Correlator polytopes

Carolina Figueiredo1,* and Francisco Vazão2,†

  • *Contact author: cfigueiredo@princeton.edu
  • †Contact author: fvvazao@mpp.mpg.de
PDF

Phys. Rev. D 113, 025005 – Published 7 January, 2026

DOI: https://doi.org/10.1103/bq27-6d26

Abstract

Recently, “cosmohedra” have been introduced as polytopes underlying the cosmological wave function for conformally coupled Tr(Φ3) theory in Friedmann-Lemaître-Robertson-Walker cosmologies, generalizing associahedra for flat space scattering amplitudes. In this paper we show that correlation functions are also directly captured by a new polytope—the Correlatron. The combinatorics of correlation functions is an interesting blend of flat space scattering amplitudes and wave functions. This is reflected in the correlatron geometry, which is a one-higher dimensional polytope sandwiched between cosmohedron and associahedron facets. We provide an explicit embedding for the correlatron, which is a natural extension of the “shaving” picture for cosmohedra to one higher dimension. As a byproduct, we also define “graph correlahedra” as polytopes for the contribution to correlators from any fixed graph. We show how the canonical form of these polytopes directly computes the graph correlator, without the power of two weights seen in previous geometric formulations. Finally, we give a prescription for extracting the full correlator from the canonical form of the correlatron.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. N. Arkani-Hamed, Y. Bai, S. He, and G. Yan, J. High Energy Phys. 05 (2018) 096.
  2. N. Arkani-Hamed, P. Benincasa, and A. Postnikov, arXiv:1709.02813.
  3. N. Arkani-Hamed, C. Figueiredo, and F. Vazão, J. High Energy Phys. 11 (2025) 029.
  4. D. Anninos, T. Anous, D. Z. Freedman, and G. Konstantinidis, J. Cosmol. Astropart. Phys. 11 (2015) 048.
  5. N. Arkani-Hamed, D. Baumann, H. Lee, and G. L. Pimentel, J. High Energy Phys. 04 (2020) 105.
  6. N. Arkani-Hamed, D. Baumann, A. Hillman, A. Joyce, H. Lee, and G. L. Pimentel, J. High Energy Phys. 09 (2025) 009.
  7. N. Arkani-Hamed, D. Baumann, A. Hillman, A. Joyce, H. Lee, and G. L. Pimentel, Phys. Rev. Lett. 135, 031602 (2025).
  8. P. Benincasa and G. Dian, SciPost Phys. 18, 105 (2025).
  9. P. Benincasa and F. Vazão, SciPost Phys. 19, 029 (2025).
  10. H. Goodhew, S. Jazayeri, and E. Pajer, J. Cosmol. Astropart. Phys. 04 (2021) 021.
  11. P. Benincasa, Int. J. Mod. Phys. A 37, 2230010 (2022).
  12. D. Baumann, H. Goodhew, and H. Lee, J. High Energy Phys. 07 (2025) 131.
  13. P. Benincasa and F. Vazão, SciPost Phys. 18, 176 (2025).
  14. S. Melville and E. Pajer, J. High Energy Phys. 05 (2021) 249.
  15. S. Jazayeri, E. Pajer, and D. Stefanyszyn, J. High Energy Phys. 10 (2021) 065.
  16. H. Goodhew, S. Jazayeri, M. H. G. Lee, and E. Pajer, J. Cosmol. Astropart. Phys. 08 (2021) 003.
  17. F. Vicente Vazão, On the analytical and combinatorial structure of cosmological observables, Ph.D. thesis, Munich University (2025).
  18. P. Benincasa and F. Vazão, Lect. Notes Phys. 1041, 131 (2025).
  19. P. Benincasa, G. Brunello, M. K. Mandal, P. Mastrolia, and F. Vazão, Phys. Rev. D 111, 085016 (2025).
  20. S. De and A. Pokraka, J. High Energy Phys. 03 (2025) 040.
  21. S. Melville and G. L. Pimentel, J. High Energy Phys. 08 (2024) 211.
  22. T. Heckelbacher, I. Sachs, E. Skvortsov, and P. Vanhove, J. High Energy Phys. 08 (2022) 139.
  23. S. Agui Salcedo and S. Melville, J. High Energy Phys. 12 (2023) 076.
  24. D. Meltzer, J. Cosmol. Astropart. Phys. 12 (2021) 018.
  25. N. Bittermann and A. Joyce, J. High Energy Phys. 03 (2023) 092.
  26. S. Céspedes, A.-C. Davis, and S. Melville, J. High Energy Phys. 02 (2021) 012.
  27. C. Chowdhury, A. Lipstein, J. Marshall, J. Mei, and I. Sachs, arXiv:2503.10598.
  28. S. De, S. Paranjape, A. Pokraka, M. Spradlin, and A. Volovich, J. High Energy Phys. 07 (2025) 174.
  29. S. De and A. Pokraka, J. High Energy Phys. 03 (2025) 040.
  30. D. Baumann, H. Goodhew, A. Joyce, H. Lee, G. L. Pimentel, and T. Westerdijk, arXiv:2504.14890.
  31. R. Glew and T. Lukowski, J. High Energy Phys. 09 (2025) 074.
  32. R. Glew, J. High Energy Phys. 07 (2025) 064.
  33. P. Benincasa, arXiv:1909.02517.
  34. B. Fan and Z.-Z. Xianyu, J. High Energy Phys. 12 (2024) 042.

  35. Of course, these are outside the physical kinematic locus where all the |k→i|>0.

  36. At loop-level the momentum polygon can be replaced by a surface, Sn, which specify the order in the topological expansion under consideration, and everything else holds the same—diagrams correspond to triangulations of Sn and russian dolls are given by maximal collections of nested (nonoverlapping) subsurfaces of Sn. For example, at one-loop n-points Sn would be the one-punctured disk with n-marked points on the boundary.

  37. N. Arkani-Hamed, H. Frost, G. Salvatori, P.-G. Plamondon, and H. Thomas (to be published).
  38. N. Arkani-Hamed, Y. Bai, S. He, and G. Yan, J. High Energy Phys. 05 (2018) 096.
  39. H. Goodhew, A. Thavanesan, and A. C. Wall, arXiv:2408.17406.
  40. A. Thavanesan, arXiv:2501.06383.

  41. Here we are assuming for simplicity that δ12345=0.

  42. N. Arkani-Hamed, S. He, G. Salvatori, and H. Thomas, J. High Energy Phys. 11 (2022) 049.
  43. N. Arkani-Hamed, S. He, T. Lam, and H. Thomas, Phys. Rev. D 107, 066015 (2023).
  44. N. Arkani-Hamed, H. Frost, G. Salvatori, P.-G. Plamondon, and H. Thomas, J. High Energy Phys. 09 (2025) 033.
  45. N. Arkani-Hamed, H. Frost, G. Salvatori, P.-G. Plamondon, and H. Thomas, J. High Energy Phys. 08 (2025) 194.
  46. G. Salvatori, J. High Energy Phys. 12 (2019) 074.
  47. N. Arkani-Hamed, Q. Cao, J. Dong, C. Figueiredo, and S. He, Phys. Rev. Lett. 134, 171601 (2025).

  48. The doubling of the variables ending on the puncture, Xi,p and X˜i,p, is important to obtain a closed polytope at one-loop as explained in [37].
