What can we learn from the radiative decays of the $D_{s 1} (2460)$ meson?

Hai-Long Fu ^1,2,*, Feng-Kun Guo ^1,2,†, Christoph Hanhart ^3,‡, and Alexey Nefediev ^4,§

¹Institute of Theoretical Physics, Chinese Academy of Sciences, Beijing 100190, China
²School of Physical Sciences, University of Chinese Academy of Sciences, Beijing 100049, China
³Institute for Advanced Simulation, Forschungszentrum Jülich, D-52425 Jülich, Germany
⁴Helmholtz-Institut für Strahlen- und Kernphysik, Universität Bonn, 53115 Bonn, Germany

^*Contact author: fuhailong@itp.ac.cn
^†Contact author: fkguo@itp.ac.cn
^‡Contact author: c.hanhart@fz-juelich.de
^§Contact author: a.nefediev@uni-bonn.de

Phys. Rev. D 113, 074026 – Published 20 April, 2026

DOI: https://doi.org/10.1103/786l-tjny

Abstract

We study the radiative decays $D_{s 1} (2460) \to γ D_{s 0}^{*} (2317)$ and $D_{s 1} (2460) \to γ D^{0} K^{+} / γ D^{+} K^{0}$ and argue them to constitute a paradigmatic case of reactions sensitive to the short-range component of the decaying meson wave function that can, in principle, be quantified in a model-independent way employing experimental data. We demonstrate how a simultaneous measurement of the above radiative decay widths, or at least a constraint on the ratio of the corresponding branching fractions, can allow one to probe the nature of the $D_{s 0}^{*} (2317)$ and $D_{s 1} (2460)$ mesons.

Physics Subject Headings (PhySH)

Article Text

References (48)

Y. Kalashnikova, A. E. Kudryavtsev, A. V. Nefediev, J. Haidenbauer, and C. Hanhart, Insights on scalar mesons from their radiative decays, Phys. Rev. C 73, 045203 (2006).
B. Aubert et al. (BABAR Collaboration), Evidence for $X (3872) \to ψ (2 S) γ$ in $B^{\pm} \to X (3872) K^{\pm}$ decays, and a study of $B \to c \bar{c} γ K$ , Phys. Rev. Lett. 102, 132001 (2009).
V. Bhardwaj et al. (Belle Collaboration), Observation of $X (3872) \to J / ψ γ$ and search for $X (3872) \to ψ^{'} γ$ in $B$ decays, Phys. Rev. Lett. 107, 091803 (2011).
R. Aaij et al. (LHCb Collaboration), Evidence for the decay $X (3872) \to ψ (2 S) γ$ , Nucl. Phys. B886, 665 (2014).
M. Ablikim et al. (BESIII Collaboration), Study of open-charm decays and radiative transitions of the $X (3872)$ , Phys. Rev. Lett. 124, 242001 (2020).
R. Aaij et al. (LHCb Collaboration), Probing the nature of the $χ_{c 1} (3872)$ state using radiative decays, J. High Energy Phys. 11 (2024) 121.
F.-K. Guo, C. Hanhart, Y. S. Kalashnikova, U.-G. Meißner, and A. V. Nefediev, What can radiative decays of the $X (3872)$ teach us about its nature?, Phys. Lett. B 742, 394 (2015).
F.-K. Guo, C. Hanhart, and A. Nefediev, Radiative decays of hadronic molecules: From confusion to inspiration, arXiv:2603.02671.
H.-L. Fu, H. W. Grießhammer, F.-K. Guo, C. Hanhart, and U.-G. Meißner, Update on strong and radiative decays of the $D_{s 0}^{*} (2317)$ and $D_{s 1} (2460)$ and their bottom cousins, Eur. Phys. J. A 58, 70 (2022).
M. F. M. Lutz and M. Soyeur, Radiative and isospin-violating decays of $d_{s}$ -mesons in the hadrogenesis conjecture, Nucl. Phys. A813, 14 (2008).
M. Cleven, H. W. Grießhammer, F.-K. Guo, C. Hanhart, and U.-G. Meißner, Strong and radiative decays of the $D_{s 0}^{*} (2317)$ and $D_{s 1} (2460)$ , Eur. Phys. J. A 50, 149 (2014).
W. A. Bardeen, E. J. Eichten, and C. T. Hill, Chiral multiplets of heavy-light mesons, Phys. Rev. D 68, 054024 (2003).
A. E. Bondar and A. I. Milstein, Phenomenology of $D_{s 1}$ mesons radiative transitions, Phys. Rev. D 111, 114019 (2025).
Z.-L. Zhang, Z.-W. Liu, S.-Q. Luo, P. Chen, and Z.-H. Guo, Masses and radiative decay widths of $D_{s 0}^{*} (2317)$ and $D_{s 1}^{'} (2460)$ and their bottom analogs, Phys. Rev. D 110, 094037 (2024).
A. Bondar, Why we do not see the radiative decays of the $D_{s 1}^{+} (2536)$ meson?, JETP Lett. 121, 231 (2025).
Z.-G. Wang, Radiative decays of the $D_{(s 0)} (2317)$ , $D_{(s 1)} (2460)$ and the related strong coupling constants, Phys. Rev. D 75, 034013 (2007).
S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
F. E. Close, N. Isgur, and S. Kumano, Scalar mesons in phi radiative decay: Their implications for spectroscopy and for studies of $C P$ violation at phi factories, Nucl. Phys. B389, 513 (1993).
N. N. Achasov, V. V. Gubin, and V. I. Shevchenko, Production of scalar $K \bar{K}$ molecules in phi radiative decays, Phys. Rev. D 56, 203 (1997).
Y. S. Kalashnikova, A. E. Kudryavtsev, A. V. Nefediev, C. Hanhart, and J. Haidenbauer, The radiative decays $ϕ \mapsto γ a_{0} / f_{0}$ in the molecular model for the scalar mesons, Eur. Phys. J. A 24, 437 (2005).
T. Barnes, F. E. Close, and H. J. Lipkin, Implications of a $D K$ molecule at 2.32 GeV, Phys. Rev. D 68, 054006 (2003).
E. E. Kolomeitsev and M. F. M. Lutz, On heavy light meson resonances and chiral symmetry, Phys. Lett. B 582, 39 (2004).
Y.-Q. Chen and X.-Q. Li, A comprehensive four-quark interpretation of $D_{s} (2317)$ , $D_{s} (2457)$ and $D_{s} (2632)$ , Phys. Rev. Lett. 93, 232001 (2004).
F.-K. Guo, P.-N. Shen, H.-C. Chiang, R.-G. Ping, and B.-S. Zou, Dynamically generated $0^{+}$ heavy mesons in a heavy chiral unitary approach, Phys. Lett. B 641, 278 (2006).
F.-K. Guo, P.-N. Shen, and H.-C. Chiang, Dynamically generated $1^{+}$ heavy mesons, Phys. Lett. B 647, 133 (2007).
D. Gamermann, E. Oset, D. Strottman, and M. J. Vicente Vacas, Dynamically generated open and hidden charm meson systems, Phys. Rev. D 76, 074016 (2007).
A. Faessler, T. Gutsche, V. E. Lyubovitskij, and Y.-L. Ma, Strong and radiative decays of the $D_{s 0}^{*} (2317)$ meson in the $d k$ molecule picture, Phys. Rev. D 76, 014005 (2007).
L. Liu, K. Orginos, F.-K. Guo, C. Hanhart, and U.-G. Meissner, Interactions of charmed mesons with light pseudoscalar mesons from lattice QCD and implications on the nature of the $D_{s 0}^{*} (2317)$ , Phys. Rev. D 87, 014508 (2013).
J. F. Amundson, C. G. Boyd, E. E. Jenkins, M. E. Luke, A. V. Manohar, J. L. Rosner, M. J. Savage, and M. B. Wise, Radiative $D^{*}$ decay using heavy quark and chiral symmetry, Phys. Lett. B 296, 415 (1992).
J. Hu and T. Mehen, Chiral Lagrangian with heavy quark-diquark symmetry, Phys. Rev. D 73, 054003 (2006).
G. Montaña, O. Kaczmarek, L. Tolos, and A. Ramos, Open-charm Euclidean correlators within heavy-meson EFT interactions, Eur. Phys. J. A 56, 294 (2020).
P. Petreczky and J. H. Weber, Strong coupling constant from moments of quarkonium correlators revisited, Eur. Phys. J. C 82, 64 (2022).
A. Beraudo, A. De Pace, M. Monteno, M. Nardi, and F. Prino, In-medium hadronization of heavy quarks and its effect on charmed meson and baryon distributions in heavy-ion collisions, Eur. Phys. J. C 82, 607 (2022).
X.-D. Huang, X.-G. Wu, X.-C. Zheng, B. Gong, and J.-X. Wang, QCD corrections of $e^{+} e^{-} \to J / ψ + c + \bar{c}$ using the principle of maximum conformality, Phys. Rev. D 110, 114010 (2024).
L. D. Landau, On the analytic properties of vertex parts in quantum field theory, Zh. Eksp. Teor. Fiz. 37, 62 (1960) [Sov. Phys. JETP 10, 62 (1960)].
F.-K. Guo, X.-H. Liu, and S. Sakai, Threshold cusps and triangle singularities in hadronic reactions, Prog. Part. Nucl. Phys. 112, 103757 (2020).
M. Bayar, F. Aceti, F.-K. Guo, and E. Oset, A discussion on triangle singularities in the $Λ_{b} \to J / ψ K^{-} p$ reaction, Phys. Rev. D 94, 074039 (2016).
M. Abumusabh et al. (Belle-II Collaboration), Observation of the radiative decay $D_{s} (2317)^{+} \to D_{s}^{*} γ$ , arXiv:2510.27174.
Y. Mikami et al. (Belle Collaboration), Measurements of the $D_{s J}$ resonance properties, Phys. Rev. Lett. 92, 012002 (2004).
P. Krokovny et al. (Belle Collaboration), Observation of the $D_{s J} (2317)$ and $D_{s J} (2457)$ in $B$ decays, Phys. Rev. Lett. 91, 262002 (2003).
B. Aubert et al. (BABAR Collaboration), Study of $B \to D_{s J}^{(*) +} {\bar{D}}^{(*)}$ decays, Phys. Rev. Lett. 93, 181801 (2004).
M. Cleven, Systematic study of hadronic molecules in the heavy-quark sector, Ph.D. thesis, Bonn University, 2013, arXiv:1405.4195.
M.-N. Tang, Y.-H. Lin, F.-K. Guo, C. Hanhart, and U.-G. Meißner, Isospin-conserving hadronic decay of the $D_{s 1} (2460)$ into $D_{s} π^{+} π^{-}$ , Commun. Theor. Phys. 75, 055203 (2023).
F.-K. Guo, Novel method for precisely measuring the $X (3872)$ mass, Phys. Rev. Lett. 122, 202002 (2019).
B. Wang, B. Yang, L. Meng, and S.-L. Zhu, Radiative transitions and magnetic moments of the charmed and bottom vector mesons in chiral perturbation theory, Phys. Rev. D 100, 016019 (2019).
J. Wang and Q. Zhao, Combined study of the isospin-violating decay $D_{s}^{*} \to D_{s} π^{0}$ and radiative decay $D_{s}^{*} \to D_{s} γ$ with intermediate meson loops, Phys. Rev. D 111, 096007 (2025).
S. M. Flatté, Coupled-channel analysis of the $π η$ and $K \bar{K}$ systems near $K \bar{K}$ threshold, Phys. Lett. B 63, 224 (1976).
H. H. Patel, Package-X: A Mathematica package for the analytic calculation of one-loop integrals, Comput. Phys. Commun. 197, 276 (2015).
