Exploring charmonia $η_{c} (6 S, 7 S)$ in the $Λ_{c}^{+} \bar{Λ}_{c}^{-}$ invariant mass spectrum of $B^{0} \to K_{S}^{0} Λ_{c}^{+} \bar{Λ}_{c}^{-}$

Cheng-Xi Liu^1,2,3,4,*, Jun-Zhang Wang^5,†, and Xiang Liu ^1,2,3,4,‡

¹School of Physical Science and Technology, Lanzhou University, Lanzhou 730000, China
²Lanzhou Center for Theoretical Physics, Key Laboratory of Theoretical Physics of Gansu Province, Key Laboratory of Quantum Theory and Applications of MoE, Gansu Provincial Research Center for Basic Disciplines of Quantum Physics, Lanzhou University, Lanzhou 730000, China
³MoE Frontiers Science Center for Rare Isotopes, Lanzhou University, Lanzhou 730000, China
⁴Research Center for Hadron and CSR Physics, Lanzhou University and Institute of Modern Physics of CAS, Lanzhou 730000, China
⁵Department of Physics and Chongqing Key Laboratory for Strongly Coupled Physics, Chongqing University, Chongqing 401331, China

^*Contact author: liuchx2025@lzu.edu.cn
^†Contact author: wangjzh@cqu.edu.cn
^‡Contact author: xiangliu@lzu.edu.cn

Phys. Rev. D 114, 074050 – Published 23 October, 2026

DOI: https://doi.org/10.1103/5lcd-6ml6

Abstract

We analyze the $B^{0} \to K_{S}^{0} Λ_{c}^{+} \bar{Λ}_{c}^{-}$ decay recently observed by the LHCb Collaboration. The $Λ_{c}^{+} \bar{Λ}_{c}^{-}$ invariant-mass spectrum exhibits an accumulation near 4.63 GeV, which we investigate together with the accompanying $Λ_{c}^{+} K_{S}^{0}$ spectrum constrained by the known $Ξ_{c} (2923)$ and $Ξ_{c} (2939)$ states. Our amplitude model includes a nonresonant term, the two established $Ξ_{c}$ contributions, and high-lying charmonium states in the $Λ_{c}^{+} \bar{Λ}_{c}^{-}$ channel. Guided by screened Godfrey-Isgur and quark-pair-creation calculations, we test the 4.63 GeV enhancement with a fixed $η_{c} (6 S)$ amplitude at $(M_{1}, Γ_{1}) = (4629.00, 24.20) MeV$ , which improves the description of the 4.63 GeV region, and examine a fixed $η_{c} (7 S)$ contribution at $(M_{2}, Γ_{2}) = (4718.84, 22.84) MeV$ , which improves the higher-mass region of the spectrum. We also evaluate the $η_{c} (n S) \to Λ_{c}^{+} \bar{Λ}_{c}^{-}$ baryonic decays via a hadron-loop mechanism and estimate the $B^{0} \to K_{S}^{0} η_{c} (n S)$ production in naive factorization. Within the narrow width approximation, the fit yields a $B (B^{0} \to K_{S}^{0} η_{c} (6 S)) \times B (η_{c} (6 S) \to Λ_{c}^{+} \bar{Λ}_{c}^{-})$ of about $6.2 \times 10^{- 6}$ , while the factorization and hadron-loop calculations give rates roughly one to three orders of magnitude lower than the above fitted ratio. These results highlight the need for more precise data and a full amplitude analysis to determine the line shapes and clarify the nature of the higher-mass contribution.

Physics Subject Headings (PhySH)

Article Text

References (35)

R. Aaij et al. (LHCb Collaboration), Study of the $B^{0} \to Λ_{c}^{+} \bar{Λ}_{c}^{-} K_{S}^{0}$ decay, Phys. Rev. D 114, 012012 (2026).
Y. B. Li et al. (Belle Collaboration), Evidence of a structure in ${\bar{K}}^{0} Λ_{c}^{+}$ consistent with a charged $Ξ_{c} (2930)^{+}$ , and updated measurement of ${\bar{B}}^{0} \to {\bar{K}}^{0} Λ_{c}^{+} \bar{Λ}_{c}^{-}$ at Belle, Eur. Phys. J. C 78, 928 (2018).
R. Aaij et al. (LHCb Collaboration), Study of the $B^{-} \to Λ_{c}^{+} \bar{Λ}_{c}^{-} K^{-}$ decay, Phys. Rev. D 108, 012020 (2023).
G. Pakhlova et al. (Belle Collaboration), Observation of a near-threshold enhancement in the $e^{+} e^{-} \to Λ_{c}^{+} Λ_{c}^{-}$ cross section using initial-state radiation, Phys. Rev. Lett. 101, 172001 (2008).
J.-Z. Wang, R.-Q. Qian, X. Liu, and T. Matsuki, Are the $Y$ states around 4.6 GeV from $e^{+} e^{-}$ annihilation higher charmonia?, Phys. Rev. D 101, 034001 (2020).
Z.-Y. Bai, D.-Y. Chen, Q. Huang, X. Liu, S.-Q. Luo, and J.-Z. Wang, Unquenched charmonium and beyond, Phys. Rep. 1204, 1 (2027).
X. Wang, X. Liu, and Y. Gao, Colloquium: Hadron production in open-charm meson pairs at $e^{+} e^{-}$ colliders, Rev. Mod. Phys. 98, 021001 (2026).
J.-Z. Wang, D.-Y. Chen, X. Liu, and T. Matsuki, Constructing $J / ψ$ family with updated data of charmoniumlike $Y$ states, Phys. Rev. D 99, 114003 (2019).
R. Aaij et al. (LHCb Collaboration), Study of the $B^{0} \to ρ (770)^{0} K^{*} (892)^{0}$ decay with an amplitude analysis of $B^{0} \to (π^{+} π^{-}) (K^{+} π^{-})$ decays, J. High Energy Phys. 05 (2019) 026.
S. Godfrey and N. Isgur, Mesons in a relativized quark model with chromodynamics, Phys. Rev. D 32, 189 (1985).
C.-X. Liu, Z.-L. Man, T.-L. Gao, and X. Liu, Prospects for observing the missing $2 D$ and $1 F$ charmonium states around 4 GeV, Phys. Rev. D 113, 074009 (2026).
T.-C. Peng, Z.-Y. Bai, J.-Z. Wang, and X. Liu, Reevaluating the $ψ (4160)$ resonance parameter using $B^{+} \to K^{+} μ^{+} μ^{-}$ data in the context of unquenched charmonium spectroscopy, Phys. Rev. D 111, 054023 (2025).
F. Takahashi et al. (Particle Data Group), Review of particle physics, Int. J. Mod. Phys. A 41, 2630011 (2026).
L. Micu, Decay rates of meson resonances in a quark model, Nucl. Phys. B10, 521 (1969).
A. Le Yaouanc, L. Oliver, O. Pène, and J.-C. Raynal, Naive quark pair creation model of strong interaction vertices, Phys. Rev. D 8, 2223 (1973).
E. S. Ackleh, T. Barnes, and E. S. Swanson, On the mechanism of open-flavor strong decays, Phys. Rev. D 54, 6811 (1996).
T. Barnes, S. Godfrey, and E. S. Swanson, Higher charmonia, Phys. Rev. D 72, 054026 (2005).
M. Jacob and G. C. Wick, On the general theory of collisions for particles with spin, Ann. Phys. (N.Y.) 7, 404 (1959).
H. G. Blundell, Meson properties in the quark model: A look at some outstanding problems, Ph.D. thesis, Carleton University, 1996.
Q.-T. Song, D.-Y. Chen, X. Liu, and T. Matsuki, Higher radial and orbital excitations in the charmed meson family, Phys. Rev. D 92, 074011 (2015).
Q.-T. Song, D.-Y. Chen, X. Liu, and T. Matsuki, Charmed-strange mesons revisited: Mass spectra and strong decays, Phys. Rev. D 91, 054031 (2015).
S. J. Brodsky and G. P. Lepage, Helicity selection rules and tests of gluon spin in exclusive quantum-chromodynamic processes, Phys. Rev. D 24, 2848 (1981).
X.-H. Liu and Q. Zhao, Further study of the helicity selection rule evading mechanism in $η_{c}$ , $χ_{c 0}$ and $h_{c}$ decaying to baryon anti-baryon pairs, J. Phys. G 38, 035007 (2011).
R. Casalbuoni, A. Deandrea, N. Di Bartolomeo, R. Gatto, F. Feruglio, and G. Nardulli, Phenomenology of heavy meson chiral lagrangians, Phys. Rep. 281, 145 (1997).
R.-Q. Qian, J.-Z. Wang, X. Liu, and T. Matsuki, Charmonium decays into $Λ_{c} {\bar{Λ}}_{c}$ pair governed by the hadronic loop mechanism, Phys. Rev. D 104, 094001 (2021).
Z. Song, C. Meng, and K.-T. Chao, $B \to η_{c} K (η_{c}^{'} K)$ decays in QCD factorization, Eur. Phys. J. C 36, 365 (2004).
H.-Y. Cheng and K.-C. Yang, Updated analysis of $a_{1}$ and $a_{2}$ in hadronic two-body decays of $B$ mesons, Phys. Rev. D 59, 092004 (1999).
N. R. Soni, B. R. Joshi, R. P. Shah, H. R. Chauhan, and J. N. Pandya, $Q \bar{Q} (Q \in {b, c})$ spectroscopy using the Cornell potential, Eur. Phys. J. C 78, 592 (2018).
B. Patel and P. C. Vinodkumar, Properties of $Q \bar{Q} (Q ε b, c)$ mesons in Coulomb plus power potential, J. Phys. G 36, 035003 (2009).
V. Kher and A. K. Rai, Spectroscopy and decay properties of charmonium, Chin. Phys. C 42, 083101 (2018).
C. T. H. Davies, C. McNeile, E. Follana, G. P. Lepage, H. Na, and J. Shigemitsu (HPQCD Collaboration), Update: Precision $D_{s}$ decay constant from full lattice QCD using very fine lattices, Phys. Rev. D 82, 114504 (2010).
D. Bečirević, G. Duplančić, B. Klajn, B. Melić, and F. Sanfilippo, Lattice QCD and QCD sum rule determination of the decay constants of $η_{c}$ , $J / ψ$ and $h_{c}$ states, Nucl. Phys. B883, 306 (2014).
K. W. Edwards et al. (CLEO Collaboration), Study of $B$ decays to charmonium states $B \to η_{c} K$ and $B \to χ_{c 0} K$ , Phys. Rev. Lett. 86, 30 (2001).
W. G. Parrott, C. Bouchard, and C. T. H. Davies (HPQCD Collaboration), $B \to K$ and $D \to K$ form factors from fully relativistic lattice QCD, Phys. Rev. D 107, 014510 (2023).
M.-X. Duan, J.-Z. Wang, Y.-S. Li, and X. Liu, Role of the newly measured $B \to K D \bar{D}$ process to establish $χ_{c 0} (2 P)$ state, Phys. Rev. D 104, 034035 (2021).
