Production of leptonium in heavy quarkonium decays

School of Physics, Shandong University, Jinan, Shandong 250100, China

^*Contact author: zyh329@mail.sdu.edu.cn
^†Contact author: jiangjun87@sdu.edu.cn

Phys. Rev. D 112, 056030 – Published 23 September, 2025

DOI: https://doi.org/10.1103/h57h-4ssj

Abstract

Lepton pairs with opposite charges can form bound states known as “leptonium” through quantum electrodynamic interactions. Heavy quarkonia such as $J / ψ$ are abundantly produced at facilities like BESIII and the future Super Tau-Charm Facility (STCF). In this work, we investigate leptonium production in heavy quarkonium decays, specifically focusing on the processes $Q ⟶ (l_{1}^{+} l_{2}^{-}) [n] + γ$ ( $l_{1, 2} = τ$ , $μ$ , $e$ ) and $Q ⟶ (l_{1}^{+} l_{2}^{-}) [n] + l_{1}^{-} l_{2}^{+}$ . Here, $Q$ denotes the heavy quarkonium $J / ψ$ or $ϒ$ , while $n = {{}^{1}S}_{0}$ or ${}^{3}{S_{1}}$ corresponds to para-leptonium and ortho-leptonium, respectively. With an annual production of $3.4 \times 10^{12} J / ψ$ events at STCF, there is significant potential to observe positronium $(e^{+} e^{-})$ , muonium $(μ^{+} e^{-})$ , and dimuonium $(μ^{+} μ^{-})$ . In particular, the ortho-dimuonium $(μ^{+} μ^{-}) [^{3} S_{1}]$ may be discovered at the future STCF, with an inclusive branching fraction of $Br (J / ψ ⟶ (μ^{+} μ^{-}) [^{3} S_{1}] + X) = 1.5 \times 10^{- 12}$ .

Physics Subject Headings (PhySH)

Article Text

References (45)

M. Deutsch, Evidence for the formation of positronium in gases, Phys. Rev. 82, 455 (1951).
V. W. Hughes, D. W. McColm, K. Ziock, and R. Prepost, Formation of muonium and observation of its Larmor precession, Phys. Rev. Lett. 5, 63 (1960).
R. Coombes et al., Detection of pi mu Coulomb bound states, Phys. Rev. Lett. 37, 249 (1976).
D. B. Cassidy and A. P. Mills, The production of molecular positronium, Nature (London) 449, 195 (2007).
D. d’Enterria, R. Perez-Ramos, and H.-S. Shao, Ditauonium spectroscopy, Eur. Phys. J. C 82, 923 (2022).
M. Ablikim et al. (BESIII Collaboration), Number of $J / ψ$ events at BESIII, Chin. Phys. C 46, 074001 (2022).
M. Achasov et al., STCF conceptual design report (Volume 1): Physics & detector, Front. Phys. (Beijing) 19, 14701 (2024).
J. Brodzicka et al. (Belle Collaboration), Physics achievements from the Belle experiment, Prog. Theor. Exp. Phys. 2012, 04D001 (2012).
A. J. Krasznahorkay et al., Observation of anomalous internal pair creation in ${}^{8}{Be}$ : A possible indication of a light, neutral boson, Phys. Rev. Lett. 116, 042501 (2016).
S. R. Gevorkian, E. A. Kuraev, A. Schiller, V. G. Serbo, and A. V. Tarasov, Production of relativistic positronium in collisions of photons and electrons with nuclei and atoms, Phys. Rev. A 58, 4556 (1998).
G.-M. Yu and Y.-D. Li, Photoproduction of large transverse momentum dimuonium ( $μ^{+} μ^{-}$ ) in relativistic heavy ion collisions, Chin. Phys. Lett. 30, 011201 (2013).
R. Francener, V. P. Goncalves, and B. D. Moreira, Photoproduction of relativistic QED bound states in hadronic collisions, Eur. Phys. J. A 58, 35 (2022).
I. F. Ginzburg, U. D. Jentschura, S. G. Karshenboim, F. Krauss, V. G. Serbo, and G. Soff, Production of bound $μ^{+} μ^{-}$ systems in relativistic heavy ion collisions, Phys. Rev. C 58, 3565 (1998).
C. Azevedo, V. P. Gonçalves, and B. D. Moreira, True muonium production in ultraperipheral $P b P b$ collisions, Phys. Rev. C 101, 024914 (2020).
G. Yu, Z. Zhao, Y. Cai, Q. Gao, Q. Hu, and H. Yang, Production of exotic electromagnetic bound systems in ultra-peripheral heavy ion collisions with two-photon processes, arXiv:2209.11439.
D. d’Enterria and H.-S. Shao, Observing true tauonium via two-photon fusion at $e^{+} e^{-}$ and hadron colliders, Phys. Rev. D 105, 093008 (2022).
D. d’Enterria and H.-S. Shao, Prospects for ditauonium discovery at colliders, Phys. Lett. B 842, 137960 (2023).
Y. Chen and P. Zhuang, Dimuonium $(μ^{+} μ^{-})$ production in a quark-gluon plasma, arXiv:1204.4389.
J. W. Moffat, Does a heavy positronium atom exist?, Phys. Rev. Lett. 35, 1605 (1975).
S. J. Brodsky and R. F. Lebed, Production of the smallest QED atom: True muonium $(μ^{+} μ^{-})$ . Phys. Rev. Lett. 102, 213401 (2009).
R. Gargiulo, S. Palmisano, E. Di Meco, E. Diociaiuti, I. Sarra, and D. Paesani, True muonium resonant production at $e^{+} e^{-}$ colliders with standard crossing angle, J. Phys. G 51, 045004 (2024).
L. D. Landau, On the angular momentum of a system of two photons, Dokl. Akad. Nauk SSSR 60, 207 (1948).
C.-N. Yang, Selection rules for the dematerialization of a particle into two photons, Phys. Rev. 77, 242 (1950).
X. Cid Vidal, P. Ilten, J. Plews, B. Shuve, and Y. Soreq, Discovering true muonium at LHCb, Phys. Rev. D 100, 053003 (2019).
Y. Ji and H. Lamm, Discovering true muonium in $K_{L} \to (μ^{+} μ^{-}) γ$ , Phys. Rev. D 98, 053008 (2018).
M. Fael and T. Mannel, On the decays $B \to K^{(*)} +$ leptonium, Nucl. Phys. B932, 370 (2018).
J.-P. Dai, H.-B. Li, S. Zhao, and Z.-Y. Zheng, Creating true muonium via charmonium radiative decay, arXiv:2412.12592.
D. d’Enterria and V. D. Le, Rare and exclusive few-body decays of the Higgs, Z, W bosons, and the top quark, J. Phys. G 52, 053001 (2025).
F. A. Martynenko, A. P. Martynenko, and A. V. Eskin, Production of dileptonic bound states in the Higgs boson decay, Phys. Rev. D 110, 056016 (2024).
S. G. Karshenboim, Precision physics of simple atoms: QED tests, nuclear structure and fundamental constants, Phys. Rep. 422, 1 (2005).
W. Bernreuther, U. Low, J. P. Ma, and O. Nachtmann, How to test $C P$ , $T$ and $C P T$ invariance in the three photon decay of polarized $s$ wave triplet positronium, Z. Phys. C 41, 143 (1988).
T. Yamazaki, T. Namba, S. Asai, and T. Kobayashi, Search for $C P$ violation in positronium decay, Phys. Rev. Lett. 104, 083401 (2010); 120, 239902(E) (2018).
A. Bogomyagkov, V. Druzhinin, E. Levichev, A. Milstein, and S. Sinyatkin, Low-energy electron-positron collider to search and study ( $μ^{+} μ^{-}$ ) bound state, EPJ Web Conf. 181, 01032 (2018).
W. E. Caswell and G. P. Lepage, Effective Lagrangians for bound state problems in QED, QCD, and other field theories, Phys. Lett. B 167, 437 (1986).
A. Sommerfeld, Über die Beugung und Bremsung der Elektronen, Ann. Phys. (Berlin) 403, 257 (1931).
A. D. Sakharov, Interaction of an electron and positron in pair production, Zh. Eksp. Teor. Fiz. 18, 631 (1948).
J. S. Schwinger, Particles, sources and fields. Volume II (CRC Press/Taylor & Francis Group, Boca Raton, 1973).
V. S. Fadin and V. A. Khoze, Threshold behavior of heavy top production in $e^{+} e^{-}$ collisions, JETP Lett. 46, 525 (1987), http://jetpletters.ru/ps/0/article_18631.shtml.
V. S. Fadin, V. A. Khoze, and T. Sjostrand, On the threshold behavior of heavy top production, Z. Phys. C 48, 613 (1990).
G. T. Bodwin, E. Braaten, and G. P. Lepage, Rigorous QCD analysis of inclusive annihilation and production of heavy quarkonium, Phys. Rev. D 51, 1125 (1995); 55, 5853(E) (1997).
G. T. Bodwin, D. K. Sinclair, and S. Kim, Quarkonium decay matrix elements from quenched lattice QCD, Phys. Rev. Lett. 77, 2376 (1996).
E. J. Eichten and C. Quigg, Quarkonium wave functions at the origin, Phys. Rev. D 52, 1726 (1995).
A. Petrelli, M. Cacciari, M. Greco, F. Maltoni, and M. L. Mangano, NLO production and decay of quarkonium, Nucl. Phys. B514, 245 (1998).
S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
M. Ablikim et al. (BESIII Collaboration), Observation of structures in the processes $e^{+} e^{-} \to ω χ_{c 1}$ and $ω χ_{c 2}$ , Phys. Rev. Lett. 132, 161901 (2024).

Phys. Rev. D 112, 056030– Published 23 September, 2025

Vol. 112, Iss. 5 — 1 September 2025

Received 6 May 2025
Accepted 27 August 2025

DOI: https://doi.org/10.1103/h57h-4ssj

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article’s title, journal citation, and DOI. Funded by SCOAP³.
