Proposal for a dedicated search for millicharged and fractionally charged particles at LANL

Yu-Dai Tsai1,2,3,*, Insung Hwang4, Ryan Schmitz5, Matthew Citron6, Kranti Gunthoti1, Jacob Steenis6, Hoyong Jeong4, Hyunki Moon4, Jae Hyeok Yoo4 et al.

Ming Xiong Liu1

  • *Contact author: yt444@cornell.edu, yudaitsai@lanl.gov
PDF

Phys. Rev. D 113, 015038 – Published 27 January, 2026

DOI: https://doi.org/10.1103/4bdh-sd5n

Abstract

In this paper, we propose an experiment, LANSCE-mQ, aiming to detect fractionally charged and millicharged particles (mCPs) using an 800 MeV proton beam fixed target at the Los Alamos Neutron Science Center (LANSCE) facility at Los Alamos National Laboratory. This search can shed new light on numerous fundamental questions, including charge quantization, the predictions of string theories and grand unification theories, the gauge symmetry of the Standard Model, dark sector models, and the tests of cosmic reheating. We propose to install two-layer scintillation detectors made of plastic (such as EJ-200) or CeBr3 to search for mCPs. Dedicated geant4 detector simulations and in situ measurements have been conducted to obtain a preliminary determination of the background rate. The dominant backgrounds are beam-induced neutrons and coincident dark current signals from the photomultiplier tubes, while beam-induced high-energy photons (γ’s) and cosmic muons are subdominant. We determined that LANSCE-mQ, the dedicated mCP experiment, has the leading mCP sensitivity for mass between ∼1 and 300 MeV.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (69)

  1. P. A. M. Dirac, Quantized singularities in the electromagnetic field, Proc. R. Soc. A 133, 60 (1931).
  2. J. S. Schwinger, Magnetic charge and quantum field theory, Phys. Rev. 144, 1087 (1966).
  3. J. C. Pati and A. Salam, Unified lepton-hadron symmetry and a gauge theory of the basic interactions, Phys. Rev. D 8, 1240 (1973).
  4. X.-G. Wen and E. Witten, Electric and magnetic charges in superstring models, Nucl. Phys. B261, 651 (1985).
  5. R. Alonso, D. Dimakou, and M. West, Fractional-charge hadrons and leptons to tell the Standard Model group apart, Phys. Lett. B 863, 139354 (2025).
  6. H.-L. Li and L.-X. Xu, Understanding the SM gauge group from SMEFT, J. High Energy Phys. 07 (2024) 199.
  7. S. Koren and A. Martin, Fractionally charged particles at the energy frontier: The SM gauge group and one-form global symmetry, SciPost Phys. 18, 004 (2025).
  8. X. Gan and Y.-D. Tsai, Cosmic millicharge background and reheating probes, J. High Energy Phys. 07 (2025) 094.
  9. B. Holdom, Two U(1)’s and ε charge shifts, Phys. Lett. B 166B, 196 (1986).
  10. R. Barkana, N. J. Outmezguine, D. Redigolo, and T. Volansky, Signs of dark matter at 21-cm?, Phys. Rev. D 98, 103005 (2018).
  11. S. Davidson, S. Hannestad, and G. Raffelt, Updated bounds on millicharged particles, J. High Energy Phys. 05 (2000) 003.
  12. A. Hayrapetyan et al. (CMS Collaboration), Search for fractionally charged particles in proton-proton collisions at s=13  TeV, Phys. Rev. Lett. 134, 131802 (2025).
  13. Z. Liu, Y.-H. Xu, and Y. Zhang, Probing dark matter particles at CEPC, J. High Energy Phys. 06 (2019) 009.
  14. A. A. Prinz et al., Search for millicharged particles at SLAC, Phys. Rev. Lett. 81, 1175 (1998).
  15. A. Ball et al. (milliQan Collaboration), Sensitivity to millicharged particles in future proton-proton collisions at the LHC, Phys. Rev. D 104, 032002 (2021).
  16. A. Ball et al., A letter of intent to install a milli-charged particle detector at LHC P5, arXiv:1607.04669.
  17. A. Ball et al., Search for millicharged particles in proton-proton collisions at s=13  TeV, Phys. Rev. D 102, 032002 (2020).
  18. S. Foroughi-Abari, F. Kling, and Y.-D. Tsai, Looking forward to millicharged dark sectors at the LHC, Phys. Rev. D 104, 035014 (2021).
  19. K. J. Kelly and Y.-D. Tsai, Proton fixed-target scintillation experiment to search for millicharged dark matter, Phys. Rev. D 100, 015043 (2019).
  20. J. H. Kim, I. S. Hwang, and J. H. Yoo, Search for sub-millicharged particles at J-PARC, J. High Energy Phys. 05 (2021) 031.
  21. G. Magill, R. Plestid, M. Pospelov, and Y.-D. Tsai, Millicharged particles in neutrino experiments, Phys. Rev. Lett. 122, 071801 (2019).
  22. R. Harnik, Z. Liu, and O. Palamara, Millicharged particles in liquid argon neutrino experiments, J. High Energy Phys. 07 (2019) 170.
  23. R. Acciarri et al. (ArgoNeuT Collaboration), Improved limits on millicharged particles using the ArgoNeuT experiment at Fermilab, Phys. Rev. Lett. 124, 131801 (2020).
  24. F. Kling, J.-L. Kuo, S. Trojanowski, and Y.-D. Tsai, FLArE up dark sectors with EM form factors at the LHC forward physics facility, Nucl. Phys. B987, 116103 (2023).
  25. M. Crisler, R. Essig, J. Estrada, G. Fernandez, J. Tiffenberg, M. Sofo haro, T. Volansky, and T.-T. Yu (SENSEI Collaboration), SENSEI: First direct-detection constraints on sub-GeV dark matter from a surface run, Phys. Rev. Lett. 121, 061803 (2018).
  26. S. N. Gninenko, D. V. Kirpichnikov, and N. V. Krasnikov, Probing millicharged particles with NA64 experiment at CERN, Phys. Rev. D 100, 035003 (2019).
  27. A. Berlin, N. Blinov, G. Krnjaic, P. Schuster, and N. Toro, Dark matter, millicharges, axion and scalar particles, gauge bosons, and other new physics with LDMX, Phys. Rev. D 99, 075001 (2019).
  28. T. Åkesson et al. (LDMX Collaboration), Light dark matter experiment (LDMX), arXiv:1808.05219.
  29. S. Perez et al. (Oscura Collaboration), Searching for millicharged particles with 1 kg of Skipper-CCDs using the NuMI beam at Fermilab, J. High Energy Phys. 02 (2024) 072.
  30. R. Plestid, V. Takhistov, Y.-D. Tsai, T. Bringmann, A. Kusenko, and M. Pospelov, New constraints on millicharged particles from cosmic-ray production, Phys. Rev. D 102, 115032 (2020).
  31. M. Du, R. Fang, and Z. Liu, Millicharged particles from proton bremsstrahlung in the atmosphere, J. High Energy Phys. 08 (2024) 174.
  32. H. Wu, E. Hardy, and N. Song, Searching for heavy millicharged particles from the atmosphere, Phys. Rev. D 110, 115037 (2024).
  33. H. Vogel and J. Redondo, Dark Radiation constraints on minicharged particles in models with a hidden photon, J. Cosmol. Astropart. Phys. 02 (2014) 029.
  34. N. Vinyoles and H. Vogel, Minicharged particles from the Sun: A cutting-edge bound, J. Cosmol. Astropart. Phys. 03 (2016) 002.
  35. J. H. Chang, R. Essig, and S. D. McDermott, Supernova 1987A constraints on sub-GeV dark sectors, millicharged particles, the QCD axion, and an axion-like particle, J. High Energy Phys. 09 (2018) 051.
  36. H. Liu, N. J. Outmezguine, D. Redigolo, and T. Volansky, Reviving millicharged dark matter for 21-cm cosmology, Phys. Rev. D 100, 123011 (2019).
  37. J.-T. Li and T. Lin, Dynamics of millicharged dark matter in supernova remnants, Phys. Rev. D 101, 103034 (2020).
  38. R. Harnik, R. Plestid, M. Pospelov, and H. Ramani, Millicharged cosmic rays and low recoil detectors, Phys. Rev. D 103, 075029 (2021).
  39. D. F. G. Fiorillo and E. Vitagliano, Self-interacting dark sectors in supernovae are fluid, Phys. Rev. Lett. 133, 251004 (2024).
  40. M. Deniz et al. (TEXONO Collaboration), Measurement of Nu(e)-bar -electron scattering cross-section with a CsI(Tl) scintillating crystal array at the Kuo-Sheng nuclear power reactor, Phys. Rev. D 81, 072001 (2010).
  41. S.-F. Ge and I. M. Shoemaker, Constraining photon portal dark matter with texono and coherent data, J. High Energy Phys. 11 (2018) 066.
  42. L. Singh et al. (TEXONO Collaboration), Constraints on millicharged particles with low threshold germanium detectors at Kuo-Sheng Reactor Neutrino Laboratory, Phys. Rev. D 99, 032009 (2019).
  43. S. Banik, Search for lightly ionizing particles in SuperCDMS and simulation of neutron backgrounds, Ph.D. thesis, Bhubaneswar, NISER, 2021.
  44. J. Aalbers et al. (LZ Collaboration), First dark matter search results from the LUX-ZEPLIN (LZ) experiment, Phys. Rev. Lett. 131, 041002 (2023).
  45. M. F. Albakry et al. (SuperCDMS Collaboration), Investigating the sources of low-energy events in a SuperCDMS-HVeV detector, Phys. Rev. D 105, 112006 (2022).
  46. M. F. Albakry et al. (SuperCDMS Collaboration), Search for low-mass dark matter via bremsstrahlung radiation and the Migdal effect in SuperCDMS, Phys. Rev. D 107, 112013 (2023).
  47. J. Aalbers et al. (LZ Collaboration), Search for new physics in low-energy electron recoils from the first LZ exposure, Phys. Rev. D 108, 072006 (2023).
  48. K. K. Boddy, K. Freese, G. Montefalcone, and B. Shams Es Haghi, Minimal dark matter freeze-in with low reheating temperatures and implications for direct detection, Phys. Rev. D 111, 063537 (2025).
  49. A. A. Aguilar-Arevalo et al. (CONNIE and Atucha-II Collaborations), Search for reactor-produced millicharged particles with Skipper-CCDs at the CONNIE and Atucha-II experiments, Phys. Rev. Lett. 134, 071801 (2025).
  50. P. W. Lisowski and K. F. Schoenberg, The los alamos neutron science center, Nucl. Instrum. Methods Phys. Res., Sect. A 562, 910 (2006).
  51. G. Shiu, P. Soler, and F. Ye, Milli-charged dark matter in quantum gravity and string theory, Phys. Rev. Lett. 110, 241304 (2013).
  52. T. Gherghetta, J. Kersten, K. Olive, and M. Pospelov, Evaluating the price of tiny kinetic mixing, Phys. Rev. D 100, 095001 (2019).
  53. A. A. Aguilar-Arevalo et al. (CCM Collaboration), First dark matter search results from Coherent CAPTAIN-Mills, Phys. Rev. D 106, 012001 (2022).
  54. https://www.berkeleynucleonics.com/cerium-bromide.
  55. P. deNiverville, Searching for light dark matter with proton-beam fixed target experiments, https://indico.ibs.re.kr/event/47/contributions/2773/attachments/2517/2724/ProtonFixedTargets.pdf.
  56. P. deNiverville, C.-Y. Chen, M. Pospelov, and A. Ritz, Light dark matter in neutrino beams: Production modelling and scattering signatures at MiniBooNE, T2K and SHiP, Phys. Rev. D 95, 035006 (2017).
  57. Y.-D. Tsai, P. deNiverville, and M. X. Liu, Dark photon and muon g−2 inspired inelastic dark matter models at the high-energy intensity frontier, Phys. Rev. Lett. 126, 181801 (2021).
  58. R. L. Burman and E. S. Smith, Parameterization of pion production and reaction cross sections at LAMPF energies, Technical Report No. LA-11502-MS, Los Alamos National Laboratory, 1989.
  59. K. Jodlowski, F. Kling, L. Roszkowski, and S. Trojanowski, Extending the reach of FASER, MATHUSLA, and SHiP towards smaller lifetimes using secondary particle production, Phys. Rev. D 101, 095020 (2020).
  60. R. L. Workman et al. (Particle Data Group), Review of particle physics, Prog. Theor. Exp. Phys. 2022, 083C01 (2022).
  61. J. Allison et al., Recent developments in Geant4, Nucl. Instrum. Methods Phys. Res., Sect. A 835, 186 (2016).
  62. Neutron News, Vol. 3, No. 3, 1992, pp. 29–37.
  63. https://www.psi.ch/en/drs.
  64. H. O. Meyer, Dark rate of a photomultiplier at cryogenic temperatures, arXiv:0805.0771.
  65. Hamamatsu Photonics K. K, Photomultiplier Tubes and Assemblies for Scintillation Counting and High Energy Physics, https://www.hamamatsu.com/content/dam/hamamatsu-photonics/sites/documents/99_SALES_LIBRARY/ etd/High_energy_PMT_TPMZ0003E.pdf.
  66. H. Jeong, Search for sub-millicharged particles at j-parc, in 31st International Symposium on Lepton Photon Interactions at High Energies, Zenodo, 10.5281/zenodo.8347283 (2023).
  67. C. Guerrero, A. Tsinganis, E. Berthoumieux, M. Barbagallo, F. Belloni, F. Gunsing, C. Weiß, E. Chiaveri et al., Performance of the neutron time-of-flight facility n_tof at CERN, Eur. Phys. J. A 49, 27 (2013).
  68. H. Abele et al., Particle physics at the european spallation source, Phys. Rep. 1023, 1 (2023).
  69. J. Arrington et al., Physics opportunities for the Fermilab booster replacement, arXiv:2203.03925.
