New herwig7 underlying event tune: From RHIC to LHC energies

Umar Sohail Qureshi1,2,*, Luke Mozarsky3,4,†, Helen Caines3, Raghav Kunnawalkam Elayavalli2, and Isaac Mooney3,5

  • *Contact author: uqureshi@cern.ch
  • †Contact author: luke.mozarsky@cern.ch
PDF

Phys. Rev. D 112, 116019 – Published 24 December, 2025

DOI: https://doi.org/10.1103/cnck-wtbh

Abstract

We present parameter sets corresponding to new underlying event tunes for the herwig7.3 Monte Carlo event generator. The existing herwig tunes are in good agreement with LHC data, however, they are not typically designed for center-of-mass energies below s=300  GeV. The tunes presented in this study can describe midrapidity data collected at the nominal RHIC energy of s=200  GeV as well as higher center-of-mass energies utilized by experiments at the LHC and Tevatron. The base “New Haven” tune is developed by fitting minimum-bias simulations of proton-proton (pp) collisions to midrapidity identified hadron and jet data from the STAR experiment. The “Nashville” tune includes a separate set of parameters developed by tuning to Tevatron proton-antiproton (pp¯) data at s=300, 900 and 1960 GeV from CDF, and LHC pp measurements from CMS at s=7  TeV, in addition to the STAR measurements. Both new tunes demonstrate significant improvements over the recommended default tune currently included in the latest version of herwig for minimum bias production. As such, we advocate using these tunes for future simulation studies at midrapidity by experimental collaborations at RHIC (STAR and sPHENIX) and the LHC (ALICE, ATLAS, and CMS).

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (29)

  1. C. Bierlich et al., A comprehensive guide to the physics and usage of pythia 8.3, SciPost Phys. Codebases 2022, 8 (2022).
  2. T. Sjostrand, S. Mrenna, and P. Z. Skands, pythia 6.4 physics and manual, J. High Energy Phys. 05 (2006) 026.
  3. E. Bothmann et al., Event generation with sherpa 2.2, SciPost Phys. 7, 034 (2019).
  4. G. Bewick et al., herwig 7.3 release note, Eur. Phys. J. C 84, 1053 (2024).
  5. M. Bahr et al., herwig++ physics and manual, Eur. Phys. J. C 58, 639 (2008).
  6. A. M. Sirunyan et al. (CMS Collaboration), Development and validation of herwig 7 tunes from CMS underlying-event measurements, Eur. Phys. J. C 81, 312 (2021).
  7. J. Bellm et al., herwig 7.2 release note, Eur. Phys. J. C 80, 452 (2020).
  8. J. Bellm, S. Gieseke, and P. Kirchgaesser, Improving the description of multiple interactions in herwig, Eur. Phys. J. C 80, 469 (2020).
  9. M. R. Aguilar, Z. Chang, R. K. Elayavalli, R. Fatemi, Y. He, Y. Ji, D. Kalinkin, M. Kelsey, I. Mooney, and V. Verkest, pythia8underlying event tune for RHIC energies, Phys. Rev. D 105, 016011 (2022).
  10. S. Gieseke, F. Loshaj, and M. Myska, Towards diffraction in herwig, arXiv:1602.04690.
  11. A. Buckley, H. Hoeth, H. Lacker, H. Schulz, and J. E. von Seggern, Systematic event generator tuning for the LHC, Eur. Phys. J. C 65, 331 (2010).
  12. C. Bierlich et al., Robust independent validation of experiment and theory: Rivet version 3, SciPost Phys. 8, 026 (2020).
  13. F. James and M. Roos, Minuit: A system for function minimization and analysis of the parameter errors and correlations, Comput. Phys. Commun. 10, 343 (1975).
  14. R. D. Ball et al. (NNPDF Collaboration), Parton distributions for the LHC Run II, J. High Energy Phys. 04 (2015) 040.
  15. S. Gieseke, C. A. Rohr, and A. Siodmok, Tuning of the multiple parton interaction model in herwig++ using early LHC data, in 3rd International Workshop on Multiple Partonic Interactions at the LHC (2012), pp. 67–74.
  16. S. Gieseke, C. Rohr, and A. Siodmok, Colour reconnections in herwig++, Eur. Phys. J. C 72, 2225 (2012).
  17. J. Adams et al. (STAR Collaboration), Identified hadron spectra at large transverse momentum in p+p and d+Au collisions at s(NN)(1/2) = 200-GeV, Phys. Lett. B 637, 161 (2006).
  18. J. Adam et al. (STAR Collaboration), Underlying event measurements in p+p collisions at s=200  GeV at RHIC, Phys. Rev. D 101, 052004 (2020).
  19. T. A. Aaltonen et al. (CDF Collaboration), Study of the energy dependence of the underlying event in proton-antiproton collisions, Phys. Rev. D 92, 092009 (2015).
  20. S. Chatrchyan et al. (CMS Collaboration), Measurement of the underlying event activity at the LHC with s=7  TeV and comparison with s=0.9  TeV, J. High Energy Phys. 09 (2011) 109.
  21. J. Adam et al. (STAR Collaboration), Measurement of groomed jet substructure observables in p+p collisions at s=200  GeV with STAR, Phys. Lett. B 811, 135846 (2020).
  22. M. Abdallah et al. (STAR Collaboration), Invariant jet mass measurements in pp collisions at s=200  GeV at RHIC, Phys. Rev. D 104, 052007 (2021).
  23. H. Caines (STAR Collaboration), Exploring jet properties in p-p collisions at 200-GeV with STAR, Nucl. Phys. A830, 263C (2009).
  24. Underlying event tunes and double parton scattering, CERN Tech. Rep., 2014.
  25. www.github.com/lmozarsky/herwig7-rhic-tune
  26. S. Gieseke, P. Kirchgaeßer, and S. Plätzer, Baryon production from cluster hadronisation, Eur. Phys. J. C 78, 99 (2018).
  27. G. Aad et al. (ATLAS Collaboration), Measurement of the transverse momentum and ϕη* distributions of Drell–Yan lepton pairs in proton–proton collisions at s=8  TeV with the ATLAS detector, Eur. Phys. J. C 76, 291 (2016).
  28. S. Chatrchyan et al. (CMS Collaboration), Measurement of the rapidity and transverse momentum distributions of Z bosons in pp collisions at s=7  TeV, Phys. Rev. D 85, 032002 (2012).
  29. https://github.com/lmozarsky/herwig7-rhic-tune.
