Gravitational deflection of vector photons via effective field theory

Yihan Ma* and Ding-fang Zeng†

  • *Contact author: yihan.ma@emails.bjut.edu.cn
  • †Contact author: dfzeng@bjut.edu.cn
PDF

Phys. Rev. D 113, 016017 – Published 16 January, 2026

DOI: https://doi.org/10.1103/df24-1qtn

Abstract

Gravitational scattering of the electromagnetic field from a heavy scalar field provides a fundamental testbed for understanding the deflection of light by massive bodies. In many approaches based on effective field theory, the calculation of scattering amplitudes quickly becomes complicated due to the large number of Feynman integrals required, especially beyond leading order. In this work, we study this problem using effective field theory in the weak field approximation. We utilize the integration-by-parts reduction techniques to precisely examine the long-range contributions governed by terms in the amplitude that are nonanalytic in momentum transfer. Using geometric optics and the eikonal approximation, we derive expressions for the deflection angle and find the origin of differences relative to earlier works.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (47)

  1. Event Horizon Telescope Collaboration et al., First M87 event horizon telescope results. IV. Imaging the central supermassive black hole, Astrophys. J. Lett. 875, L4 (2019).
  2. Kazunori Akiyama, Antxon Alberdi et al., First M87 event horizon telescope results. V. Physical origin of the asymmetric ring, Astrophys. J. Lett. 875, L5 (2019).
  3. Event Horizon Telescope Collaboration et al., First M87 event horizon telescope results. II. Array and instrumentation, Astrophys. J. Lett. 875, L2 (2019).
  4. Event Horizon Telescope Collaboration et al., First Sagittarius A* event horizon telescope results. I. The shadow of the supermassive black hole in the center of the Milky Way, Astrophys. J. Lett. 930, L12 (2022).
  5. K. S. Virbhadra and George F. R. Ellis, Schwarzschild black hole lensing, Phys. Rev. D 62, 084003 (2000).
  6. G. W. Gibbons and M. C. Werner, Applications of the Gauss–Bonnet theorem to gravitational lensing, Classical Quantum Gravity 25, 235009 (2008).
  7. Simonetta Frittelli, Thomas P. Kling, and Ezra T. Newman, Spacetime perspective of Schwarzschild lensing, Phys. Rev. D 61, 064021 (2000).
  8. V. Bozza, S. Capozziello, G. Iovane, and G. Scarpetta, Strong field limit of black hole gravitational lensing, Gen. Relativ. Gravit. 33, 1535 (2001).
  9. Naoki Tsukamoto, Deflection angle in the strong deflection limit in a general asymptotically flat, static, spherically symmetric spacetime, Phys. Rev. D 95, 064035 (2017).
  10. N. Heidari, A. A. Araújo Filho, R. C. Pantig, and A. Övgün, Absorption, scattering, geodesics, shadows and lensing phenomena of black holes in effective quantum gravity, Phys. Dark Universe 47, 101815 (2025).
  11. John F. Donoghue, Leading quantum correction to the newtonian potential, Phys. Rev. Lett. 72, 2996 (1994).
  12. John F. Donoghue, General relativity as an effective field theory: The leading quantum corrections, Phys. Rev. D 50, 3874 (1994).
  13. John F. Donoghue and Tibor Torma, Infrared behavior of graviton-graviton scattering, Phys. Rev. D 60, 024003 (1999).
  14. Dong Bai and Yue Huang, More on the bending of light in quantum gravity, Phys. Rev. D 95, 064045 (2017).
  15. E. Guadagnini, Gravitational deflection of light and helicity asymmetry, Phys. Lett. B 548, 19 (2002).
  16. Giacomo Brunello, Effective field theory approach to general relativity and Feynman diagrams for coalescing binary systems, arXiv:2211.01321.
  17. Zvi Bern, Perturbative quantum gravity and its relation to gauge theory, Living Rev. Relativity 5, 5 (2002).
  18. Z. Bern, J. J. M. Carrasco, and H. Johansson, New relations for gauge-theory amplitudes, Phys. Rev. D 78, 085011 (2008).
  19. Lance J. Dixon, A brief introduction to modern amplitude methods, Particle Physics: The Higgs Boson and Beyond, 10.5170/CERN-2014-008.31.
  20. N. E. J. Bjerrum-Bohr, John F. Donoghue, Barry R. Holstein, Ludovic Planté, and Pierre Vanhove, Bending of light in quantum gravity, Phys. Rev. Lett. 114, 061301 (2015).
  21. N. Emil J. Bjerrum-Bohr, John F. Donoghue, Barry R. Holstein, Ludovic Planté, and Pierre Vanhove, Light-like scattering in quantum gravity, J. High Energy Phys. 11 (2016) 117.
  22. Laporta, High-precision calculation of multi-loop Feynman integrals by difference equations, Int. J. Mod. Phys. A 15, 5087 (2000).
  23. Roman Lee, Presenting LiteRed: A tool for the loop integrals reduction, arXiv:1212.2685.
  24. Roman N. Lee, LiteRed 1.4: A powerful tool for reduction of multiloop integrals, J. Phys. Conf. Ser. 523, 012059 (2014).
  25. J. M. Martín-García, R. Portugal, and L. R. U. Manssur, The invar tensor package, Comput. Phys. Commun. 177, 640 (2007).
  26. José M. Martín-García, xperm: Fast index canonicalization for tensor computer algebra, Comput. Phys. Commun. 179, 597 (2008).
  27. J. M. Martín-García, D. Yllanes, and R. Portugal, The invar tensor package: Differential invariants of Riemann, Comput. Phys. Commun. 179, 586 (2008).
  28. B. Latosh, Feyngrav: Feyncalc extension for gravity amplitudes, Classical Quantum Gravity 39, 165006 (2022).
  29. B. Latosh, Feyngrav 2.0, Comput. Phys. Commun. 292, 108871 (2023).
  30. R. Mertig, M. Böhm, and A. Denner, Feyn calc—computer-algebraic calculation of Feynman amplitudes, Comput. Phys. Commun. 64, 345 (1991).
  31. Vladyslav Shtabovenko, Rolf Mertig, and Frederik Orellana, Feyncalc 9.3: New features and improvements, Comput. Phys. Commun. 256, 107478 (2020).
  32. R. Keith Ellis and Giulia Zanderighi, Scalar one-loop integrals for QCD, J. High Energy Phys. 02 (2008) 002.
  33. Hiren H. Patel, Package -x 2.0: A Mathematica package for the analytic calculation of one-loop integrals, Comput. Phys. Commun. 218, 66 (2017).
  34. N. E. J. Bjerrum-Bohr, John F. Donoghue, and Pierre Vanhove, On-shell techniques and universal results in quantum gravity, J. High Energy Phys. 02 (2014) 111.
  35. Barry R. Holstein, Analytical on-shell calculation of low energy higher order scattering, J. Phys. G 44, 01LT01 (2017).
  36. Huan-Hang Chi, Graviton bending in quantum gravity from one-loop amplitudes, Phys. Rev. D 99, 126008 (2019).
  37. Charles A. Brau, Modern problems in classical electrodynamics, 2003.
  38. Paul M. Alsing, The optical-mechanical analogy for stationary metrics in general relativity, Am. J. Phys. 66, 779 (1998).
  39. Ratindranath Akhoury, Ryo Saotome, and George Sterman, High energy scattering in perturbative quantum gravity at next-to-leading power, Phys. Rev. D 103, 064036 (2021).
  40. K. S. Virbhadra, D. Narasimha, and S. M. Chitre, Role of the scalar field in gravitational lensing, arXiv:astro-ph/9801174.
  41. Cong Zhang, Jerzy Lewandowski, Yongge Ma, and Jinsong Yang, Black holes and covariance in effective quantum gravity, Phys. Rev. D 111, L081504 (2025).
  42. David Prinz, Gravity-matter Feynman rules for any valence, Classical Quantum Gravity 38, 215003 (2021).
  43. N. E. J. Bjerrum-Bohr, Barry R. Holstein, Ludovic Planté, and Pierre Vanhove, Graviton-photon scattering, Phys. Rev. D 91, 064008 (2015).
  44. B. A. Dubrovin, A. T. Fomenko, and S. P. Novikov, Modern Geometry—Methods and Applications (Springer, New York, 1992).
  45. C. Itzykson and J. B. Zuber, Quantum Field Theory, International Series In Pure and Applied Physics (McGraw-Hill, New York, 1980).
  46. A. Gonoskov, T. G. Blackburn, M. Marklund, and S. S. Bulanov, Charged particle motion and radiation in strong electromagnetic fields, Rev. Mod. Phys. 94, 045001 (2022).
  47. Patrick Copinger, James P. Edwards, Anton Ilderton, and Karthik Rajeev, Pair creation, backreaction, and resummation in strong fields, Phys. Rev. D 111, 036009 (2025).

Outline

Information

Phys. Rev. D 113, 016017– Published 16 January, 2026
  • Received 6 April 2025
  • Revised 18 November 2025
  • Accepted 8 December 2025
