Triad representation for the anisotropic tensor renormalization group in four dimensions

Yuto Sugimoto* and Shoichi Sasaki†

  • *Contact author: sugimoto@nucl.phys.tohoku.ac.jp
  • †Contact author: ssasaki@nucl.phys.tohoku.ac.jp
PDF

Phys. Rev. D 112, 094514 – Published 25 November, 2025

DOI: https://doi.org/10.1103/c3qc-tn48

Abstract

The development of tensor renormalization group (TRG) algorithm in higher dimensions is an important and urgent task, as the TRG is expected to provide a way to overcome the sign problem in lattice quantum chromodynamics (QCD) calculations at finite density. One possible approach that enables faster computations in four-dimensional lattice theories is the anisotropic tensor renormalization group (ATRG). However, the computational cost remains substantial and requires significant computational resources. In this paper, we propose a novel algorithm, called the triad-ATRG, which is based on the ATRG and other improved TRG variants with triad network representation. This method achieves lower scaling with respect to the bond dimension, while minimizing the loss of accuracy in the free energy and other physical quantities. We also present parallel implementations of both the ATRG and triad-ATRG on multiple GPUs, which significantly improve performance compared to CPU-based calculations for the four-dimensional system.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (72)

  1. M. Levin and C. P. Nave, Phys. Rev. Lett. 99, 120601 (2007).
  2. Y. Shimizu, Chin. J. Phys. 50, 749 (2012).
  3. Y. Shimizu, Mod. Phys. Lett. A 27, 1250035 (2012).
  4. J. F. Yu, Z. Y. Xie, Y. Meurice, Y. Liu, A. Denbleyker, H. Zou, M. P. Qin, and J. Chen, Phys. Rev. E 89, 013308 (2014).
  5. Y. Shimizu and Y. Kuramashi, Phys. Rev. D 90, 014508 (2014).
  6. Y. Shimizu and Y. Kuramashi, Phys. Rev. D 90, 074503 (2014).
  7. J. F. Unmuth-Yockey, Y. Meurice, J. Osborn, and H. Zou, Proc. Sci. LATTICE2014 (2014) 325 [arXiv:1411.4213].
  8. H. Zou, Y. Liu, C.-Y. Lai, J. Unmuth-Yockey, A. Bazavov, Z. Y. Xie, T. Xiang, S. Chandrasekharan, S. W. Tsai, and Y. Meurice, Phys. Rev. A 90, 063603 (2014).
  9. S. Wang, Z. Y. Xie, J. Chen, B. Normand, and T. Xiang, Chin. Phys. Lett. 31, 070503 (2014).
  10. S. Takeda and Y. Yoshimura, Prog. Theor. Exp. Phys. 2015, 043B01 (2015).
  11. L.-P. Yang, Y. Liu, H. Zou, Z. Y. Xie, and Y. Meurice, Phys. Rev. E 93, 012138 (2016).
  12. N. Nakamoto and S. Takeda, Computation of correlation functions by tensor renormalization group method (2016), 10.24517/00011105.
  13. H.-H. Zhao, Z.-Y. Xie, T. Xiang, and M. Imada, Phys. Rev. B 93, 125115 (2016).
  14. H. Kawauchi and S. Takeda, Phys. Rev. D 93, 114503 (2016).
  15. M. Bal, M. Mariën, J. Haegeman, and F. Verstraete, Phys. Rev. Lett. 118, 250602 (2017).
  16. R. Sakai, S. Takeda, and Y. Yoshimura, Prog. Theor. Exp. Phys. 2017, 063B07 (2017).
  17. R. Sakai, D. Kadoh, Y. Kuramashi, Y. Nakamura, S. Takeda, and Y. Yoshimura, EPJ Web Conf. 175, 11019 (2018).
  18. D. Kadoh, Y. Kuramashi, Y. Nakamura, R. Sakai, S. Takeda, and Y. Yoshimura, J. High Energy Phys. 03 (2018) 141.
  19. Y. Shimizu and Y. Kuramashi, Phys. Rev. D 97, 034502 (2018).
  20. D. Kadoh, Y. Kuramashi, Y. Nakamura, R. Sakai, S. Takeda, and Y. Yoshimura, J. High Energy Phys. 05 (2019) 184.
  21. Y. Kuramashi and Y. Yoshimura, J. High Energy Phys. 08 (2019) 023.
  22. Y. Yoshimura, Y. Kuramashi, Y. Nakamura, S. Takeda, and R. Sakai, Phys. Rev. D 97, 054511 (2018).
  23. S. Akiyama, Y. Kuramashi, T. Yamashita, and Y. Yoshimura, Proc. Sci. LATTICE2019 (2019) 138 [arXiv:1911.12954].
  24. A. Bazavov, S. Catterall, R. G. Jha, and J. Unmuth-Yockey, Phys. Rev. D 99, 114507 (2019).
  25. S. Akiyama, Y. Kuramashi, T. Yamashita, and Y. Yoshimura, Phys. Rev. D 100, 054510 (2019).
  26. D. Kadoh, Y. Kuramashi, Y. Nakamura, R. Sakai, S. Takeda, and Y. Yoshimura, J. High Energy Phys. 02 (2020) 161.
  27. S. Akiyama, D. Kadoh, Y. Kuramashi, T. Yamashita, and Y. Yoshimura, J. High Energy Phys. 09 (2020) 177.
  28. C. Delcamp and A. Tilloy, Phys. Rev. Res. 2, 033278 (2020).
  29. S. Iino, S. Morita, and N. Kawashima, Phys. Rev. B 101, 155418 (2020).
  30. S. Hong and D.-H. Kim, Phys. Rev. E 101, 012124 (2020).
  31. S. Akiyama and Y. Kuramashi, Phys. Rev. D 104, 014504 (2021).
  32. S. Akiyama, Y. Kuramashi, T. Yamashita, and Y. Yoshimura, J. High Energy Phys. 01 (2021) 121.
  33. S. Akiyama, Y. Kuramashi, and Y. Yoshimura, Phys. Rev. D 104, 034507 (2021).
  34. J. Bloch, R. G. Jha, R. Lohmayer, and M. Meister, Phys. Rev. D 104, 094517 (2021).
  35. M. Fukuma, D. Kadoh, and N. Matsumoto, Prog. Theor. Exp. Phys. 2021, 123B03 (2021).
  36. M. Hirasawa, A. Matsumoto, J. Nishimura, and A. Yosprakob, J. High Energy Phys. 12 (2021) 011.
  37. P. Milde, J. Bloch, and R. Lohmayer, Proc. Sci. LATTICE2021 (2022) 462 [arXiv:2112.01906].
  38. K. Nakayama, L. Funcke, K. Jansen, Y.-J. Kao, and S. Kühn, Phys. Rev. D 105, 054507 (2022).
  39. T. Kuwahara and A. Tsuchiya, Prog. Theor. Exp. Phys. 2022, 093B02 (2022).
  40. S. Akiyama, Y. Kuramashi, and T. Yamashita, Prog. Theor. Exp. Phys. 2022, 023I01 (2022).
  41. S. Akiyama, J. High Energy Phys. 11 (2022) 030.
  42. S. Akiyama and Y. Kuramashi, J. High Energy Phys. 05 (2022) 102.
  43. R. G. Jha, arXiv:2201.01789.
  44. X. Luo and Y. Kuramashi, Phys. Rev. D 107, 094509 (2023).
  45. S. Akiyama and Y. Kuramashi, J. High Energy Phys. 10 (2023) 077.
  46. S. Akiyama, R. G. Jha, and J. Unmuth-Yockey, Phys. Rev. D 110, 034519 (2024).
  47. A. Samlodia, V. Longia, R. G. Jha, and A. Joseph, Phys. Rev. D 110, 034504 (2024).
  48. S. Akiyama and Y. Kuramashi, J. High Energy Phys. 09 (2024) 086.
  49. K. H. Pai, S. Akiyama, and S. Todo, J. High Energy Phys. 03 (2025) 027.
  50. H. Kanno, S. Akiyama, K. Murakami, and S. Takeda, arXiv:2412.08959.
  51. X. Luo and Y. Kuramashi, J. High Energy Phys. 07 (2025) 036.
  52. Y.-H. Tseng, S.-W. Li, and F.-J. Jiang, arXiv:2503.12361.
  53. Z. Y. Xie, J. Chen, M. P. Qin, J. W. Zhu, L. P. Yang, and T. Xiang, Phys. Rev. B 86, 045139 (2012).
  54. D. Adachi, T. Okubo, and S. Todo, Phys. Rev. B 102, 054432 (2020).
  55. D. Kadoh and K. Nakayama, arXiv:1912.02414.
  56. K. Nakayama, Proc. Sci. LATTICE2023 (2024) 029 [arXiv:2401.06389].
  57. K. Nakayama, arXiv:2307.14191.
  58. N. Halko, P. G. Martinsson, and J. A. Tropp, SIAM Rev. 53, 217 (2011).
  59. S. Morita, R. Igarashi, H.-H. Zhao, and N. Kawashima, Phys. Rev. E 97, 033310 (2018).
  60. L. De Lathauwer, B. De Moor, and J. Vandewalle, SIAM J. Matrix Anal. Appl. 21, 1253 (2000).
  61. S. Akiyama, Tensor renormalization group approach to higher-dimensional lattice field theories, Ph.D. thesis, University of Tsukuba, 2022, https://tsukuba.repo.nii.ac.jp/records/2005504.
  62. H. Oba, Prog. Theor. Exp. Phys. 2020, 013B02 (2020).
  63. L. Wang and F. Verstraete, arXiv:1110.4362.
  64. C. Wang, S.-M. Qin, and H.-J. Zhou, Phys. Rev. B 90, 174201 (2014).
  65. S. Iino, S. Morita, and N. Kawashima, Phys. Rev. B 100, 035449 (2019).
  66. K. Nakayama and M. Schneider, Phys. Rev. D 110, 094501 (2024).
  67. Y. Sugimoto and S. Sasaki, Proc. Sci. LATTICE2024 (2025) 038 [arXiv:2412.14104].
  68. R. G. Jha and A. Samlodia, Comput. Phys. Commun. 294, 108941 (2024).
  69. T. Yamashita and T. Sakurai, Comput. Phys. Commun. 278, 108423 (2022).
  70. Z.-C. Gu and X.-G. Wen, Phys. Rev. B 80, 155131 (2009).
  71. P. H. Lundow and K. Markström, Nucl. Phys. B993, 116256 (2023).
  72. https://github.com/QuantumKitHub/TensorOperations.jl/tree/master.
