Sensitivity to longitudinal vector boson scattering and doubly charged Higgs boson production in W±W±jj at future hadron colliders

Aram Apyan and Samuel Kelson

Chilufya Mwewa and Marc-André Pleier

Luka Nedic

Karolos Potamianos

PDF

Phys. Rev. D 112, 093001 – Published 4 November, 2025

DOI: https://doi.org/10.1103/99r1-vq2h

Abstract

We study the sensitivity to longitudinal vector boson scattering at a 27-, 50-, and 100-TeV pp collider using events containing two leptonically decaying same-electric-charge W bosons produced in association with two jets. The baseline FCC-hh detector parametrization within the Delphes framework is used under the assumption of fully efficient pileup mitigation. A tightly constrained phase space with a dijet mass greater than 2 TeV is considered in order to suppress the impact of potential instrumental backgrounds. Based on this setup, the expected sensitivity to the production of longitudinally polarized same-sign W boson pairs is evaluated. Additionally, expected limits are set on doubly charged Higgs bosons produced via vector boson fusion processes and decaying to same-sign W boson pairs.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (49)

  1. M. J. G. Veltman, Second threshold in weak interactions, Acta Phys. Pol. B 8, 475 (1977), https://inspirehep.net/literature/110700.
  2. B. W. Lee, C. Quigg, and H. B. Thacker, The strength of weak interactions at very high-energies and the Higgs boson mass, Phys. Rev. Lett. 38, 883 (1977).
  3. B. W. Lee, C. Quigg, and H. B. Thacker, Weak interactions at very high-energies: The role of the Higgs boson mass, Phys. Rev. D 16, 1519 (1977).
  4. ATLAS Collaboration, Observation of a new particle in the search for the standard model Higgs boson with the ATLAS detector at the LHC, Phys. Lett. B 716, 1 (2012).
  5. CMS Collaboration, Observation of a new boson at a mass of 125 GeV with the CMS experiment at the LHC, Phys. Lett. B 716, 30 (2012).
  6. D. Espriu and B. Yencho, Longitudinal WW scattering in light of the Higgs boson discovery, Phys. Rev. D 87, 055017 (2013).
  7. J. Chang, K. Cheung, C.-T. Lu, and T.-C. Yuan, WW scattering in the era of post-Higgs-boson discovery, Phys. Rev. D 87, 093005 (2013).
  8. S. J. Lee, M. Park, and Z. Qian, Probing unitarity violation in the tail of the off-shell Higgs boson in VLVL mode, Phys. Rev. D 100, 011702 (2019).
  9. A. Abada et al., FCC-hh: The hadron collider: Future circular collider conceptual design report volume 3, Eur. Phys. J. Spec. Top. 228, 755 (2019).
  10. CEPC Conceptual Design Report: Volume 1—Accelerator, 2018, https://inspirehep.net/literature/1692577.
  11. ATLAS Collaboration, Evidence for electroweak production of W±W±jj in pp collisions at s=8  TeV with the ATLAS detector, Phys. Rev. Lett. 113, 141803 (2014).
  12. CMS Collaboration, Study of vector boson scattering and search for new physics in events with two same-sign leptons and two jets, Phys. Rev. Lett. 114, 051801 (2015).
  13. CMS Collaboration, Observation of electroweak production of same-sign W boson pairs in the two jet and two same-sign lepton final state in proton–proton collisions at s=13  TeV, Phys. Rev. Lett. 120, 081801 (2018).
  14. ATLAS Collaboration, Observation of electroweak production of a same-sign W boson pair in association with two jets in pp collisions at s=13  TeV with the ATLAS detector, Phys. Rev. Lett. 123, 161801 (2019).
  15. CMS Collaboration, Measurements of production cross sections of WZ and same-sign WW boson pairs in association with two jets in proton–proton collisions at s=13  TeV, Phys. Lett. B 809, 135710 (2020).
  16. ATLAS Collaboration, Measurement and interpretation of same-sign W boson pair production in association with two jets in pp collisions at s=13  TeV with the ATLAS detector, J. High Energy Phys. 04 (2024) 026.
  17. A. Ballestrero, E. Maina, and G. Pelliccioli, Different polarization definitions in same-sign WW scattering at the LHC, Phys. Lett. B 811, 135856 (2020).
  18. ATLAS Collaboration, Evidence for longitudinally polarized W bosons in the electroweak production of same-sign W boson pairs in association with two jets in pp collisions at s=13  TeV with the ATLAS detector, Phys. Rev. Lett. 135, 111802 (2025).
  19. CMS Collaboration, Measurements of production cross sections of polarized same-sign W boson pairs in association with two jets in proton–proton collisions at s=13  TeV, Phys. Lett. B 812, 136018 (2021).
  20. J. Searcy, L. Huang, M.-A. Pleier, and J. Zhu, Determination of the WW polarization fractions in pp→W±W±jj using a deep machine learning technique, Phys. Rev. D 93, 094033 (2016).
  21. J. Lee, N. Chanon, A. Levin, J. Li, M. Lu, Q. Li, and Y. Mao, Polarization fraction measurement in same-sign WW scattering using deep learning, Phys. Rev. D 99, 033004 (2019).
  22. P. Azzi et al., Standard model physics at the HL-LHC and HE-LHC, CERN Yellow Rep. Monogr. 7, 1 (2019).
  23. J. Roloff, V. Cavaliere, M.-A. Pleier, and L. Xu, Sensitivity to longitudinal vector boson scattering in semileptonic final states at the HL-LHC, Phys. Rev. D 104, 093002 (2021).
  24. CMS Collaboration, Prospects for the measurement of vector boson scattering production in leptonic W±W± and WZ diboson events at s=14  TeV at the High-Luminosity LHC, Technical Report No. CMS-PAS-FTR-21-001, CERN, Geneva, 2021, https://cds.cern.ch/record/2776773.
  25. T. Yang, S. Qian, Z. Guan, C. Li, F. Meng, J. Xiao, M. Lu, and Q. Li, Longitudinally polarized ZZ scattering at a muon collider, Phys. Rev. D 104, 093003 (2021).
  26. H. Georgi and M. Machacek, Doubly charged Higgs bosons, Nucl. Phys. B262, 463 (1985).
  27. CMS Collaboration, Search for charged Higgs bosons produced in vector boson fusion processes and decaying into vector boson pairs in proton–proton collisions at s=13  TeV, Eur. Phys. J. C 81, 723 (2021).
  28. J. Alwall et al., The automated computation of tree-level and next-to-leading order differential cross sections, and their matching to parton shower simulations, J. High Energy Phys. 07 (2014) 079.
  29. D. Buarque Franzosi, O. Mattelaer, R. Ruiz, and S. Shil, Automated predictions from polarized matrix elements, J. High Energy Phys. 04 (2020) 082.
  30. R. D. Ball et al., Parton distributions from high-precision collider data: NNPDF Collaboration, Eur. Phys. J. C 77, 663 (2017).
  31. C. Bierlich et al., A comprehensive guide to the physics and usage of pythia 8.3, SciPost Phys. Codebases 2022, 8 (2022).
  32. A. Denner, C. Haitz, and G. Pelliccioli, NLO EW and QCD corrections to polarised same-sign WW scattering at the LHC, J. High Energy Phys. 11 (2024) 115.
  33. M. Aleksa et al., Calorimeters for the FCC-hh, arXiv:1912.09962.
  34. J. de Favereau, C. Delaere, P. Demin, A. Giammanco, V. Lemaître, A. Mertens, and M. Selvaggi, Delphes 3, A modular framework for fast simulation of a generic collider experiment, J. High Energy Phys. 02 (2014) 057.
  35. M. Selvaggi, Delphes fcc-hh card, https://github.com/delphes/delphes/blob/master/cards/FCC/FCChh.tcl. Accessed: 2025.
  36. M. Selvaggi, A Delphes parameterisation of the FCC-hh detector, Technical Report No. CERN-FCC-PHYS-2020-0003, CERN, Geneva, 2020, https://cds.cern.ch/record/2717698.
  37. M. Cacciari, G. P. Salam, and G. Soyez, fastjet user manual, Eur. Phys. J. C 72, 1896 (2012).
  38. M. Cacciari, G. P. Salam, and G. Soyez, The anti-kt jet clustering algorithm, J. High Energy Phys. 04 (2008) 063.
  39. ATLAS Collaboration, Tools for estimating fake/non-prompt lepton backgrounds with the ATLAS detector at the LHC, J. Instrum. 18, T11004 (2023).
  40. J. Butterworth et al., PDF4LHC recommendations for LHC Run II, J. Phys. G 43, 023001 (2016).
  41. T. Chen and C. Guestrin, xgboost: A scalable tree boosting system, in Proceedings of the 22nd ACM SIGKDD International Conference on Knowledge Discovery and Data Mining (ACM, 2016), pp. 785–794, 10.1145/2939672.2939785.
  42. F. Pedregosa et al., Scikit-learn: Machine learning in python, J. Mach. Learn. Res. 12, 2825 (2011), http://jmlr.org/papers/v12/pedregosa11a.html.
  43. D. Rainwater, R. Szalapski, and D. Zeppenfeld, Probing color-singlet exchange in Z+2-jet events at the CERN LHC, Phys. Rev. D 54, 6680 (1996).
  44. W. Verkerke and D. P. Kirkby, The roofit toolkit for data modeling, eConf C0303241, MOLT007 (2003), https://inspirehep.net/literature/621398.
  45. L. Moneta, K. Belasco, K. S. Cranmer, S. Kreiss, A. Lazzaro, D. Piparo, G. Schott, W. Verkerke, and M. Wolf, The roostats project, Proc. Sci., ACAT2010 (2010) 057.
  46. ATLAS Collaboration, Formulae for Estimating Significance, Technical Report No. ATL-PHYS-PUB-2020-025, 2020, https://cds.cern.ch/record/2736148.
  47. G. Cowan, K. Cranmer, E. Gross, and O. Vitells, Asymptotic formulae for likelihood-based tests of new physics, Eur. Phys. J. C 71, 1554 (2011).
  48. M. Zaro and H. Logan, Recommendations for the interpretation of LHC searches for H50,H5± and H5±± in vector boson fusion with decays to vector boson pairs, Technical Report No. LHCHXSWG-2015-001, CERN, Geneva, 2015, https://cds.cern.ch/record/2002500.
  49. A. L. Read, Modified frequentist analysis of search results (the CLs method), in Workshop on Confidence Limits (2000), pp. 81–100, 10.5170/CERN-2000-005.81.
