Finding supermassive black hole binary mergers in Pulsar Timing Array data

Sharon Mary Tomson*, Boris Goncharov, and Rutger van Haasteren

  • *Contact author: sharon.mary.tomson@aei.mpg.de
PDF

Phys. Rev. D 113, 124027 – Published 10 June, 2026

DOI: https://doi.org/10.1103/99r4-ks5s

Abstract

Galaxy observations suggest that mergers of supermassive black hole binaries (SMBHBs) are rare events on cosmological scales, with characteristic rates of order one per decade across the observable Universe. In this work, we present a framework to search for merging SMBHBs in pulsar timing array (PTA) data using a physically complete waveform model that includes the late inspiral, merger, ringdown, and gravitational-wave memory. This approach enables a unified treatment of continuous premerger emission and the nonoscillatory memory signal associated with coalescence. Using simulated PTA datasets, we demonstrate a proof of principle for parameter estimation of merging SMBHBs, focusing on representative systems with chirp masses of 108 and 1010M⊙ at distances of 3 Mpc and 100 Mpc respectively. These signals are distinguishable for a PTA consisting of 25 pulsars observed over 13 years with 100 ns timing precision. For these sufficiently strong signals, we recover the simulated binaries with log Bayes factors exceeding 10, and show that chirp mass and luminosity distance can be jointly constrained with uncertainties governed by the characteristic mass-distance degeneracy of the signal. The sky position uncertainties are of the order of a few degrees, which could potentially enable electromagnetic follow-up and multimessenger observations of SMBHB mergers. We also show that the measurement uncertainties on the parameters of simulated merging binaries depend weakly on the presence of the gravitational wave background with Hellings-Downs correlations in our simulated data. We further demonstrate that commonly used memory burst approximations lead to biased strain amplitudes and inferred source parameters when compared to the full SMBHB waveform, even when optimally tuned. These results establish a pathway toward searching for SMBHB mergers and late-stage inspirals with PTAs using physically complete waveform models, complementing existing searches for continuous gravitational waves.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (80)

  1. R. S. Foster and D. C. Backer, Astrophys. J. 361, 300 (1990).
  2. M. A. McLaughlin, Classical Quantum Gravity 30, 224008 (2013).
  3. R. N. Manchester et al., Pub. Astron. Soc. Aust. 30, e017 (2013).
  4. G. Desvignes et al., Mon. Not. R. Astron. Soc. 458, 3341 (2016).
  5. P. Tarafdar et al., Pub. Astron. Soc. Aust. 39, e053 (2022).
  6. K. J. Lee, in Frontiers in Radio Astronomy and FAST Early Sciences Symposium 2015, Astronomical Society of the Pacific Conference Series Vol. 502, edited by L. Qain and D. Li (Astronomical Society of the Pacific, San Francisco, 2016), p. 19.
  7. M. T. Miles, R. M. Shannon, M. Bailes, D. J. Reardon, M. J. Keith, A. D. Cameron, A. Parthasarathy, M. Shamohammadi, R. Spiewak, W. van Straten, S. Buchner, F. Camilo, M. Geyer, A. Karastergiou, M. Kramer, M. Serylak, G. Theureau, and V. Venkatraman Krishnan, Mon. Not. R. Astron. Soc. 519, 3976 (2023).
  8. J. P. W. Verbiest et al., Mon. Not. R. Astron. Soc. 458, 1267 (2016).
  9. Z. Arzoumanian, P. T. Baker, H. Blumer, B. Bécsy, A. Brazier, P. R. Brook, S. Burke-Spolaor, S. Chatterjee, S. Chen, J. M. Cordes, N. J. Cornish, F. Crawford, H. T. Cromartie, M. E. Decesar, P. B. Demorest, T. Dolch, J. A. Ellis, E. C. Ferrara, W. t. Fiore (Nanograv Collaboration), Astrophys. J. Lett. 905, L34 (2020).
  10. B. Goncharov et al., Astrophys. J. Lett. 917, L19 (2021).
  11. B. Goncharov, E. Thrane, R. M. Shannon, J. Harms, N. D. R. Bhat, G. Hobbs, M. Kerr, R. N. Manchester, D. J. Reardon, C. J. Russell, X.-J. Zhu, and A. Zic, Astrophys. J. Lett. 932, L22 (2022).
  12. S. Chen et al., Mon. Not. R. Astron. Soc. 508, 4970 (2021).
  13. J. Antoniadis et al., Mon. Not. R. Astron. Soc. 510, 4873 (2022).
  14. G. Agazie et al., Astrophys. J. Lett. 951, L8 (2023).
  15. J. Antoniadis et al. (EPTA Collaboration and InPTA Collaboration), Astron. Astrophys. 678, A50 (2023).
  16. D. J. Reardon et al., Astrophys. J. Lett. 951, L6 (2023).
  17. M. T. Miles et al., Mon. Not. R. Astron. Soc. 536, 1489 (2025).
  18. H. Xu et al., Res. Astron. Astrophys. 23, 075024 (2023).
  19. A. Afzal et al., Astrophys. J. Lett. 951, L11 (2023).
  20. J. Antoniadis et al. (EPTA Collaboration and InPTA Collaboration), Astron. Astrophys. 685, A94 (2024).
  21. J. Ellis, F. Jenet, and X. Siemens, in American Astronomical Society Meeting Abstracts #219, American Astronomical Society Meeting Abstracts Vol. 219 (American Astronomical Society, 2012), p. 146.20.
  22. T. Damour and A. Vilenkin, Phys. Rev. Lett. 85, 3761 (2000).
  23. Y. Xia, J. Wang, S. Kuroyanagi, W. Yan, Y. Wen, A. Kapur, J. Zou, Y. Feng, V. Di Marco, S. Mishra, C. J. Russell, S. Wang, D. Zhao, and X. Zhu, Universe 11, 81 (2025).
  24. M. Turner, Astrophys. J. 216, 610 (1977).
  25. M. Favata, Classical Quantum Gravity 27, 084036 (2010).
  26. R. van Haasteren and Y. Levin, Mon. Not. R. Astron. Soc. 401, 2372 (2010).
  27. S. Dandapat, A. Susobhanan, L. Dey, A. Gopakumar, P. T. Baker, and P. Jetzer, Phys. Rev. D 109, 103018 (2024).
  28. N. Agarwal et al., arXiv:2508.16534.
  29. J. A. Taylor, R. Burnette, B. Bécsy, and N. J. Cornish, Phys. Rev. D 111, 022006 (2025).
  30. S. Dandapat, M. Ebersold, A. Susobhanan, P. Rana, A. Gopakumar, S. Tiwari, M. Haney, H. M. Lee, and N. Kolhe, Phys. Rev. D 108, 024013 (2023).
  31. R. Epstein, Astrophys. J. 223, 1037 (1978).
  32. D. R. Madison, D. F. Chernoff, and J. M. Cordes, Phys. Rev. D 96, 123016 (2017).
  33. N. Sago, K. Ioka, T. Nakamura, and R. Yamazaki, Phys. Rev. D 70, 104012 (2004).
  34. Y. B. Zel’dovich and A. G. Polnarev, Sov. Astron. 18, 17 (1974).
  35. V. B. Braginsky and K. S. Thorne, Nature (London) 327, 123 (1987).
  36. D. Christodoulou, Phys. Rev. Lett. 67, 1486 (1991).
  37. M. Favata, Astrophys. J. Lett. 696, L159 (2009).
  38. N. Seto, Mon. Not. R. Astron. Soc. 400, L38 (2009).
  39. M. S. Pshirkov, D. Baskaran, and K. A. Postnov, Mon. Not. R. Astron. Soc. 402, 417 (2010).
  40. J. B. Wang et al., Mon. Not. R. Astron. Soc. 446, 1657 (2015).
  41. K. Aggarwal et al., Astrophys. J. 889, 38 (2020).
  42. G. Agazie et al. (The Nanograv Collaboration), Astrophys. J. 963, 61 (2024).
  43. G. Agazie et al., Astrophys. J. 987, 5 (2025).
  44. J. Yoo, K. Mitman, V. Varma, M. Boyle, S. E. Field, N. Deppe, F. Hébert, L. E. Kidder, J. Moxon, H. P. Pfeiffer, M. A. Scheel, L. C. Stein, S. A. Teukolsky, W. Throwe, and N. L. Vu, Phys. Rev. D 108, 064027 (2023).
  45. N. Bishop, R. Gomez, L. Lehner, and J. Winicour, arXiv:gr-qc/9705033.
  46. J. Moxon, M. A. Scheel, S. A. Teukolsky, N. Deppe, N. Vu, F. Hébert, L. E. Kidder, and W. Throwe, Phys. Rev. D 107, 064013 (2023).
  47. K. Mitman, J. Moxon, M. A. Scheel, S. A. Teukolsky, M. Boyle, N. Deppe, L. E. Kidder, and W. Throwe, Phys. Rev. D 102, 104007 (2020).
  48. J. A. Ellis, X. Siemens, and J. D. E. Creighton, Astrophys. J. 756, 175 (2012).
  49. J. W. McKee et al., Mon. Not. R. Astron. Soc. 461, 2809 (2016).
  50. S. M. Tomson, Smbhb_merger_memory, https://github.com/sharontomson/SMBHB_Merger_Memory (2026), gitHub repository.
  51. M. T. Miles et al., Mon. Not. R. Astron. Soc. 536, 1467 (2025).
  52. R. van Haasteren, Y. Levin, P. McDonald, and T. Lu, Mon. Not. R. Astron. Soc. 395, 1005 (2009).
  53. W. Coles, G. Hobbs, D. J. Champion, R. N. Manchester, and J. P. W. Verbiest, Mon. Not. R. Astron. Soc. 418, 561 (2011).
  54. R. M. Shannon and J. M. Cordes, Astrophys. J. 725, 1607 (2010).
  55. L. Lentati, P. Alexander, M. P. Hobson, S. Taylor, J. Gair, S. T. Balan, and R. van Haasteren, Phys. Rev. D 87, 104021 (2013).
  56. R. van Haasteren and M. Vallisneri, Mon. Not. R. Astron. Soc. 446, 1170 (2015).
  57. B. Allen and J. D. Romano, Phys. Rev. Lett. 134, 031401 (2025).
  58. M. Crisostomi, R. van Haasteren, P. M. Meyers, and M. Vallisneri, arXiv:2506.13866.
  59. R. W. Hellings and G. S. Downs, Astrophys. J. Lett. 265, L39 (1983).
  60. Z. Arzoumanian et al. (NANOGrav Collaboration), Astrophys. J. 821, 13 (2016).
  61. J. Antoniadis, Z. Arzoumanian, S. Babak, M. Bailes, A. S. Bak Nielsen, P. T. Baker, C. G. Bassa, B. Bécsy, A. Berthereau, M. Bonetti, A. Brazier, P. R. Brook, M. Burgay, S. Burke-Spolaor, R. N. Caballero, J. A. Casey-Clyde et al., Mon. Not. R. Astron. Soc. 510, 4873 (2022).
  62. S. Hee, W. J. Handley, M. P. Hobson, and A. N. Lasenby, Mon. Not. R. Astron. Soc. 455, 2461 (2016).
  63. S. R. Taylor, P. T. Baker, J. S. Hazboun, J. Simon, and S. J. Vigeland, enterprise_extensions (2021) https://github.com/nanograv/enterprise_extensions, v2.4.3.
  64. A. Petiteau, S. Babak, A. Sesana, and M. de Araújo, Phys. Rev. D 87, 064036 (2013).
  65. J. Ellis and R. van Haasteren, ptmcmcsampler: Parallel tempering MCMC sampler package written in Python, Astrophysics Source Code Library, record ascl:1912.017 (2019) https://ui.adsabs.harvard.edu/abs/2019ascl.soft12017E.
  66. D. Pollney and C. Reisswig, Astrophys. J. Lett. 732, L13 (2011).
  67. M. Favata, Phys. Rev. D 84, 124013 (2011).
  68. A. Sesana, Astrophys. J. 719, 851 (2010).
  69. E. M. Gutiérrez, L. Combi, S. C. Noble, M. Campanelli, J. H. Krolik, F. López Armengol, and F. García, Astrophys. J. 928, 137 (2022).
  70. T. Bogdanović, M. C. Miller, and L. Blecha, Living Rev. Relativity 25, 3 (2022).
  71. J. Cardinal Tremblay, B. Goncharov, R. van Haasteren, N. D. R. Bhat, Z.-C. Chen, V. Di Marco, S. Iguchi, A. Kapur, W. Ling, R. Mandow, S. Mishra, D. J. Reardon, R. M. Shannon, H. Sudou, J. Wang, S.-Y. Zhao, X.-J. Zhu, and A. Zic, arXiv:2508.20007.
  72. B. P. Abbott et al., Ann. Phys. (Berlin) 529, 1600209 (2017).
  73. S. M. Tomson et al., Astrophys. J. Lett. 996, L9 (2026).
  74. S. Field, V. Varma, J. Blackman, B. Gadre, C. Galley, T. Islam, K. Mitman, M. Pürrer, A. Ravichandran, M. Scheel, L. Stein, and J. Yoo, J. Open Source Softwaare 10, 7073 (2025).
  75. https://github.com/bencebecsy/pta_replicator.
  76. https://github.com/sharontomson/SMBHB_Merger_Memory.
  77. J. A. Ellis, M. Vallisneri, S. R. Taylor, and P. T. Baker, enterprise: Enhanced Numerical Toolbox Enabling a Robust PulsaR Inference SuitE (2020) 10.5281/zenodo.4059815.
  78. https://github.com/bvgoncharov/enterprise_warp.
  79. https://github.com/nanograv/enterprise.
  80. S. M. Tomson, Simulated pulsar timing array data for smbhb merger searches with full waveform memory (2026) 10.5281/zenodo.19385397.
