Daily modulation constraints on light dark matter with DAMIC-M

K. Aggarwal1, I. Arnquist2, N. Avalos3, X. Bertou4,3, N. Castelló-Mor5, C. Centeno-Lorca5, A. E. Chavarria1, J. Cuevas-Zepeda6, A. Dastgheibi-Fard7 et al. (DAMIC-M Collaboration)

A. Dastgheibi-Fard7, C. De Dominicis3, O. Deligny4, J. Duarte-Campderros5, E. Estrada8, R. Gaïor3, E.-L. Gkougkousis9, T. Hossbach2, L. Iddir3, B. J. Kavanagh5, B. Kilminster9, I. Lawson10, A. Letessier-Selvon3, H. Lin11, P. Loaiza4, A. Lopez-Virto5, R. Lou6, H. Lumengo-Kidimbu3, K. J. McGuire1, S. Munagavalasa6, J. Noonan6, D. Norcini11, S. Paul6, P. Privitera6,3,12, P. Robmann9, B. Roach6, D. Rosenmerkel11, M. Settimo13, R. Smida6, M. Traina5, R. Vilar5, R. Yajur6, D. Venegas-Vargas11, C. Zhu11, and Y. Zhu3 (DAMIC-M Collaboration)

PDF

Phys. Rev. D 114, 032010 – Published 19 August, 2026

DOI: https://doi.org/10.1103/c9fm-ymf2

Abstract

The flux of Hidden Sector particles from the Galactic halo reaching an underground detector can be significantly attenuated by interactions within the Earth for sufficiently large scattering cross- sections. This attenuation gives rise to a characteristic daily modulation in the detection rate, due to Earth’s rotation. We present results from a search for such a modulation using a 1.257 kg-day dataset collected with the DAMIC-M Low Background Chamber. A model-independent analysis reveals no significant modulation in the 1e− event rate over periods from 1 to 48 h, highlighting the excellent temporal stability of the detector. In a complementary model-dependent analysis, we target the expected daily modulation signature of Hidden Sector particles, with masses in the range [0.53,2]  MeV/c2, interacting with electrons via a dark photon mediator. By leveraging the expected temporal evolution of the signal, we set improved constraints on Dark Matter masses below 1.2  MeV/c2, surpassing our previous limits.

View figure in article

Physics Subject Headings (PhySH)

See Also

Probing Benchmark Models of Hidden-Sector Dark Matter with DAMIC-M

K. Aggarwal et al. (DAMIC-M Collaboration)
Phys. Rev. Lett. 135, 071002 (2025)

Article Text

References (59)

  1. G. Bertone, D. Hooper, and J. Silk, Particle dark matter: Evidence, candidates and constraints, Phys. Rep. 405, 279 (2005).
  2. C. Boehm, P. Fayet, and J. Silk, Light and heavy dark matter particles, Phys. Rev. D 69, 101302 (2004).
  3. M. Pospelov, A. Ritz, and M. B. Voloshin, Secluded WIMP dark matter, Phys. Lett. B 662, 53 (2008).
  4. D. Hooper and K. M. Zurek, A natural supersymmetric model with MeV dark matter, Phys. Rev. D 77, 087302 (2008).
  5. X. Chu, T. Hambye, and M. H. G. Tytgat, The four basic ways of creating dark matter through a portal, J. Cosmol. Astropart. Phys. 05 (2012) 034.
  6. S. Knapen, T. Lin, and K. M. Zurek, Light dark matter: Models and constraints, Phys. Rev. D 96, 115021 (2017).
  7. A. Drukier and L. Stodolsky, Principles and applications of a neutral-current detector for neutrino physics and astronomy, Phys. Rev. D 30, 2295 (1984).
  8. M. W. Goodman and E. Witten, Detectability of certain dark-matter candidates, Phys. Rev. D 31, 3059 (1985).
  9. A. Drukier, K. Freese, and D. Spergel, Detecting cold dark matter candidates, Phys. Rev. D 33, 3495 (1986).
  10. J. Billard et al., Direct detection of dark matter—APPEC committee report*, Rep. Prog. Phys. 85, 056201 (2022).
  11. R. Essig, J. Mardon, and T. Volansky, Direct detection of sub-GeV dark matter, Phys. Rev. D 85, 076007 (2012).
  12. I. Arnquist et al. (DAMIC-M Collaboration), First constraints from DAMIC-M on sub-GeV dark-matter particles interacting with electrons, Phys. Rev. Lett. 130, 171003 (2023).
  13. P. Adari, A. A. Aguilar-Arevalo, D. Amidei, G. Angloher, and E. A. Armengaud, EXCESS workshop: Descriptions of rising low-energy spectra, SciPost Phys. Proc. 9, 001 (2022).
  14. L. Barak et al. (SENSEI Collaboration), SENSEI: Characterization of single-electron events using a skipper charge-coupled device, Phys. Rev. Appl. 17, 014022 (2022).
  15. T. Emken and C. Kouvaris, DaMaSCUS: The impact of underground scatterings on direct detection of light dark matter, J. Cosmol. Astropart. Phys. 10 (2017) 031.
  16. T. Emken, R. Essig, C. Kouvaris, and M. Sholapurkar, Direct detection of strongly interacting sub-GeV dark matter via electron recoils, J. Cosmol. Astropart. Phys. 09 (2019) 070.
  17. A. Gould, J. A. Frieman, and K. Freese, Probing the Earth with wimps, Phys. Rev. D 39, 1029 (1989).
  18. J. I. Collar and F. T. Avignone, III, The effect of elastic scattering in the Earth on cold dark matter experiments, Phys. Rev. D 47, 5238 (1993).
  19. F. Hasenbalg, D. Abriola, F. T. Avignone, J. I. Collar, D. E. Di Gregorio, A. O. Gattone, H. Huck, D. Tomasi, and I. Urteaga, Cold dark matter identification: Diurnal modulation revisited, Phys. Rev. D 55, 7350 (1997).
  20. C. Kouvaris and I. M. Shoemaker, Daily modulation as a smoking gun of dark matter with significant stopping rate, Phys. Rev. D 90, 095011 (2014).
  21. B. J. Kavanagh, R. Catena, and C. Kouvaris, Signatures of Earth-scattering in the direct detection of Dark Matter, J. Cosmol. Astropart. Phys. 01 (2017) 012.
  22. P. Privitera, The DAMIC-M experiment: Status and first results, in Proceedings of XVIII International Conference on Topics in Astroparticle and Underground Physics—PoS(TAUP2023) (SISSA, Trieste, 2024), Vol. 441, p. 066.
  23. I. Arnquist et al. (DAMIC-M Collaboration), Search for daily modulation of MeV dark matter signals with DAMIC-M, Phys. Rev. Lett. 132, 101006 (2024).
  24. K. Aggarwal et al. (DAMIC-M Collaboration), Probing benchmark models of hidden-sector dark matter with DAMIC-M, Phys. Rev. Lett. 135, 071002 (2025).
  25. I. Arnquist et al. (DAMIC-M Collaboration), The DAMIC-M low background chamber, J. Instrum. 19, T11010 (2024).
  26. S. E. Holland, An overview of CCD development at Lawrence Berkeley National Laboratory, Exp. Astron. 14, 83 (2002).
  27. S. E. Holland, D. E. Groom, N. P. Palaio, R. J. Stover, and M. Wei, Fully depleted, back-illuminated charge-coupled devices fabricated on high-resistivity silicon, IEEE Trans. Electron Devices 50, 225 (2003).
  28. S. E. Holland, W. F. Kolbe, and C. J. Bebek, Device design for a 12.3-megapixel, fully depleted, back-illuminated, high-voltage compatible charge-coupled device, IEEE Trans. Electron Devices 56, 2612 (2009).
  29. A. Aguilar-Arevalo et al. (DAMIC Collaboration), Search for low-mass WIMPs in a 0.6 kg day exposure of the DAMIC experiment at SNOLAB, Phys. Rev. D 94, 082006 (2016).
  30. J. Janesick, T. Elliott, A. Dingiziam, R. Bredthauer, C. Chandler, J. Westphal, and J. Gunn, New advancements in charge-coupled device technology: Subelectron noise and 4096×4096  pixel CCDs, Proc. SPIE Int. Soc. Opt. Eng. 1242, 223 (1990).
  31. C. E. Chandler, R. A. Bredthauer, J. R. Janesick, J. A. Westphal, and J. E. Gunn, Sub-electron noise charge coupled devices, Proc. SPIE Int. Soc. Opt. Eng. 1242, 238 (1990).
  32. J. Tiffenberg, M. Sofo-Haro, A. Drlica-Wagner, R. Essig, Y. Guardincerri, S. Holland, T. Volansky, and T.-T. Yu, Single-electron and single-photon sensitivity with a silicon Skipper CCD, Phys. Rev. Lett. 119, 131802 (2017).
  33. J. R. Janesick, Scientific Charge-Coupled Devices (SPIE Optical Engineering Press, Bellingham, Washington, USA, 2001).
  34. N. R. Lomb, Least-squares frequency analysis of unequally spaced data, Astrophys. Space Sci. 39, 447 (1976).
  35. J. D. Scargle, Studies in astronomical time series analysis. II. Statistical aspects of spectral analysis of unevenly spaced data, Astrophys. J. 263, 835 (1982).
  36. J. T. VanderPlas, Understanding the lomb–scargle periodogram, Astrophys. J. Suppl. Ser. 236, 16 (2018).
  37. R. Essig, M. Fernandez-Serra, J. Mardon, A. Soto, T. Volansky, and T.-T. Yu, Direct detection of sub-GeV dark matter with semiconductor targets, J. High Energy Phys. 05 (2016) 046.
  38. C. McCabe, The Earth’s velocity for direct detection experiments, J. Cosmol. Astropart. Phys. 02 (2014) 027.
  39. D. Baxter et al., Recommended conventions for reporting results from direct dark matter searches, Eur. Phys. J. C 81, 907 (2021).
  40. J. H. Davis, Probing sub-GeV mass strongly interacting dark matter with a low-threshold surface experiment, Phys. Rev. Lett. 119, 211302 (2017).
  41. B. J. Kavanagh, Earth scattering of superheavy dark matter: Updated constraints from detectors old and new, Phys. Rev. D 97, 123013 (2018).
  42. T. Emken and C. Kouvaris, How blind are underground and surface detectors to strongly interacting dark matter?, Phys. Rev. D 97, 115047 (2018).
  43. D. Hooper and S. D. McDermott, Robust constraints and novel gamma-ray signatures of dark matter that interacts strongly with nucleons, Phys. Rev. D 97, 115006 (2018).
  44. J. Bramante, B. Broerman, R. F. Lang, and N. Raj, Saturated overburden scattering and the multiscatter frontier: Discovering dark matter at the planck mass and beyond, Phys. Rev. D 98, 083516 (2018).
  45. M. S. Mahdawi and G. R. Farrar, Constraints on dark matter with a moderately large and velocity-dependent DM-nucleon cross-section, J. Cosmol. Astropart. Phys. 10 (2018) 007.
  46. C. V. Cappiello, Analytic approach to light dark matter propagation, Phys. Rev. Lett. 130, 221001 (2023).
  47. B. J. Kavanagh, verne [Code, v2.1], https://github.com/bradkav/verne, 10.5281/zenodo.15359975 (2025).
  48. A. Lantero-Barreda, C. Centeno, B. J. Kavanagh, and N. Castelló-Mor, A fast earth-scattering formalism for light dark matter with dark photon mediators, arXiv:2511.10589.
  49. X. Bertou, A. Desai, T. Emken, R. Essig, T. Volansky, and T.-T. Yu, Earth-scattering induced modulation in low-threshold dark matter experiments, J. High Energy Phys. 11 (2025) 042.
  50. C. Dreyer, R. Essig, M. Fernandez-Serra, A. Singal, and C. Zhen, Fully ab-initio all-electron calculation of dark matter-electron scattering in crystals with evaluation of systematic uncertainties, Phys. Rev. D 109, 115008 (2024).
  51. G. Cappellini and F. B. R. Del Sole, Lucia Reining, Model dielectric function for semiconductors, Phys. Rev. B 47, 9892 (1993).
  52. J. K. Simon Knapen and T. Lin, Dark matter-electron scattering in dielectrics, Phys. Rev. D 104, 015031 (2021).
  53. T. T. Z. Z. Sinéad M. Griffin, Katherine Inzani, and K. M. Zurek, Extended calculation of dark matter-electron scattering in crystal targets, Phys. Rev. D 104, 095015 (2021).
  54. K. Ramanathan and N. Kurinsky, Ionization yield in silicon for eV-scale electron-recoil processes, Phys. Rev. D 102, 063026 (2020).
  55. G. Cowan, K. Cranmer, E. Gross, and O. Vitells, Asymptotic formulae for likelihood-based tests of new physics, Eur. Phys. J. C 71, 1554 (2011); 73, 2501(E) (2013).
  56. I. M. Bloch et al. (SENSEI Collaboration), SENSEI at SNOLAB: Single-electron event rate and implications for dark matter, Phys. Rev. Lett. 134, 161002 (2025).
  57. P. Adari et al. (SENSEI Collaboration), First direct-detection results on sub-gev dark matter using the SENSEI detector at SNOLAB, Phys. Rev. Lett. 134, 011804 (2025).
  58. XENON Collaboration, Light dark matter search with ionization signals in XENON1T, Phys. Rev. D 123, 251801 (2019).
  59. M. Battaglieri et al., Us cosmic visions: New ideas in dark matter 2017: Community report, arXiv:1707.04591.
