Cosmic-ray spatial distribution and diffuse gamma-ray and neutrino fluxes

Paolo Lipari1,2,3,* and Silvia Vernetto4,5,†

  • *Contact author: paolo.lipari@roma1.infn.it
  • †Contact author: vernetto@to.infn.it
PDF

Phys. Rev. D 113, 103001 – Published 1 May, 2026

DOI: https://doi.org/10.1103/5kq1-gqhw

Abstract

Determining the spatial distribution of Galactic cosmic rays (CRs) is fundamental to understand how these particles propagate in interstellar space and to infer their source spectra. The most sensitive method of studying this problem is observing the gamma-ray and neutrino diffuse fluxes produced in the inelastic interactions of CR protons and nuclei with interstellar gas that encode the energy and spatial distributions of the interacting particles. Most theoretical models assume that the spatial and energy dependencies of the spectra of CR protons and nuclei are factorized, so that the CR energy spectra have the same shape at all points of the Milky Way. However, on the base of the Fermi-LAT observations, some authors have tentatively inferred that particles in the inner regions of the Milky Way have significantly harder spectra. Recently the ground-based telescopes Tibet-ASγ, LHAASO, and HAWC have extended the measurements of the diffuse gamma-ray flux to much higher energies, and the IceCube neutrino telescope has obtained evidence for a ν flux from the Galactic disk. These new measurements allow for new tests of the factorization hypothesis, and disfavor models in which the spectral shape of CR protons and nuclei is harder in the inner part of the Galaxy. In fact, the LHAASO data above 30 TeV are in better agreement with the opposite hypothesis, that cosmic rays is the inner Galaxy have softer spectra than those in the outer Galaxy. This result, that has currently only modest significance due to large statistical and systematic uncertainties, could be explained by assuming that the CR confinement volume increases with energy. An alternative explanation is that a significant fraction of cosmic rays in the multi-PeV energy range is of extragalactic origin.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (34)

  1. M. Ackermann et al. (Fermi-LAT Collaboration), Fermi-LAT observations of the diffuse gamma-ray emission: Implications for cosmic rays and the interstellar medium, Astrophys. J. 750, 3 (2012).
  2. P. Lipari and S. Vernetto, Diffuse galactic gamma ray flux at very high energy (LV–2018), Phys. Rev. D 98, 043003 (2018).
  3. L. Tibaldo, D. Gaggero, and P. Martin, Gamma rays as probes of cosmic-ray propagation and interactions in galaxies, Universe 7, 141 (2021).
  4. S. Gabici, C. Evoli, D. Gaggero, P. Lipari, P. Mertsch, E. Orlando, A. Strong, and A. Vittino, The origin of galactic cosmic rays: Challenges to the standard paradigm, Int. J. Mod. Phys. D 28, 1930022 (2019).
  5. M. Kachelriess and D. V. Semikoz, Cosmic ray models, Prog. Part. Nucl. Phys. 109, 103710 (2019).
  6. F. Acero et al. (Fermi-LAT Collaboration), Development of the model of galactic interstellar emission for standard point-source analysis of Fermi Large Area Telescope Data, Astrophys. J. Suppl. Ser. 223, 26 (2016).
  7. M. Amenomori et al. (Tibet ASgamma Collaboration), First detection of sub-PeV diffuse gamma rays from the galactic disk: Evidence for ubiquitous galactic cosmic rays beyond PeV energies, Phys. Rev. Lett. 126, 141101 (2021).
  8. Z. Cao et al. (LHAASO Collaboration), Measurement of ultra-high-energy diffuse gamma-ray emission of the galactic plane from 10 TeV to 1 PeV with LHAASO-KM2A, Phys. Rev. Lett. 131, 151001 (2023).
  9. Z. Cao et al. (LHAASO Collaboration), Measurement of very-high-energy diffuse gamma-ray emissions from the galactic plane with LHAASO-WCDA, Phys. Rev. Lett. 134, 081002 (2025).
  10. R. Alfaro et al. (HAWC Collaboration), Galactic gamma-ray diffuse emission at TeV energies with HAWC data, Astrophys. J. 961, 104 (2024).
  11. R. Abbasi et al. (IceCube Collaboration), Observation of high-energy neutrinos from the galactic plane, Science 380, adc9818 (2023).
  12. G. Giacinti, M. Kachelriess, D. V. Semikoz, and G. Sigl, Cosmic ray anisotropy as signature for the transition from galactic to extragalactic cosmic rays, J. Cosmol. Astropart. Phys. 07 (2012) 031.
  13. P. Abreu et al. (Pierre Auger Collaboration), Constraints on the origin of cosmic rays above 1018  eV from large scale anisotropy searches in data of the Pierre Auger Observatory, Astrophys. J. Lett. 762, L13 (2012).
  14. A. Aab et al. (Pierre Auger Collaboration), Cosmic-ray anisotropies in right ascension measured by the Pierre Auger Observatory, Astrophys. J. 891, 142 (2020).
  15. A. A. Halim et al. (Pierre Auger Collaboration), Large-scale cosmic-ray anisotropies with 19 yr of data from the Pierre Auger Observatory, Astrophys. J. 976, 48 (2024).
  16. S. Mollerach and E. Roulet, A scenario for the Galactic cosmic rays between the knee and the second-knee, J. Cosmol. Astropart. Phys. 03 (2019) 017.
  17. X. J. Lv, X.-J. Bi, K. Fang, Y.-Q. Guo, H.-H. He, L.-L. Ma, P.-F. Yin, Q. Yuan, and M.-J. Zhao, Precise measurement of the cosmic-ray spectrum and ⟨ln A⟩ by LHAASO: Connecting the galactic to the extragalactic components, Astrophys. J. 979, 225 (2025).
  18. S. Vernetto and P. Lipari, Absorption of very high energy gamma rays in the Milky Way, Phys. Rev. D 94, 063009 (2016).
  19. N. Aghanim et al. (Planck Collaboration), Planck intermediate results. XLVIII. Disentangling galactic dust emission and cosmic infrared background anisotropies, Astron. Astrophys. 596, A109 (2016).
  20. K. M. Ferriere, The interstellar environment of our galaxy, Rev. Mod. Phys. 73, 1031 (2001).
  21. Fermi–LAT background model. Available at: https://fermi.gsfc.nasa.gov/ssc/data/access/lat/BackgroundModels.html.
  22. D. Gaggero, A. Urbano, M. Valli, and P. Ullio, Gamma-ray sky points to radial gradients in cosmic-ray transport, Phys. Rev. D 91, 083012 (2015).
  23. D. Gaggero, D. Grasso, A. Marinelli, A. Urbano, and M. Valli, The gamma-ray and neutrino sky: A consistent picture of Fermi-LAT, Milagro, and IceCube results, Astrophys. J. Lett. 815, L25 (2015).
  24. R. Yang, F. Aharonian, and C. Evoli, Radial distribution of the diffuse γ-ray emissivity in the galactic disk, Phys. Rev. D 93, 123007 (2016).
  25. T. K. Gaisser, T. Stanev, and S. Tilav, Cosmic ray energy spectrum from measurements of air showers, Front. Phys. (Beijing) 8, 748 (2013).
  26. E. J. Ahn, R. Engel, T. K. Gaisser, P. Lipari, and T. Stanev, Cosmic ray interaction event generator SIBYLL 2.1, Phys. Rev. D 80, 094003 (2009).
  27. K. Yan, R. Y. Liu, R. Zhang, C. M. Li, Q. Yuan, and X. Y. Wang, Insights from LHAASO and IceCube into the origin of the galactic diffuse teraelectronvolt–petaelectronvolt emission, Nat. Astron. 8, 628 (2024).
  28. K. Fang and K. Murase, Decomposing the origin of TeV–PeV emission from the galactic plane: Implications of multimessenger observations, Astrophys. J. Lett. 957, L6 (2023).
  29. P. Lipari and S. Vernetto, Resolved and unresolved galactic gamma-ray sources, Phys. Rev. D 111, 063035 (2025).
  30. P. Lipari and S. Vernetto, Spectral shapes of galactic gamma-ray sources, Phys. Rev. D 111, 123040 (2025).
  31. V. Vecchiotti, G. Peron, E. Amato, S. Menchiari, G. Morlino, G. Pagliaroli, and F. L. Villante, Interpreting the LHAASO galactic diffuse emission data, J. Cosmol. Astropart. Phys. 09 (2025) 041.
  32. P. De La Torre Luque, D. Gaggero, D. Grasso, A. Marinelli, and M. Rocamora, The cosmic-ray sea explains the diffuse galactic gamma-ray and neutrino emission from GeV to PeV, J. Cosmol. Astropart. Phys. 12 (2025) 041.
  33. C. Prevotat, Z. Zhu, S. Koldobskiy, A. Neronov, D. Semikoz, and M. Ahlers, Diffuse gamma-ray and neutrino emission from the Milky Way and the local knee in the cosmic ray spectrum, Phys. Rev. D 112, 123033 (2025).
  34. A. Albert et al. (ANTARES and IceCube Collaborations), Joint constraints on galactic diffuse neutrino emission from the ANTARES and IceCube Neutrino Telescopes, Astrophys. J. Lett. 868, L20 (2018).
