Residual anomaly detection with density estimation

Ranit Das1,*, Gregor Kasieczka2,†, and David Shih1,‡

  • *Contact author: ranit@physics.rutgers.edu
  • †Contact author: gregor.kasieczka@uni-hamburg.de
  • ‡Contact author: shih@physics.rutgers.edu
PDF

Phys. Rev. D 112, 114049 – Published 31 December, 2025

DOI: https://doi.org/10.1103/6hgk-q52g

Abstract

We present R-ANODE, a new method for data-driven, model-agnostic resonant anomaly detection that raises the bar for both performance and interpretability. The key to R-ANODE is to enhance the inductive bias of the anomaly detection task by fitting a normalizing flow directly to the small and unknown signal component, while holding fixed a background model (also a normalizing flow) learned from sidebands. In doing so, R-ANODE is able to outperform all classifier-based, weakly supervised approaches as well as the previous ANODE method, which fit a density estimator to all of the data in the signal region instead of just the signal. We show that the method works equally well whether the unknown signal fraction is learned or fixed and is even robust to signal fraction misspecification. Finally, with the learned signal model, we can sample and gain qualitative insights into the underlying anomaly, which greatly enhances the interpretability of resonant anomaly detection and offers the possibility of simultaneously discovering and characterizing the new physics that could be hiding in the data.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (43)

  1. ATLAS Collaboration, Exotic Physics Searches (2023), https://twiki.cern.ch/twiki/bin/view/AtlasPublic/ExoticsPublicResults.
  2. ATLAS Collaboration, Supersymmetry searches (2023), https://twiki.cern.ch/twiki/bin/view/AtlasPublic/SupersymmetryPublicResults.
  3. ATLAS Collaboration, Higgs and Diboson Searches (2023), https://twiki.cern.ch/twiki/bin/view/AtlasPublic/HDBSPublicResults.
  4. CMS Collaboration, CMS Exotica Public Physics Results (2023), https://twiki.cern.ch/twiki/bin/view/CMSPublic/PhysicsResultsEXO.
  5. CMS Collaboration, CMS Supersymmetry Physics Results (2023), https://twiki.cern.ch/twiki/bin/view/CMSPublic/PhysicsResultsSUS.
  6. CMS Collaboration, CMS Beyond-two-generations (B2G) Public Physics Results (2023), https://twiki.cern.ch/twiki/bin/view/CMSPublic/PhysicsResultsB2G.
  7. LHCb Collaboration, Publications of the QCD, Electroweak and Exotica Working Group (2023), http://lhcbproject.web.cern.ch/lhcbproject/Publications/LHCbProjectPublic/Summary_QEE.html.
  8. G. Kasieczka, B. Nachman, D. Shih et al., Rep. Prog. Phys. 84, 124201 (2021).
  9. T. Aarrestad et al., SciPost Phys. 12, 043 (2022).
  10. G. Karagiorgi, G. Kasieczka, S. Kravitz, B. Nachman, and D. Shih, Nat. Rev. Phys. 4, 399 (2022).
  11. V. Belis, P. Odagiu, and T. K. Aarrestad, Rev. Phys. 12, 100091 (2024).
  12. B. Nachman and D. Shih, Phys. Rev. D 101, 075042 (2020).
  13. A. Hallin, J. Isaacson, G. Kasieczka, C. Krause, B. Nachman, T. Quadfasel, M. Schlaffer, D. Shih, and M. Sommerhalder, Phys. Rev. D 106, 055006 (2022).
  14. G. Kasieczka, B. Nachman, and D. Shih, R&D Dataset for LHC Olympics 2020 Anomaly Detection Challenge (2022).
  15. T. Sjöstrand, S. Mrenna, and P. Skands, J. High Energy Phys. 05 (2006) 026.
  16. T. Sjöstrand, S. Mrenna, and P. Skands, Comput. Phys. Commun. 178, 852 (2008).
  17. J. de Favereau, C. Delaere, P. Demin, A. Giammanco, V. Lemaître, A. Mertens, and M. Selvaggi, J. High Energy Phys. 02 (2014) 057.
  18. A. Mertens, J. Phys. Conf. Ser. 608, 012045 (2015).
  19. M. Selvaggi, J. Phys. Conf. Ser. 523, 012033 (2014).
  20. M. Cacciari and G. P. Salam, Phys. Lett. B 641, 57 (2006).
  21. M. Cacciari, G. P. Salam, and G. Soyez, J. High Energy Phys. 04 (2008) 063.
  22. M. Cacciari, G. P. Salam, and G. Soyez, Eur. Phys. J. C 72, 1896 (2012).
  23. J. Thaler and K. Van Tilburg, J. High Energy Phys. 03 (2011) 015.
  24. J. Thaler and K. Van Tilburg, J. High Energy Phys. 02 (2012) 093.
  25. T. Finke, M. Hein, G. Kasieczka, M. Krämer, A. Mück, P. Prangchaikul, T. Quadfasel, D. Shih, and M. Sommerhalder, Phys. Rev. D 109, 034033 (2024).
  26. D. Shih, Additional QCD Background Events for LHCO2020 R&D (signal region only) (2021).
  27. G. Papamakarios, T. Pavlakou, and I. Murray, arXiv:1705.07057.
  28. L. Dinh, D. Krueger, and Y. Bengio, arXiv:1410.8516.
  29. C. Durkan, A. Bekasov, I. Murray, and G. Papamakarios, arXiv:1906.04032.
  30. F. Pedregosa, G. Varoquaux, A. Gramfort, V. Michel, B. Thirion, O. Grisel, M. Blondel, P. Prettenhofer, R. Weiss, V. Dubourg et al., J. Mach. Learn. Res. 12, 2825 (2011), https://www.jmlr.org/papers/v12/pedregosa11a.html.
  31. G. Ke, Q. Meng, T. Finley, T. Wang, W. Chen, W. Ma, Q. Ye, and T.-Y. Liu, in Advances in Neural Information Processing Systems, Vol. 30, edited by I. Guyon, U. V. Luxburg, S. Bengio, H. Wallach, R. Fergus, S. Vishwanathan, and R. Garnett (Curran Associates, Inc., Long Beach, CA, 2017).
  32. J. H. Collins, K. Howe, and B. Nachman, Phys. Rev. Lett. 121, 241803 (2018).
  33. J. H. Collins, K. Howe, and B. Nachman, Phys. Rev. D 99, 014038 (2019).
  34. J. A. Raine, S. Klein, D. Sengupta, and T. Golling, Front. Big Data 6, 899345 (2023).
  35. A. Hallin, G. Kasieczka, T. Quadfasel, D. Shih, and M. Sommerhalder, Phys. Rev. D 107, 114012 (2023).
  36. M. Freytsis, M. Perelstein, and Y. C. San, J. High Energy Phys. 02 (2024) 220.
  37. E. Buhmann, C. Ewen, G. Kasieczka, V. Mikuni, B. Nachman, and D. Shih, Phys. Rev. D 109, 055015 (2024).
  38. https://it.rutgers.edu/oarc
  39. R. Das, Residual anode (2023), https://github.com/rd804/R-ANODE
  40. A. Paszke, S. Gross, F. Massa, A. Lerer, J. Bradbury, G. Chanan, T. Killeen, Z. Lin, N. Gimelshein, L. Antiga et al., arXiv:1912.01703.
  41. D. P. Kingma and J. Ba, arXiv:1412.6980.
  42. I. Loshchilov and F. Hutter, arXiv:1711.05101.
  43. I. Loshchilov and F. Hutter, Biometrics 21, 761 (1965).
