B→K+ axionlike particles: Effective versus UV-complete models and enhanced two-loop contributions

Xiyuan Gao* and Ulrich Nierste†

  • *Contact author: xiyuan.gao@kit.edu
  • †Contact author: ulrich.nierste@kit.edu
PDF

Phys. Rev. D 112, 055008 – Published 5 September, 2025

DOI: https://doi.org/10.1103/5j2t-2kdf

Abstract

An axionlike particle a (ALP) can explain the excess of B→K+invisible events at Belle II. However, many analyses of ALP scenarios are oversimplified. We revisit the B→Ka transition rate in a popular minimal and UV complete model with two Higgs doublets (2HDM) and a complex singlet [Dine-Fischler-Srednicki-Zhitnitsky (DFSZ) model]. To this end we compare our results with previous studies which derived the b¯sa vertex from the b¯sA vertex, where A is the heavy pseudoscalar of the 2HDM, in terms of an a−A mixing angle. We find this approach to work only at the leading one-loop order, while it fails at the two-loop level. Furthermore, while an approximate Z2 symmetry suppresses the leading-order amplitude by a factor of 1/tanβ, which is the ratio of the two vacuum expectation values of the Higgs doublets, we find the two-loop contribution unsuppressed and phenomenologically relevant for tanβ≳5. We determine the allowed parameter space and underline the importance of better searches for ϒ→γ+invisible and for a possible excess in B→Kμ+μ−. We further study the low-energy axion effective theory which leads to a divergent and basis-dependent amplitude. As a conceptual result, we clarify the ambiguities and identify which low-energy framework is consistent with the DFSZ model.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (59)

  1. I. Adachi et al. (Belle-II Collaboration), Evidence for B+→K+νν− decays, Phys. Rev. D 109, 112006 (2024).
  2. W. Altmannshofer, A. Crivellin, H. Haigh, G. Inguglia, and J. Martin Camalich, Light new physics in B→K(*)νν−?, Phys. Rev. D 109, 075008 (2024).
  3. R. D. Peccei and H. R. Quinn, CP conservation in the presence of instantons, Phys. Rev. Lett. 38, 1440 (1977).
  4. R. D. Peccei and H. R. Quinn, Constraints imposed by CP conservation in the presence of instantons, Phys. Rev. D 16, 1791 (1977).
  5. B. Batell, M. Pospelov, and A. Ritz, Multi-lepton signatures of a hidden sector in rare B decays, Phys. Rev. D 83, 054005 (2011).
  6. E. Izaguirre, T. Lin, and B. Shuve, Searching for axionlike particles in flavor-changing neutral current processes, Phys. Rev. Lett. 118, 111802 (2017).
  7. D. Aloni, Y. Soreq, and M. Williams, Coupling QCD-scale axionlike particles to gluons, Phys. Rev. Lett. 123, 031803 (2019).
  8. S. Chakraborty, M. Kraus, V. Loladze, T. Okui, and K. Tobioka, Heavy QCD axion in b→s transition: Enhanced limits and projections, Phys. Rev. D 104, 055036 (2021); 108, 039903(E) (2023).
  9. M. B. Gavela, R. Houtz, P. Quilez, R. Del Rey, and O. Sumensari, Flavor constraints on electroweak ALP couplings, Eur. Phys. J. C 79, 369 (2019).
  10. M. Bauer, M. Neubert, S. Renner, M. Schnubel, and A. Thamm, Flavor probes of axion-like particles, J. High Energy Phys. 09 (2022) 056.
  11. D. Bisht, S. Chakraborty, and A. Samanta, A comprehensive study of ALPs from B-decays, J. High Energy Phys. 07 (2025) 092.
  12. L. Calibbi, T. Li, L. Mukherjee, and M. A. Schmidt, Is dark matter the origin of the B→Kνν¯ excess at Belle II?, arXiv:2502.04900.
  13. J. Martin Camalich and R. Ziegler, Flavor phenomenology of light dark sectors, arXiv:2503.17323.
  14. H. Georgi, D. B. Kaplan, and L. Randall, Manifesting the invisible axion at low-energies, Phys. Lett. 169B, 73 (1986).

  15. The interpretation with renormalizable group (RG) flow [16, 17] cannot relax this problem, due to the arbitrary boundary condition at ultraviolet (UV).

  16. K. Choi, S. H. Im, C. B. Park, and S. Yun, Minimal flavor violation with axion-like particles, J. High Energy Phys. 11 (2017) 070.
  17. M. Bauer, M. Neubert, S. Renner, M. Schnubel, and A. Thamm, The low-energy effective theory of axions and ALPs, J. High Energy Phys. 04 (2021) 063.
  18. M. Dine, W. Fischler, and M. Srednicki, A simple solution to the strong CP problem with a harmless axion, Phys. Lett. 104B, 199 (1981).
  19. A. R. Zhitnitsky, On possible suppression of the axion hadron interactions. (In Russian), Yad. Fiz. 31, 497 (1980) [Sov. J. Nucl. Phys. 31, 260 (1980)].
  20. M. Freytsis, Z. Ligeti, and J. Thaler, Constraining the axion portal with B→Kl+l−, Phys. Rev. D 81, 034001 (2010).
  21. S. L. Glashow and S. Weinberg, Natural conservation laws for neutral currents, Phys. Rev. D 15, 1958 (1977).
  22. G. C. Branco, P. M. Ferreira, L. Lavoura, M. N. Rebelo, M. Sher, and J. P. Silva, Theory and phenomenology of two-Higgs-doublet models, Phys. Rep. 516, 1 (2012).
  23. M. B. Wise, Radiatively induced flavor changing neutral Higgs boson couplings, Phys. Lett. B 103, 121 (1981).
  24. L. J. Hall and M. B. Wise, Flavor-changing Higgs boson couplings, Nucl. Phys. B187, 397 (1981).
  25. J. M. Frere, J. A. M. Vermaseren, and M. B. Gavela, The elusive axion, Phys. Lett. 103B, 129 (1981).
  26. A. Kachanovich, U. Nierste, and I. Nišandžić, Higgs portal to dark matter and B→K(*) decays, Eur. Phys. J. C 80, 669 (2020).
  27. M. J. Dolan, F. Kahlhoefer, C. McCabe, and K. Schmidt-Hoberg, A taste of dark matter: Flavour constraints on pseudoscalar mediators, J. High Energy Phys. 03 (2015) 171; 07 (2015) 103(E).
  28. G. Senjanovic and A. Sokorac, On the decoupling of superheavy particles at low-energies, Nucl. Phys. B164, 305 (1980).
  29. D. Chang, W. S. Hou, and W.-Y. Keung, Two loop contributions of flavor changing neutral Higgs bosons to μ→eγ, Phys. Rev. D 48, 217 (1993).
  30. S. Davidson, μ→eγ in the 2HDM: An exercise in EFT, Eur. Phys. J. C 76, 258 (2016).
  31. W. Altmannshofer, S. Gori, N. Hamer, and H. H. Patel, Electron EDM in the complex two-Higgs doublet model, Phys. Rev. D 102, 115042 (2020).
  32. L. Di Luzio, M. Giannotti, E. Nardi, and L. Visinelli, The landscape of QCD axion models, Phys. Rep. 870, 1 (2020).
  33. S. Weinberg, A new light boson?, Phys. Rev. Lett. 40, 223 (1978).
  34. F. Wilczek, Problem of strong p and t invariance in the presence of instantons, Phys. Rev. Lett. 40, 279 (1978).
  35. N. D. Christensen and C. Duhr, feynrules—Feynman rules made easy, Comput. Phys. Commun. 180, 1614 (2009).
  36. A. Alloul, N. D. Christensen, C. Degrande, C. Duhr, and B. Fuks, feynrules 2.0—A complete toolbox for tree-level phenomenology, Comput. Phys. Commun. 185, 2250 (2014).
  37. T. Hahn, Generating Feynman diagrams and amplitudes with feynarts 3, Comput. Phys. Commun. 140, 418 (2001).

  38. mr≪mA in the large tanβ limit.

  39. J. Fleischer and O. V. Tarasov, Calculation of Feynman diagrams from their small momentum expansion, Z. Phys. C 64, 413 (1994).
  40. V. Shtabovenko, R. Mertig, and F. Orellana, New developments in feyncalc 9.0, Comput. Phys. Commun. 207, 432 (2016).
  41. V. Shtabovenko, R. Mertig, and F. Orellana, feyncalc 9.3: New features and improvements, Comput. Phys. Commun. 256, 107478 (2020).
  42. R. Mertig, M. Bohm, and A. Denner, FEYN CALC: Computer algebraic calculation of Feynman amplitudes, Comput. Phys. Commun. 64, 345 (1991).
  43. A. V. Smirnov and F. S. Chuharev, FIRE6: Feynman Integral REduction with Modular Arithmetic, Comput. Phys. Commun. 247, 106877 (2020).
  44. V. Shtabovenko, FeynHelpers: Connecting feyncalc to FIRE and Package-X, Comput. Phys. Commun. 218, 48 (2017).
  45. V. Shtabovenko, R. Mertig, and F. Orellana, feyncalc 10: Do multiloop integrals dream of computer codes?, Comput. Phys. Commun. 306, 109357 (2025).
  46. A. I. Davydychev and J. B. Tausk, Two loop selfenergy diagrams with different masses and the momentum expansion, Nucl. Phys. B397, 123 (1993).
  47. U. Nierste, Indirect CP violation in the neutral kaon system beyond leading logarithms and related topics, Ph.D. thesis, Technische Universität München, 1995, arXiv:hep-ph/9510323.
  48. T. Inami and C. S. Lim, Effects of superheavy quarks and leptons in low-energy weak processes KL→μμ¯,K+→π+νν¯ and K0↔K¯0, Prog. Theor. Phys. 65, 297 (1981); 65, 1772(E) (1981).
  49. R. Santos and A. Barroso, On the renormalization of two Higgs doublet models, Phys. Rev. D 56, 5366 (1997).
  50. B. Grinstein, C. W. Murphy, and P. Uttayarat, One-loop corrections to the perturbative unitarity bounds in the CP-conserving two-Higgs doublet model with a softly broken Z2 symmetry, J. High Energy Phys. 06 (2016) 070.
  51. E. E. Jenkins, A. V. Manohar, and P. Stoffer, Low-energy effective field theory below the electroweak scale: Operators and matching, J. High Energy Phys. 03 (2018) 016; 12 (2023) 043(E).
  52. E. E. Jenkins, A. V. Manohar, and P. Stoffer, Low-energy effective field theory below the electroweak scale: Anomalous dimensions, J. High Energy Phys. 01 (2018) 084; 12 (2023) 042(E).

  53. As pointed out in [54], ΛUV is not necessarily equal to the ALP decay constant f. The UV cut-off scale is the one above which the heavy particles can no longer be integrated out.

  54. G. Alonso-Álvarez, F. Ertas, J. Jaeckel, F. Kahlhoefer, and L. J. Thormaehlen, Leading logs in QCD axion effective field theory, J. High Energy Phys. 07 (2021) 059.
  55. J. F. Gunion and H. E. Haber, The CP conserving two Higgs doublet model: The Approach to the decoupling limit, Phys. Rev. D 67, 075019 (2003).
  56. M. S. Bilenky and A. Santamaria, One loop effective Lagrangian for a standard model with a heavy charged scalar singlet, Nucl. Phys. B420, 47 (1994).
  57. M. Bauer, M. Neubert, and A. Thamm, Collider probes of axion-like particles, J. High Energy Phys. 12 (2017) 044.
  58. R. S. Chivukula and H. Georgi, Composite technicolor standard model, Phys. Lett. B 188, 99 (1987).
  59. G. D’Ambrosio, G. F. Giudice, G. Isidori, and A. Strumia, Minimal flavor violation: An effective field theory approach, Nucl. Phys. B645, 155 (2002).
