Beam-dump ceiling and its experimental implications: The case of a portable experiment

Doojin Kim1,2,*, Jaehoon Yu3,†, Jong-Chul Park4,5,‡, and Hyunyong Kim6,2,§

  • *Contact author: doojin.kim@usd.edu
  • †Contact author: jaehoon@uta.edu
  • ‡Contact author: jcpark@cnu.ac.kr
  • §Contact author: hyunyong.kim@cern.ch
PDF

Phys. Rev. D 113, 115006 – Published 2 June, 2026

DOI: https://doi.org/10.1103/5nst-v9lh

Abstract

We generalize the nature of the so-called beam-dump “ceiling” beyond which the improvement on the sensitivity reach in the search for fast-decaying mediators dramatically slows down, and we point out its experimental implications that motivate tabletop-sized beam-dump experiments for the search. Light (bosonic) mediators are well-motivated new-physics particles, as they can appear in dark-sector portal scenarios and models to explain various laboratory-based anomalies. Due to their low mass and feebly interacting nature, beam-dump-type experiments, utilizing high-intensity particle beams, can play a crucial role in probing the parameter space of such visibly decaying mediators—in particular, the “prompt decay” region, where the mediators feature relatively large coupling and mass. We present a general and semianalytic proof that the ceiling effectively arises in the prompt-decay region of an experiment and show its insensitivity to data statistics, background estimates, and systematic uncertainties, considering a concrete example, the search for axion-like particles interacting with ordinary photons at three benchmark beam facilities: PIP-II at FNAL, and SPS and LHC-dump at CERN. We then identify optimal criteria to perform a cost-effective and short-term experiment to reach the ceiling, demonstrating that very short-baseline compact experiments enable access to the parameter space unreachable thus far.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (44)

  1. A. J. Krasznahorkay et al., Observation of anomalous internal pair creation in Be8: A possible indication of a light, neutral boson, Phys. Rev. Lett. 116, 042501 (2016).
  2. A. J. Krasznahorkay et al., New evidence supporting the existence of the hypothetic X17 particle, arXiv:1910.10459.
  3. A. J. Krasznahorkay, M. Csatlós, L. Csige, J. Gulyás, A. Krasznahorkay, B. M. Nyakó, I. Rajta, J. Timár, I. Vajda, and N. J. Sas, New anomaly observed in He4 supports the existence of the hypothetical X17 particle, Phys. Rev. C 104, 044003 (2021).
  4. A. J. Krasznahorkay et al., New anomaly observed in C12 supports the existence and the vector character of the hypothetical X17 boson, Phys. Rev. C 106, L061601 (2022).
  5. A. J. Krasznahorkay, A. Krasznahorkay, M. Csatlós, L. Csige, J. Timár, M. Begala, A. Krakó, I. Rajta, and I. Vajda, Observation of the X17 anomaly in the decay of the Giant Dipole Resonance of Be8, arXiv:2308.06473.
  6. A. Aguilar-Arevalo et al. (LSND Collaboration), Evidence for neutrino oscillations from the observation of ν¯e appearance in a ν¯μ beam, Phys. Rev. D 64, 112007 (2001).
  7. A. A. Aguilar-Arevalo et al. (MiniBooNE Collaboration), Unexplained excess of electron-like events from a 1-GeV neutrino beam, Phys. Rev. Lett. 102, 101802 (2009).
  8. A. A. Aguilar-Arevalo et al. (MiniBooNE Collaboration), Significant excess of electronlike events in the MiniBooNE short-baseline neutrino experiment, Phys. Rev. Lett. 121, 221801 (2018).
  9. A. A. Aguilar-Arevalo et al. (MiniBooNE Collaboration), Updated MiniBooNE neutrino oscillation results with increased data and new background studies, Phys. Rev. D 103, 052002 (2021).
  10. P. Abratenko et al. (MicroBooNE Collaboration), Search for an anomalous production of charged-current νe interactions without visible pions across multiple kinematic observables in MicroBooNE, Phys. Rev. Lett. 135, 081802 (2025).
  11. P. Abratenko et al. (MicroBooNE Collaboration), Inclusive search for anomalous single-photon production in MicroBooNE, arXiv:2502.06064.
  12. B. Batell et al., Dark sector studies with neutrino beams, in Snowmass 2021 (2022); arXiv:2207.06898.
  13. P. Ilten, Y. Soreq, M. Williams, and W. Xue, Serendipity in dark photon searches, J. High Energy Phys. 06 (2018) 004.
  14. M. Bauer, P. Foldenauer, and J. Jaeckel, Hunting all the hidden photons, J. High Energy Phys. 07 (2018) 094.
  15. M. Fabbrichesi, E. Gabrielli, and G. Lanfranchi, The dark photon, 10.1007/978-3-030-62519-1 (2020).
  16. J.-F. Fortin, H.-K. Guo, S. P. Harris, D. Kim, K. Sinha, and C. Sun, Axions: From magnetars and neutron star mergers to beam dumps and BECs, Int. J. Mod. Phys. D 30, 2130002 (2021).
  17. W. Jang, D. Kim, K. Kong, Y. Kwon, J.-C. Park, M. S. Ryu, S. Shin, R. G. Van de Water, U.-K. Yang, and J. Yu, Search prospects for axionlike particles at rare nuclear isotope accelerator facilities, Phys. Rev. D 107, L031901 (2023).
  18. B. Dutta, D. Kim, and H. Kim, Proposal to use LHC general-purpose detectors in “beam-dump” measurements for long-lived particles, Phys. Lett. B 861, 139246 (2025).
  19. R. Ainsworth et al., An upgrade path for the Fermilab accelerator complex, arXiv:2106.02133.
  20. C. C. Ahdida et al., SPS Beam Dump Facility—Comprehensive Design Study, edited by M. Calviani, B. Goddard, R. Jacobsson, and M. Lamont, CERN Yellow Reports: Monographs, Vol. 2/2020 (2020); arXiv:1912.06356.
  21. J. Maestre et al., Design and behaviour of the large hadron collider external beam dumps capable of receiving 539  MJ/dump, J. Instrum. 16, P11019 (2021).
  22. A. Apyan et al., DarkQuest: A dark sector upgrade to SpinQuest at the 120 GeV Fermilab main injector, in Snowmass 2021 (2022); arXiv:2203.08322.
  23. E. Cortina Gil et al. (NA62 Collaboration), The beam and detector of the NA62 experiment at CERN, J. Instrum. 12, P05025 (2017).
  24. S. Alekhin et al., A facility to search for hidden particles at the CERN SPS: The SHiP physics case, Rep. Prog. Phys. 79, 124201 (2016).
  25. H. Primakoff, Photoproduction of neutral mesons in nuclear electric fields and the mean life of the neutral meson, Phys. Rev. 81, 899 (1951).
  26. C. Ahdida et al. (SHiP Collaboration), The SHiP experiment at the proposed CERN SPS beam dump facility, Eur. Phys. J. C 82, 486 (2022).
  27. R. Albanese et al. (SHiP Collaboration), BDF/SHiP at the ECN3 High-Intensity Beam Facility, Technical Report (CERN, Geneva, 2023).
  28. S. Agostinelli et al. (GEANT4 Collaboration), geant4–a simulation toolkit, Nucl. Instrum. Methods Phys. Res., Sect. A 506, 250 (2003).
  29. F. Abudinén et al. (Belle-II Collaboration), Search for axion-like particles produced in e+e− collisions at Belle II, Phys. Rev. Lett. 125, 161806 (2020).
  30. F. Bergsma et al. (CHARM Collaboration), Search for axion like particle production in 400-GeV proton-copper interactions, Phys. Lett. 157B, 458 (1985).
  31. J. D. Bjorken, S. Ecklund, W. R. Nelson, A. Abashian, C. Church, B. Lu, L. W. Mo, T. A. Nunamaker, and P. Rassmann, Search for neutral metastable penetrating particles produced in the SLAC beam dump, Phys. Rev. D 38, 3375 (1988).
  32. E. M. Riordan et al., A search for short lived axions in an electron beam dump experiment, Phys. Rev. Lett. 59, 755 (1987).
  33. G. Abbiendi et al. (OPAL Collaboration), Multiphoton production in e+e− collisions at s=181−GeV to 209-GeV, Eur. Phys. J. C 26, 331 (2003).
  34. A. M. Sirunyan et al. (CMS Collaboration), Evidence for light-by-light scattering and searches for axion-like particles in ultraperipheral PbPb collisions at sNN=5.02  TeV, Phys. Lett. B 797, 134826 (2019).
  35. G. Aad et al. (ATLAS Collaboration), Measurement of light-by-light scattering and search for axion-like particles with 2.2  nb−1 of Pb+Pb data with the ATLAS detector, J. High Energy Phys. 03 (2021) 243; 11 (2021) 050(E).
  36. D. Banerjee et al. (NA64 Collaboration), Search for axionlike and scalar particles with the NA64 experiment, Phys. Rev. Lett. 125, 081801 (2020).
  37. J. Blumlein et al., Limits on neutral light scalar and pseudoscalar particles in a proton beam dump experiment, Z. Phys. C 51, 341 (1991).
  38. D. Aloni, C. Fanelli, Y. Soreq, and M. Williams, Photoproduction of axionlike particles, Phys. Rev. Lett. 123, 071801 (2019).
  39. V. Brdar, B. Dutta, W. Jang, D. Kim, I. M. Shoemaker, Z. Tabrizi, A. Thompson, and J. Yu, Axionlike particles at future neutrino experiments: Closing the cosmological triangle, Phys. Rev. Lett. 126, 201801 (2021).
  40. J. L. Feng, I. Galon, F. Kling, and S. Trojanowski, Axionlike particles at FASER: The LHC as a photon beam dump, Phys. Rev. D 98, 055021 (2018).
  41. A. Berlin, N. Blinov, G. Krnjaic, P. Schuster, and N. Toro, Dark matter, millicharges, axion and scalar particles, gauge bosons, and other new physics with LDMX, Phys. Rev. D 99, 075001 (2019).
  42. P. Bhattarai et al. (DAMSA Collaboration), DAMSA experiment conceptual design white paper, arXiv:2601.15255.
  43. A. De Roeck, The ship experiment: Search for hidden particles (2025), presented on June 25, (2025) https://indico.cern.ch/event/1441321/contributions/6542403/attachments/3078461/5451176/deroeck_LLP2025_SHIP_v2-2.pdf.
  44. R. Jacobsson (private communication).
