Probing the cosmic ray background of gamma-ray astronomy with hadron colliders

Clara E. Leitgeb* and Robert D. Parsons‡

Andrew M. Taylor†

Kenneth J. Ragan§

David Berge∥ and Cigdem Issever

  • DESY, Platanenallee 6, D-15738 Zeuthen, Germany

  • *Contact author: clara.leitgeb@physik.hu-berlin.de
  • †Contact author: andrew.taylor@desy.de
  • ‡Contact author: daniel.parsons@physik.hu-berlin.de
  • §Contact author: ragan@physics.mcgill.ca
  • ∥Contact author: david.berge@desy.de
  • Contact author: isseverc@physik.hu-berlin.de
PDF

Phys. Rev. D 112, 083042 – Published 17 October, 2025

DOI: https://doi.org/10.1103/djx4-qs8m

Abstract

Hadronic cosmic particles (cosmic rays) and gamma rays are constantly absorbed in the Earth’s atmosphere and result in air showers of secondary particles. Cherenkov radiation from these atmospheric events is used to measure cosmic gamma rays with ground-based telescopes. We focus here on the dominant hadronic cosmic-ray-initiated background events in the atmosphere, which give rise to gamma-ray-like air showers for gamma-ray telescopes. It is shown that only a small subset of hadronic cosmic-ray interactions, those which produce a large energy neutral pion, are responsible for this background. We subsequently address how the predictions of this background vary depending on the hadronic interaction model adopted. The pseudorapidity range of the energetic pions, with respect to the shower axis produced in these background events, is shown to be large. We show that collider experiments, specifically LHCf and the Relavistic Heavy Ion Collider (RHICf), probe cosmic ray interactions precisely within this pseudorapidity range. Present and future measurements with these instruments are shown to be able to test the ability for current hadronic interaction models to accurately describe these background events.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (49)

  1. A. Albert, R. Alfaro, C. Alvarez et al., Astrophys. J. 905, 76 (2020).
  2. Z. Cao, F. Aharonian, Q. An et al., Astrophys. J. Suppl. Ser. 271, 25 (2024).
  3. J. Holder, arXiv:1510.05675.
  4. W. R. Nelson, H. Hirayama, and D. W. O. Rogers, The EGS4 code System: Solution of gamma-ray and electron transport problems, http://inis.iaea.org/search/search.aspx?orig_q=RN:45082043.
  5. W. R. Nelson and Y. Namito, The EGS4 Code System: Solution of Gamma-Ray and Electron Transport Problems (Nuclear Energy Data Center, Japan, 1990).
  6. H. E. S. S. Collaboration, Nat. Astron. 4, 167 (2020).
  7. S. Navas et al., Phys. Rev. D 110, 030001 (2024).
  8. J. Matthews, Astropart. Phys. 22, 387 (2005).
  9. T. C. Weekes, M. F. Cawley, D. J. Fegan et al., Astrophys. J. 342, 379 (1989).
  10. D. Berge, S. Funk, and J. Hinton, Astron. Astrophys. 466, 1219 (2007).
  11. F. Aharonian, A. G. Akhperjanian, U. Barres de Almeida et al., Phys. Rev. Lett. 101, 261104 (2008).
  12. M. Aguilar, D. Aisa, B. Alpat et al., Phys. Rev. Lett. 113, 221102 (2014).
  13. M. Aguilar, D. Aisa, B. Alpat et al., Phys. Rev. Lett. 114, 171103 (2015).
  14. O. Adriani, Y. Akaike, K. Asano et al., Phys. Rev. Lett. 119, 181101 (2017).
  15. O. Adriani, Y. Akaike, K. Asano et al., Phys. Rev. Lett. 122, 181102 (2019).
  16. Q. An, R. Asfandiyarov, P. Azzarello et al., Sci. Adv. 5, eaax3793 (2019).
  17. G. Ambrosi, Q. An et al. (DAMPE Collaboration), Nature (London) 552, 63 (2017).
  18. S. Ostapchenko, Phys. Rev. D 83, 014018 (2011).
  19. T. Pierog, I. Karpenko, J. M. Katzy, E. Yatsenko, and K. Werner, Phys. Rev. C 92, 034906 (2015).
  20. F. Riehn, R. Engel, A. Fedynitch, T. K. Gaisser, and T. Stanev, Phys. Rev. D 102, 063002 (2020).
  21. D. Heck et al., corsika: A Monte Carlo code to simulate extensive air showers (1998).
  22. T. Huege, SciPost Phys. Proc. 13, 028 (2023).
  23. C. Bierlich, S. Chakraborty, N. Desai et al., SciPost Phys. Codebases 2022, 8 (2022).
  24. M. Bleicher, E. Zabrodin, C. Spieles et al., J. Phys. G 25, 1859 (1999).
  25. J. M. Alameddine, J. Soedingrekso, A. Sandrock, M. Sackel, and W. Rhode, J. Phys. Conf. Ser. 1690, 012021 (2020).
  26. G. Battistoni, T. Boehlen, F. Cerutti et al., Ann. Nucl. Energy 82, 10 (2015).
  27. O. Adriani et al., Report No. CERN-LHCC-2006-004, CERN, 2006.
  28. G. Maier and J. Knapp, Astropart. Phys. 28, 72 (2007).
  29. J. Sitarek, D. Sobczyńska, M. Szanecki, K. Adamczyk, P. Cumani, and A. Moralejo, Astropart. Phys. 97, 1 (2018).
  30. D. Heck, J. Knapp, J. N. Capdevielle, G. Schatz, and T. Thouw, corsika: A Monte Carlo code to simulate extensive air showers (1998).
  31. A. Pastor-Gutiérrez, H. Schoorlemmer, R. D. Parsons, and M. Schmelling, Eur. Phys. J. C 81, 369 (2021).
  32. E.-J. Ahn, R. Engel, T. K. Gaisser, P. Lipari, and T. Stanev, Phys. Rev. D 80, 094003 (2009).
  33. ATLAS Collaboration, The pythia 8 A3 tune description of ATLAS minimum bias and inelastic measurements incorporating the Donnachie-Landshoff diffractive model, Technical Report No. ATL-PHYS-PUB-2016-017, CERN, Geneva, 2016, https://cds.cern.ch/record/2206965.
  34. M. Fieg, F. Kling, H. Schulz, and T. Sjöstrand, Phys. Rev. D 109, 016010 (2024).
  35. R. Ulrich, T. Pierog, and C. Baus, Cosmic Ray Monte Carlo Package, crmc, 1.8.0, Zenodo, 10.5281/zenodo.4558706 (2021).
  36. M. Ohishi, L. Arbeletche, V. de Souza, G. Maier, K. Bernlöhr, A. M. Olaizola, J. Bregeon, L. Arrabito, and T. Yoshikoshi, J. Phys. G 48, 075201 (2021).
  37. ATLAS Collaboration, J. Instrum. 3, S08003 (2008).
  38. The LHCb Collaboration, Int. J. Mod. Phys. A 30, 1530022 (2015).
  39. S. Chatrchyan, J. Instrum. 3, S08004 (2008).
  40. The CMS Collaboration, J. Instrum. 16, P02010 (2021).
  41. R. Blair et al., The CDF II detector technical design report, Technical Report No. FERMILAB-DESIGN-1996-01, FERMILAB-PUB-96-390-E, 1996.
  42. K. Goulianos, M. Gallinaro, K. Hatakeyama, S. Lami, C. Mesropian, and K. Terashi, Nucl. Instrum. Methods Phys. Res., Sect. A 518, 42 (2004).
  43. T. Sako, Proc. Sci. KMI2017 (2017) 031.
  44. K. H. Ackermann et al., Nucl. Instrum. Methods Phys. Res., Sect. A 499, 624 (2003).
  45. O. Adriani, L. Bonechi, M. Bongi et al., Phys. Rev. D 86, 092001 (2012).
  46. O. Adriani, E. Berti, L. Bonechi et al., Phys. Lett. B 780, 233 (2018).
  47. F.Aharonian et al. (The HESS Collaboration), Astron. Astrophys. 457, 899 (2006).
  48. M. Linhoff, L. Beiske, N. Biederbeck et al., Proc. Sci. ICRC2023 (2023) 703.
  49. R. D. Parsons, corsika Toy IACT, https://github.com/ParsonsRD/CORSIKA_toy_IACT (2021).
