Laboratory frame representation of time-dependent gravitational waveforms

Lars Fischer1,*, Tom Krokotsch1,†, and Gudrid Moortgat-Pick1,2

  • *Present address: Institute for Quantum Electronics and Quantum Center, ETH Zurich, 8093 Zurich, Switzerland.
  • †Contact author: tom.krokotsch@desy.de
PDF

Phys. Rev. D 112, 124085 – Published 30 December, 2025

DOI: https://doi.org/10.1103/h3nh-3hxg

Abstract

Next-generation gravitational wave (GW) experiments will explore higher frequencies where wavelengths become comparable to the dimensions of the detector. In this regime, GWs may be detected not only through mechanical deformations from tidal forces, but also via induced effective currents in electromagnetic background fields. However, the calculation of these signals often requires transforming the GW metric to all orders into the laboratory frame of the detector. Here, we derive a closed-form expression for the metric transformation of general chirplike waveforms expressed in terms of the transverse-traceless GW metric components, their integral, and their derivative. For more complex signals, where analytical integration is impractical, we provide an efficient approximation based on Taylor expansions of the retarded time to coalescence. We find that quasi-Newtonian chirp signals can be accurately transformed using a monochromatic approximation, while also demonstrating that more complex waveforms require the general transformation, which we derive. Thus, the calculated transformations provide essential tools for designing high-frequency GW experiments and analyzing signals from compact object mergers at mega- to gigahertz frequencies.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (31)

  1. A. Einstein and N. Rosen, On gravitational waves, J. Franklin Inst. 223, 43 (1937).
  2. H. Bondi, Plane gravitational waves in general relativity, Nature (London) 179, 1072 (1957).
  3. M. Rakhmanov, Fermi-normal, optical, and wave-synchronous coordinates for spacetime with a plane gravitational wave, Classical Quantum Gravity 31, 085006 (2014).
  4. M. Maggiore, Gravitational Waves: Volume 1: Theory and Experiments (Oxford University Press, New York, 2007).
  5. A. Berlin, D. Blas, R. T. D’Agnolo, S. A. R. Ellis, R. Harnik, Y. Kahn, and J. Schütte-Engel, Detecting high-frequency gravitational waves with microwave cavities, Phys. Rev. D 105, 116011 (2022).
  6. V. Domcke, C. Garcia-Cely, and N. L. Rodd, A novel search for high-frequency gravitational waves with low-mass axion haloscopes, Phys. Rev. Lett. 129, 041101 (2022).
  7. J. Weber, Gravitational radiation, Phys. Rev. Lett. 18, 498 (1967).
  8. J. Weber, Detection and generation of gravitational waves, Phys. Rev. 117, 306 (1960).
  9. P. L. Fortini and C. Gualdi, Fermi normal co-ordinate system and electromagnetic detectors of gravitational waves, Il Nuovo Cimento B (1971-1996) 71, 37 (1982).
  10. K.-P. Marzlin, Fermi coordinates for weak gravitational fields, Phys. Rev. D 50, 888 (1994).
  11. A. Berlin, D. Blas, R. T. D’Agnolo, S. A. R. Ellis, R. Harnik, Y. Kahn, J. Schütte-Engel, and M. Wentzel, Electromagnetic cavities as mechanical bars for gravitational waves, Phys. Rev. D 108, 084058 (2023).
  12. K. M. W. Pappas, J. T. Fry, S. Cheng, A. C. Cesaní, J. L. Ouellet, C. P. Salemi, I. Vital, L. Winslow, V. Domcke, S. M. Lee, J. W. Foster, R. Henning, Y. Kahn, N. L. Rodd, and B. R. Safdi, High-frequency gravitational wave search with abracadabra-10 cm, arXiv:2505.02821.
  13. N. Aggarwal, O. D. Aguiar, D. Blas, A. Bauswein, G. Cella et al., Challenges and opportunities of gravitational wave searches above 10 kHz, arXiv:2501.11723.
  14. G. Franciolini, A. Maharana, and F. Muia, Hunt for light primordial black hole dark matter with ultra-high-frequency gravitational waves, Phys. Rev. D 106, 103520 (2022).
  15. L. Chung-Jukko, E. A. Lim, and D. J. E. Marsh, Multimessenger signals from compact axion star mergers, Phys. Rev. D 110, 063506 (2024).
  16. K. Schmieden and M. Schott, The global network of cavities to search for gravitational waves (GravNet): A novel scheme to hunt gravitational waves signatures from the early universe, Proc. Sci. EPS-HEP2023 (2024) 102 [arXiv:2308.11497].
  17. J. Reina-Valero, J. R. Navarro-Madrid, D. Blas, A. Díaz-Morcillo, I. G. Irastorza, B. Gimeno, and J. Monzó-Cabrera, High-frequency gravitational waves detection with the BabyIAXO haloscopes, Phys. Rev. D 111, 043024 (2025).
  18. R. Ballantini, P. Bernard, S. Calatroni, E. Chiaveri, A. Chincarini et al., Microwave apparatus for gravitational waves observation, arXiv:gr-qc/0502054.
  19. L. Fischer, B. Giaccone, I. Gonin, A. Grassellino, W. Hillert et al., First characterisation of the mago cavity, a superconducting rf detector for kHz–MHz gravitational waves, Classical Quantum Gravity 42, 115015 (2025).
  20. A. J. Millar, G. G. Raffelt, J. Redondo, and F. D. Steffen, Dielectric haloscopes to search for axion dark matter: Theoretical foundations, J. Cosmol. Astropart. Phys. 01 (2017) 061.
  21. V. Domcke, S. A. R. Ellis, and J. Kopp, Dielectric haloscopes as gravitational wave detectors, Phys. Rev. D 111, 035031 (2025).
  22. D. Horns, J. Jaeckel, A. Lindner, A. Lobanov, J. Redondo, and A. Ringwald, Searching for WISPy cold dark matter with a dish antenna, J. Cosmol. Astropart. Phys. 04 (2013) 016.
  23. J. Liu, K. Dona, G. Hoshino, S. Knirck, N. Kurinsky et al., Broadband solenoidal haloscope for terahertz axion detection, Phys. Rev. Lett. 128, 131801 (2022).
  24. R. Capdevilla, R. Harnik, T. Kim, and T. Krokotsch, High-frequency gravitational wave detection by the BREAD experiment, Phys. Rev. D 112, 035031 (2025).
  25. L. Blanchet, Post-Newtonian theory for gravitational waves, Living Rev. Relativity 27, 4 (2024).
  26. T. A. Apostolatos, C. Cutler, G. J. Sussman, and K. S. Thorne, Spin-induced orbital precession and its modulation of the gravitational waveforms from merging binaries, Phys. Rev. D 49, 6274 (1994).
  27. L. E. Kidder, Coalescing binary systems of compact objects to (post)5/2-Newtonian order. v. spin effects, Phys. Rev. D 52, 821 (1995).
  28. M. Bezares and C. Palenzuela, Gravitational waves from dark boson star binary mergers, Classical Quantum Gravity 35, 234002 (2018).
  29. T. Dietrich, D. Radice, S. Bernuzzi, F. Zappa, A. Perego, B. Brügmann, S. V. Chaurasia, R. Dudi, W. Tichy, and M. Ujevic, CoRe database of binary neutron star merger waveforms, Classical Quantum Gravity 35, 24LT01 (2018).
  30. M. E. Gertsenshtein, Wave resonance of light and gravitational waves, Sov. Phys. JETP 14, 84 (1962), http://jetp.ras.ru/cgi-bin/e/index/e/14/1/p84?a=list.
  31. J. Egge, Axion haloscope signal power from reciprocity, J. Cosmol. Astropart. Phys. 04 (2023) 064.
