  • Open Access

Characterizing CMB noise anisotropies from CMB delensing

Louis Legrand1,2 and Julien Carron3

PDF

Phys. Rev. D 112, 083538 – Published 21 October, 2025

DOI: https://doi.org/10.1103/dcj9-hhl4

Abstract

Undoing the effect of gravitational lensing on the cosmic microwave background (CMB) (“delensing”) is essential in shaping constraints on weak signals limited by lensing effects on the CMB, for example on a background of primordial gravitational waves. Removing these anisotropies induced by large-scale structures from the CMB maps also generally helps our view of the primordial Universe by sharpening the acoustic peaks and the damping tail. However, practical implementations of delensing transfer parts of these anisotropies to the noise maps. This will induce a new large scale “mean-field” bias to any anisotropy estimator applied to the delensed CMB, and this bias directly traces large-scale structures. This paper analytically quantifies this delensed noise mean field and its impact on quadratic and likelihood-based lensing estimators. We show that for Simons-Observatory-like surveys, this mean-field bias can reach 15% in cross-correlation with large-scale structures if unaccounted for. We further demonstrate that this delensed noise mean field can be safely neglected in likelihood-based estimators without compromising the quality of lensing reconstruction or B-mode delensing, provided the resulting lensing map is properly renormalized.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (36)

  1. Antony Lewis and Anthony Challinor, Weak gravitational lensing of the CMB, Phys. Rep. 429, 1 (2006).
  2. M. Tristram et al., Improved limits on the tensor-to-scalar ratio using BICEP and Planck data, Phys. Rev. D 105, 083524 (2022).
  3. P. A. R. Ade et al. (BICEP and Keck Collaborations), Improved constraints on primordial gravitational waves using Planck, WMAP, and BICEP/Keck observations through the 2018 observing season, Phys. Rev. Lett. 127, 151301 (2021).
  4. Julien Carron, Antony Lewis, and Anthony Challinor, Internal delensing of Planck CMB temperature and polarization, J. Cosmol. Astropart. Phys. 05 (2017) 035.
  5. Sebastian Belkner, Julien Carron, Louis Legrand, Caterina Umiltà, Clem Pryke, and Colin Bischoff (CMB-S4 Collaboration), CMB-S4: Iterative internal delensing and r constraints, Astrophys. J. 964, 148 (2024).
  6. Toshiya Namikawa et al., Simons observatory: Constraining inflationary gravitational waves with multitracer B-mode delensing, Phys. Rev. D 105, 023511 (2022).
  7. Emilie Hertig et al. (Simons Observatory Collaboration), The Simons Observatory: Combining cross-spectral foreground cleaning with multitracer B-mode delensing for improved constraints on inflation, Phys. Rev. D 110, 043532 (2024).
  8. Daniel Green, Joel Meyers, and Alexander van Engelen, CMB delensing beyond the B modes, J. Cosmol. Astropart. Phys. 12 (2017) 005.
  9. Selim C. Hotinli, Joel Meyers, Cynthia Trendafilova, Daniel Green, and Alexander van Engelen, The benefits of CMB delensing, J. Cosmol. Astropart. Phys. 04 (2022) 020.
  10. Christopher M. Hirata and Uros Seljak, Reconstruction of lensing from the cosmic microwave background polarization, Phys. Rev. D 68, 083002 (2003).
  11. Julien Carron and Antony Lewis, Maximum a posteriori CMB lensing reconstruction, Phys. Rev. D 96, 063510 (2017).
  12. Louis Legrand and Julien Carron, Robust and efficient CMB lensing power spectrum from polarization surveys, Phys. Rev. D 108, 103516 (2023).
  13. Louis Legrand and Julien Carron, Lensing power spectrum of the cosmic microwave background with deep polarization experiments, Phys. Rev. D 105, 123519 (2022).
  14. Marius Millea, Ethan Anderes, and Benjamin D. Wandelt, Bayesian delensing of CMB temperature and polarization, Phys. Rev. D 100, 023509 (2019).
  15. Marius Millea and Uros Seljak, Marginal unbiased score expansion and application to CMB lensing, Phys. Rev. D 105, 103531 (2022).
  16. F. Ge et al. (SPT-3G Collaboration), Cosmology from CMB lensing and delensed EE power spectra using 2019–2020 SPT-3G polarization data, Phys. Rev. D 111, 083534 (2025).
  17. Patricia Larsen, Anthony Challinor, Blake D. Sherwin, and Daisy Mak, Demonstration of cosmic microwave background delensing using the cosmic infrared background, Phys. Rev. Lett. 117, 151102 (2016).
  18. Antón Baleato Lizancos, Anthony Challinor, and Julien Carron, Limitations of CMB B-mode template delensing, Phys. Rev. D 103, 023518 (2021).
  19. Y. Akrami et al. (Planck Collaboration), Planck 2018 results. IV. Diffuse component separation, Astron. Astrophys. 641, A4 (2020).
  20. Julien Carron, Mark Mirmelstein, and Antony Lewis, CMB lensing from Planck PR4 maps, J. Cosmol. Astropart. Phys. 09 (2022) 039.
  21. Takemi Okamoto and Wayne Hu, CMB lensing reconstruction on the full sky, Phys. Rev. D 67, 083002 (2003).
  22. P. A. R. Ade et al. (Planck Collaboration), Planck 2015 results. XV. Gravitational lensing, Astron. Astrophys. 594, A15 (2016).
  23. Cora Dvorkin and Kendrick M. Smith, Reconstructing patchy reionization from the cosmic microwave background, Phys. Rev. D 79, 043003 (2009).
  24. Toshiya Namikawa, CMB mode coupling with isotropic polarization rotation, Mon. Not. R. Astron. Soc. 506, 1250 (2021).
  25. P. A. R. Ade et al. (BICEP/Keck Collaboration), BICEP/Keck. XVII. Line-of-sight distortion analysis: Estimates of gravitational lensing, anisotropic cosmic birefringence, patchy reionization, and systematic errors, Astrophys. J. 949, 43 (2023).
  26. Omar Darwish, Optimal joint reconstruction from CMB observations: Application to cosmic birefringence, patchy reionization and CMB lensing, Phys. Rev. D 112, 023514 (2025).
  27. Antony Lewis, Anthony Challinor, and Duncan Hanson, The shape of the CMB lensing bispectrum, J. Cosmol. Astropart. Phys. 03 (2011) 018.
  28. Abhishek S. Maniyar, Yacine Ali-Haïmoud, Julien Carron, Antony Lewis, and Mathew S. Madhavacheril, Quadratic estimators for CMB weak lensing, Phys. Rev. D 103, 083524 (2021).
  29. Martin Bucher, Carla Sofia Carvalho, Kavilan Moodley, and Mathieu Remazeilles, CMB lensing reconstruction in real space, Phys. Rev. D 85, 043016 (2012).
  30. Julien Carron and Antony Lewis, Spherical bispectrum expansion and quadratic estimators, J. Cosmol. Astropart. Phys. 07 (2024) 067.
  31. Julien Carron, On likelihood-based analysis of the gravitationally (de)lensed CMB, arXiv:2502.02399.
  32. N. Aghanim et al., Planck 2018 results. VIII. Gravitational lensing, Astron. Astrophys. 641, A8 (2020).
  33. Aurelien Benoit-Levy, Typhaine Dechelette, Karim Benabed, Jean-Francois Cardoso, Duncan Hanson, and Simon Prunet, Full-sky CMB lensing reconstruction in presence of sky-cuts, Astron. Astrophys. 555, A37 (2013).
  34. Julien Carron, Real-world CMB lensing quadratic estimator power spectrum response, J. Cosmol. Astropart. Phys. 02 (2023) 057.
  35. Gerrit S. Farren et al. (ACT Collaboration), The Atacama Cosmology Telescope: Cosmology from cross-correlations of unWISE Galaxies and ACT DR6 CMB lensing, Astrophys. J. 966, 157 (2024).
  36. Toshiya Namikawa, Duncan Hanson, and Ryuichi Takahashi, Bias-hardened CMB lensing, Mon. Not. R. Astron. Soc. 431, 609 (2013).
