How to determine nucleon polarization at existing collider experiments?

Yu-Tie Liang1,2,*, Xiao-Rong Lv1,2, Andrzej Kupsc3,4,†, Boxing Gou1,2,‡, and Hai-Bo Li5,2,§

  • *Contact author: liangyt@impcas.ac.cn
  • †Contact author: andrzej.kupsc@physics.uu.se
  • ‡Contact author: gouboxing@impcas.ac.cn
  • §Contact author: lihb@ihep.ac.cn
PDF

Phys. Rev. D 112, L031502 – Published 27 August, 2025

DOI: https://doi.org/10.1103/c642-1lzb

Abstract

We propose a novel approach to measure the spin polarization of protons produced in electron-positron collisions. Using existing tracking devices and supporting structure material, general-purpose spectrometers can be utilized as a large-acceptance polarimeter without a hardware upgrade. With the proposed approach, the spin polarization of protons can be revealed, providing a complementary and accurate description of the final-state particles. This could have far-reaching implications, such as enabling the complete determination of the nucleon timelike electromagnetic form factors.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. B. Abi et al. (Muon g−2 Collaboration), Measurement of the positive muon anomalous magnetic moment to 0.46 ppm, Phys. Rev. Lett. 126, 141801 (2021).
  2. D. P. Aguillard et al. (Muon g−2 Collaboration), Measurement of the positive muon anomalous magnetic moment to 0.20 ppm, Phys. Rev. Lett. 131, 161802 (2023).
  3. D. Barber et al., The first achievement of longitudinal spin polarization in a high energy electron storage ring, Phys. Lett. B 343, 436 (1995).
  4. I. Nakagawa et al., Polarization measurements of RHIC-pp RUN05 using CNI pC-Polarimeter, AIP Conf. Proc. 915, 912 (2007).
  5. I. G. Alekseev et al., Measurements of single and double spin asymmetry in pp elastic scattering in the CNI region with a polarized atomic hydrogen gas jet target, Phys. Rev. D 79, 094014 (2009).
  6. M. Beckmann et al., The longitudinal polarimeter at hera, Nucl. Instrum. Methods Phys. Res., Sect. A 479, 334 (2002).
  7. A. Zec et al., Ultrahigh-precision Compton polarimetry at 2 GeV, Phys. Rev. C 109, 024323 (2024).
  8. M. Woods (SLD Collaboration), The scanning Compton polarimeter for the SLD experiment, in Workshop on High-energy Electron Polarimeters (Pre-symposium for SPIN 96) (1996), pp. 843–845.
  9. J. M. Grames et al., High precision 5 MeV Mott polarimeter, Phys. Rev. C 102, 015501 (2020).
  10. M. Ablikim et al. (BESIII Collaboration), Polarization and entanglement in baryon-antibaryon pair production in electron-positron annihilation, Nat. Phys. 15, 631 (2019).
  11. Y. Guan et al. (Belle Collaboration), Observation of transverse Λ/Λ¯ hyperon polarization in e+e− annihilation at Belle, Phys. Rev. Lett. 122, 042001 (2019).
  12. G. Bunce et al., Λ0 hyperon polarization in inclusive production by 300-GeV protons on beryllium, Phys. Rev. Lett. 36, 1113 (1976).
  13. J. Duryea et al., Polarization of Ξ− hyperons produced by 800-GeV protons, Phys. Rev. Lett. 67, 1193 (1991).
  14. L. Adamczyk et al. (STAR Collaboration), Global Λ hyperon polarization in nuclear collisions: Evidence for the most vortical fluid, Nature (London) 548, 62 (2017).
  15. M. S. Abdallah et al. (STAR Collaboration), Pattern of global spin alignment of ϕ and K*0 mesons in heavy-ion collisions, Nature (London) 614, 244 (2023).
  16. M. Ablikim et al., Design and construction of the besiii detector, Nucl. Instrum. Methods Phys. Res., Sect. A 614, 345 (2010).
  17. M. Ablikim et al. (BESIII Collaboration), Number of J/ψ events at BESIII, Chin. Phys. C 46, 074001 (2022).
  18. S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
  19. F. Bauer et al. (EDDA Collaboration), Measurement of spin-correlation parameters ANN, ASS, and ASL at 2.1 GeV in proton-proton elastic scattering, Phys. Rev. Lett. 90, 142301 (2003).
  20. J. Bystricky, F. Lehar, and P. Winternitz, Formalism of nucleon-nucleon elastic scattering experiments, J. Phys. France 39, 1 (1978).
  21. F. Betz et al., Polarization parameter in p−p scattering from 328 to 736 MeV, Phys. Rev. 148, 1289 (1966).
  22. D. Cheng et al., Nucleon-nucleon polarization between 300 and 700 MeV, Phys. Rev. 163, 1470 (1967).
  23. O. Chamberlain et al., Small-angle p−p cross sections and polarization at 300 MeV, Phys. Rev. 95, 1348 (1954).
  24. M. Albrow et al., Polarization in elastic proton-proton scattering between 0.86 and 2.74  GeV/c, Nucl. Phys. B23, 445 (1970).
  25. M. W. McNaughton and E. P. Chamberlin, pp elastic analyzing power from 318 to 800 MeV, Phys. Rev. C 24, 1778 (1981).
  26. B. von Przewoski et al., Proton proton analyzing power and spin correlation measurements between 250 MeV and 450 MeV at 7°<θc.m.<90° with an internal target in a storage ring, Phys. Rev. C 58, 1897 (1998).
  27. P. R. Bevington et al., Polarization analyzing power Ay(θ) in pp elastic scattering at 643, 787, and 796 MeV, Phys. Rev. Lett. 41, 384 (1978).
  28. D. Besset et al., Measurement of the spin-dependent parameters D, R, A, and P for small-angle p−p elastic scattering between 300 and 600 MeV, Phys. Rev. D 21, 580 (1980).
  29. Y. Onel et al., Elastic p↑p↑ scattering between 240 and 470 MeV, Phys. Rev. D 40, 35 (1989).
  30. O. Chamberlain et al., Experiments with 315-Mev polarized protons: Proton-proton and proton-neutron scattering, Phys. Rev. 105, 288 (1957).
  31. L. Greeniaus et al., Measurements of pp and pHe4 analyzing powers at medium energies, Nucl. Phys. A322, 308 (1979).
  32. C.-Z. Yuan and M. Karliner, Cornucopia of antineutrons and hyperons from a super J/ψ factory for next-generation nuclear and particle physics high-precision experiments, Phys. Rev. Lett. 127, 012003 (2021).
  33. M. Ablikim et al. (BESIII Collaboration), Probing CP symmetry and weak phases with entangled double-strange baryons, Nature (London) 606, 64 (2022).
  34. GWDAC online database, https://gwdac.phys.gwu.edu/.
  35. M. Achasov et al., STCF conceptual design report (Volume 1): Physics & detector, Front. Phys. 19, 14701 (2024).
  36. M. Ablikim et al. (BESIII Collaboration), First study of reaction Ξ0n→Ξ−p using Ξ0-nucleus scattering at an electron-positron collider, Phys. Rev. Lett. 130, 251902 (2023).
  37. M. Ablikim et al. (BESIII Collaboration), First study of antihyperon-nucleon scattering Λ−p→Λ−p and measurement of Λp→Λp cross section, Phys. Rev. Lett. 132, 231902 (2024).
  38. R. Kunne et al., Asymmetry in p¯p elastic scattering, Phys. Lett. B 206, 557 (1988).
  39. M. Ablikim et al. (BESIII Collaboration), Precise measurements of decay parameters and cp asymmetry with entangled Λ−Λ¯ pairs, Phys. Rev. Lett. 129, 131801 (2022).
  40. D. Grosnick et al., The design and performance of the FNAL high-energy polarized-beam facility, Nucl. Instrum. Methods Phys. Res., Sect. A 290, 269 (1990).
  41. J. Chen et al., Properties of the QCD matter: Review of selected results from the relativistic heavy ion collider beam energy scan (RHIC BES) program, Nucl. Sci. Tech. 35, 214 (2024).
  42. R. Abdul Khalek et al., Science requirements and detector concepts for the electron-ion collider: EIC yellow report, Nucl. Phys. A1026, 122447 (2022).
  43. D. P. Anderle et al., Electron-ion collider in China, Front. Phys. 16, 64701 (2021).
  44. Y. Onuki, Belle II status and prospect, Nucl. Part. Phys. Proc. 318–323, 78 (2022).
  45. A. Hayrapetyan et al. (CMS Collaboration), Development of the CMS detector for the CERN LHC run 3, J. Instrum. 19, P05064 (2024).
  46. G. Aad et al. (ATLAS Collaboration), The ATLAS experiment at the CERN Large Hadron Collider: A description of the detector configuration for run 3, J. Instrum. 19, P05063 (2024).
  47. R. Aaij et al., LHCB detector performance, Int. J. Mod. Phys. A 30, 1530022 (2015).
  48. V. Klochkov, The compressed baryonic matter experiment at fair, Nucl. Phys. A1005, 121945 (2021).
