Liu, and R. B. Mann, Phys. Rev. Lett. 123, 071103 (2019).
  13. J. P. S. Lemos, Phys. Lett. B 353, 46 (1995).
  14. L. Vanzo, Phys. Rev. D 56, 6475 (1997).
  15. S. Aminneborg, I. Bengtsson, D. Brill, S. Holst, and P. Peldan, Classical Quantum Gravity 15, 627 (1998).
  16. M. Banados, A. Gomberoff, and C. Martinez, Classical Quantum Gravity 15, 3575 (1998).
  17. R. B. Mann, Ann. Isr. Phys. Soc. 13, 311 (1997), arXiv:gr-qc/9709039.
  18. D. Birmingham, Classical Quantum Gravity 16, 1197 (1999).
  19. G. T. Horowitz and R. C. Myers, Phys. Rev. D 59, 026005 (1998).
  20. S. Surya, K. Schleich, and D. M. Witt, Phys. Rev. Lett. 86, 5231 (2001).
  21. N. Banerjee and S. Dutta, J. High Energy Phys. 07 (2007) 047.
  22. A. Anabalon, D. Astefanesei, D. Choque, and J. D. Edelstein, J. High Energy Phys. 07 (2020) 129.
  23. S. A. Mohanty and S. Mahapatra, arXiv:2604.05538.
  24. A. Anabalón, P. Concha, J. Oliva, C. Quijada, and E. Rodríguez, Phys. Lett. B 835, 137521 (2022).
  25. S. Gunasekaran, R. B. Mann, and D. Kubiznak, J. High Energy Phys. 11 (2012) 110.
  26. C. Gao, Phys. Rev. D 104, 064038 (2021).
  27. C. Gao and T. Saken, Eur. Phys. J. C 86, 481 (2026).
  28. M. Tavakoli, J. Wu, and R. B. Mann, J. High Energy Phys. 12 (2022) 117; 12 (2023) 12.
  29. C. Quijada, A. Anabalón, R. B. Mann, and J. Oliva, Phys. Rev. D 110, L021902 (2024).
  30. J. Plebański, Lectures on Non-Linear Electrodynamics (Nordita, Copenhagen, 1970).
  31. I. H. Salazar, A. García, and J. Plebański, J. Math. Phys. (N.Y.) 28, 2171 (1987).
  32. E. Ayon-Beato and A. Garcia, Phys. Rev. Lett. 80, 5056 (1998).
  33. E. Ayon-Beato and A. Garcia, Phys. Lett. B 493, 149 (2000).
  34. E. Ayon-Beato and A. Garcia, Phys. Lett. B 464, 25 (1999).
  35. A. A. Díaz García, Ann. Phys. (Amsterdam) 441, 168880 (2022).
  36. M. Bravo-Gaete, F. F. Santos, and X. Zhang, Fortschr. Phys. 73, e70049 (2025).
  37. A. A. Garcia-Diaz, arXiv:2112.06302.
  38. E. Ayón-Beato, Ann. Phys. (Amsterdam) 469, 169771 (2024).
  39. A. Álvarez, M. Bravo-Gaete, M. M. Juárez-Aubry, and G. V. Rodríguez, Phys. Rev. D 105, 084032 (2022).
  40. J. Lin, M. Bravo-Gaete, and X. Zhang, Phys. Rev. D 109, 104039 (2024).
  41. M. Bravo-Gaete, L. Guajardo, D. F. Higuita-Borja, and J. A. Méndez-Zavaleta, Phys. Rev. D 113, 024039 (2026).
  42. M. Bravo-Gaete, L. Guajardo, and J. Oliva, Phys. Rev. D 106, 024017 (2022).
  43. S. Hyun and C. H. Nam, Eur. Phys. J. C 79, 737 (2019).
  44. M. S. Churilova and Z. Stuchlik, Ann. Phys. (Amsterdam) 418, 168181 (2020).
  45. M. Russel, Combinatorics (John Wiley and Sons, New York, 2003).
  46. W. Sun, M. J. Powell-Palm, and J. Chen, arXiv:2105.01337.
  47. Z. Avetisyan, O. Evnin, and K. Mkrtchyan, Phys. Rev. Lett. 127, 271601 (2021).
  48. Z. Avetisyan, O. Evnin, and K. Mkrtchyan, J. High Energy Phys. 08 (2022) 112.
