Determination of proton electromagnetic form factors from DVCS measurements

Anoushiravan Moradi1, Muhammad Goharipour2,3, H. Fatehi1, and K. Azizi1,4,3,* (MMGPDs Collaboration)

  • *Contact author: kazem.azizi@ut.ac.ir
PDF

Phys. Rev. D 113, 054034 – Published 23 March, 2026

DOI: https://doi.org/10.1103/c8q9-vxtn

Abstract

We present a detailed analysis of the proton electromagnetic form factors (FFs) using exclusive photon leptoproduction (EP) data in kinematic regions where the Bethe-Heitler (BH) contribution dominates the deeply virtual Compton scattering (DVCS) cross section. By exploiting the sensitivity of the BH amplitude to the Dirac and Pauli FFs, we extract F1(t), F2(t), and the corresponding Sachs FFs within several fitting scenarios based on dipole and P-pole parametrizations, and evaluate the charge and magnetic radii of the proton. In this fitting scenario, we show that EP measurements in the range 0.11<|t|<0.45  GeV2 can provide constraints on F1(t), while offering limited sensitivity to F2(t). The extracted charge radius values tend to be smaller than those obtained from traditional elastic electron-proton scattering measurements and are consistent, within uncertainties, with recent high-precision PRad results. These findings indicate that EP measurements, especially when covering smaller values of |t|, can serve as a complementary tool for determining the proton electromagnetic structure and may contribute to ongoing efforts to better understand the proton charge radius. The methodology developed here provides a framework for future combined analyses of EP and elastic electron-proton scattering data which enables a unified determination of the nucleon FFs.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (105)

  1. X.-D. Ji, Phys. Rev. D 55, 7114 (1997).
  2. A. V. Belitsky, D. Mueller, and A. Kirchner, Nucl. Phys. B629, 323 (2002).
  3. S. Alekhin, Phys. Rev. D 68, 014002 (2003).
  4. X.-D. Ji, Phys. Rev. Lett. 78, 610 (1997).
  5. A. V. Radyushkin, Phys. Lett. B 380, 417 (1996).
  6. A. V. Radyushkin, Phys. Rev. D 56, 5524 (1997).
  7. J. C. Collins and A. Freund, Phys. Rev. D 59, 074009 (1999).
  8. M. Guidal, H. Moutarde, and M. Vanderhaeghen, Rep. Prog. Phys. 76, 066202 (2013).
  9. K. Kumericki, S. Liuti, and H. Moutarde, Eur. Phys. J. A 52, 157 (2016).
  10. E. C. Aschenauer et al., Phys. Rev. D 112, 036010 (2025).
  11. Y. Guo, F. P. Aslan, X. Ji, and M. G. Santiago, Phys. Rev. Lett. 135, 261903 (2025).
  12. G. Xie, W. Kou, Q. Fu, Z. Ye, and X. Chen, Eur. Phys. J. C 83, 900 (2023).
  13. V. M. Braun, P. Gotzler, and A. N. Manashov, arXiv:2512.14295.
  14. M. Diehl, Phys. Rep. 388, 41 (2003).
  15. X. Ji, Annu. Rev. Nucl. Part. Sci. 54, 413 (2004).
  16. A. V. Belitsky and A. V. Radyushkin, Phys. Rep. 418, 1 (2005).
  17. S. Boffi and B. Pasquini, Riv. Nuovo Cimento 30, 387 (2007).
  18. M. Diehl, Eur. Phys. J. A 52, 149 (2016).
  19. B. Kriesten and S. Liuti, Phys. Rev. D 105, 016015 (2022).
  20. C. Mezrag, Few Body Syst. 63, 62 (2022).
  21. C. Lorcé, A. Metz, B. Pasquini, and P. Schweitzer, arXiv:2507.12664.
  22. M. Boër et al., arXiv:2512.15064.
  23. M. Burkardt, Int. J. Mod. Phys. A 18, 173 (2003).
  24. S. Kaur, S. Xu, C. Mondal, X. Zhao, and J. P. Vary (BLFQ Collaboration), Phys. Rev. D 109, 014015 (2024).
  25. K. Cichy, M. Constantinou, P. Sznajder, and J. Wagner, Phys. Rev. D 110, 114025 (2024).
  26. C. A. Aidala, S. D. Bass, D. Hasch, and G. K. Mallot, Rev. Mod. Phys. 85, 655 (2013).
  27. X. Ji, F. Yuan, and Y. Zhao, Nat. Rev. Phys. 3, 27 (2021).
  28. M. V. Polyakov and P. Schweitzer, Int. J. Mod. Phys. A 33, 1830025 (2018).
  29. V. D. Burkert, L. Elouadrhiri, and F. X. Girod, Nature (London) 557, 396 (2018).
  30. K. Kumerički, Nature (London) 570, E1 (2019).
  31. V. Martínez-Fernández, D. Binosi, C. Mezrag, and Z.-Q. Yao, arXiv:2509.06669.
  32. Y. Guo, X. Ji, M. G. Santiago, K. Shiells, and J. Yang, J. High Energy Phys. 05 (2023) 150.
  33. L. Calero Diaz and D. Keller, Phys. Rev. D 112, 096001 (2025).
  34. B. Kriesten, S. Liuti, L. Calero-Diaz, D. Keller, A. Meyer, G. R. Goldstein, and J. Osvaldo Gonzalez-Hernandez, Phys. Rev. D 101, 054021 (2020).
  35. M. Guidal, M. V. Polyakov, A. V. Radyushkin, and M. Vanderhaeghen, Phys. Rev. D 72, 054013 (2005).
  36. M. Diehl and P. Kroll, Eur. Phys. J. C 73, 2397 (2013).
  37. H. Hashamipour, M. Goharipour, K. Azizi, and S. V. Goloskokov, Phys. Rev. D 107, 096005 (2023).
  38. H. Hashamipour, M. Goharipour, and S. S. Gousheh, Phys. Rev. D 100, 016001 (2019).
  39. F. Irani, M. Goharipour, H. Hashamipour, and K. Azizi, Phys. Rev. D 108, 074018 (2023).
  40. S. Bhattacharya, K. Cichy, M. Constantinou, X. Gao, A. Metz, J. Miller, S. Mukherjee, P. Petreczky, F. Steffens, and Y. Zhao, J. High Energy Phys. 01 (2025) 146.
  41. H. Pagels, Phys. Rev. 144, 1250 (1966).
  42. M. Goharipour, H. Hashamipour, H. Fatehi, F. Irani, K. Azizi, and S. V. Goloskokov (MMGPDs Collaboration), Phys. Rev. D 112, 014016 (2025).
  43. M. Goharipour, H. Hashamipour, F. Irani, and K. Azizi (MMGPDs Collaboration), Phys. Rev. D 109, 074042 (2024).
  44. J.-P. Karr, D. Marchand, and E. Voutier, Nat. Rev. Phys. 2, 601 (2020).
  45. H. Gao and M. Vanderhaeghen, Rev. Mod. Phys. 94, 015002 (2022).
  46. W. Xiong and C. Peng, Universe 9, 182 (2023).
  47. I. T. Lorenz, H. W. Hammer, and U.-G. Meissner, Eur. Phys. J. A 48, 151 (2012).
  48. R. Pohl, R. Gilman, G. A. Miller, and K. Pachucki, Annu. Rev. Nucl. Part. Sci. 63, 175 (2013).
  49. J. C. Bernauer and R. Pohl, Sci. Am. 310, 18 (2014).
  50. C. E. Carlson, Prog. Part. Nucl. Phys. 82, 59 (2015).
  51. R. J. Hill, EPJ Web Conf. 137, 01023 (2017).
  52. C. Peset, A. Pineda, and O. Tomalak, Prog. Part. Nucl. Phys. 121, 103901 (2021).
  53. Y.-H. Lin, H.-W. Hammer, and U.-G. Meißner, Sci. Bull. 69, 419 (2024).
  54. R. B. Lumpay, J. C. Jusoy, R. Apas, and E. Auxtero, arXiv:2501.11195.
  55. S. Park, R. Gupta, B. Yoon, S. Mondal, T. Bhattacharya, Y.-C. Jang, B. Joó, and F. Winter (Nucleon Matrix Elements (NME) Collaboration), Phys. Rev. D 105, 054505 (2022).
  56. S. Xu, C. Mondal, J. Lan, X. Zhao, Y. Li, and J. P. Vary (BLFQ Collaboration), Phys. Rev. D 104, 094036 (2021).
  57. M. Goharipour, F. Irani, H. Hashamipour, and K. Azizi (MMGPDs Collaboration), Phys. Lett. B 864, 139423 (2025).
  58. M. Goharipour, F. Irani, M. H. Amiri, H. Fatehi, B. Falahi, A. Moradi, and K. Azizi (MMGPDs Collaboration), Nucl. Phys. B1017, 116962 (2025).
  59. H.-y. Gao, Int. J. Mod. Phys. E 12, 1 (2003); 12, 567(E) (2003).
  60. I. A. Qattan et al., Phys. Rev. Lett. 94, 142301 (2005).
  61. C. F. Perdrisat, V. Punjabi, and M. Vanderhaeghen, Prog. Part. Nucl. Phys. 59, 694 (2007).
  62. C. B. Crawford et al., Phys. Rev. Lett. 98, 052301 (2007).
  63. J. Arrington, W. Melnitchouk, and J. A. Tjon, Phys. Rev. C 76, 035205 (2007).
  64. J. C. Bernauer et al. (A1 Collaboration), Phys. Rev. Lett. 105, 242001 (2010).
  65. J. C. Bernauer et al. (A1 Collaboration), Phys. Rev. C 90, 015206 (2014).
  66. Z. Ye, J. Arrington, R. J. Hill, and G. Lee, Phys. Lett. B 777, 8 (2018).
  67. W. Xiong et al., Nature (London) 575, 147 (2019).
  68. M. E. Christy et al., Phys. Rev. Lett. 128, 102002 (2022).
  69. T. Williams, J. Rittenhouse West, D. W. Higinbotham, and F. Benmokhtar, arXiv:2511.12007.
  70. H. Vaziri, M. R. Shojaei, and P. Masjuan, arXiv:2512.23107.
  71. X.-D. Ji, J. Phys. G 24, 1181 (1998).
  72. K. Goeke, M. V. Polyakov, and M. Vanderhaeghen, Prog. Part. Nucl. Phys. 47, 401 (2001).
  73. P. Kroll, H. Moutarde, and F. Sabatie, Eur. Phys. J. C 73, 2278 (2013).
  74. G. Duplančić, S. Nabeebaccus, K. Passek-Kumerički, B. Pire, L. Szymanowski, and S. Wallon, J. High Energy Phys. 03 (2023) 241.
  75. J.-W. Qiu and Z. Yu, Phys. Rev. D 107, 014007 (2023).
  76. J. C. Collins, L. Frankfurt, and M. Strikman, Phys. Rev. D 56, 2982 (1997).
  77. S. V. Goloskokov and P. Kroll, Eur. Phys. J. C 42, 281 (2005).
  78. S. V. Goloskokov and P. Kroll, Eur. Phys. J. C 53, 367 (2008).
  79. D. Müller, T. Lautenschlager, K. Passek-Kumericki, and A. Schaefer, Nucl. Phys. B884, 438 (2014).
  80. L. Favart, M. Guidal, T. Horn, and P. Kroll, Eur. Phys. J. A 52, 158 (2016).
  81. M. Čuić, G. Duplančić, K. Kumerički, and K. Passek-K., J. High Energy Phys. 12 (2023) 192; 02 (2024) 225(E).
  82. R. Boussarie, M. Fucilla, L. Szymanowski, and S. Wallon, Phys. Rev. Lett. 134, 041901 (2025).
  83. Y. Hatta, H. T. Klest, K. Passek-K., and J. Schoenleber, arXiv:2501.12343.
  84. D. Q. Adams et al., arXiv:2410.23469.
  85. A. V. Belitsky and D. Mueller, Phys. Rev. D 82, 074010 (2010).
  86. M. Benali et al., Nat. Phys. 16, 191 (2020).
  87. K. Kumericki, D. Mueller, K. Passek-Kumericki, and A. Schafer, Phys. Lett. B 648, 186 (2007).
  88. K. Kumericki, D. Mueller, and K. Passek-Kumericki, Nucl. Phys. B794, 244 (2008).
  89. K. Kumerički and D. Mueller, Nucl. Phys. B841, 1 (2010).
  90. K. Kumerički and D. Müller, EPJ Web Conf. 112, 01012 (2016).
  91. H. S. Jo et al. (CLAS Collaboration), Phys. Rev. Lett. 115, 212003 (2015).
  92. J. J. Kelly, Phys. Rev. C 70, 068202 (2004).
  93. F. James and M. Roos, Comput. Phys. Commun. 10, 343 (1975).
  94. H. Dembinski and P. O. et al. (2020), 10.5281/zenodo.3949207.
  95. R. Pohl et al., Nature (London) 466, 213 (2010).
  96. U.-G. Meißner, J. Phys. Conf. Ser. 2586, 012006 (2023).
  97. Z.-F. Cui, D. Binosi, C. D. Roberts, and S. M. Schmidt, Chin. Phys. C 46, 122001 (2022).
  98. M. Ridwan and T. Mart, Mod. Phys. Lett. A 38, 2350157 (2023).
  99. Y. Chen and C. Lorcé, Phys. Rev. D 107, 096003 (2023).
  100. S. Navas et al. (Particle Data Group), Phys. Rev. D 110, 030001 (2024).
  101. C. Alexandrou, S. Bacchio, M. Constantinou, J. Finkenrath, K. Hadjiyiannakou, K. Jansen, G. Koutsou, and A. Vaquero Aviles-Casco, Phys. Rev. D 100, 014509 (2019).
  102. C. Alexandrou, K. Hadjiyiannakou, G. Koutsou, K. Ottnad, and M. Petschlies, Phys. Rev. D 101, 114504 (2020).
  103. Y.-C. Jang, R. Gupta, H.-W. Lin, B. Yoon, and T. Bhattacharya, Phys. Rev. D 101, 014507 (2020).
  104. M. Defurne et al. (Jefferson Lab Hall A Collaboration), Phys. Rev. C 92, 055202 (2015).
  105. M. Defurne et al., Nat. Commun. 8, 1408 (2017).
